D ConnectNg To The Ac Outlet Through The Ps-250 And OptOnal Ps-240 - Icom IC-GM651 Instruction Manual

D Connecting to the AC outlet through the PS-250
and optional PS-240
DC power cable
PS-250
(Purchase
separately)
PS-240
GND
12 V or 24 V
battery
AC power cable
(Supplied with
the PS-240)
To AC outlet
When AC voltage s stopped applyng, the PS-240
swtches to the DC operaton, then AC voltage s appled
agan, t swtches back to AC operaton automatcally.
IC-GM651
GND
GND
DC power cable
(Supplied with
DC power cable
the PS-250)
(Supplied with
the IC-GM651)
Terminal guard
Keep the terminal guard
attached after connect-
ing cables.
CONNECTIONS AND MAINTENANCE
CAUTION: NEVER short the DC power termnals of the
PS-250/PS-240 when connectng a DC power cable. Oth-
erwse there s danger of electrc shock and/or equpment
damage.
