Carrier Performance 38TSA Product Data
  1. Manuals
  2. Brands
  3. Carrier Manuals
  4. Air Conditioner
  5. Puron 38TSA
  6. Product data
Carrier Performance 38TSA Product Data

Carrier Performance 38TSA Product Data

Performance series 14 seer 60 hz with puron refrigerant sizes 024 thru 060
Hide thumbs Also See for Performance 38TSA:

Advertisement

Quick Links

Download this manual
Copyright 2004 Carrier Corporation
Product
Data
Performance™ 14
38TSA (60 Hz)
Air Conditioner
®
with Puron
Refrigerant
Sizes 024 thru 060
Carrier's Performance™ 14 Air
Conditioners with Puron® refrigerant
provide a collection of features unmatched
by any other family of equipment. The
38TSA family has been designed utilizing
Carrier's Puron refrigerant. The
environmentally sound refrigerant allows
you to make a responsible decision in the
protection of the earth's ozone layer.
Carrier's Performance 14 systems with
Puron refrigerant meet the Energy Star®
guidelines for energy efficiency.
FEATURES
Puron® Environmentally Sound
Refrigerant — Is Carrier's unique
refrigerant designed to help protect the
environment. Puron is an HFC refrigerant
that does not contain chlorine which is
damaging to the ozone layer. The most
important advantage of Puron refrigerant is
that it has not been banned in future air
conditioning systems as the traditional
refrigerant R-22 has been. Puron
refrigerant is in service in thousands of
systems providing highly reliable,
environmentally sound performance. For
specific R-22 phase out information see
your Carrier distributor.
Carrier's Infinity® Controls — These
industry-leading controls, when installed
with Carrier's Ideal Humidity™ variable-
speed furnaces or fan coils, provide the
homeowner with:
–unparalleled control of temperature,
humidity, indoor air quality, and zoning
–unprecedented ease of use
–simple operation through on-screen, text-
based service reminders
Optional remote access through telephone
or Internet is also available when combined
with a remote connectivity kit.
WeatherArmor™ III Protection
Package — This three-part protection
system begins with the galvanized steel
cabinet. Once coated with a layer of zinc
phosphate, a modified polyester powder
coating is then applied and baked on,
providing each unit with a hard, smooth
finish that will last for many years.
Additionally, the coil protector, made of a
coated steel wire grid with vertical 3/8 in.
spacing, is designed to help protect the coil
from inclement weather, vandalism and
incidental damage. It provides protection
Form 38TSA-8PD

Advertisement

loading

Related Manuals for Carrier Performance 38TSA

Summary of Contents for Carrier Performance 38TSA

  • Page 1 Carrier’s Puron refrigerant. The environmentally sound refrigerant allows you to make a responsible decision in the protection of the earth’s ozone layer. Carrier’s Performance 14 systems with Puron refrigerant meet the Energy Star® guidelines for energy efficiency. FEATURES Puron® Environmentally Sound Refrigerant —...
  • Page 2 A special liquid all screws on cabinet exterior are ceramic any product in the Carrier family. Long line filter drier designed to trap nearly 4 coated for a long-lasting, rust-resistant, term reliability is assured through the use times the volume of contaminants of quality appearance..

  • Page 3: Model Number Nomenclature

    Model number nomenclature 38TSA 14 SEER Split-System Air Conditioner Packaging Series Nominal Capacity 024 — 24,000 Btuh 042 — 42,000 Btuh 030 — 30,000 Btuh 048 — 48,000 Btuh Electrical 036 — 36,000 Btuh 060 — 60,000 Btuh 3 — 208/230-1 Physical data Unit Size-Series 024-34...
  • Page 4 Infinity Network Interface Module (Connects Heat Recovery and Energy Recovery Ventilators or older two- SYSTXCCNIM01** speed outdoor models to system.) SYSTXXXBPU01 Decorative Back Plate for Infinity Control (Decorative wall plate.) * When applied with Carrier’s IdealHumidity™ series 58MVP, 58CVA (X), and FE Indoor Models. ** Must be installed in Dual-Fuel Infinity system applications.
  • Page 5 Accessory usage guideline REQUIRED FOR REQUIRED FOR REQUIRED FOR LOW-AMBIENT LONG-LINE SEA COAST ACCESSORY APPLICATIONS (Below 55°F) APPLICATIONS* (Over 50 Ft) APPLICATIONS (Within 2 Miles) Crankcase Heater Evaporator Freeze Thermostat Winter Start Control † Accumulator Compressor Start Assist — Capacitor and Relay Low-Ambient Controller or Low-Ambient Pressure Switch Wind Baffle...
  • Page 6 9. Outdoor Air Temperature Sensor Designed for use with Carrier Thermostats listed in this publication. This device enables the thermostat to display the outdoor temperature. This device also is required to enable special thermostat features such as auxiliary heat lock out.

