ASSEMBLY

Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking
belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to
the top of the walking belt or the shipping carton. This does not affect treadmill performance. If there is lubricant
on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires the included hex keys
mallet , adjustable wrench
For help identifying the assembly hardware, see the drawings below. The number in parentheses below each
drawing is the key number of the part, from the PART LIST on page 24. The number following the parentheses is
the quantity needed for assembly. Note: If a part is not in the parts bag, check to see if it has been preassem-
bled. To avoid damaging plastic parts, do not use power tools for assembly.
Bague
d'Espacement de
la Roue (94)–4
Écrou (12)–4
Boulon du Montant (4)–4
and your own Phillips screwdriver
, and wire cutters
Rondelle du
Montant (7)–2
Vis de 3/4" (3)–8
Boulon de la Roue(5)–2
6
1/2" Screw (119)–1
.
Rondelle Étoilée
de la Rampe
(11)–4
Vis de Mise à Terre
en Argent (10)–2
Boulon du Cadre(1)–2
, rubber
Rondelle Étoilée
du Montant (6)–4
Boulon de la
Rampe (9)–4
