Copyright 1999 Carrier Corporation
Product
Data
38TSA (60 Hz)
Air Conditioner
®
with Puron
(R-410A)
Sizes 024 thru 042
Carrier's WeatherMaker 38TSA with
Puron® provides a completely unique
collection of features which cannot be
matched by any other family of
equipment. The 38TSA family has been
designed as the first air conditioning
system utilizing Carrier's unique Puron
refrigerant. The environmentally sound
refrigerant allows you to make a
responsible decision in the protection of
the earth's ozone layer. Carrier's
WeatherMaker systems with Puron meet
the Energy Star® guidelines for energy
efficiency.

AVAILABLE OPTIONS

Puron® Environmentally Sound
Refrigerant — Is Carrier's unique
refrigerant designed to help protect the
environment. Puron is an HFC refrigerant
that does not contain chlorine which is
damaging to the ozone layer. The most
important advantage of Puron refrigerant is
that it has not been banned in future air
conditioning systems as the traditional
refrigerant R-22 has been. Puron
refrigerant is in service in thousands of
systems providing highly reliable,
environmentally sound performance. For
specific R-22 phase out information see
your Carrier distributor.
WeatherArmor™ III System — The
casing steel is galvanized and coated with a
layer of zinc phosphate. A modified
polyester powder coating is then applied
and baked on, providing each unit with a
hard, smooth finish that will last for many
years.
All screws on the cabinet exterior are
SermaGuard™ coated for a long lasting,
rust-resistant, quality appearance.
The coil is protected by an enhanced
WeatherArmor™ heavy duty inlet grille.
Constructed of a coated 12 gage steel wire
grid and with spacing of 3/8 in., the guard
helps to protect the coil from inclement
weather, vandalism, and incidental
damage. It provides protection while not
restricting airflow and maintaining ease of
coil inspection and cleaning.
High Efficiency Performance — Is
delivered through a combination of
features including Carrier's Puron
refrigerant, scroll compressor, and
advanced heat transfer surfaces. Efficiency
ratings are 14 SEER (Seasonal Energy
Form 38TSA-3PD

Advertisement

Table of Contents
loading

Related Manuals for Carrier 38TSA

Summary of Contents for Carrier 38TSA

  • Page 1: Available Options

    Carrier’s WeatherMaker 38TSA with Puron® provides a completely unique collection of features which cannot be matched by any other family of equipment. The 38TSA family has been designed as the first air conditioning system utilizing Carrier’s unique Puron refrigerant. The environmentally sound...
  • Page 2 field installation. The installation of this away from the area. exclusive laminated plate beneath the TXV adds to the efficiency of the 38TSA’s. compressor to eliminate sound External Service Valves — Both service Assured Future Service — By utilizing transmission to the rest of the system.

  • Page 3: Model Number Nomenclature

    Model number nomenclature 38TSA Deluxe 14 SEER Split-System Air Conditioner Packaging Series Nominal Capacity 024 — 24,000 Btuh 036 — 36,000 Btuh Electrical 030 — 30,000 Btuh 042 — 42,000 Btuh 3 — 208/230-1 Physical data Unit Size-Series 024-30, 32...
  • Page 4 Accessories ORDERING NO. DESCRIPTION KAATD0101TDR Time-Delay Relay — All Sizes KSALA0301410 Low-Ambient Pressure Switch — All Sizes P251-0083 (RCD) Low-Ambient Controller — All Sizes 32LT660004* (RCD) MotorMaster® Control — All Sizes KAAFT0101AAA† Evaporator Freeze Thermostat — All Sizes KAAWS0101AAA† Winter Start Control — All Sizes KSACY0101AAA Cycle Protector —...
  • Page 5 Accessory description and usage (Listed alphabetically) 1. Ball Bearing Fan Motor A fan motor with ball bearings which permits speed reduction while maintaining bearing lubrication. SUGGESTED USE: Required on all units where Low-Ambient Controller (full modulation feature) or MotorMaster® Control has been added. 2.

  • Page 6: Electrical Data

    Electrical data 60°C 75°C 60°C 75°C FUSE** OPER VOLTS* COMPR UNIT SIZE- WIRE WIRE LENGTH LENGTH CKT BKR SERIES V/PH SIZE† SIZE† (Ft)‡ (Ft)‡ AMPS 024-30, 32 61.0 13.5 17.4 030-30, 32 72.5 14.7 19.2 208/230/1 036-30, 32 83.0 15.4 20.1 042-30, 32 105.0...
  • Page 7 Dimensions...

