  • Page 1 ® QUANTUM DIGITAL MASTERING PROCESSOR User Manual...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS C A U T I O N R I S K O F E L E C T R I C S H O C K D O N O T O P E N A T T E N T I O N : R I S Q U E D E C H O C E L E C T R I Q U E - N E P A S O U V R I R W A R N I N G : T O R E D U C E T H E R I S K O F F I R E O R E L E C T R I C...

  • Page 3: Lithium Battery

    Professional Products Manufacturer’s Address: 8760 S. Sandy Parkway Sandy, Utah 84070, USA declares that the product: Product name: dbx Quantum Product option: N/A conforms to the following Product Specifications: Safety: EN 60065 (1993) IEC65 (1985) with Amendments 1,2, 3 EMC:...

  • Page 4: Table Of Contents

    Section 1 - Getting Started 1.1 Rear Panel Connections ...2 1.2 Front Panel ...2 1.3 Quantum Wizard ...4 1.4 Signal Path ...4 1.5 Mastering and the Quantum...5 Section 2 - Navigation 2.1 Multiband Compressor...8 2.2 Broadband Compressor ...9 2.3 Multiband Gate ...10 2.4 Broadband Gate ...11...
  • Page 5 Fig 4.2 Parametric EQ Types ...37 Fig. 4.3 Sidechain Signal Flow...39 Fig C.1 Sync Termination Jumper ...69 Fig. C.2 Studio Sync Connections...70 Fig H.1 TPDF Dither ...81 Fig H.2 Noise Shaping ...82 Fig H.3 Truncation...83 ® QUANTUM User Manual Table of Contents...
  • Page 7 QUANTUM INTRODUCTION INTRO CUSTOMER SERVICE INFO What is QUANTUM? WARRANTY INFO ®...

  • Page 8: What Is Quantum

    1.1 What is QUANTUM? The dbx QUANTUM is the first mastering processor that offers a sampling rate of up to 96kHz, a true 48-bit digital signal path with up to 24-bit digital output. Below are some of QUANTUM’s features: •...

  • Page 9: Service Contact Info

    Application Guide in section 5. Whether you are going from the workstation to a DAW, DAT, or a stand-alone CD-R, the QUANTUM covers all the digital sample rates 96, 88.2, 48, or 44.1kHz. The QUANTUM will dither down to 24, 20, 16, or 8 bits. See the Appendix for all the possible conversions.
  • Page 10 In no event shall dbx or its dealers be liable for special or consequential damages or from any delay in the performance of this warranty due to caus- es beyond their control. ® QUANTUM User Manual...
  • Page 11 Section 1 QUANTUM Getting Started ®...

  • Page 12: Section 1 - Getting Started

    These connectors provide full MIDI functionality to the QUANTUM. The Out/Thru jack allows you to use the QUANTUM at any point in the MIDI chain. For a complete guide to all the MIDI and SYSEX functionality of the QUANTUM, see Section 3: Software Operations.

  • Page 13: Getting Started

    After you have chosen a program, you may want to change some of the parameters to meet your specific needs. One of the most useful tools available on the QUANTUM for setting up a proper compression curve is the curve window. In the curve window you can see the com- bined effects of dynamics-related parameters expressed in a graphical format.

  • Page 14: Quantum Wizard

    1.3 QUANTUM Wizard The easiest way to program the QUANTUM is using the Wizard. To access the Wizard, press and hold the PROGRAM button. Once in the Wizard mode, you will select the task that you are performing. The QUANTUM will automatically choose the correct chain type for your task.

  • Page 15: Mastering And The Quantum

    "hotter" mix. The easiest way of setting up the multiband compressor in QUANTUM, is to use the monitor in conjunction with the crossover and the compressor.
  • Page 16 As you have seen, setting up the multiband compressor is an iterative process that takes time to perfect. By using the multiband compressor along with the other tools available in QUANTUM you will be able to create much larger sounding mixes and masters. QUANTUM User Manual QUANTUM ®...
  • Page 17 Section 2 QUANTUM NAVIGATION ®...

  • Page 18: Section 2 - Navigation

    Navigation NAVIGATION Control of each of the bands within the QUANTUM’s multiband dynamic modules is made possible in two different ways. You may either use the “All page” or individual band adjust- ments. The “All page” is signified by a large “All” seen where the program number would nor- mally be.

