Windsor Cadet CDT7IHB Operator Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CARPET EXTRACTOR
MODEL:
CDT7IHB
10080240
Bitte lesen Sie diese Anleitungen, bevor Sie die Maschine in Gebrauch nehmen
8.603-684.0 -M 04/26/11
PRV NO. 980016
Read instructions before operating the machine
Operating Instructions (ENG)
Bedienungsanleitung (GER)
IPX4

Advertisement

Table of Contents
loading

Related Manuals for Windsor Cadet CDT7IHB

Summary of Contents for Windsor Cadet CDT7IHB

  • Page 1 CARPET EXTRACTOR Operating Instructions (ENG) Bedienungsanleitung (GER) MODEL: CDT7IHB 10080240 IPX4 Read instructions before operating the machine Bitte lesen Sie diese Anleitungen, bevor Sie die Maschine in Gebrauch nehmen 8.603-684.0 -M 04/26/11 PRV NO. 980016...

  • Page 2: Machine Data Log/Overview

    MACHINE DATA LOG/OVERVIEW Warranty Registration Thank you for purchasing a Windsor product. Warranty registration is quick and easy. Your registration will allow us to serve you better over the lifetime of the product. To register your product go to: www.windsorind.com/WarrantyRegistration.aspx...

  • Page 3: Table Of Contents

    Controls/Components ........3-2 Filling the Solution Tank........3-5 Machine Operation........3-6 Cleaning Procedure........3-9 Accessory Tool Usage........ 3-10 MAINTENANCE Periodic Maintenance ........4-1 Daily/Regular Maintenance......4-1 Vacuum Motor Replacement......4-2 Belt Replacement..........4-3 Solution Pump Replacement......4-4 Machine Troubleshooting......4-5 Wiring Diagram ..........4-6 CDT7IHB 86036840 03/12/07...

  • Page 4: How To Use This Manual

    They are listed in this general order: Parts may be ordered from authorized Windsor dealers. When placing an order for parts, the Vacuum Motor Replacement machine model and machine serial number are Belt Replacement important.

  • Page 5: Important Safety Instructions

    This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices for more than normal housekeeping purposes. Maintenance and repairs must be done by qualified personnel. If foam or liquid comes out of machine, switch off immediately. SAVE THESE INSTRUCTIONS CDT7IHB 86036840 03/12/07...

  • Page 6: Hazard Intensity Level

    Unless Operation Guide is Read and understood. In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use Windsor approved replacement parts. CDT7IHB 86036840 03/12/07...

  • Page 7: Safety Label Location

    SAFETY LABEL LOCATION NOTE: These drawings indicate the location of safety labels on the CDT7IHB. If, at any time, the labels become illegible contact your Windsor representative for prompt replacement. WARNING DECAL 86242230 PRV NO. 500009 CDT7IHB 86036840 03/12/07...

  • Page 8: Technical Specifications

    HEIGHT: 34” (86.36 cm) SOLUTION CAPACITY: 7 gallons (26.5ltr) WIDTH: 17.5” (44.45 cm) RECOVERY CAPACITY: 7 gallons (26.5ltr) SOLUTION SPRAY: 2 quick change BRUSH SPEED: 1000 rpm jets. POWER CABLE: 50’ (12.7 m) (1mm) 34” (86.36cm) 41” 17.5” (104cm) (44.45cm) CDT7IHB 86036840 11/02/10...

  • Page 9: Controls/Components

    Brush Motor Circuit Breaker. 4 amp. Breaker protecting brush motor. Vacuum Motor Circuit Breaker. 7 amp. Breaker protecting vacuum motor. Recovery Dump Hose. Facilitates draining dirty cleaning solution. Solution Dump Hose. Facilitates draining excess cleaning solution from solution tank. CDT7IHB 86036840 03/12/07...
  • Page 10 Recovery Tank. Used to collect dirty cleaning solution. Solution Tank. Used to hold cleaning solution. Recovery Tank Dome. Vacuum Shoe. Brush Housing. Front Lifting Handle. Cleaning Solution Filter. CDT7IHB 86036840 03/12/07...
  • Page 11 CONTROLS/COMPONENT LOCATIONS Solution Intake Cover. Vacuum Intake Cover. Float Shut-Off. Clean-Out Opening. Pour Spout. Lift Handle. CDT7IHB 86036840 03/12/07...
  • Page 12 Non-Compatible Chemicals STEP Alkalis Aldehydes Detergents Aromatic Hydrocarbons Hydroxides SP Butyls Replace recovery Soaps Carbon Tetrachloride tank Vinegar Clorox* Chlorinated Bleaches Chlorinated Hydrocarbons Lysol* Methyl Ethel Ketone (MEK) Perchorethylene (perc) Phenolics Trichlorethylene D-Limonene * Product Trademark Names CDT7IHB 86036840 03/12/07...
  • Page 13 For good operation the brush must 1/8in skim the carpet. If circuit breaker (3mm) trips raise brush to prevent damage CORRECT to motor or carpet. INCORRECT STEP Turn on both Vacuum and Pump PUMP VACUUM motor switches (“ON”=“I”). CDT7IHB 86036840 11/02/10...
  • Page 14 The continuous setting allows the operator to set the switch in the “on” CONTINUOUS position with one touch, and is typically used in large areas where long cleaning passes are made. CDT7IHB 86036840 03/12/07...

