American Dynamics ADC700 Specifications

FEATURES
•
1/3-inch interline color
CCD
•
330 TV lines resolution
•
2.0 lux light sensitivity
•
Supports DC-type or
EE-type auto iris lenses
•
CS lens mount with
C adapter
•
Automatic white balance
•
Automatic electronic
shutter
•
Automatic gain control
•
12 VDC input
•
Low power consumption
ADC700 and ADC700X
1/3-INCH COLOR CCD CAMERA
The ADC700 and ADC700X color 1/3-inch
CCD cameras are an excellent choice for value
driven, entry level applications.
With 330 TV lines resolution and other
advanced features, the camera delivers a clean,
sharp picture. Good low light sensitivity
(2.0 lux, f1.2), along with automatic electronic
shutter and automatic gain control, assures
that the camera will operate in a wide range of
lighting conditions. For more extreme lighting
conditions, the camera also supports the use of
DC-type or EE-type auto iris lenses.
www.americandynamics.net