  • Page 19: Broadband Compressor

    Navigate through the Pages by depressing "Next Page" or "Prev Page" ® Navigation 2.2 Broadband Compressor successively until arriving at the desired Page Page 1 Page 2 Compr Threshold On/Loc/Off OverEasy® Ratio Auto Gain Loc/On/Off Section 2 Page 3 Attack Hold Release QUANTUM User Manual...

  • Page 20: Multiband Gate

    "Gate" button successively until arriving at the desired band QUANTUM User Manual Navigate through the Pages by depressing "Next Page" or "Prev Page" successively until arriving at the desired Page Page 1 Gate On/Loc/Off Bands...

  • Page 21: Broadband Gate

    Navigate through the Pages by depressing "Next Page" or "Prev Page" ® 2.4 Broadband Gate successively until arriving at the desired Page Page 1 Page 2 Gate On/Loc/Off Attack Bands Threshold Hold Ratio Release Section 2 Navigation Page 3 Max Att QUANTUM User Manual...

  • Page 22: Multiband Limiter

    Navigate through the bands by depressing the "Limiter" button successively until arriving at the desired band QUANTUM User Manual Navigate through the Pages by depressing "Next Page" or "Prev Page" successively until arriving at the desired Page Limiter Attack On/Loc/Off Threshold...

  • Page 23: Broadband Limiter

    Navigating the"Broadband Limiter" Navigate through the Pages by depressing "Next Page" or "Prev Page" ® Navigation 2.6 Broadband Limiter successively until arriving at the desired Page Limiter Attack On/Loc/Off Threshold Hold Type Release Section 2 OverEasy® Auto On/Off QUANTUM User Manual...

  • Page 24: Eq/Xover

    The "EQ/XOver" button toggles between EQ and XOver. Depress once to access EQ and a second time for XOver QUANTUM User Manual successively until arriving at the desired Page Page 1 Page 2 EQ On/Off Band 1 FC Pos Pre/Post Slope...

  • Page 25: Eq/Seq

    Section 2 Navigation Page 3 Page 4 Page 5 Band 3 FC Band 4 FC Level Level Band 3 FC Band 4 FC Level Level QUANTUM User Manual Page 6 Band 5 FC Slope Level Band 5 FC Slope Level...

  • Page 26: Norm/Output

    "Norm/Output" button successively until arriving at the desired band QUANTUM User Manual Navigate through the Pages by depressing "Next Page" or "Prev Page" successively until arriving at the desired Page Page 1 Normalize On/Off Normalize Level...

  • Page 27: Other

    ® Navigation 2.10 Other Type IV On/Off Color Level Stereo Adj On/Off Balance De-Esser On/Off Type Freq Width Amount TCM On/Off TCM Time Ambience On/Off Thresh1 Amount Width QUANTUM User Manual Section 2...

  • Page 28: Utility

    Navigate through the Pages by depressing "Next Page" or "Prev Page" Page 1 Page 2 Limiter Limiter Input Output Clock BNC Freq QUANTUM User Manual successively until arriving at the desired Page Page 3 Page 4 Page 5 Page 6 Limiter Limiter Limiter...

  • Page 29: Section 3 - Software Operations

    Section 3 QUANTUM SOFTWARE SOFTWARE OPERATIONS ®...

  • Page 30: Fx Chains

    QUANTUM’s storage system. 3.1 FX Chains The following charts show the signal flow through the QUANTUM’s FX chains. Note that the location of the parametric EQ (PEQ) changes according to Pre/Post settings.
  • Page 31 QUANTUM Chain Type: Stereo Broadband PEQ may be Pre or Post Dynamics What the QUANTUM screen shows for Pre: Stereo Adjust What the QUANTUM screen shows for Post: Stereo Input Stereo Ambience Adjust Fig 3.2 ® Software Operations 3.1 FX Chains (cont.)
  • Page 32 Section 3 Software Operations 3.1 FX Chains (cont.) Chain Type: Mono PEQ may be Pre or Post Dynamics What the QUANTUM screen shows for Pre: Mono Input CH1 or CH2 What the QUANTUM screen shows for Post: Mono Input CH1 or CH2 De-Esser Fig.

  • Page 33: Programs/Setups

    QUANTUM The QUANTUM has a unique method of storing your settings. It stores your changes to para- meters as setups. These setups are an immediately accessible library of your changes. No mat- ter what program you are currently working with, you can call up any setup that uses that same configuration: stereo-linked or dual mono.

