24 DISPLAYING THE FIRMWARE
VERSIONS
Both the radio and DSP firmware versions are indi-
cated on the LCD after the radio switches ON for 2
seconds, unless a "Starting Message" has been pro-
grammed.
Figure 39 displays Radio and DSP Firmware versions.
<71BSV200A710>
<DSP V109>
Figure 39
Figure 40 shows the programmable starting message
"Your Message Here".
Your Message Here
Figure 40
25 DISPLAYING THE SERIAL NUM-
BER
Push and Hold [D], turn ON the radio, the serial num-
ber is indicated (Maximum 8 digits). When the [D] key
is released, the radio will reboot in the normal mode.
Figure 41 shows KY0000329 serial number.
Figure 41
DISPLAYING THE PROGRAM-
26
MING SOFTWARE VERSION
Push and Hold [A], and turn ON the radio, the program-
ming software version is indicated. When the [A] key is
released, the radio will reboot in the normal mode.
Figure 42 shows V-0.2.3195 version.
Set by p-kgprg 023195
Figure 42
9
Serial KY000329
27 DATA CHECK
The IC-FR9010/FR9020 has a self diagnostic function.
All data in the EEROM is checked every time the radio
is switched ON. If the data is not properly stored, the
radio automatically turns to programming mode.
Figure 43 shows ERROM Data error.
EEROM Data Error
Figure 43
28 ERROR MESSAGES
If there is a problem with the RX PLL, TX PLL or PA,
then the ALM LED flashes ON and indicates which
section has the issue. Figure 46 displays a RX PLL
error, note this may be displayed in REM mode if the
remote channel lines are open or a channel is selected
remotely that is not programmed. (EXXX will be dis-
played instead of CXXX, where XXX is the channel
number.)
Figure 44 displays a RX PLL error.
Figure 45 displays a TX PLL error.
Figure 46 displays a PA error.
RX
TX
C001
RX PLL Error
Figure 44
RX
TX
C001
TX PLL Error
Figure 45
RX
TX
C001
PA Error
Figure 46
29 FIRMWARE ERROR DETECTION
When the radio itself detects a malfunction, the main
CPU will restart automatically.
MD
N
MD
N
MD
N
