- Page 1 Promi-SD™ User Manual Promi-SD-OA Version 1.0 by Bluetooth Enabling Wireless Serial Communications Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
-
Page 2: Table Of Contents
Using a Terminal Program ..................20 2.2.1 Connecting Promi-SD™ to host. 2.2.2 Making the first Promi-SD™/Bluetooth connection 2.2.3 Making Promi-SD™ do INQUIRY SCAN and PAGE SCAN 2.2.4 Releasing the existing Bluetooth connection 2.2.5 Automatic connection of two Promi-SD™ Units 2.2.6 AT command vs. - Page 3 Hardware Reset......................29 Optional Antennas .........30 For Multi-Serial Connections ......32 Promi-MSP™ ......................32 7. Legal Notice ............33 8. Contact Information........35 Appendix A: Power Adaptor Specification ..36 Appendix B: AT command sets ......39 Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
-
Page 4: Product Description
. Product Description 1.1 About Promi-SD™ Promi-SD™ is developed for long range, easy-to-install, low-cost, wireless serial communications. Provided is point-to-point wireless connection without standard RS232 cables. For point-to-multipoint connections, please refer to our Promi-MSP™, providing all the features of RS485. - Page 5 Part no. PSD00-00010 Fig. 1.1.3 USB Power Adaptor Part no. PSD00-00020 *You may use USB port to supply power to Promi-SD™ using this USB power cable Fig. 1.1.4 DC Power Cable Part no. PSD00-00030 *Red colored line of DC power cable is for ‘+’...
- Page 6 Fig. 1.1.5 Special RS232 Cable (Female-Female) ONLY for PC to PROMI-SD202-OA connection Part no. PSD00-00070 Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
-
Page 7: External View
ON/OFF SWITCH HARD RESET SWITCH Figure 1.2.2 Promi-SD right side view DC Connector Figure 1.2.3 Promi-SD left side view Please refer to the 1.5 Power Supply section for Promi-SD™ power options Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... -
Page 8: Led Indicator
1.3 LED Indicator The Promi-SD™ STATUS LED indicates the following: Amber STATUS LED indicates standard mode on Promi-SD™ power-up. Green STATUS LED indicates Promi-SD™ is connected to another Bluetooth device Green flashing STATUS LED every second indicates Promi-SD™ INQUIRY operation Green flashing STATUS LED every 3 seconds indicates Promi-SD™... -
Page 9: Power Supply
Figure 1.5.1. DC plug polarity Promi-SD202-OA (Class1): 4V~12V, 150mA minimum Current Consumption Data at different speeds of serial communications: Current Consumption Condition of Baud Rate (Promi-SD202-OA) 9600bps 40 mA 115200bps 72 mA Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... -
Page 10: Interface- Rs232 / Bluetooth
Figure 1.7.1 9-PIN DSUB (Male) The serial interface is RS232 DCE configured; a DTE device can be connected. Baud rate: 1200~115200 bps Signal Direction Input Output Input Table 1.7.1. Promi-SD-OA, 9-PIN Specification Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... -
Page 11: Bluetooth Interface
1.6.2 Bluetooth Interface Bluetooth Specification V 1.1 Level 18 dBm (Promi-SD202-OA) Range ~100m (Promi-SD202-OA) Bluetooth protocols RFCOMM, L2CAP, SDP Supported Profiles General Access Profile Serial Port Profile Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... -
Page 12: Configuration
Then activate SD INQUIRY SCAN and PAGE SCAN from PromiWIN Let’s suppose there are 2 Promi-SD™s, SD1 and SD2: Connect the SD1 to a host serial port and turn on the SD. Check the SD1 STATUS LED color. Amber indicates standard mode. Start the... - Page 13 Please open PromiWIN PromWIN configuration menu to set up the PromiWIN to be matched with Promi-SD. Check COM port number of your PC where Promi-SD is plugged in. Check BaudRate/Parity/StopBit. Users need select correct configuration value of Promi-SD to start.
- Page 14 Figure 1 Device Name: Shows default device name of Promi-SD. Ex) PSDv3a-120296 PSDv3a means the version of firmware of Promi-SD. Users may change the Device name at Device Setting page. Device Hardware Address: Default Bluetooth Device Address. Current Mode: This show current operation MODE of Promi-SD.
- Page 15 Mode1 will try connection to the last connected device only. Mode2: Promi-SD that has been set to Mode2 will wait fro connection from the last connected device only. Mode3: In Mode3, Promi-SD will be discoverable/connectable by any kind of Bluetooth devices.
- Page 16 Device Name: Users may change the device name to be more friendly. Signal: If users want to remove the response signals from Promi-SD, such as OK, CONNECT, DISCONNECT, ERROR on each events, users may turn off the signal here. This can be done by ATS10=n command.
