INSTALLATION INSTRUCTIONS
DishDrawer
dishwasher
TM
DD36SDFTX2
& DD36STI2
models
(Designer)
(Integrated)
US CA
590208C
08.12

Advertisement

Table of Contents
loading

Summary of Contents for Fisher & Paykel DD36SDFTX2

  • Page 1 INSTALLATION INSTRUCTIONS DishDrawer dishwasher DD36SDFTX2 & DD36STI2 models (Designer) (Integrated) US CA 590208C 08.12...
  • Page 2: Safety And Warnings

    SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! WARNING! Installation of this dishwasher requires basic mechanical and electrical skills. Electrical hazard Be sure to leave these Instructions with the Customer. Installation must comply with your local building, electricity, and plumbing regulations. Before installing the dishwasher, remove the house fuse or open the circuit breaker.
  • Page 3 PARTS SUPPLIED - ALL MODELS Side mounting Wire clip (1) Clamp (1) Rubber Drain hose Drain hose Phillips 1½ ” (38 mm) Moisture protection bracket kit washer for support (1) joiner (1) 5⁄8” (16 mm) bottom fixing tape (1) (for securing (for securing (A and B) (2) inlet hose (1)
  • Page 4: Product Dimensions

    PRODUCT DIMENSIONS Plan Side Product dimensions inches (mm) overall height of product 18 13⁄16”( 18 13⁄16”( (incl. front panel height) overall width of product 35 ¼ ”( min. 33 11⁄16”( overall depth of product 22 ½ ”( 22 ½ ”( (excl.
  • Page 5: Cabinetry Dimensions

    CABINETRY DIMENSIONS 11⁄16” (18 mm) 1⁄16” (2 mm) Plan Side 1⁄16” (2 mm) Important! Ensure correct chassis position. In order for product to function, cabinetry must not block the drawer front from closing hard against the chassis. Minimum clearances from adjacent cabinetry min.
  • Page 6 INTEGRATED MODELS ONLY - CUSTOM FRONT PANEL CALCULATIONS FRONT PANEL SPECIFICATIONS min. 1⁄16”(2mm) 5⁄8 - 13⁄16” (16-20 mm) panel thickness Maximum weight of panel: 20 lb (9 kg) Adequately sealed to withstand moisture (122 F/50 C @ 80% RH). Because of it being a hot and wet environment generally, the back and sides of the panel should be completely sealed with a waterproof vapor barrier (ie polyurethane) to prevent damage to the panel.
  • Page 7 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION REMOVE THE DRAWER REMOVE THE ACCESS COVER & POWER CORD Product may move. Mark chassis position on cavity To prevent kinked hoses, we recommend rotating the drawer counter-clockwise and resting it on its side after removal. WARNING! Electrical Shock Hazard Press the release...
  • Page 8: Cavity Preparation

    CAVITY PREPARATION 3⁄8” (10mm) Important! Moisture COUNTERTOP protection The power outlet must be tape must located in a cabinet adjacent be applied. to the dishwasher cavity. 1⁄16” (2mm) 110-120 VAC max. 15 A Water Connection These marks indicate formed bracket screw Recommended HOT locations, if securing (Maximum 140°F/60°C).
  • Page 9 INTEGRATED MODELS ONLY - PREPARATION FOR EXTERNAL VENTING THROUGH SAME CABINET Services can be located either side of dishwasher External Venting kit (1) Shelf cutouts max. 3⁄16” (5 mm) VENT HOSE ø max. 1½ ” (38 mm) ø 2 3⁄8” (60 mm) ø...
  • Page 10 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE Left hand side Right hand side Drain hose - 78 ½" (2000 mm) Drain hose - 59 1⁄16" (1500 mm) Inlet hose - 64 ¾" (1650 mm) Inlet hose - 37 3⁄8" (950 mm) Power cord - 29 ½"...
  • Page 12 NOW CHOOSE WHICH INSTALLATION METHOD (a) or (b) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (a) - SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) ATTACH SIDE MOUNTING BRACKETS INTEGRATED ONLY - ATTACH VENTING HOSE Clip all four side mounting brackets into their slots Check that the fitted elbow is rotated using a flat-bladed...
  • Page 13 PULL THROUGH HOSES & MOVE INTO THE CAVITY SECURE THE DRAWER Open the drawer halfway. Using a flat-bladed Vent Hose screwdriver, prise (Integrated the gray Replace the gray models only) rubber plug out rubber plug back into of the trim moulding. the trim moulding and ensure the trim seal is facing forward.
  • Page 14 ALTERNATIVE METHOD (b) - SECURE BY DRAWER REMOVAL INTEGRATED ONLY - ATTACH VENTING HOSE PULL THROUGH HOSES & MOVE INTO THE CAVITY Check that the fitted elbow is rotated left or right (depending on the direction of the routing), then ensure the venting hose is Vent Hose securely attached to it.
  • Page 15 REMOVE THE DRAWER SECURE THE DRAWER TO THE CABINETRY Product may The product has three pairs move. Mark of fixing points: chassis position on cavity (Refer to PARTS SUPPLIED for relevant parts) To prevent kinked hoses, we recommend rotating the drawer Ensure the sound insulation anti-clockwise and is repositioned correctly.
  • Page 16 INTEGRATED MODELS ONLY - INSTALLING THE FRONT PANEL ATTACH PANEL TO PANEL BRACKET REMOVE BRACKET FROM PRODUCT WARNING! Important! Electrical Shock Hazard Use all 14 screws provided as shown. Before continuing, ensure that the product is disconnected from the power supply. 5⁄8”...
  • Page 17 ADJUST PANEL HEIGHT TO ALIGN THE CABINETRY GAPS + or - 1⁄16” (2 mm) Insert an appropriately sized Philips screwdriver into the hole above the door pin and rotate the panel up or down to align the gaps in your cabinetry. Repeat on the other side if necessary.
  • Page 18 THERE ARE THREE DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. Dishwasher and Standpipe Ø 1½ ” (38 mm) Dishwasher using Air Break with Drain Hose Joiner Dishwasher using sink trap with drain hose joiner If space is limited for fixing, push hose through drain If space is limited...
  • Page 19 CONNECT INLET HOSE TO HOT WATER SWITCH PRODUCT ON Tighten coupling with wrench. Ensure the supplied rubber washer is No leaks! fitted inside the coupling. Important! Ensure that drain connection will comply with local plumbing regulations.
  • Page 20: Final Checklist

    FINAL CHECKLIST TROUBLESHOOTING Check all parts are installed. Excessive water remaining above the filter plate, after the rinse cycle Check for a kinked drain hose or blocked waste connection, highloop not Ensure product is level, securely fastened to the cabinetry and opens and properly installed or drain hose not routed correctly.