  • Page 8: Combination Ratings

    Combination ratings SEER FACTORY- SUPPLIED Carrier Gas Furnace or UNIT INDOOR TOT. CAP. ENHANCE- Standard Accessory SIZE-SERIES UNIT BTUH MENT Rating TDR† CK5A/CK5BA036* 25,000 14.00 14.00 12.10 CC5AA024 24,000 13.30 13.30 11.55 CC5AA030 24,600 13.50 13.50 11.65 CC5A/CD5AA036 25,000 14.00 14.00...

  • Page 9: Combination Ratings Continued

    Combination ratings continued SEER FACTORY- SUPPLIED Carrier Gas Furnace or UNIT INDOOR TOT. CAP. ENHANCE- Standard Accessory SIZE-SERIES UNIT BTUH MENT Rating TDR† CC5A/CD5AW030 29,000 13.50 13.50 11.70 CC5A/CD5AW042 30,000 13.70 13.70 12.00 CD5A/CD5AW036 29,600 13.80 13.80 12.05 CE3AA030 29,000 13.50...
  • Page 10 Combination ratings continued SEER FACTORY- SUPPLIED Carrier Gas Furnace or UNIT INDOOR TOT. CAP. ENHANCE- Standard Accessory SIZE-SERIES UNIT BTUH MENT Rating TDR† COILS + 58MVP120-20 VARIABLE SPEED FURNACE CC5A/CD5AA042 30,000 TDR&TXV 15.00 15.00 13.30 CD5AW036 29,600 TDR&TXV 15.00 15.00 13.20...
  • Page 11 Combination ratings continued SEER FACTORY- SUPPLIED Carrier Gas Furnace or UNIT INDOOR TOT. CAP. ENHANCE- Standard Accessory SIZE-SERIES UNIT BTUH MENT Rating TDR† COILS + 58MVP060-14 VARIABLE SPEED FURNACE CC5A/CD5AA036 35,000 TDR&TXV 14.50 14.50 12.60 CK3BA036 35,000 TDR&TXV 14.50 14.50 12.65...
  • Page 12 Combination ratings continued SEER FACTORY- SUPPLIED Carrier Gas Furnace or UNIT INDOOR TOT. CAP. ENHANCE- Standard Accessory SIZE-SERIES UNIT BTUH MENT Rating TDR† CC5A/CD5AW042 40,000 13.30 13.30 11.60 CC5A/CD5AW048 41,000 13.50 13.50 11.70 CC5A/CD5AW060 42,000 13.50 13.50 11.95 CD5AA048 41,000 13.40...
  • Page 13 † In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in perfor- mance. Use either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Carrier furnaces are equipped with TDR.

  • Page 14: Detailed Cooling Capacities

    Detailed cooling capacities* CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 15 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 16 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 17 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 18 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 19 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 20 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...

  • Page 21: Condenser Only Ratings

    Condenser only ratings* CONDENSER ENTERING AIR TEMPERATURES °F °F 38TSA024-30, 32 22.7 21.5 20.3 19.1 17.9 16.7 15.4 14.1 66.8 76.5 86.3 96.0 106.0 115.0 125.0 135.0 1.07 1.22 1.38 1.56 1.75 1.97 2.19 2.44 25.0 23.6 22.3 21.0 19.7 18.4 17.0 15.6...
  • Page 22 Condenser only ratings* continued CONDENSER ENTERING AIR TEMPERATURES °F °F 38TSA042-30, 32 38.6 36.5 34.5 32.4 30.4 28.3 26.2 23.9 70.3 80.0 89.6 99.2 109.0 118.0 128.0 137.0 1.72 1.96 2.22 2.53 2.86 3.24 3.66 4.11 42.3 40.0 37.8 35.6 33.4 31.1 28.8...

  • Page 23: Typical Installation

    Typical installation AIR CONDITIONER COMFORT VENTILATOR COMFORT ZONE II CONTROL CENTER HUMIDIFIER FURNACE COIL FURNACE AIR CLEANER A98600...

  • Page 24: Guide Specifications

    Indianapolis, IN 46231 11-99 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book Page 24 Catalog No. 523-788 Printed in U.S.A. PC 101 Form 38TS -3PD Replaces 38TSA-2PD 3a 2a...
