AX6220Z/AX6240Z
Energy-Efficient, DSP-Powered and Ethernet/USB-Controlled
1000/900-Watt 70/100 V High-Impedance Power Amplifier
Technical Specifications
Power Output HI-Z
Peak, 1% THD, 1 kHz sine wave
Stereo (both channels driven)
• 70 V
• 100 V
RMS, 1% THD, 1 kHz sine wave
Stereo (both channels driven)
• 70 V
• 100 V
Audio Inputs / Outputs
• Line level inputs
• PC control
• Input impedance
• Input sensitivity
• Input clipping
• Overall system gain @ 10 Ω
• Outputs
• Output circuit type
• Minimum load impedance
System Information
• Frequency response
• THD+N
• Signal-to-noise ratio
• Damping factor
• Crosstalk
• Indicators
• Operating temperature
• Cooling method
AX6220Z
AX6240Z
500 W
900 W
700 W
1300 W
350 W
700 W
480 W
1000 W
2 x 3-pin Euroblock and XLR / TRS combo
Type B USB on front or IEEE 802.3
Ethernet network connector on
back panel
10 kΩ unbalanced, 20 kΩ balanced
1 V @ 20 Ω
11 Vrms (+23 dBu)
37 dB (70 V) / 40 dB (100 V)
4-position barrier strip
Class D
14 Ω (70 V) / 20 Ω (100 V)
30 Hz – 20 kHz (-0.3 / -2 dB) (70 V)
30Hz – 20 kHz (-0.3 / -1 dB) (100 V)
< 0.25% @ 1 W, 1 kHz dBr into
14 Ω load
87 dB (@ input 2 dBu)
93 dB (@ +22 dBu)
> 200 @ 62 Ω
> 68 dB below rated power 1 kHz
Power indicator LED ring
illumination (yellow)
Overload/Protection LED ring (red)
LCD display with VU meters,
system fault, overheating,
overcurrent / overdrive indicators
14° F to 104° F
(-10° C to +40° C)
Automatic variable speed fan
Digital Signal Processing (DSP)
• Display
• Digital delay function
(per channel)
• Digital crossover function
• Digital EQ function
• Digital dynamics function
(per channel)
• Presets
Power Supply
• Power consumption @
1/8 rated power
• Power efficiency
• AC power source
Dimensions / Weight
• Dimensions (H x W x D)
• Weight
Materials
• Case material
• Face plate material
• Included accessories
3
LCD 128 x 32, amber backlit
0 – 300 ms
3 filter types, up to 48 dB/octave
8-band parametric, (per channel)
2-band dynamic equalizer
Zero attack limiter
20 total presets, 19 user-definable
200 W
84 %
100~120 V AC 50/60 Hz
220~240 V AC 50/60 Hz
3.5 x 17 x 16" / 88 x 432 x 406 mm
21.4 lbs / 9.7 kg
Cold-rolled steel
Perforated steel
Rack mount brackets
