American Dynamics Tyco ADC770 Specification Sheet

FEATURES
•
1/3-inch interline color
CCD
•
Digital Signal Processing
(DSP)
•
480 TV lines resolution
•
0.4 lux low light
sensitivity, 0.02 lux at
1/32 slow shutter
•
Wide dynamic range
(WDR)
•
Automatic electronic
shutter (AES)
•
Digital slow shutter
(DSS)
•
Dual (H&V) edge
enhancement
•
Automatic gain control
(AGC)
Lenses sold separately
•
Six backlight
compensation (BLC)
zones
•
On-screen Menus
•
On-screen Camera Titles
•
Supports DC and
Video-type auto iris
lenses
•
C/CS lens mount
•
Phase adjustable line-
lock
•
24 VAC or 12 VDC input
•
Internal isolation
transformer
ADC770
1/3-INCH COLOR DSP CAMERA WITH
WIDE DYNAMIC RANGE
The ADC770 1/3-inch color DSP camera offers an
advanced solution to your specific video surveillance
needs. Solid and powerful, these cameras are
engineered for optimal performance in low light and
contrasting lighting conditions.
On-screen menus provide simple access to the
camera's parameter settings. Low light sensitivity
renders sharp images in scenes as dim as 0.4 lux.
Digital Slow Shutter (DSS) provides an even greater
level of low light viewing capability. Digital Signal
Processing (DSP) combines with 480 TV lines of
resolution to deliver the best in picture quality.
Equipped with built-in Auto Tracking White (ATW)
Balance and One-Touch White Balance (AWB), the
ADC770 can produce accurate color pictures in a
broad range of lighting conditions. The One-Touch
feature makes these one of the easiest cameras in the
industry to adjust for manual white balance.
The ADC770 camera also features motion detection
with alarm output, six backlight compensation
(BLC) zones (two are user-definable), phase-
adjustable line-lock for "roll-free" switching, and a
fully isolated power supply that allows you to
connect multiple cameras to a single 24 VAC source
with minimal interference from ground loops.
These energy efficient cameras are suited for a wide
range of applications and save you money in
operational costs.
