Icom IC-400PRO Instruction Manual page 7

t [DUP] KEY*
➥
N N Push to toggle the transmit frequency mode between
N N
duplex and simplex. (CB channel 1 to 8 only)
• Duplex: The set TX frequency is used for the transmission.
• Simplex: The set RX frequency is used for the transmis-
sion.
➥
N N Push and hold to set the selected channel to priority
N N
or normal.
• Priority channel is used for both group and priority scans.
➥
F F Push to toggle the 5tone mute activity between CONT
F F
(Continuous Tone) and SGL (Single Tone).
• CONT: SelCall mute is released.
• SGL: SelCall mute is activated. In this case, [PTT] switch
action is inhibited while SelCall mute is activated.
y [SCN] KEY*
➥
N N Push to start or stop the scan. N N
➥
N N Push and hold to enter the scan type selection mode. N N
• Push [ ]/[ ] to select the desired scan type.
• Push [SCN] to set the channel as a tag channel.
- " S " appears for tag channels.
➥
F F Push to recall the received ID code. F F
• Push [ ]/[ ] to select the record.
➥
N N : Stands for Normal mode operation.
N N
➥
F F : Stands for Function mode operation.
F F
PANEL DESCRIPTION
u [MONI] KEY*
➥
N N Activates the following functions on each channel
N N
independently:
• Push and hold the key to release the mute to the channel
(audio is emitted; 'Audible' condition).
- " " appears.
• During " " appears, push the key to mute the channel
(sets to 'Inaudible').
NOTE: The unmute condition ('Audible' condition)
may automatically return to the mute condition
('Inaudible' condition) after a specified time period
depending on the pre-setting.
➥
F F Push to transmit the SelCall code on the selected
F F
channel.
➥
F F Push and hold to enter the SelCall code/code number
F F
selection mode (p. 17).
• Push [ ]/[ ] to select the desired code/code number.
*Information
Up to two desired functions, one each for Normal and
Function mode, can be re-assigned to [
[DUP], [SCN] and [MONI] keys with the optional CS-
400PRO
CLONING SOFTWARE
The default setting is used in this instruction manual, for
description.
], [ ], [ O ],
. (p. 34)
1
1
2