  • Page 34: Saving A Setup

    “Link Setup”. Make your selection by pressing the STORE button again. Remember that there is room in the QUANTUM to store 50 linked setups and 50 mono setups, in addition to the fac- tory setups.

  • Page 35: Saving A Program

    (the “Parameter 2” line). 2. Use the DATA WHEEL to scroll to the place where you want to add the new setup. The QUANTUM “makes room” for your setup, no matter where you want to place it. Saving a program Saving a program is done by following these steps: 1.

  • Page 36: The Bypass Function

    Software Operations 3.5 The Bypass Function BYPASS To bypass the QUANTUM press the BYPASS button once. All digital dynamic modules are ren- dered inactive. The QUANTUM also has a CLONE BYPASS mode, passes the digital audio through the QUAN- TUM to the digital output directly as it came in—a digital clone. To use the CLONE BYPASS mode, simply press and hold the BYPASS button for 2 seconds.
  • Page 37 Section 4.) The third segment of the compressor meter is the plus (+) sign. It is blackened when the signal is being fully compressed at the ratio set by the Ratio Parameter. ® Software Operations 3.6 Meters (cont.) Peak Shoulder Gain Reduction Meter Input/Output Curve Section 3 QUANTUM User Manual...

  • Page 38: Monitor Outputs

    De-Essing is being applied to the signal. 3.7 Monitor Outputs Monitoring separate bands is a useful and easily accomplished function in the QUANTUM. By pressing the METER/MONITOR button twice you are able to access the monitor selection page.

  • Page 39: Section 4 - Detailed Parameters

    Section 4 QUANTUM PARAMETERS DETAILED PARAMETERS ®...

  • Page 40: Multiband Compression

    The point when the QUANTUM (or any compressor) starts to compress is the "knee." When the QUANTUM starts to reduce the level of a signal abruptly right as it passes over the threshold this is called "hard knee" compression. OverEasy® (soft knee as it is sometimes called) is when the level of the signal is compressed gradually.
  • Page 41 Threshold -60 to 0 dB (per band or global) Threshold is the signal level at which the QUANTUM starts to compress. If the threshold is set to -10 dBFS, then any signal larger than -10 dBFS is compressed, while any signal that has a level lower than -10dBFS is left at the same level.

  • Page 42: Broadband Compression

    The point when the QUANTUM (or any compressor) starts to compress is the "knee." When the QUANTUM starts to reduce the level of a signal abruptly right as it passes over the threshold this is called "hard knee" compression. OverEasy® (soft knee as it is sometimes called) is when the volume of the sound is compressed gradually.

  • Page 43: Multiband Gate

    Release 360 dB / Sec to 5 dB / Sec Release is how fast the QUANTUM comes out of compression. The release is in dB per second. For example, if release is set to 5 dB /sec, signal at 10dB of gain reduction, release time is 2 seconds.

  • Page 44: Broadband Gate

    This sets the maximum amount of attenuation for the gate. 4.4 Broadband Gate The QUANTUM's broadband gate is available in the non-multiband chain types. It works just like the multiband gate with the exception of the fact that it functions on the entire signal band.

  • Page 45: Multiband Limiting

    There are ten levels of OverEasy® that can be used on the QUANTUM's limiters Auto On/Off/LOC and On/Off When auto is turned on the QUANTUM will continuously set the attack / hold / release con- trols itself. It can be set globally or locally per band.

  • Page 46: Broadband Limiting

    Attack .01 to 200 m Sec (per band or global) This is the speed at which the QUANTUM limiter starts to compress the signal once it has crossed the threshold. Set the attack time longer for lower frequency bands, and shorter for higher frequency bands.
  • Page 47 There are 5 bands of EQ on the QUANTUM that can be used for something as subtle as sweet- ening a mix to drastic changes. Bands 1 and 5 are shelves while 2 through 4 are fully para- metric.

  • Page 48: Xover

    Amount of boost or cut. Adjustable in 1/2 dB steps. 4.8 XOver There are three crossover points on the QUANTUM, creating 4 bands. Tuning them allows you to select which frequencies to process with which of the multiband dynamics processors. The QUANTUM uses phase compensated, Butterworth 1st and 3rd order filters.

  • Page 49: Seq

    Output Processing Fig. 4.3 Within the SEQ menu on the QUANTUM the following parameters are user adjustable: Press the EQ/XOVER button twice when in non-multiband mode to access the SEQ. Schain EQ On/Off This control turns all 5 bands on/off.

