Printek MtP300 Quick Setup Instructions

Important:
1. You must charge the battery for at least 2½ hours prior to the first use.
2. Maximum battery capacity is first reached after completing three complete charge and discharge cycles.
3. Always use Genuine Printek Media to ensure optimal performance.
•
To load media:
•
Move the Paper Door Release in the direction indicated in Figure A and open the Paper Door.
•
Move the media support as shown in Figure B and place the roll between the supports. Make sure the media rotates
freely. Lay the leading edge of the media through the print head as shown in Figure C, and close the door.
•
To install the battery: Slide the battery into the battery compartment until the release lever on the battery snaps into place.
You may remove the battery by pressing the release lever toward the bottom of the printer and pulling the battery out of the
battery compartment.
•
To charge the battery, connect a power adapter (sold separately) to the appropriate power source and plug the output
cable into the printer's Power Connector as shown in Figure A. The Battery Indicator will turn on indicating that the battery
is being charged.
•
To perform a self test, press and hold the
Note: For more information, refer to the MtP300 Series Operator's Manual. You may download this manual at www.printek.com.
Serial I/O
Connector
Power
Connector
Magnetic Card
Reader
Power
Paper Feed
Figure A
Paper Door Release
MtP300 Quick Setup Instructions
Paper Feed Button while turning on the printer with the
Paper Supply Gauge Paper Door
/Advance
Power Button.
Tear Bar
Release Lever
Battery
Media Support
Figure B
Paper Leading Edge
Figure C
