- Page 1 E4H-CE AND E8-CE SERIES WATER PURIFICATION MACHINES /hr to 45 m 18,000 gpd to 288,000 gpd Control Narrative Manual...
-
Page 3: Table Of Contents
GE OSMONICS E4H-CE AND E8-CE WATER OVERVIEW Hardware Software Operator Interface Terminal (OIT) START-UP Operation Screen Alarm History Screen Machine Status Screen Utilities Screen Set-Up Screen Figure Title Start-Up Screen Operation Screen Alarm History Screen Machine Status Screen Utilities Screen... -
Page 5: Overview
OVERVIEW The GE Osmonics E4H-CE and E8-CE water treatment systems consist of modular equipment that is designed to work together with the reverse osmosis (RO) machine at the heart of the system. The Programmable Logic Controller (PLC) and Operator Interface Terminal (OIT) are pro- grammed to control a complete, integrated system. -
Page 6: Operator Interface Terminal (Oit)
Operator Interface Terminal (OIT) Screen The available screens for the PanelView are as listed: START-UP: OPERATION: ALARM HISTORY: Displays last five alarms conditions. STATUS: UTILITIES: SET-UP: Contact information for customer. Gives run options for machine, alarm, and status messages. Displays last five operating conditions. Adjusts contrast, screen center, and allows user to clean dis- play. -
Page 7: Start-Up
START-UP The START-UP Screen is displayed upon start-up of the E-CE Series RO machine. This touch screen gives customer contact information. Figure 2.1 Start-Up Screen To get to the next screen, press anywhere on the screen or wait twenty (20) seconds. -
Page 8: Operation Screen
Operation Screen The Operation Screen displays the control function for the E-CE Series RO machine. FUNCTION OPERATION Switches machine to run AUTO/HAND Switches machine to Auto or Hand Switches machine to CIP mode FILL Energizes the inlet solenoid valve to fill machine PURGE Manually puts RO machine into Permeate Purge... - Page 9 The RO machine is controlled using the Operation Screen. The FILL button energizes the inlet solenoid valve allowing the RO machine to fill water. The machine will run for ten (10) minutes filling the machine. This needs to be done before the RO machine can oper- ate.
-
Page 10: Alarm History Screen
Alarm History Screen The ALARM Message, located above the Control Buttons, shows the user current Alarm Conditions. NUMBER Figure 2.3 Alarm History Screen FUNCTION OPERATION BACK Takes user back to OPERATION Screen ALARM Takes user to ALARM Screen ALARM RESET Resets current ALARM conditions UTILITIES Takes users to UTILITIES Screen... -
Page 11: Alarm Messages
ALARM ACTION DISPLAYED LOW INLET Shuts down RO PRESSURE machine HI PERMEATE Shuts down RO PRESSURE machine HI TEMP Shuts down RO machine HIGH Alarm light dis- played on pH meter HIGH Shuts down RO CONDUCTIVI- machine MOTOR 1 Shuts down RO START machine FAILURE... -
Page 12: Machine Status Screen
Machine Status Screen The Machine Status Screen displays the last five run conditions. NUMBER Figure 2.4 Machine Status Screen FUNCTION OPERATION BACK Takes user back to OPERATION Screen ALARM Takes user to ALARM Screen ALARM RESET Resets current ALARM Conditions UTILITIES Takes users to UTILITIES Screen... -
Page 13: Status Screen System Message
System Message SYSTEM MESSAGE RO MODE CIP MODE PERMEATE PURGE MODE MANUAL SHUTDOWN ALARM SHUTDOWN PRETREATMENT SERVICE POST-TREATMENT SERVICE Table 2.2 Status Screen DEFINITION Normal Operating Mode. Clean-In-Place Mode used for cleaning. Permeate is “recycled” back through RO machine. RO machine switched OFF by manually pressing ON/OFF button RO machine has shutdown due to one of the Alarms described in Table 2.1. -
Page 14: Utilities Screen
Utilities Screen The Utilities Screen allows the user to adjust contrast, screen center, and clean the display. FUNCTION OPERATION CONTRAST + Darkens OIT Screen CONTRAST - Lightens OIT Screen CALIBRATE Allows users to adjust SCREEN position of OIT Screen CLEAN Allows users to adjust OIT SCREEN Screen without changing RO... -
Page 15: Set-Up Screen
Set-Up Screen The Set-Up Screen allows the users to clear Alarm History, run time, and status. This Screen allows users to download new program information. FUNCTION OPERATION ALARM Clears history of Alarm HISTORY conditions STATUS Clears history of system HISTORY conditions RUN TIME Allows users to adjust... - Page 17 +33 1 64 10 3747 Fax Manufactured in the USA Asia/Pacific Operations 1044/8 SOI 44/2 Sukhumvit Road Prakanong Bangkok 10110 THAILAND +66 2 38 14213 Phone +66 2 39 18183 Fax ' Copyright 2002, GE Osmonics, Inc. Printed in USA, P/N 1233380 Rev. A...
