MULTIQUIP GA-6HA Starting Instructions

GA-6HA AC Generator

Starting Instructions

The following instructions are intended to assist the
user in starting the GA-6HA AC Generator. Please read
the entire instructions before starting.
Engine Oil Check
1. To check the engine oil level, place the generator on
secure level ground with the engine stopped.
2. Remove the filler cap/dipstick from the engine oil filler
hole and wipe it clean.
3. Insert and remove the dipstick without screwing it into
the filler neck. Check the oil level shown on the
dipstick.
4. If the oil level is low (Figure 1), fill to the edge of the
oil filler hole with the recommended oil type (Table 1).
Maximum oil capacity is 1.16 quarts (1.1 liters).
Figure 1. Engine Oil Dipstick (Oil Level)
T b a e l . 1 M
e S s a n o r o e T m e p a r u t e r
p S n i r , g u S m m r e r o u A u t m
+ 2 1 ° 0 F o t 1 + ° 5 F
W n i r e t
4 + ° 0 F o t 1 + ° 5 F
e B o l w 1 + ° 5 F
WARNING WARNING WARNING
WARNING WARNING
Gasoline is extremely flammable, and its
vapors can cause an explosion if ignited.
DO NOT start the engine near spilled fuel
or combustible fluids.
DO NOT fill the fuel tank while the engine is running or
hot. DO NOT overfill tank, since spilled fuel could ignite if
it comes into contact with hot engine parts or sparks from
the ignition system. Store fuel in approved containers, in
well-ventilated areas and away from sparks and flames.
t o r o O l i G a r e d
G a r e d f o m o r o t l i o
i h ( h g r e h t n a M S l c s a
n
S A E 0 3
S A E 0 3
S A E 0 1 - W 0 3
Explosive Fuel Hazards
Fuel Check
1. Close the fuel cock before filling the fuel tank.
2. Remove the fuel cap located on top of fuel tank.
3. Read the fuel gauge located on top of the fuel tank (Figure
2) to determine if the fuel level is low. If fuel is low,
replenish with clean unleaded fuel .
4. When refueling, be sure to use a strainer for filtration.
DO NOT top-off fuel. DO NOT fill the tank beyond
capacity. Wipe up any spilled fuel immediately!
Before Starting the Engine
1. Be sure to disconnect all electrical loads from the
generator prior to starting the engine.
2. NEVER start the engine with the main circuit breaker
in the ON position. Always place the main circuit
breaker (Figure 3) in the OFF position before starting.
) s
Figure 3. Main Circuit Breaker (OFF)
Starting the Engine
1. Place the engine fuel valve lever (Figure 4) to the ON
position.
Figure 4. Engine Fuel Valve Lever
Figure 2. Fuel Gauge