  • Page 50: Type Iv

    Amount of boost or cut. Adjustable in 1/2 dB steps. 4.10 Type IV™ The QUANTUM uses dbx Type IV™ 96 kHz converters. Type IV™ gives you more A to D head- room and the ability to add Tape Saturation Emulation. (For more information on Type IV™...

  • Page 51: Ambience

    Freq. 800 Hz to 8.00 kHz This is the center frequency the De-Esser uses when in Band Pass mode or the corner frequency used when in High Pass mode. ® Detailed Parameters 4.12 Ambience 4.13 TCM™ 4.14 De-Esser QUANTUM User Manual Section 4...

  • Page 52: Normalization

    Normalize On/Off Turns the Normalizer on or off. Level –12 dB to +12 dB The final output stage of the QUANTUM. This lets you adjust the final volume you send out of the unit. Ceiling -3.0 to 0.0 dBFS This parameter allows you set the overall output ceiling level of normalization.
  • Page 53 Sets the routing of the Dither output. When All is selected, the Dither is routed to the digital outputs and the D/A. When the Dither Out is set to Digital, the dithered signal is sent to the digital outputs and the full 24-bit output is sent to the D/A. ® QUANTUM User Manual...

  • Page 55: Section 5 - Utilities

    Section 5 QUANTUM UTILITIES UTILITIES ®...

  • Page 56: Input

    Set this to match the frequency that you would like the QUANTUM to operate it’s internal clock at. If the QUANTUM is slaved to a jittery master clock, the QUANTUM will clean up the jitter and output only clean and steady clock frequencies. If you are unsure of your master clock device, we recommend you use the QUANTUM as the master.

  • Page 57: Digital Input Controls

    This turns the high pass filter (HPF) On/Off. The high pass filter affects only the digital inputs. Use The HPF to remove any DC offset in the input signal. The QUANTUM’s HPF is set at 1.75 Both input levels and the high pass filter are defeated when the clone bypass is activated.

  • Page 58: Midi Channels

    5.6 MIDI Program Changes Program Changes: When the QUANTUM is set to receive on one or all of the MIDI channels, it will recognize a Program Change command. If the number is legal (i.e., within the device's range of selectable programs) the QUANTUM will respond by changing to the new program.

  • Page 59: A/D Calibrate

    “A/D CAL FAIL!” If this happens you should turn the QUANTUM off then back on. If the problem persists, call dbx technical support at 1-801-568-7660 for assistance. Call after the unit is allowed to warm up to operating temper- ature (approx.
  • Page 61 Section 6 QUANTUM APPLICATIONS APPLICATION GUIDE ®...

  • Page 62: Section 6 - Application Guide

    2. Connect 2-track right output to the QUANTUM’s channel two input. 3. Connect the QUANTUM’s AES/EBU or S/PDIF OUTPUT to digital recorder. Software 1. Press the UTILITY button to enter the QUANTUM’s utility section. Change the INPUT to ANALOG. 2. Change the CLOCK to desired internal sample rate.

  • Page 63: Digital Mastering

    2. Connect the QUANTUM’s AES/EBU or S/PDIF output to AES/EBU S/PDIF of DAT machine. Software 1. Press the UTILITY button to enter the QUANTUM’s utility section. Change the INPUT to AES/EBU or S/PDIF. 2. Change the CLOCK to AES/EBU or S/PDIF.

  • Page 64: Daw To Dat

    2. Connect the QUANTUM’s AES/EBU or S/PDIF output to AES/EBU S/PDIF of DAT machine. Software 1. Press the UTILITY button to enter the QUANTUM’s utility section. Change the INPUT to AES/EBU or S/PDIF. 2. Change the CLOCK to AES/EBU or S/PDIF.

  • Page 65: Analog Tracking

    1. Connect external Mic Preamp’s output to the QUANTUM’s input. 2. Connect the QUANTUM’s output to analog tape machine input. Software 1. Press the UTILITY button to enter the QUANTUM’s utility section. Change the INPUT to ANALOG. 2. Change the CLOCK to INT96.

  • Page 66: Digital Tracking

    1. Connect external Mic Preamp’s output to the QUANTUM’s input. 2. Connect the QUANTUM’s AES/EBU or S/PDIF output to the digital recorder’s input. Software 1. Press the UTILITY button to enter the QUANTUM’s utility section. Change the INPUT to ANALOG. 2. Change the CLOCK to desired sample rate.

