Owner's Manual
Air-cooled Recreational
Vehicle Generators
QUIETPACT 55, 65 and 75
• Models: 004702-0, 004703-0
004704-0, 004705-0
004706-0, & 004707-0
QUIETPACT
55G
POWERED BY GUARDIAN 760cc OHVI V-TWIN
INDUSTRIAL
This manual should remain with the unit.

Advertisement

Table of Contents
loading

Related Manuals for Generac Power Systems 004702-0, 004703-0, 004704-0, 004705-0, 004706-0, 004707-0

Summary of Contents for Generac Power Systems 004702-0, 004703-0, 004704-0, 004705-0, 004706-0, 004707-0

  • Page 1 Owner’s Manual Air-cooled Recreational Vehicle Generators QUIETPACT 55, 65 and 75 • Models: 004702-0, 004703-0 004704-0, 004705-0 004706-0, & 004707-0 QUIETPACT POWERED BY GUARDIAN 760cc OHVI V-TWIN INDUSTRIAL This manual should remain with the unit.

  • Page 2: Introduction

    Proper maintenance and care of your generator ensure a minimum number of problems and keep operating expenses at a minimum. See your Generac Authorized Service Dealer for service aids and acces- sories. HOW TO OBTAIN SERVICE...

  • Page 3: Table Of Contents

    Installation Checklist ...35 Section 8 – Troubleshooting ...36 Troubleshooting Guide ...36 Section 9 – Notes...37 Section 10 – Electrical Data ...38 Section 11 – Exploded Views and Parts Lists...40 Section 12 – Warranty ...52 Table of Contents Generac ® Power Systems, Inc.

  • Page 4: Safety Rules

    If you use a procedure, work method or operating tech- nique Generac does not specifically recommend, you must satisfy yourself that it is safe for you and others. You also must make sure the procedure, work method or operating technique that you choose does not render the generator unsafe.

  • Page 5: Fire Hazards

    LP gas is highly EXPLOSIVE. The gas is heavier than air and tends to settle in low areas where even the slightest spark can ignite the gas and cause an explosion. Safety Rules FIRE HAZARDS EXPLOSION HAZARDS Generac ® Power Systems, Inc.

  • Page 6: Section 1 - General Information

    5. Circuit Breaker 6. Optional Remote Panel Receptacle 7. Generator AC Output Leads 8. Starter Contactor 9. Fuel Inlet 10. Fuel Primer Switch Generac ® Power Systems, Inc. 2. Serial Number __________________ 4. Rated Voltage __________________ 6. Hertz __________________________ DO NOT PRESS START BUTTON LONGER THEN 15 SECONDS PER ATTEMPT.

  • Page 7: Generator Applicability

    Figure 1.2, page 6, shows the generator lead wire connections for 120/240 VAC loads. Also refer to section 2.1.4 Line Breakers for cir- cuit breaker ratings. This procedure should be done by a Generac Authorized Service Dealer or other qualified installer. Generac ®...

  • Page 8: Specifications

    0.51 0.80 NOTE NOTE: Generac does not recommend using any gasoline containing alcohol (such as “gasohol”). If you use any gasoline containing alcohol, it must not contain more than 10 percent ethanol, and it must be removed from the generator during storage.

  • Page 9: Engine Specifications

    REMOVE AND INSPECT FUSE. (SEE OWNER'S MANUAL TROUBLE SHOOTING GUIDE.) PRESS PRIME SWITCH FOR 10 SECONDS BEFORE STARTING. WHEN STARTING, DO NOT PRESS START BUTTON LONGER THEN 15 SECONDS PER ATTEMPT. Generac ® Power Systems, Inc. exceeding 240 Volt 25A 2P...

  • Page 10: Optional Remote Start/Stop Panel

    Instructions and information in this manual assume the generator has been properly installed, connected, serviced, tested and adjusted by a qualified installation technician or installation contractor. Generac ® Power Systems, Inc. 2.4.1 INSTALLATION Generator installation must have been properly com-...

  • Page 11: Starting The Generator

    Never turn ON electrical loads until after the genera- tor engine has started and stabilized at no-load. Generac ® Power Systems, Inc.

  • Page 12: Do Not Overload The Generator

    Should oil pressure drop below a preset level, switch contacts close, and the engine automatically shuts down. The unit should not be restarted until oil is added. 10 Generac ® Power Systems, Inc. 2.8.2 HIGH TEMPERATURE SWITCH This switch (Figure 2.3), which has normally open...

  • Page 13: Overvoltage Protection

    Section 3 – Maintenance QUIETPACT 55, 65, and 75 Recreational Vehicle Generators 2.8.6 25-HOUR CHECK-UP After the 25-hour break-in period, contact a Generac Authorized Service Dealer for the following mainte- nance. (The vehicle owner is responsible for any charges relating to normal unit maintenance.) •...

