  • Page 1 This product is compliant with the applicable CE requirements. ASSEMBLY MANUAL / OWNER’S MANUAL...

  • Page 2: Table Of Contents

    Serial Number __________________________ Date of Purchase ____________________ To register your product warranty, contact your local distributor. If you have questions or problems with your product, please contact your local Schwinn distributor. ® To find your local distributor, go to: www.nautilusinternational.com Nautilus, Inc., www.NautilusInc.com, 18225 NE Riverside Parkway, Portland, OR 97230, U.S.A. - Customer Service: technics@...

  • Page 3: Important Safety Instructions - Assembly

    Important Safety InStructIonS -aSSembly This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Obey the following warnings: Read and understand all warnings on this machine. Carefully read and understand the Assembly instructions. • Keep bystanders and children away from the product you are assembling at all times.

  • Page 4: Safety Warning Labels / Serial Number

    Safety WarnIng labelS and SerIal number Serial Number Product Specifications • Read, understand and obey all warnings on this machine. • Keep children away. • Not intended for use by anyone under 14 years of age. • Prior to use, read and understand the Owner’s Manual.

  • Page 5: Specifications

    SpecIfIcatIonS Maximum User Weight: 136 kg ( 300 lbs. ) Machine Weight: 39.3 kg ( 86.6 lbs. ) Total Surface Area (foot print) of equipment: 133.3 cm 10705.5 cm ( 1662.5 inches ( 52.5” ) Power Requirements: Operational Voltage: 220V - 240V AC, 50Hz 158.6 cm Operating Current: 0.4A ( 62.5” ) 67.5 cm Regulatory Approvals: ( 26.6” ) This product conforms to the applicable EN ISO 20957 International Standards for Stationary Training Equipment, Class H.

  • Page 6: Parts

    partS Item Description Item Description Console AC Adapter Water Bottle Holder Left Pedal Seat Back Front Stabilizer Seat Cover Right Pedal Seat Frame Assembly Upper Shroud Seat Bottom Shroud Cap Seat Adjustment Handle Console Mast Rear Stabilizer MP3 Cord Frame...

  • Page 7: Hardware

    HardWare / toolS Item Description Item Description Button Head Hex Screw, M8x20 Phillips Head Screw, M5x12 Button Head Hex Screw, M6x12 Lock Washer, M6 Flat Washer, M8 Curved Washer, M6 Lock Washer, M8 Phillips Head Screw, M6x25 Flat Washer, M6 Curved Washer, M8 Tools Included 4 mm 6 mm...

  • Page 8: Assembly

    aSSembly 1. Attach StabilizerS to Frame Note: H ardware is pre-installed and not on the Hardware Card. *...
  • Page 9 2. Attach the Seat Frame Assembly to the Seat Rail NOTICE: Do not crimp the Heart Rate Cable. Once all hardware has been inserted, be sure to fully tighten it.
  • Page 10 3. Attach Seat Pads to Seat Frame Assembly...
  • Page 11 4. Attach Cover to Frame Assembly 5. Attach Seat Adjustment Handle to Frame Assembly...
  • Page 12 6. Connect the Cables and Attach the Console Mast to Frame Assembly NOTICE: Do not crimp Console Cables.
  • Page 13 7. Remove Hardware from Console NOTICE: Do not crimp the cable. Note: H ardware is pre-installed and not on the Hardware Card. * 8. Connect Cables and Attach Console to Frame Assembly NOTICE: Align the clips on the cable connectors and make sure the connectors lock. Do not crimp cables.
  • Page 14 9. Attach Pedals to Frame Assembly NOTICE: The Left Pedal is reverse-threaded. Be sure to attach Pedals on the proper side of the Bike. Orientation is based from a seated position on the bike. The Left Pedal has an “L”, the Right Pedal an “R”.
  • Page 15 10. Attach Water Bottle Holder to Frame Assembly...
  • Page 16 11. Connect AC Adapter to Frame Assembly 12. Final Inspection Inspect your machine to ensure that all hardware is tight and components are properly assembled. Be sure to record the serial number in the field provided at the front of this manual. Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Owner’s Manual.

  • Page 17: Moving The Machine

    before you Start Moving the Machine The machine may be moved by one or more persons depending on their physical abilities and capacities. Make sure that you and others are all physically fit and able to move the machine safely. 1. R emove the power cord.