- Page 17 Select PromiWIN and repeat the preceding procedure for SD2 Select the ‘Connection(out)’ icon in the list control box and click the search button. 10. Now the additional SD2 enters INQUIRY operation. Figure 4. Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
-
Page 18: Setting Operating Mode For Automatic Connection
The following simple steps describe the SD operating mode change procedure. After making a Bluetooth wireless connection between two SD units, set the operating mode of one SD to MODE 1, as shown in Figure 6. Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... - Page 19 Turn off both SD power supplies. From now, when both SD units are powered up again, they will automatically connect. (To release this feature, reset both SD units. Amber SD STATUS LED indicates successful reset process.) Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
-
Page 20: Using A Terminal Program
5. Enter ‘AT’ command at the prompt. An SD ‘OK’ reply indicates proper operation. 2.2.2 Making the first Promi-SD™/Bluetooth connection As stated before, Bluetooth wireless connections can be made with any other Bluetooth device supporting Bluetooth SPP (Serial Port Profile). For Bluetooth wireless connections to an SD, first make another SD ‘Discoverable’... -
Page 21: Making Promi-Sd™ Do Inquiry Scan And Page Scan
STATUS LED. ATD000B53000080 CONNECT 2.2.3 Making Promi-SD™ do INQUIRY SCAN and PAGE SCAN Unlike many Bluetooth serial dongles, the SD has an internal, rechargeable battery. As stated before, to maximize battery life, the SD INQUIRY SCAN and Promi-SD™... -
Page 22: Releasing The Existing Bluetooth Connection
Once connected successfully, the SD becomes transparent to any serial applications on hosts. Data may be transferred within the radio range of the According to SD terminology, this operating status is called ‘ONLINE Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... -
Page 23: Automatic Connection Of Two Promi-Sd™ Units
2. Release the current Bluetooth connection by entering ‘ATH’ command. Once disconnected successfully, the SD returns the ‘DISCONNECT’ message. DISCONNECT 2.2.5 Automatic connection of two Promi-SD™ Units Two SD units connect automatically when powered up. For automatic SD connection first make a Bluetooth connection between two SD units. Once connected, the SD stores the 48-bit BD_ADDR of its counterpart. - Page 24 6. Turn both SD units power off. The SD pair will connect automatically when they are powered up again. 7. To release this paring, set them to MODE 0 by entering ‘AT+BTMODE, 0’. or reset the units by pressing the RESET button. AT+BTMODE,0 Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
-
Page 25: At Command Vs. Operational Status
1) Effective when Promi-SD™ is not in connection with Bluetooth. 2) Effective when Promi-SD™ is in connection status with Bluetooth. 3) Recommend to be used when Promi-SD™ is not in connections status with Bluetooth 4) To apply new values to Promi-SD™, software reset requires by ATZ command or restart Promi-SD™. -
Page 26: Technical Specifications
For data communications 27 mA with Host only During INQUIRY mode 96 mA For Master connection 96 mA During SCAN (page & 25 mA inquiry) mode Park mode 34 mA Non-Park mode 40 mA Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... -
Page 27: Environmental
RS232, Female DSUB-9, 1200~230400 baud, 3.5 Maximum distance between Promi-SD™s In open space, maximum distances between two Promi-SD units were tested using different types of Optional Antennas. Users may extend wireless link distance up to 1.2Km via Promi-SD202-OA with Patch Antennas for both sides. -
Page 28: Troubleshooting
Troubleshooting 4.1 Enabling/Disabling of Response Signals -OK, CONNECT, DISCONNECT & ERROR Promi-SD™ will respond to users on the current status, success & failure of connections, and error mode. Both PromiWIN™ and Terminal Programs will receive related response signals from Promi-SD™. -
Page 29: Hardware Reset
ATS10=0 : Disabling/OFF 4 signals ATS10? : To see current status 4.2 Hardware Reset For Hardware reset, press the button on the right side of the Promi-SD™ unit with a narrow tool such as a ball-point pen. HARD RESET SWITCH Promi-SD™... -
Page 30: Optional Antennas
(2) Patch Antenna (w/ RF extension cable & wall-attachable nails) Part No.: PSD00-00060 8.5dBi Including a 30cm RF extension cable Longer RF extension cable Part No.: PSD00-00061: 1m length For 3m and longer length, please ask it to our support@initium.co.kr Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... - Page 31 Part No. : PSD00-00062 Anchor Support *This will be needed if there is a need to attach the Patch antenna to the wall. *Distance Data between Promi-SD™s when Optional Antennas are used: Model no. Antennas for two Promi-SD units Max. Distance...