  • Page 14: Changing The Engine Oil And/Or Oil Filter

    1.8 liters or 1.9 quarts with oil filter change. DO NOT FILL ABOVE THE “FULL ” MARK. 8. Install and tighten the dipstick before operating the engine. 12 Generac ® Power Systems, Inc. 9. Start the engine and check for leaks. Figure 3.2 — Engine Oil Filter NOTE: Check the oil level and fill to the “FULL ”...

  • Page 15: Checking The Engine Spark Plug

    Figure 3.5 – Fuel Filter FUEL FILTER CLEAN SPARK ARRESTOR NOTE: Figure 3.6 - Spark Arrestor TAILPIPE P/N 0E0907 RETAINER P/N 0D5133A SPARK ARRRESTOR SCREEN P/N 0D5133 RETAINING SCREW P/N 045764 Generac ® Power Systems, Inc. 13 TO FUEL PUMP...

  • Page 16: Cleaning The Generator

    Keep unautho- rized personnel away from batteries. Damage will result if the battery connections are made in reverse. 14 Generac ® Power Systems, Inc. DANGER Do not dispose of the battery in a fire. The battery is capable of exploding.

  • Page 17: Major Service Manual

    Generac Authorized Service Dealer. 3.11 EXERCISING THE GENERATOR Generac recommends that you start and operate the generator at least once every seven days. Let the unit run for at least 30 minutes to “exercise” the engine.

  • Page 18: Section 4 - Notes

    Section 4 – Notes QUIETPACT 55, 65, and 75 Recreational Vehicle Generators 16 Generac ® Power Systems, Inc.

  • Page 19: Part Ii - Installation Instructions

    PART II – INSTALLATION INSTRUCTIONS DANGER ONLY QUALIFIED ELECTRICIANS OR CONTRACTORS SHOULD ATTEMPT INSTALLATION!!

  • Page 20: Safety Rules

    NOTICE TO INSTALLER These Installation Instructions have been published by Generac to aid in the installation of the products described in this manual. Generac assumes that installation personnel are familiar with the proce- dures for installing such products, or similar prod- ucts that Generac manufactures.
  • Page 21 Do not allow gas vapors to enter the vehicle. Safety Rules FIRE HAZARDS EXPLOSION HAZARDS Generac ® Power Systems, Inc. 19...

  • Page 22: Section 5 - General Information

    Constructions Materials Section, 178 Rexdale Boulevard, Rexdale, Ontario, Canada, M9W 1R3. EQUIPMENT DESCRIPTION Instructions and information in this section pertain to Generac air-cooled generators. These generators are designed specifically for installing in recreational vehicles. They operate 120-volt, single-phase, 60- Hertz, AC electrical loads.

  • Page 23: Major Features And Dimensions

    Section 5 – General Information QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Figure 5.2 - Major Features and Dimensions (Drawing No. 0E1058-A) Generac ® Power Systems, Inc. 21...

  • Page 24: Section 6 - Installation

    • The location must provide easy access to frequent- ly serviced components, such as filters, oil drains, spark plugs and other common maintenance parts. 22 Generac ® Power Systems, Inc. • The location must provide sufficient room to allow • The location must provide adequate cooling and...

  • Page 25: Suspended Mounting

    26-gauge galvanized steel. NOTE: may be constructed of any material. Generac rec- ommends that the compartment be constructed of 1/2-inch thick plywood (not strandboard), with the floor made of a double thickness of 1/2-inch ply- wood with the grain of the wood at cross section for added strength (Figure 6.5).

  • Page 26: Sound Insulating Materials

    Manufactured lock seams are shown in Figure 6.6. Installer constructed compartments typically utilize a standard lap joint. 24 Generac ® Power Systems, Inc. Figure 6.6 – Types of Lock Seams • After the compartment has been metal lined and...

  • Page 27: Acoustics

    This heat- ed air (although cooler than exhaust muffler) is then deflected out the bottom toward the ground. Figure 6.9 – Airflow Through Engine/Generator DANGER DANGER GUARDIA by Generac Power Syste QUIETPACT INDUSTRIAL Generac ® Power Systems, Inc. 25...

  • Page 28: Testing The Installation

    NOTE: ALL AIR INTAKES AND EXHAUST OUTLETS MUST BE KEPT CLEAR OF ANY OBSTRUCTIONS. ALL OPEN AREA IS REQUIRED FOR COOLING. 6.3.2 TESTING THE INSTALLATION Generac recommends testing the installation to be sure adequate cooling airflow is available to the unit before placing the unit into service. If the unit shows signs of overheating, you will need to enlarge the air openings.

  • Page 29: Fuel Tank

    If the generator is to share the vehicle engine's tank, separate fuel pickup tubes are required for the engine and the generator. Generac recommends that you make the fuel pickup tube 2 to 3 inches (51 to 76 mm) shorter than the vehicle engine's pickup tube.