  • Page 18: Leveling The Machine

    Leveling the Machine Levelers are found on each side of the Rear Stabilizer and on the Frame Rail. On the Rear Stabilizer, turn the knob to adjust the stabilizer foot. Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or damage to the machine can occur. To adjust the leveler on the Frame Rail: 1. L oosen the upper locking nut. 2. T urn the leveler to adjust the height. Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or damage to the machine can occur.

  • Page 19: Important Safety Instructions

    Important Safety InStructIonS This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Before using this equipment, obey the following warnings: Read and understand the complete Manual. Keep the Manual for future reference. R ead and understand all warnings on this machine. If at any time the Warning stickers become loose, unreadable or dislodged, contact your local Schwinn distributor for replacement stickers. ® • Children must not be let on or near to this machine. Moving parts and other features of the machine can be dangerous to children. • Not intended for use by anyone under 14 years of age.

  • Page 20: Features

    featureS Console Transport Wheel MP3 Input Fully Shrouded Flywheel USB Port Pedal Water Bottle Holder Storage Bin Transport Handle Seat Adjustment Handle Stabilizer Handlebar, Upright Leveler Speakers Handlebar, Side Contact Heart Rate (CHR) Sensors Media Tray Power Connector Telemetry Heart Rate (HR) Receiver WARNING indicates a hazardous Heart rate monitoring systems may be inaccurate. Over exercising may result in serious injury or WARNING situation which, if not avoided, could death. If you feel faint stop exercising immediately. result in death or serious injury. DANGER indicates a hazardous D A N G E R situation which, if not avoided, will result in death or serious injury.

  • Page 21: Console Features

    Console Features The Console provides important information about your workout and lets you control the resistance levels while you exercise. The Console features the Schwinn Dual Track display with touch control buttons to navigate you through the exercise ™ programs. Upper Display 40% 70% 40% 70% PAUSE/ QUICK ST ART Lower Display GOAL TRACK PROGRAMS Resistance Level Quick Buttons Resistance Level Quick Buttons CURRENT WORKOUT LAST 30 DA YS LONGEST WORKOUT LAST WORKOUT CALORIE RECORD LAST 7 DA YS Achievement Indicator Lights Keypad Functions Resistance Increase () button- Increases the workout resistance level...
  • Page 22 Achievement Indicator Lights- when an achievement level is reached or a result is reviewed, the achievement indicator light will activate. Schwinn Dual Track™ Display Upper Display Data Program Display User Display 40% 70% Achievement Display Program Display The Program Display shows information to the User and the grid display area shows the course profile for the program. Each column in the profile shows one interval (workout segment). The higher the column, the higher the resistance level. The flashing column shows your current interval. Intensity Display The Intensity Display shows the level of work at that moment based on the current resistance level. RKOUT Heart Rate Zone Display The Heart Rate Zone shows which zone the current heart rate value falls into for the current User. These Heart Rate Zones can be used as a workout guide for a certain target zone (anaerobic, aerobic, or fat burn). Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only.
  • Page 23 40% 70% Lower Display Data The Lower Display shows the Workout Values. and can be customized for each User (Consult the “Edit User Profile” section PAUSE/ of this manual). GOAL TRACK Speed The Speed display field shows the machine speed in miles per hour (mph) or kilometers per hour (km/h). CURRENT WORKOUT LAST WORKOUT LAST 7 DA YS Time The TIME display field shows the total time count of the workout, the average Time for the User Profile, or the total operational time of the machine. Note: If a Quick Start workout is performed for more than 99 minutes and 59 seconds (99:59), the units for Time will shift to hours and minutes ( 1 hour, 40 minutes ). Distance The Distance display shows the distance count (miles or km) in the workout. Note: T o change the measurement units to English Imperial or metric, refer to the “Console Setup Mode” section in this manual. Level The LEVEL display shows the current resistance level in the workout. The RPM display field shows the pedal revolutions per minute (RPM). Heart Rate (Pulse) The Heart Rate display shows the beats per minute (BPM) from the heart rate monitor. When a heart rate signal is received by the Console, the icon will flash.
  • Page 24 Remote Heart Rate Monitor Monitoring your Heart Rate is one of the best procedures to control the intensity of your exercise. Contact Heart Rate (CHR) sensors are installed to send your heart rate signals to the Console. The Console can also read telemetry HR signals from a Heart Rate Chest Strap Transmitter that operates in the 4.5kHz - 5.5kHz range. Note: The heart rate chest strap must be an uncoded heart rate strap from Polar Electro or an uncoded POLAR compatible model. (Coded PO- ® heart rate straps such as POLAR OwnCode chest straps will ® ® ® not work with this equipment.) If you have a pacemaker or other implanted electronic device, consult your doctor before using a wireless chest strap or other telemetric heart rate QUICK PAUSE/ ST ART...
  • Page 25 The most efficient procedure to burn fat during exercise is to start at a slow pace and gradually increase your intensity until your heart rate reaches between 60 – 85% of your maximum heart rate. Continue at that pace, keeping your heart rate in that target zone for over 20 minutes. The longer you maintain your target heart rate, the more fat your body will burn. The graph is a brief guideline, describing the generally suggested target heart rates based on age. As noted above, your opti- mal target rate may be higher or lower. Consult your physician for your individual target heart rate zone. Note: A s with all exercises and fitness regimens, always use your best judgment when you increase your exercise time or intensity.

