BATTERY CHARGING
D Rapid charging with the BC-119N+AD-100
The optonal BC-119N provdes rapd chargng of the optonal L-
Ion battery pack. The followng tems are addtonally requred:
• An AD-100 charger adapter
• An AC adapter (may be suppled wth the BC-119N dependng
on the verson) or a DC power cable (OPC-515L/CP-17L).
AC adapter
(Not suppled wth
some versons.)
Optonal OPC-
515L (for 13.8 V
power source) or
CP-17L (for 12 V
cgarette lghter
socket) can be
used nstead of
the AC adapter.
31
Battery pack
IMPORTANT!:
Ensure the gude lobes
on the battery pack are
correctly algned wth
the gude rals nsde of
the charger adapter.
Transceiver
Turn power OFF
AD-100 charger
adapter s nstalled
n BC-119N.
*See the
nstructon manual
for detals of the
charger LED
ndcaton,
operaton, etc.
Lobes
Gude rals
