Tripp Lite PowerVerter APSX3024SW Specification Sheet

Model #: APSX3024SW
PowerVerter® APS X Series 3000W Inverter/Charger with Auto-Transfer Switching and Hardwire Input/Output
Description
Tripp Lite's APSX3024SW DC-to-AC inverter with automatic line-to-battery transfer and integrated charging system serves as an extended run UPS,
a standalone power source or an automotive inverter. Supplies up to 3000 watts of continuous 230V sine wave AC power from any 24V battery or
automotive DC source. When hardwire AC input is energized, commercial power passes through to connected equipment and the battery set is
recharged via 3 stage, 23/90 amp charging system. In UPS mode, the APS system responds to blackouts and severe voltage fluctuations with a
near instantaneous automatic transfer to battery-derived AC output. Includes a set of high current DC input terminals for simple installation (user
supplies batteries and cabling - see owner's manual for recommendations). Passes sine wave utility or generator power during battery charging and
UPS line power operation, and sine wave AC output in inverter and UPS backup modes. Built-in Automatic Voltage Regulation (AVR) corrects line
power AC brownouts and overvoltages without using battery power during battery charging and UPS standby modes. Reliable large transformer
design, with frequency control powers resistive electronic loads or large inductive motors, compressors and other items with high current needs on
startup. Optional APSRM4 wired remote power switch with full status LEDs provides remote power inverter on/off switching and continuous status
information (part# APSRM4 sold separately). Supports an unlimited amount of runtime with any number of user-supplied batteries connected. Highly
adaptable to a variety of applications and site conditions with adjustable charger settings for wet/gel battery types and selectable line to battery
power transfer voltages.
Applications
Versatile inverter/charger system with auto-transfer switching serves as an automotive inverter for RVs, over-the-road trucking, conversion vans,
high humidity environments and fleet service vehicles; a standalone alternative power source for off-grid, alternative energy or export applications
and as an uninterruptible power supply (UPS) for items compatible with selectabe half-cycle (10ms) or full-cycle (20ms) transfer times. NOTE: For
sump pump applications, Tripp Lite recommends its "UT" Utility Truck Inverter/Chargers.
Package Includes
APSX3024SW Inverter/Charger
Instruction manual with warranty information
Features
Supports 230V AC output from a 230V AC line power source or 24V DC battery source
3000W continuous sinewave AC output in inverter mode
Double Boost output supports momentary start-up loads up to 200% of the continuous rating for up to 10 seconds (see specification chart) -
Highlights
24V DC or 230V (selectable) AC input & output; 230V, 50/60 Hz, pure sine
wave output (hardwired)
3000 watts continuous, 4500 watts OverPower and 6000 watts DoubleBoost
inverter output
3-stage, 23/90 amp selectable wet/dry cell battery charger; Auto Transfer
Switching
Automatic Voltage Regulation corrects brownouts and overvoltages without
using battery power