  • Page 26: Operations

    operatIonS What to Wear Wear rubber-soled athletic shoes. You will need the appropriate clothes for exercise that allow you to move freely. How Often Should You Exercise Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only. The heart rate displayed on the console may be inaccurate and should be used for reference only. • 3 times a week for 30 minutes each day. • Schedule workouts in advance and try to follow the schedule.

  • Page 27: Quick Start Program

    Initial Setup During the first power-up, the Console should be setup with the date, time and your preferred measurement units. 1. D ate: Push the Increase/Decrease buttons to adjust the currently active value (flashing). Push the Left/Right buttons to change which segment is the currently active value (month / day / year). 2. P ush OK to set. 3. T ime: Push the Increase/Decrease buttons to adjust the currently active value (flashing). Push the Left/Right buttons to change which segment is the currently active value (hour / minute / AM or PM). 4. P ush OK to set. 5. U nits of Measurement: Push the Increase/Decrease buttons to adjust between “MILES” (Imperial English) or “KM” (metric). 6. Push OK to set. The Console goes back to the Power-Up / Idle Mode screen. Note: To adjust these selections, consult the “Console Set-Up Mode” section. Quick Start ( Manual ) Program The Quick Start ( Manual ) program lets you start a workout without entering any information. During a Manual Workout, each column represents a 2 minute time period. The active column will advance across the screen every 2 minutes. If the workout lasts for more than 30 minutes, the active column is fixed on the farthest column on the right and pushes the previous columns off the display. 1. Sit on the machine.
  • Page 28 Select a User Profile Every workout is saved to a User Profile. Be sure to select the proper User Profile before starting a workout. The last User that completed a workout will be the default user. User Profiles are assigned the default values until they are customized by editing. Be sure to edit the User Profile for more accurate calorie and heart rate information. From the Power-Up Mode screen, push the Increase() or Decrease() buttons to select one of the User Profiles. The Console will display the name of the User Profile and the User Profile Icon. Edit User Profile 1. F rom the Power-Up Mode screen, push the Increase() or Decrease() buttons to select one of the User Profiles. 2. P ush the OK button to select the User Profile. 3. T he Console display shows the EDIT prompt and the current User Profile name. Push OK to start the Edit User Profile option. T o exit the Edit User Profile option, push the PAUSE/END button and the console will go back to the Power-Up Mode screen. 4. T he Console display shows the NAME prompt and the current User Profile name. Note: The User name will be blank if this is the first edit. The name of a User Profile is limited to 10 characters. T he currently active segment will flash. Use the Increase/Decrease buttons to move through the alphabet and blank space (found between A and Z). To set each segment, use the Left() or Right() buttons to shift between segments.
  • Page 29 9. T he Console will go to the Power-Up Mode screen with the user selected. Reset a User Profile 1. F rom the Power-Up Mode screen, push the Increase() or Decrease() buttons to select one of the User Profiles. 2. P ush the OK button to select the User Profile. 3. T he Console display shows the current User Profile name and the EDIT prompt. Push the Increase() or Decrease() buttons to change the prompt. Note: To exit the Edit User Profile option, push the PAUSE/END button and the console will go back to the Power-Up Mode screen. 4. T he Console display shows the RESET prompt and the current User Profile name. Push OK to start the Reset User Profile option. 5. T he Console will now confirm the request to reset the User profile (the default selection is ‘NO’). Push the Increase() or Decrease() buttons to adjust the selection. 6. P ush OK to make your selection. 7. The Console will go to the Power-Up Mode screen.
  • Page 30 Rolling Hills Rolling Hills Ride in the Park Ride in the Park Easy Tour Easy Tour Stream Crossing ondary Case 6: Profile Programs Secondary Case 6: Profile Programs Rolling Hills Rolling Hills Ride in the Park Ride in the Park Easy Tour Easy Tour Stream Crossing...
  • Page 31 Fitness Test Program The Fitness Test measures the improvements of your physical fitness level. The test compares your power output (in Watts) to your heart rate. As your fitness level improves, your power output will increase at a given heart rate. Note: The Console must be able to read the heart rate information from the Contact Heart Rate (CHR) sensors or Heart Rate Monitor (HRM) to work correctly. You can start the Fitness Test from the FEEDBACK category. The Fitness Test program first prompts you to select your fitness level—Beginner ( “BEG” ) or Advanced ( “ADV” ). The Console will use the Age and Weight values for the selected User Profile to calculate the Fitness Score. Start to workout and hold the Heart Rate Sensors. When the test starts, the intensity of the workout slowly increases. This means you will work harder, and as a result, your heart rate increases. The intensity continues to increase automatically until your heart rate reaches the “Test Zone”. This zone is individually computed to be near 75 percent of the maximum heart rate of your User Profile. When you reach the Test Zone, the machine holds the intensity steady for 3 minutes. This lets you reach a stable condition (where your heart rate becomes steady). At the end of the 3 minutes, the Console measures your heart rate and the power output. These numbers, along with information about your age and weight, are computed to produce a “Fitness Score”.

