1 Preparing for Installation

1.1 Audience

This guide is intended for HP service representatives and other persons trained to install hardware
options in HP 10000 series racks. Such persons are expected to understand the hazards of working
in this environment and to take suitable precautions to minimize danger to themselves and
others.

1.2 Documentation Resources

You can download the documentation for components referenced in this installation guide from
the following locations:
• HP 10000 Series Rack (Documentation option):
http://h18004.www1.hp.com/products/servers/proliantstorage/racks
• HP Cluster Platform:
http://docs.hp.com/en/highperfcomp.html

1.3 Kit Description

The c-Class enclosure cable management bracket described in this manual is designed to align
and support the InfiniBand cables that lead from HP BladeSystem c-Class InfiniBand switches.
For example, the InfiniBand cables that run from an HP BLc 4X DDR InfiniBand switch mounted
in the rear of the HP BladeSystem c-Class enclosure to another switch, or a similar interconnect
device. The kit provides strain relief for the cables connected to the individual InfiniBand
interconnect ports and ensures a good connection. It also ensures the correct bend radius for the
cable and provides channels for cable routing and cable management. One HP BladeSystem
c-Class enclosure cable management bracket is required for each bay of system interconnect
device.
NOTE:
The c-Class server blade enclosure cable management bracket is designed to support
24 AWG (0.41 inch) diameter, 26 AWG (0.37 inch) diameter, and 28 AWG (0.33 inch) diameter
QSFP InfiniBand cables. Consult the documentation supplied with your cluster before installing
the brackets and routing the cables.

1.4 Kit Contents

Verify that the cable management bracket kit contains the following components:
• Packaging and documentation.
• The bracket hardware shown in Figure 1-1.
1.1 Audience 7
