Shure MX405 Specifications

MX405 and MX410 Miniature Gooseneck Microphones
Overview
Flexible in more ways than one, Microflex Miniature Gooseneck microphones deliver unsurpassed style and performance for conference rooms and similar
applications. Offering desktop or mounted bases, wired or wireless options, and even interchangeable cartridges, it's easy to get the perfect fit for your
conferencing installation. Fully compatible with SLX® wireless systems, including the SLX4L wireless receiver with logic output for applications requiring
logic functionality.
Specifications
(subject to change)
Type
Frequency Response
Polar Pattern (at 1 kHz)
Output Impedance
Output Configuration
Sensitivity (at 1 kHz , open circuit voltage)
Maximum SPL (1 kHz at 1% THD, 1 kW load)
Equivalent Output Noise (A-weighted)
Signal-to-Noise Ratio
(referenced at 94 dB SPL at 1 kHz)
Dynamic Range (1 kΩ load at 1 kHz)
Common Mode Rejection (10 Hz to 100 kHz)
Preamplifier Output Clipping Level (1% THD)
Polarity
Weight
Logic Connections
Mute Switch Attenuation
Cable
Environmental Conditions
Power Requirements
Available Models
The polar pattern of the cartridge is indicated by the model number suffix: C = Cardioid, S = Supercardioid, N = No Cartridge
MX405/C, MX405/S
MX405R/N
MX410/C, MX410/S
MX410R/N
MX405LP/C, MX405LP/S
MX405RLP/N
MX410LP/C, MX410LP/S
MX410RLP/N
www.shure.com
Condenser (electret bias)
50–17000 Hz
MX405/C, MX410/C: Cardioid
MX405/S, MX410/S: Supercardioid
EIA Rated at 150 Ω (170 Ω actual)
Active Balanced
Cardioid: –35 dBV/Pa (18 mV)
Supercardioid: –34 dBV/Pa (21 mV)
1 Pascal=94 dB SPL
Cardioid: 121 dB
Supercardioid: 120 dB
Cardioid: 28 dB SPL
Supercardioid: 27 dB SPL
Cardioid: 66 dB
Supercardioid: 68 dB
93 dB
45 dB minimum
-8 dBV (0.4 V)
3-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 2
relative to pin 3 of output XLR connector.
5-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 4
relative to pin 2 of output XLR connector.
MX405: 0.054 kg (0.119 lbs)
MX410: 0.068 kg (0.150 lbs)
MX400DP: 0.516 kg (1.138 lbs)
MX400SMP (w/ Kit): 0.125 kg (0.275 lbs)
LED IN: Active low (≤1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V.
LOGIC OUT: Active low (≤1.0V), sinks up to 20mA, TTL compatible. Absolute maximum
voltage: -0.7V to 50V (up to 50V through 3kΩ).
-50 dB minimum
MX400DP: 6.1 m (20 ft) attached cable with shielded audio pair terminated at a 3-pin
male XLR and three unterminated conductors for logic control
Operating Temperature: -18–57 °C (0–135 °F)
Storage Temperature: -29–74 °C (-20–165 °F)
Relative Humidity: 0–95%
48–52 Vdc phantom, 8.0 mA
5 inch (127 mm) Gooseneck, bi-color status indicator ring, includes surface mount preamp
5 inch (127 mm) Gooseneck, light ring, includes surface mount preamp
10 inch (254 mm) Gooseneck, bi-color status indicator ring, includes surface mount preamp
10 inch (254 mm) Gooseneck, no cartridge, light ring, includes surface mount preamp
5 inch (127 mm) Gooseneck, bi-color status indicator ring, less preamp
5 inch (127 mm) Gooseneck, no cartridge, light ring, less preamp
10 inch (254 mm) Gooseneck, cardioid, bi-color status indicator ring, less preamp
10 inch (254 mm) Gooseneck, no cartridge, light ring, less preamp
*for detailed dimensions please
reference MX405/410 user
guide
MX410 and MX405
Miniature Goosenecks
MX400SMP
Surface Mount Preamp
MX400DP
Wired Desktop Base (also available as MX890
Wireless Desktop Base)
