OPERATION MANUAL
FA71FVEK
FA100FVEK
Air Conditioner
English
Español
Advertisement
Table of Contents
Related Manuals for Daikin FAY71FVE
Summary of Contents for Daikin FAY71FVE
-
Page 1: Operation Manual
OPERATION MANUAL English SPLIT SYSTEM Air Conditioner Español MODELS (Wall mounted type) FAY71FVE FA71FVEK FAY100FVE FA100FVEK FAY71FAVE FAY100FAVE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE. LEA CUIDADOSAMENTE ESTAS INSTRUCCIONES ANTES DE INSTALAR. - Page 2 Thank you for purchasing this Daikin air condi- tioner. Carefully read this operation manual before using the air conditioner. It will tell you how to use the unit properly and help you if any trouble occurs. After reading the manual, file it away for future reference.
- Page 3 TEST AVAILABLE TEST R(Y)100 R(Y)71...
-
Page 4: Table Of Contents
10. TROUBLE SHOOTING ........ 10 The unit is individually operated. 11. SPECIFICATIONS ........11 NOTE • Contact your Daikin dealer in case of changing the combination or setting of group control and 1. WHAT TO DO BEFORE OPERA- two remote controller control systems. - Page 5 • The precautions described below are WARN- For refrigerant leakage, consult your dealer. When the air conditioner is to be installed in a ING and CAUTION. These are very important small room, it is necessary to take proper mea- precautions concerning safety. Be sure to sures so that the amount of any leaked refriger- observe all of them without fail.
-
Page 6: Operation Range
Do not operate the air conditioner with a wet hand. COOLING An electric shock may result. INDOOR OUT- OUTDOOR Do not place items which might be damaged DOOR TEMPERA- by moisture under the indoor unit which may TEMPERA- HUMIDITY UNIT TURE (°C) be damaged by water. -
Page 7: Name And Function Of Each Switch And Display On The Remote Controller
d. Where there are considerable voltage fluctua- 5. NAME AND FUNCTION OF EACH tions such as a factory or plant SWITCH AND DISPLAY ON THE e. Vehicles and vessels f . Where there is much spray of oil and vapor REMOTE CONTROLLER such as a cookery, etc. -
Page 8: Operation Procedure
• After 6 to 8 minutes (maximum 10 minutes) of • Operating procedure varies with heat pump type DEFROST OPERATION, the system returns to and cooling only type. Contact your Daikin dealer HEATING OPERATION. to confirm your system type. • To protect the unit, turn on the main power switch Regarding outside air temperature and heat- 6 hours before operation. - Page 9 A. UP AND DOWN DIRECTION • An indoor fan runs to discharge a gentle wind automatically until the temperature inside the air conditioner reaches a certain level. At this time, Press the AIR FLOW DIRECTION ADJUST but- ton to select the air direction as shown below. the remote controller displays “...
-
Page 10: Optimum Operation
B. LEFT AND RIGHT DIRECTION TIMER ON/OFF Grasp the air flow blades at the tip and move the blades to the left and right. Press the TIMER ON/OFF button. The timer setting procedure ends. The display “ ” changes from flash- ing light to a constant light. -
Page 11: Maintenance (For Service Personnel)
B)Washing with water • When the display shows “ ” (TIME TO CLEAN When the air filter is very AIR FILTER), ask a qualified service person to dirty, use soft brush and clean the filters (Referó to MAINTENANCE). neutral detergent. Remove water and dry in the shade. -
Page 12: Not Malfunction Of The Air Conditioner
• Refer to “FAN OPERATION”. becomes uneven. It is necessary to clean the inside of the indoor unit. Ask your Daikin dealer Cut off the power supply. for details on cleaning the unit. This operation •... -
Page 13: Trouble Shooting
MALFUNCTION Use curtains or blinds. CODE • When there are too many inhabitants in the Measure: Notify your Daikin dealer and inform room (when cooling). him/her of the display. Cooling effect decreases if heat gain of the room is too large. -
Page 14: Specifications
11. SPECIFICATIONS (These specifications are in compliance with SASO386.) INDOOR UNIT FA71FVEK FA100FVEK FAY71FVE FAY100FVE OUTDOOR UNIT R71FUVAL R100FUVAL RY71FUVAL RY100FUVAL RATED VOLTAGE RATED FREQUENCY COOLING POWER INPUT RATING CURRENT INPUT RAT- 19.3 26.6 19.7 26.7 CAPACITY kcal/h 5800 8200... - Page 15 3P170549-3 EM95A057F (0602) HT...