  • Page 7: Electrical Data

    Electrical data 60°C 75°C 60°C 75°C FUSE** OPER VOLTS* COMPR UNIT SIZE- WIRE WIRE LENGTH LENGTH CKT BKR SERIES V/PH SIZE† SIZE† (Ft)‡ (Ft)‡ AMPS 024-34 60.0 12.8 16.8 030-33 72.5 14.7 19.2 036-33 83.0 15.4 20.4 208/230/1 042-33 105.0 18.6 24.4 048-31...
  • Page 8 Dimensions...

  • Page 9: Combination Ratings

    Combination ratings SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ *CK5PA036 23,600 — 14.00 — — 12.15 CC5A/CD5AA024 22,800 NONE —...

  • Page 10: Combination Ratings Continued

    Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CK3BA024 22,800 — — — 14.50 13.20 CK3BA030 23,000 —...
  • Page 11 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CK5PA030 23,000 TDR&TXV 14.50 — — — 13.05...
  • Page 12 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CC5A/CD5AW042 30,000 NONE — — 13.70 — 12.00...
  • Page 13 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CE3AA042 30,000 — — — 15.00 13.30 CK3BA030 29,000 —...
  • Page 14 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CC5A/CD5AW036 29,600 — — — 15.00 13.00 CK5A/CK5BA042 30,000 —...
  • Page 15 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ FK4(C,D)NF001 35,000 TDR&TXV 14.50 — — — 12.50...
  • Page 16 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CC5A/CD5AC048 36,000 — — — 15.00 13.05 CC5A/CD5AW036 35,000 —...
  • Page 17 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CC5A/CD5AW036 35,000 — — — 14.50 12.60 CD5AA048 36,000 —...
  • Page 18 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ FV4(A,B)NF005 41,500 TDR&TXV 15.00 — — — 13.20...
  • Page 19 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CK5PT060 41,500 TDR&TXV 14.50 — — — 13.15...
  • Page 20 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CK3BA048 41,000 — — — 14.50 12.70 CK3BA060 41,500 —...
  • Page 21 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory SIZE-SERIES MODEL Capacity Enhance Rating TDR† Puron TXV‡ Puron TXV‡ CK3BA048 46,500 — — — 14.00 12.00 CK3BA060 47,000 —...
  • Page 22 Combination ratings continued SEER Carrier Gas Carrier Furnace or Gas Furnace or Accessory UNIT INDOOR Cooling Factory Standard Accessory TDR† and Accessory TDR† SIZE-SERIES MODEL Capacity Enhance Rating Puron TXV‡ Puron TXV‡ CC5A/CD5AC048 45,500 — — — 13.50 11.80 CC5A/CD5AW048 46,000 —...
  • Page 23 † In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in perfor- mance. Use either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Carrier furnaces are equipped with TDR.‡...

  • Page 24: Detailed Cooling Capacities

    Detailed cooling capacities* CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 25 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 26 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 27 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 28 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 29 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 30 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 31 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 32 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 33 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 34 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 35 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 36 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 37 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...
  • Page 38 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡ kW** Total Sens‡...

  • Page 39: Condenser Only Ratings

    Condenser only ratings* CONDENSER ENTERING AIR TEMPERATURES °F °F 38TSA024-34 22.5 21.2 19.8 18.5 17.1 15.7 14.2 12.7 67.2 76.7 86.2 95.7 105.2 114.6 123.9 133.3 0.89 1.05 1.23 1.43 1.65 1.88 2.12 2.38 24.8 23.4 22.0 20.5 19.0 17.5 15.9 14.2 68.4...
  • Page 40 Condenser only ratings* continued CONDENSER ENTERING AIR TEMPERATURES °F °F 38TSA042-33 38.6 36.5 34.5 32.4 30.4 28.3 26.2 23.9 70.3 80.0 89.6 99.2 109.0 118.0 128.0 137.0 1.72 1.96 2.22 2.53 2.86 3.24 3.66 4.11 42.3 40.0 37.8 35.6 33.4 31.1 28.8 26.3...
  • Page 41 System design summary 1. Intended for outdoor installation with free air inlet and outlet. Outdoor fan external static pressure available is less than 0.01-in. wc. 2. Minimum outdoor operating air temperature without low-ambient operation accessories is 55°F (12.8°C). For Low Ambient applications see the Accessory Usage Guideline in this literature for accessory requirements.

  • Page 44: Guide Specifications

    Fans enhancements. Condenser fan will be direct-drive propeller type, discharging air upward. • Carrier Corporation Indianapolis, IN 46231 7-04 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book Page 44 Catalog No.
