AX6220Z/AX6240Z
Energy-Efficient, DSP-Powered and Ethernet/USB-Controlled
1000/900-Watt 70/100 V High-Impedance Power Amplifier
Architect's and Engineer's Specifications Continued
Dimensional Drawings
Performance criteria met by the amplifier shall include:
• RMS power output (1 kHz @ 1% THD, 100 V) of 1000 W/channel for AX6240Z and 700 W/channel for the AX6220Z
• Input sensitivity of 1 V (10 Ω/20 Ω for AX6240Z/AX6220Z)
• Input clipping of 11 Vrms (+23 dBu)
• Overall gain (10 Ω) at 70/100 V of 37/40 dB
• Frequency Response of 30 Hz-20 kHz within +0.3/-2 dB at 70 V and +0.3/-1 dB at 100 V
• Distortion (THD+N; 1 W, 1 kHz) of less than 0.25% at 7 Ω/14 Ω (AX6240Z/AX6220Z)
• Signal to Noise Ratio of 87/93 dB at 2 dBu/+22 dBu
• Damping Factor (62 Ω) of greater than 220
• Crosstalk (1 kHz at rated power) of greater than -70 dB for AX6240Z and -68 dB for AX6220Z
AC power requirements of the amplifier shall be 100~120 V or 220~240 V at 50/60Hz.
Physical characteristics of the amplifier shall be:
• Height x Width x Depth of 3.5 x 17 x 16" / 89 x 432 x 406 mm
• Net weight of not more than 21.6 lbs / 9.8 kg
Model: The power amplifier shall be the BEHRINGER EUROCOM AX6220Z/AX6240Z.
5