  • Page 67: Analog Mixing

    1. Connect the analog console’s outputs to the QUANTUM’s analog inputs. 2. Connect the QUANTUM’s analog outputs to the recorder. Software 1. Press the UTILITY button to enter the QUANTUM’s utility section. Change the INPUT to ANALOG. 2. Change the CLOCK INT96.

  • Page 68: Digital Mixing

    Section 6 Application Guide 6.7 Digital Mixing Hardware 1. Connect AES/EBU or S/PDIF output of the digital console to the QUANTUM’s AES/EBU or S/PDIF input. 2. Connect the QUANTUM’s AES/EBU or S/PDIF output to AES/EBU S/PDIF of DAT machine. Software 1.

  • Page 69: Analog To Digital Converter

    1. Connect line inputs to QUANTUM’s analog inputs. 2. Connect the QUANTUM’s AES/EBU or S/PDIF OUTPUT to digital recorder. Software 1. Press the UTILITY button to enter the QUANTUM’s utility section. Change the INPUT to ANALOG. 2. Change the CLOCK to desired internal sample rate.

  • Page 70: Sample Rate Converter

    Section 6 Application Guide 6.9 Sample Rate Converter Hardware 1. Connect AES/EBU or S/PDIF output of the digital source to the QUANTUM’s AES/EBU or S/PDIF input. 2. Connect the QUANTUM’s AES/EBU or S/PDIF output to AES/EBU S/PDIF of DAT machine. Software 1.

  • Page 71: Appendix

    Appendix QUANTUM ®...

  • Page 72: Hard & Soft Resets

    MIDI operations. A.4 Flash Downloads The QUANTUM has the ability to update its operating system (OS) to the latest version available over the Internet. If your PC can receive/transmit MIDI data, then you are in business. 1. Connect the MIDI output from your PC to the MIDI input of the QUANTUM.

  • Page 73: Typeiv™ White Paper

    VU meters, often having no peak indicators whatsoever. If only digital were more forgiving like ® ® TypeIV™ White Paper QUANTUM User Manual Appendix B Appendix B...
  • Page 74 Above this, in the logarithmic region, high-level input signals get “mapped” into the top 4 dB of the A/D con- verter. This mapping is analogous to the signal compression effect that occurs when recording high-level signals onto analog tape. QUANTUM User Manual Signal Level...
  • Page 75 A/D clip level, thus preserving the high-frequency content of the signal. ® ® ® TypeIV™ White Paper TYPE IV™ Over Region A/D Converter Linear Region Figure 2 - Input Signal Levels Mapped to Type IV Over Region Appendix B Appendix B 0 dB FS Noise Floor QUANTUM User Manual...
  • Page 76 Appendix B TypeIV™ White Paper Amplitude Amplitude QUANTUM User Manual Figure 3a - Signal Having Low and High Frequency Content Figure 3b - Signal of Fig. 3a Going Beyond the A/D Clip Level QUANTUM Time A/D Clip Level Time A/D Clip Level ®...
  • Page 77 Figure 3d - Type IV Mapping Preserves High-Frequency Information Appendix B High-Frequency Content A/D Clip Level Low-Frequency Content Time A/D Clip Level A/D Clip Level TYPE IV™ Over Region Time TYPE IV™ Over Region A/D Clip Level QUANTUM User Manual...

  • Page 78: Clock Modes

    This is essential for accurate monitoring at different points along the chain. With an analog input and downstream digital units, using the QUANTUM as a master clock will keep the digital signal accurate. While the differences in jittery sync without a master clock may be miniscule, it is better to reduce the vari- ables in favor of accuracy.

  • Page 79: Quantum Sync Input

    Refer all servicing to qualified service personnel. Disconnect mains power before servicing. QUANTUM comes with the sync input terminated. For certain configurations, you may wish to have the sync input be unterminated. However, dbx Professional Products recommends that the sync input be terminated whenever you are using a Superclock, e.g., DigiDesign ProTools®, sync.
  • Page 80 QUANTUM’s sync input. The same is true if you wish to use several QUANTUMs in a tapped configuration. QUANTUM can also be used in a daisy chain fashion. In a daisy chain configuration, each piece of equipment can remain terminated (and should if you are using a SuperClock) and so the termination can remain in the default position.

