ZonePro
Digital Zone Processor
The ZonePro
Background Music (BGM) applications, while maintaining a simple, secure and intuitive
interface. From the powerful DSP modules to the multiple control interfaces, the ZonePro
products provide all the processing and control necessary for BGM installations.
Additionally, the GUI interface and Wizard function allows any contractor to quickly set up
and optimize the unit to its full potential by streamlining the setup process and providing a
menu based setup procedure that includes system setup and configuration.
The ZonePro products are based on the same unparalleled design philosophy that made the
DriveRack family famous. This philosophy, "To provide everything you need between the
sources and the amplifiers," creates a full featured processor capable of almost any BGM
application. The ZonePro products offer two mic/line inputs on Euroblock connectors, and
four line inputs on mono-summing dual RCA jacks. Outputs are also on Euroblock con-
nectors. Each input channel provides EQ, while the mic/line inputs also offer two DSP insert
blocks with a selection of Compression, Notch Filtering, Auto Gain Control, Advanced
Feedback Suppression (AFS
matrix where each of the inputs can be selected as the main source or priority source. Paging
can be done from the Mic/line inputs; both paging and priority override offer full Ducking
capability. Each output also provides Autowarmth
Parametric EQ, a selectable Dynamics module and output Delay. For more information
please visit www.dbxpro.com.
• Advanced Feedback
• Autowarmth
• Auto Gain Control
• Compression
• Limiting
• Noise Gating
• Notch Filtering
• Bandpass and Crossover
640/641
™
TM products have been created to provide state-of-the-art signal processing for
™
Suppression (AFS
™
®
Filters
), Gating, and De-Essing. Each output zone provides a routing
, full Bandpass and Crossover filtering,
®
• Parametric EQ
) • Security Lockout
• Wall Panel Control
• RS-232 and Ethernet Control
• IEC, UL, and CSA Certified
®
8760 S. Sandy Pkwy.
Sandy, Utah 84070
Phone (801) 568-7660
Fax (801) 568-7662
Int'l Fax (801) 568-7583
customer@dbxpro.com
http://www.dbxpro.com
A Harman International Company
18-0284 -A 01/04