-
Page 32: For Multi-Serial Connections
For multiple serial connections, we recommend Promi-MSP™. Promi-MSP™ has 7 default Bluetooth connections and can be expanded to up to 21 connections. More information on Promi-MSP™ can be found in its User Manual at www.initium.co.kr <Fig. 7.1.1 Promi-MSP™> Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... -
Page 33: Legal Notice
Legal Notice About this Document This document provides introductory instructions on how to set up and manage Promi-SD™ within your networking environment. Should you require more information, please refer to AVE Trademark Acknowledgements The Bluetooth trademarks are owned by their proprietor and used by Initium Co., Ltd. - Page 34 LICENSORS OR SUPPLIERS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. This warranty does not cover replacement of products damaged by abuse, accident, misuse, neglect, alteration, repair, disaster, improper installation or improper testing. Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
-
Page 35: Contact Information
. Contact Information This manual is available in a printable PDF version on-line and on the CD enclosed in the Promi-SD product package. For additional support related to Promi-SD and this document, contact INITIUM via: Manufacturer: INITIUM Co., Ltd. #716, Kumgang-Hitech Valley, 133 Sangdaewon, Jungwon, Sungnam, Kyunggi, 462-120, Korea Tel.: +82-31-777-5703... -
Page 36: Appendix A: Power Adaptor Specification
2.1.2.1. Nominal input frequency : 50 / 60 Hz 2.1.2.2. Rated input frequency : 47 - 63 Hz 2.1.3. AC INPUT CURRENT : MAX 0.3 A (RMS) at 90 Vac 2.2 OUTPUT CHARACTERISTICS 2.2.1. DC OUTPUT Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... - Page 37 2.3.4. STORAGE HUMIDITY : 90 % RELATIVE 2.3.5. BURN-IN PROCESS 2.3.5.1. All unit shall be subjected to burn-in process of mass production. 2.3.5.2. TEMPERATURE : 30 +/-5'C 2.3.5.3. LOAD CONDITION : 2 A Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 38 2.3.5.4. INPUT VOLTAGE : 110 / 220 Vac 3. MECHANICAL CHARACTERISTICS 3.1. DIMENSIONAL SIZE LENGTH : 66 mm WIDTH : 48.5 mm HIGHT : 35 mm 3.2. OUTPUT CABLE CABLE LENGTH : 1850 +/- 50 Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
-
Page 39: Appendix B: At Command Sets
<cr><lf>BD_ADDR, Device Name , Class of Device<cr><lf> <cr><lf>OK<cr><lf> Description : This command is used to inquiry other Bluetooth devices nearby. The INQUIRY process is carried out during the predefined time duration (30 Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr... - Page 40 AT command. Your SD does INQUIRY SCAN and PAGE SCAN until it has a connection from other Bluetooth device. Once connected, your SD returns ‘CONNECT’ message. You can use ‘AT+BTCANCEL’ to cancel this operation. This AT command has the same effect of ‘AT+BTSCAN,3,0’. Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 41 Cancel currently ongoing operation of your SD. Response : <cr><lf>OK <cr><lf> Description : This AT command works only when your SD is busy in doing ‘AT+BTSCAN’, ‘ATD’ or ‘AT+BTINQ?’. Once canceled successfully, your SD will become Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 42 AT commands or do soft- reset. To enable authentication or encryption, set authentication or encryption parameter as 1. Otherwise set either of them as 0. Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 43 When the authentication is enabled in your SD, you should assign passkey. Two Bluetooth devices which are to be connected should have the same passkey. The default passkey of your SD is ‘1234’. You can assign maximum 16 alphanumeric characters as a passkey. Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 44 This AT command just deletes the info of paired devices stored on SD’s Flash memory. To delete the same info resides on SD’s RAM, you have to do software reset or hardware reset. Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 45 Parity = N (No parity), E (Even parity) or O (Odd parity). Stopbit = 1 or 2. Handshaking = 1 or 0 (If ‘1’, hardware handshaking will be used. If ‘0’, handshaking function of Promi-SD will be turned off) Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 46 <cr><lf>OK<cr><lf> timeout of infinity. AT+BTSCAN,n,to<cr> Enable inquiry or Page scans. <cr><lf>OK<cr><lf> If n=1, disable page and enable inquiry. If n=2, enable page and disable inquiry. If n=3, enable both page and inquiry. Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 47 Up to 16 characters. AT+BTINFO?<cr> Retrieve local device information <cr><lf>112233445 including BD address, Friendly name, 566,FriendlyName, Mode,State,Authent mode of device, internal operation state and status of authentication ication,Encryption< and encryption features. cr><lf> <cr><lf>OK<cr><lf> Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 48 <cr><lf>OK<cr><lf> ‘nn’ should be ASCII code (Decimal), printable character. Default escape charater is ‘+++’ AT+PINQ?<cr> For Periodic Inquiry. Promi-SD will try <cr><lf>OK<cr><lf> to inquire nearby Bluetooth devices periodically and deliver the inquired Promi-SD™ User Manual ver 1.0 Model: Promi-SD202-OA www.initium.co.kr...
- Page 49 Host. To lease periodic inquiry function, AT+BTCANCEL. AT&V Shows S-register values S-register command: If you change the values of S-register, please reboot Promi-SD. ATSnn=mm<cr>: To change ATSnn register value ATSnn?: To check current ATSnn register value. ATS3 Stream UART policy (Default 0) If set as ‘0’, throughput is the priority, if set as ‘1’, Latency...
- Page 50 If set to ‘1’, Promi-SD will accept CDC signal from other peer (DCE-configured) Bluetooth device. ATS14 ATS14=1<cr>: Users may use DTR/DSR lines for communications ATS14=0<cr>: Users may use DTR/DSR lines for Loop- back only. Default value of ATS14 is 0.