  • Page 81: Sysex Definitions

    When zz = 6Ch Linked Setup type is selected When zz = 6Dh Dual Mono Setup type is selected When a Request One Setup procedure is received, the QUANTUM will respond with a Receive One Setup proce- dure. Receive One Setup (43h)
  • Page 82 Program data The Receive One Setup procedure is used to load a Setup into the QUANTUM. The number of setup bytes to be received (n) is different for each setup. If the QUANTUM is sent a Receive One setup procedure where the setup number is not a valid RAM destination, it will be ignored.
  • Page 83 SYS_HEAD, 21(h), F7(h) The Reset Device procedure causes the QUANTUM to reboot the software as if the power had been turned off, and then back on. If edits have been made to the current program without saving, they will be lost.

  • Page 84: Midi Cc - Multiband Chains

    45 -> Gate Hold time Band2 cc 46 -> Gate Release Band2 cc 47 -> Gate Max Attn Band2 cc 48 -> Gate On/Off Band3 QUANTUM User Manual QUANTUM cc 49 -> Gate Threshold Band3 cc 50 -> Gate Gate Ratio Band3 cc 51 ->...

  • Page 85: Midi Cc - Stereo Non-Multiband

    23 -> DSr On Off cc 24 -> DSr DS HP Freq cc 25 -> DSr DS Range cc 26 -> DSr DS Type QUANTUM User Manual ® Appendix E MIDI CC Tables cc 113-> Limiter On Off Band4 cc 114->...

  • Page 86: Midi Cc - Dual Mono Chains

    5 -> EQ Freq BAND1 cc 6 -> EQ Slope BAND1 cc 7 -> EQ Lvl BAND1 cc 8 -> EQ Freq BAND2 QUANTUM User Manual QUANTUM cc 91 -> EQ Freq BAND1 cc 92 -> EQ Slope BAND1 cc 93 ->...
  • Page 87 121 -> Limiter Hold time cc 122 -> Limiter Release cc 123 -> Limiter Over Easy cc 124 -> Limiter Auto cc 125 -> MONO TCM™ On Off cc 126 -> MONO TCM™ Time cc 127 -> OutEff Bits QUANTUM User Manual...

  • Page 88: Factory Programs

    47) De-ess Voc / Monster Gtr 48) Country Voc / Twang E Gtr 49) Rumble Bass / FunkstompGt 50) Mono Def. / Mono Def. QUANTUM User Manual QUANTUM 51) Pop Master1 52) Piano Track 53) Studio Voc / Acoustic Gt...

  • Page 89: Factory Setups

    Small Voc Country Voc De-ess Voc Fat Kick Thick Kick Brite Snare Slam Snare Rim Shot Tight Toms Ringing Tom Rumble Bass Slap Bass Big Piano Brite Horns Acoustic Gt Folk Gtr Twang E Gtr Monster Gtr FunkstompGt QUANTUM User Manual...

  • Page 90: Specifications

    D-A Conversion: Dynamic Range: THD+Noise: Frequency Response: Interchannel Crosstalk: QUANTUM User Manual Female XLR and 1/4” TRS (Pin 2 and tip hot) Electronically balanced/unbalanced, RF filtered Balanced >18 kΩ, unbalanced >9 kΩ +24 dBu balanced or unbalanced >40 dB, typically >55 dB at 1 kHz -∞...
  • Page 91 Appendix H TPDF Dither. (a) 24-Bit word output, (b) 20-Bit word output, (c) 16-Bit word output (d) 8-Bit word output. Parameters: Input -60dBFS, 1 kHz; FFT Length= 2048, Sample Rate= 48 Khz, Averages= 32; Graph Steps= 1024. ® QUANTUM User Manual...
  • Page 92 Appendix H 16-Bit TPDF dither. (a) Shape “off”, (b) with shape set to “S1”, (c) with shape set to “S2.” Parameters: Input -60dBFS, 1 kHz; FFT Length= 2048, Sample Rate= 48 Khz, Averages= 32; Graph Steps= 1024. ® QUANTUM User Manual...
  • Page 93 QUANTUM Appendix H (a) 24-Bit word, (b) 16-Bit truncated output, no dither. Parameters: Input -60dBFS, 1 kHz; FFT Length= 2048, Sample Rate= 48 Khz, Averages= 32; Graph Steps= 1024. ® QUANTUM User Manual...
  • Page 94 ® A Harman International Company 8760 South Sandy Parkway Sandy, Utah 84070 Phone: (801) 568-7660 Fax (801) 568-7662 Int’l Fax: (219) 462-4596 Questions or comments? E-mail us at: customer@dbxpro.com or visit our World Wide Web home page at: www.dbxpro.com 18-5385-D...