  • Page 30: Some Important Considerations

    Vapor withdrawal systems use the gas vapors that form above the liquid fuel in the tank. Do NOT attempt to use the generator with any liquid with- drawal type system. 28 Generac ® Power Systems, Inc. 6.5.5 PRIMARY REGULATOR Gas pressure delivered to the solenoid valve must be properly regulated by means of a primary gas regula- tor.

  • Page 31: Fuel Supply Lines

    Never tee the generator engine exhaust pipe into the vehicle engine exhaust piping. This causes excessive back pressure on the genera- tor engine. Also, water from one engine can damage the other engine. DANGER Generac ® Power Systems, Inc. 29...

  • Page 32: Mufflers And Spark Arrestors

    (see Figure 6.17). Use only Generac supplied hardware. Substitution of parts may cause damage to the screen or a loose fit to the tailpipe.

  • Page 33: Wiring

    The power supply cord must comply with all applic- able codes, standards and regulations. It must be large enough to handle the full amperage to which it will be subjected. (See page 33 for illustration.) SOURCES Generac ® Power Systems, Inc. 31...

  • Page 34: Ground Fault Circuit Interrupters

    0 to 10 (0 to 3) 11 to 15 (3.4 to 4.5) 16 to 20 (4.5 to 6) *For warm weather, use No. 2 cable up to 20 feet. 32 Generac ® Power Systems, Inc. 1. Connect the battery cable from the battery post or Check to be sure the battery cable boot for the starter cable has been installed.
  • Page 35 QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Figure 6.18 — Transfer Switch Isolation Method QUIETPACT POWERED BY GUARDIAN 760cc OHVI V-TWIN INDUSTRIAL Figure 6.19 — Installation With Isolation Receptacle QUIETPACT POWERED BY GUARDIAN 760cc OHVI V-TWIN INDUSTRIAL Generac ® Power Systems, Inc. 33...

  • Page 36: Optional Accessories

    Do not make any unnecessary adjustments. Factory settings are correct for most applica- tions. When making adjustments, however, be careful to avoid overspeeding the engine. 34 Generac ® Power Systems, Inc. Before starting, complete the following: 1. Check the engine crankcase oil level and, if nec- 2.

  • Page 37: Testing Under Load

    The switch has normally open (N.O.) contacts. When the engine temperature is too high, switch contacts close, and the engine shuts down automatically. GENERAC RECOMMENDS THAT YOU TEST THE GENERATOR FOR ADEQUATE COOLING. INSTALLATION CHECKLIST LOCATION AND SUPPORT Generator is properly located.

  • Page 38: Section 8 - Troubleshooting

    PROBLEM Engine won’t crank. Engine cranks, won't start. Engine starts hard, runs rough. Engine starts, then shuts down. No AC output voltage. 36 Generac ® Power Systems, Inc. CAUSE 7.5 amp fuse blown. Loose, or corroded or defective battery cable(s).

  • Page 39: Section 9 - Notes

    Section 9 – Notes QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Generac ® Power Systems, Inc. 37...

  • Page 40: Section 10 - Electrical Data

    SCR - STARTER CONTACTOR RELAY SW1 - SWITCH, START/STOP SW2 - SWITCH FUEL PRIMER SP1 - SPARK PLUG #1 CYL. SP2 - SPARK PLUG #2 CYL. TC - TERMINAL, CONN. 4-TAB - CONNECTOR 38 Generac ® Power Systems, Inc. BATTERY J1-4 J1-5 J1-6...
  • Page 41 V-Twin – Drawing No. 0E1057-B SUPPLIED BY CUSTOMER 6 2A ELECTRONIC VOLTAGE REGULATOR Section 10 — Electrical Data STATOR CLOSEST TO BEARING BLACK WHITE GREEN CUSTOMER AC CONNECTION NEUTRAL CONNECTION BY CUSTOMER BLACK WHITE Generac ® Power Systems, Inc. 39 FIELD REMOTE PANEL CONNECTOR...

