Tripp Lite DWT2647XE Specifications

Model #: DWT2647XE
Tilt Wall Mount for 26" to 55" Flat-Screen Displays
Description
Tripp Lite's VESA-compliant DWT2647XE Tilt Flat-Screen Wall Mount's low-profile design features an open frame for easy wall access and optimal
display positioning flexibility. With tilt adjustment for improved viewing angles in applications where the audience is located below the display, it packs
a lot of functionality into an unobtrusive frame. It can also free up valuable space in your workstation by allowing you to effortlessly reposition your
display at any time, even after installation. Its durable, all-metal construction with scratch-resistant, powder-coat finish supports weights of up to 165
lbs. and fits most 26- to 55-inch flat-panel displays. It comes with all necessary mounting hardware and features horizontal adjustment to
compensate for off-center wall studs. A built-in bubble level enables accurate display leveling. For peace of mind, the DWT2647XE comes backed
by a 5-year warranty and green, RoHS-compliant design.
Package Includes
DWT2647XE Tilt Flat-Screen Wall Mount
Mounting Hardware
Owner's Manual
Specifications
OVERVIEW
Display Mount Type
Mounting Location
PHYSICAL
Unit weight (lbs)
Unit weight (kg)
Color
Display Size (in.)
Display Size (cm)
VESA Pattern (mm)
Motion
Highlights
Economy
Wall
6.16
2.79
Black
26 - 55
66.04 - 139.70
100x100, 200x100, 200x200, 400x200, 400x400
Tilt
Low-profile mounting keeps unit out of sight for sleek, professional appearance
Fits most flat-panel displays from 26" to 55"
Open frame for easy wall access
Tilt adjustment improves viewing angles in applications where the audience is
below the display
Horizontal adjustment compensates for off-center wall studs
Wide range of motion with -10° to 0° tilt capability
Equipped with a bubble level for accurate display leveling
Supports up to 165 lbs.
5-year warranty