  • Page 32: Pausing Or Stopping

    The Target Heart Rate programs use your age and other User information to set the Heart Rate Zone values for your workout. The console display then gives prompts for you to set up your workout: 1. S elect the Heart Rate Control workout level: BEGINNER ( “BEG” ) or ADVANCED ( “ADV” ) and push OK. 2. P ush the Increase() or Decrease() buttons to select the percentage of maximum heart rate: 50–60%, 60–70%, 70– 80%, 80–90%. Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only. The heart rate displayed on the console is an approximation and should be used for reference only. 3. P ush the Increase() or Decrease() buttons to select the Goal type, and push OK. 4. P ush the Increase() or Decrease() buttons to set the goal value for the workout. Note: Be sure to allow time for your heart rate to reach the desired heart rate zone when setting the goal.

  • Page 33: Results / Cool Down Mode

    T IME (total), DISTANCE (total), and CALORIES (total) b.) S PEED (average), RPM (average), and HEART RATE (average) c.) T IME (average), LEVEL (average), and CALORIES (average). Push the Left() or Right() buttons to move through the result channels manually. During the Cool Down period, the Resistance Level will adjust to a third of the average Level of the workout. The Cool Down resistance level can be adjusted with the Resistance Increase and Decrease buttons, but the Console will not display the value. You can push PAUSE/END to stop the Results / Cool Down period and go back to Power-Up Mode. If there is no RPM or HR signal, the Console automatically goes into Sleep Mode. GOAL TRACK Statistics (and Achievements) The statistics from every workout are recorded to a User Profile. The Schwinn Dual Track Console shows the Goal Track workout Statistics on the Lower Display in three channels: ™ a.) T IME (total), DISTANCE (total), and CALORIES (total) b.) S PEED (average), RPM (average), and HEART RATE (average) c.) T IME (average), DISTANCE (average) / or LEVEL (average) *, and CALORIES (average) * If the Goal Track Statistic is a single workout, LEVEL (average) is displayed. If the Goal Track Statistic is a combination of multiple workouts, DISTANCE (average) is displayed instead of LEVEL (average). To view the GOAL TRACK statistics of a User Profile: 1. F rom the Power-Up screen, push the Increase() or Decrease() buttons to select a User Profile. 2. P ush the GOAL TRACK button. The Console will display the LAST WORKOUT values and activate the corresponding Achievement light.
  • Page 34 4. P ush the Increase() button to move to “LAST 30 DAYS”. The Console will display the total values for the previous thirty days. Use the Left() or Right() buttons to move through all the workout statistic channels. 5. P ush the Increase() button to move to the “LONGEST WORKOUT”. The Console will display the workout values with the most Time value. Use the Left() or Right() buttons to move through all the workout statistic channels. 6. P ush the Increase() button to move to the “CALORIE RECORD”. The Console will display the workout values with the most Calories value. Use the Left() or Right() buttons to move through all the workout statistic channels. 7. P ush the Increase() button to move to “BMI”, or Body Mass Index. The Console will display the BMI value based on the User settings. Be sure the height value is correct for your User Profile, and the weight value is current. The BMI Measurement is a useful tool that shows the relationship between weight and height that is associated with body fat and health risk. The table below gives a general rating for the BMI score: Underweight Below 18.5 Normal 18.5 – 24.9 Overweight 25.0 – 29.9 Obesity 30.0 and above Note: The rating may overestimate body fat in athletes and others who have a muscular build. It may also underestimate body fat in older persons and others who have lost muscle mass. Contact your doctor for more information about Body Mass Index (BMI) and the weight that is appropriate for you. Use the values calculated or measured by the machine’s computer for reference purposes only.