  • Page 42: Section 11 - Exploded Views And Parts Lists

    Section 11 — Exploded Views and Parts Lists QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Base & Pulley – Drawing No. 0E1323-A 36 6 40 Generac ® Power Systems, Inc. " "B "A " "B TO CARB. 26 52...
  • Page 43 ASSEMBLY, RV V-TWIN FUEL LINE (GASOLINE ONLY) GROMMET, 38.1 DIA. CROSS SLIT (GASOLINE ONLY) PLUG PLASTIC 1.50" (LP ONLY) WASHER LOCK SPECIAL 1/4" SCREEN, SPARK ARRESTOR RETAINER, SPARK ARREST SCREEN SCREW HHTT M4-0.7 X 8 BP Generac ® Power Systems, Inc. 41...
  • Page 44 Section 11 — Exploded Views and Parts Lists QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Enclosure – Drawing No. 0E1011-B GROUND TO ENGINE GROUND TO CONT. PANEL 33 3 TARTER VIEW "A" 42 Generac ® Power Systems, Inc. 12 2 2 19 9 VIEW "A"...
  • Page 45 BRACKET, LP REGULATOR MOUNTING (LP ONLY) SCREW HHTT M4-0.7 X 10 BP (LP ONLY) SCREW HHC M8-1.25 X 16 G8.8 (LP ONLY) WASHER FLAT 5/16-M8 ZINC (GASOLINE ONLY) WASHER FLAT 5/16-M8 ZINC (LP ONLY) PANEL, AIR IN DUCT Generac ® Power Systems, Inc. 43...
  • Page 46 Section 11 — Exploded Views and Parts Lists QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Sheet Metal – Drawing No. 0E1012-B 44 Generac ® Power Systems, Inc. 94 4 92 2 2 "A" A 91 1 74 75 100 0 "B"...
  • Page 47 WASHER LOCK #8 (GASOLINE ONLY) NUT HEX M4-0.7 G8 YC (GASOLINE ONLY) SCREW HHTT M6-1.0 X 16 YC CLAMP VINYL 1.06 X .406 (LP ONLY) WASHER FLAT 1/4-M6 (LP ONLY) SCREW HHTT M6-1.0 X 12 (LP ONLY) Generac ® Power Systems, Inc. 45...
  • Page 48 Section 11 — Exploded Views and Parts Lists QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Control Panel – Drawing No. 0E1013-A 12 2 14 4 46 Generac ® Power Systems, Inc. 27 7 28,2 45 5 44 4 34 35...
  • Page 49 NUT TRIC M5 X .8 COMPARTMENT, AIR BOX 2.3 FT. TAPE, 1/2" X 1/16" CLOSED CELL WIRE HARNESS, QP RV (GASOLINE ONLY)(NOT SHOWN) WIRE HARNESS, QP RV (LP ONLY) (NOT SHOWN) WIRE ASS'Y STARTER TO C/PNL (NOT SHOWN) Generac ® Power Systems, Inc. 47...
  • Page 50 Section 11 — Exploded Views and Parts Lists QUIETPACT 55, 65, and 75 Recreational Vehicle Generators 760 V-Twin Engine – Drawing No. 0E1014-B 48 Generac ® Power Systems, Inc.
  • Page 51 STUD, ROCKER ARM M8-1.0 x 57mm PLATE, PUSH ROD GUIDE SCREW HHFC M8-1.25 X 65mm ASSEMBLY, HEAD #2 VALVE, INTAKE VALVE, EXHAUST PUSHROD 147 TAPPET, SOLID STARTER, V-TWIN ENGINE WASHER LOCK M8 SCREW, HHC M8-1.25 X 85mm Generac ® Power Systems, Inc. 49...
  • Page 52 Section 11 — Exploded Views and Parts Lists QUIETPACT 55, 65, and 75 Recreational Vehicle Generators LP Regulator – Drawing No. 0E1530 50 Generac ® Power Systems, Inc.
  • Page 53 SEAL, INLET REGULATOR SUPPORT, INLET SEAL PIN, PIVOT ARM LEVER, REGULATOR GASKET, DIAPHRAGM RIVET .118 X .125 ALUMINUM SUPPORT, DIAPHRAGM DIAPHRAGM, TWIN REGULATOR CAP, DIAPHRAGM SUPPORT COVER,TWIN REGULATOR SCREW HHTT M4-0.7 X 8 BP Generac ® Power Systems, Inc. 51...

  • Page 54: Section 12 - Warranty

    Limited Warranties for Generac Power Systems, Inc.,” which is enclosed herewith on a separate sheet, also provided to you by Generac. The ECS Warranty applies only to the emission control system of your new engine. If there is any conflict in terms between the ECS Warranty and the Generac Warranty, the ECS Warranty shall apply except in circumstances where the Generac Warranty may provide a longer warranty period.

  • Page 55: Emission Control System Warranty

    Such use voids this ECS Warranty and shall be sufficient grounds for disallowing an ECS Warranty claim. Generac shall not be held liable hereunder for failures of any warranted parts of a Generac engine caused by the use of such an unapproved, add-on, modified, counterfeit and/or ‘grey market’...
  • Page 56 Generac Power Systems, Inc. (Generac) will, at its option, repair or replace any part which, upon examination, inspec- tion and testing by Generac or a Generac Authorized Warranty Service Facility, is found to be defective under normal use and service, in accordance with the warranty schedule set forth below. Any equipment that the purchaser/owner claims to be defective must be returned to and examined by the nearest Generac Authorized Warranty Service Facility.
