AX6220Z/AX6240Z
Energy-Efficient, DSP-Powered and Ethernet/USB-Controlled
1000/900-Watt 70/100 V High-Impedance Power Amplifier
Product Overview
Featuring comprehensive digital signal processing
(DSP) and remote setup via Ethernet/USB, the Eurocom
AX6240Z and AX6220Z are professional high-performance
2-channel power amplifiers for installation with 70/100
V distributed speaker systems. The AX6240Z delivers up
to 700 watts RMS per channel at 70 V (7 Ω), and up to
1000 watts RMS per channel at 100 V (10 Ω). The AX6240Z
delivers up to 350 watts RMS per channel at 70 V (14 Ω),
and up to 500 watts RMS per channel at 100 V (20 Ω).
Both models utilize transformerless Class-D topology
and state-of-the-art switch-mode power technology
to provide low noise and superior transient response
while reducing amplifier energy costs by up to 85%.
Dual variable-speed fans create back-to-front ventilation
to keep racks running cool, and "zero-attack" limiters
combine with independent DC and thermal overload
protections to safeguard the amplifiers and connected
speaker systems.
Featuring 24-bit/96 kHz converters to ensure flawless
signal integrity, the AX6240Z/AX6220Z processing
section maintains an extremely broad dynamic range
while offering sophisticated DSP options including delay,
crossover, dynamics, and both parametric (8-band)
and dynamic (2-band) EQ. Parameters may be set and
stored using intuitive front-panel controls and the amber
backlit LCD, which also displays meters and indicates
muting, system fault, over-current, and overdrive.
The front panel also has an illuminated master volume
knob with a clipping indicator. A front-panel USB
connector is included to allow setup on a local PC,
while a rear-panel Ethernet connection enables remote
control and monitoring using the BEHRINGER Amp
Remote software application. Changes to settings may be
prevented with secure lockout.
Input channels accept balanced or unbalanced
microphone or line-level signals via XLR/TRS combination
jacks or 3-pin Euroblock connectors. Outputs are
connected to speakers via a 4-screw terminal strip.
A 2-pin Euroblock socket is provided for sequential power
control and remote power on/off. All mating Euroblock
connectors are included, as are integrated rack ears and
screw covers. Designed for high-power applications in
the most demanding distributed speaker installations,
the Eurocom AX6240Z and AX6220Z offer maximum
performance and unsurpassed value.
