Maintenance
Description Fuse rating
25 SENSOR 1
26 SENSOR 2
27 IGN COIL
28 SPARE
29 SPARE
30 SPARE
31 SPARE
32 SPARE
7 54
G4KE - Stop Lamp Switch, Immobilizer Module, A/CON Relay, Fuel Pump Relay, Condenser Fan
Relay (Low/High), Crankshaft Position Sensor, Oil Control Valve #1/2, Camshaft Position Sensor
10A
#1/2, Oxygen Sensor (Up), Variable Intake Manifold Valve
G6DC - PCM, A/CON Relay, Fuel Pump Relay, Injector #1~#6, Immobilizer Module
G4KE - PCM, Oxygen Sensor (Down)
15A
G6DC - PCM, Oxygen Sensor #1~#4, Variable Charge Motion Actuator
G4KE - Condenser, Ignition Coil #1~#4
20A
G6DC - Condenser #1/2, Ignition Coil #1~#6
10A -
15A -
20A -
25A -
30A -
Protected component