  • Page 35: Console Service Mode

    conSole Setup mode The Console Setup Mode lets you input the date and time, set the units of measurement to either English or Metric, change the machine type, control the sound settings ( on/ off), or see maintenance statistics (Error Log and Run Hours – for service technician use only). 1. H old down the PAUSE/END button and Right button together for 3 seconds while in the Power-Up Mode to go into the Console Setup Mode. Note: Push PAUSE/END to exit the Console Setup Mode and return to the Power-Up Mode screen. 2. T he Console display shows the Date prompt with the current setting. To change, push the Increase/Decrease buttons to adjust the currently active value (flashing). Push the Left/Right buttons to change which segment is the currently active value (month / day / year). 3. P ush OK to set. 4. T he Console display shows the Time prompt with the current setting. Push the Increase/Decrease buttons to adjust the currently active value (flashing). Push the Left/Right buttons to change which segment is the currently active value (hour / minute / AM or PM). 5. P ush OK to set. 6. T he Console display shows the Units prompt with the current setting. To change, push OK to start the Units option. Push the Increase/Decrease buttons to change between “MILES” (Imperial English units) and “KM” (metric units). Note: I f the units change when there is data in User Statistics, the statistics convert to the new units. 7. Push OK to set.

  • Page 36: Maintenance

    maIntenance Read all maintenance instructions fully before you start any repair work. In some conditions, an assistant is required to do the necessary tasks. Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that regular maintenance is done. Worn or damaged components must be repaired or replaced immediately. Only manufacturer supplied components can be used to maintain and repair the equipment. To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the wall outlet and the machine and wait 5 minutes before cleaning, maintaining or repairing the machine. Place the power cord in a secure location. Daily: Before each use, examine the exercise machine for loose, broken, damaged, or worn parts. Do not use if found in this condition. Repair or replace all parts at the first sign...

  • Page 37: Maintenance Parts

    Maintenance Parts...
  • Page 38 Console Shroud, Left Speed Sensor Magnet Seat Back Transport Wheel Console Cable, Lower Seat Cover Stabilizer, Front Shroud, Right Water Bottle Holder Heart Rate Cable, Lower Pedal, Right Handlebar, Side Speed Sensor Shroud, Upper Seat Bottom Crank Arm Shroud Cap Seat Adjustment Handle Servo Motor Console Cable, Upper Frame Assembly Brake Assembly Heart Rate Cable, Upper Rear Stabilizer Flywheel Console Mast Pedal, Left Drive Belt...

  • Page 39: Troubleshooting

    troubleSHootIng Condition/Problem Things to Check Solution No display/partial display/ Check electrical (wall) Make sure unit is plugged into a functioning wall outlet. unit will not turn on outlet Check connection at front Connection should be secure and undamaged. Replace adapter of unit or connection at unit if either are damaged. Check data cable integrity All wires in cable should be intact. If any are visibly crimped or cut, replace cable. Check data cable Be sure cable is connected securely and oriented properly. Small connections/orientation latch on connector should line up and snap into place.
  • Page 40 No speed/RPM reading, Check data cable integrity All wires in cable should be intact. If any are cut or crimped, Console displays “Please replace cable. Pedal” error code Check data cable Be sure cable is connected securely and oriented properly. Small connections/orientation latch on connector should line up and snap into place. Check magnet position Magnet should be in place on pulley. (requires shroud removal) Check Speed Sensor (re- Speed sensor should be aligned with magnet and connected to quires shroud removal) data cable. Realign sensor if necessary. Replace if there is any damage to the sensor or the connecting wire. Console shuts off (enters Check electrical (wall) Make sure unit is plugged into a functioning wall outlet.
  • Page 42 Nautilus Bowflex Schwinn Fitness Universal ® ® ® ® 8003249.090113.A...