  • Page 15: Cleaning Procedure

    Large amounts of water or foam entering the vacuum system can damage the vacuum motor. If you notice either condition, shut down the VACUUM INTAKE COVER machine immediately. Empty recovery tank and/or add defoamer to recovery tank. CDT7IHB 86036840 03/12/07...

  • Page 16: Cleaning Procedure

    To speed drying, use a Windblower™ fan. STEP Empty recovery tank by releasing dump hose. Use a hose with cold water to clean out the recovery tank. Also drain solution tank after each RECOVERY DRAIN use. SOLUTION DRAIN CDT7IHB 86036840 03/12/07...

  • Page 17: Accessory Tool Usage

    1 ½ inch hose cuff into hole. STEP Turn on Pump and Vacuum Switch. PUMP VACUUM Note: Be sure intermittent/continuous switch is in center (off) position and brush is in storage position. STEP Squeeze handle on accessory tool to begin cleaning. CDT7IHB 86036840 03/12/07 3-10...

  • Page 18: Maintenance

    8. Check cooling air screen (located on frame behind left wheel) for lint or debris. 9. Check float and shut-off screen and clean as necessary. NOTE: Always store machine with brush in “Store” position. CDT7IHB 86036840 03/12/07...

  • Page 19: Vacuum Motor Replacement

    27809) to the solution tank. Wire 6. Remove the vacuum motor. Terminal 7. Reverse process to install vacuum motor. Important: These brushes wear quicker Vacuum Motor Carbon Brushes Replacement (Windsor) Note: as the length shortens due to Place End Cap increased heat. stop in Spring inside brush groove.

  • Page 20: Belt Replacement

    (p/n 86249420 PRV NO. 62759) to the brush housing to remove belt. NOTE: All components associated with driving the brush will come out with the side plate. 7. Reverse process to install belt. 86249420 PRV NO. 62759 86227350 PRV NO. 05016 CDT7IHB 86036840 03/12/07...

  • Page 21: Solution Pump Replacement

    PRV NO. 42-809332 PRV NO. 65187 Pump Replacement Parts for Flojet 73 psi (86006110 PRV NO. 65189) Pump Hsng 86288790 PRV NO. 41387 Pump Repair Kit 86004600 PRV NO. 47176 Hsng/Pump Repair Kit 86136040 PRV NO. 47350 CDT7IHB 86036840 03/12/07...

  • Page 22: Troubleshooting Chart

    1. Brush switch off. 1. Turn on brush switch. Brush Does Not Spin 2. Brush circuit breaker tripped 2. Reset circuit breaker. 3. Brush belt broken. 3. Replace as necessary. 4. Faulty brush motor. 4. Call for service. CDT7IHB 86036840 03/12/07...

  • Page 23: Wiring Diagram

    WIRING DIAGRAM (86003650 PRV NO. 34362) (86268750 PRV NO.88567) (86268900 PRV NO. 88655) (86268350 PRV NO.88270) (86001240 PRV NO. 14020) (86268750 PRV NO. 88567) (86004480 PRV NO 41353) CDT7IHB 86036840 03/12/07...

  • Page 24: Frame Assembly

    FRAME ASSEMBLY (SEE PG. 5-11) CDT7IHB 86036840 03/12/07...
  • Page 25 SCR, 1/4-20 X 1/2 HHCS PLTD 86006530 70057 SCR, 1/4-20 X 1 PPHMS SS 86272160 66052 PIN, ROLL I/8” X 1.0”L 86276610 70697 SCR, 1/4-20 X 1.25 PPHMS SS 86005710 57105 NUT, 1/4-20 HEX W/ STD WASHER CDT7IHB 86036840 03/12/07...
  • Page 26 BRUSH ASSEMBLY CDT7IHB 86036840 03/12/07...

  • Page 27: Brush Assembly

    PULLEY ASM, BRUSH 86003390 29208 DRIVER ASM, BRUSH 86001140 12514 BRUSH ASM, 15 IN 86227150 05158 ADAPTER, BRUSH BRG. DIE CAST 86228890 09137 BEARING, R6 3/8 ID 86028010 47383 BRUSH BEARING ASM. 86004750 47416 KIT, BRNG/ADPTR EXTRCTR CDT7IHB 86036840 02/22/11...

  • Page 28: Pump Assembly

    PUMP ASSEMBLY (SEE SOLUTION TANK) CDT7IHB 86036840 03/12/07...
  • Page 29 HOSE, 3/8 OD X 1/4 ID URTHN X 22" OPEN 86281900 39531 HOSE, 1/4 ID NYLON X 5" 86253020 73963 SCREEN, INTAKE 86282350 39721 HOSE, 3/8 ID NYLON YLW X 17” 86279930 29277 DUCT, 1/2 ID SPLT FLX X 16” CDT7IHB 86036840 03/12/07...
  • Page 30 PUMP ASSEMBLY PRIOR TO SERIAL 1000153482 (SEE SOLUTION TANK) CDT7IHB 86036840 03/12/07...
  • Page 31 HOSE, 1/4 ID NYLON X 5” 86253020 73963 SCREEN, INTAKE 86004400 39591 HOSE, 3/8 ID NYLON YLW X 29” 86003490 31074 ELBOW, SWIVEL 1/4 MPT X 1/4 TUBE 86008360 78419 TEE, 3/8 MPT X 3/8 TUBE QC CDT7IHB 86036840 03/12/07...

  • Page 32: Vacuum Shoe Assembly

    VACUUM SHOE ASSEMBLY CDT7IHB 86036840 03/12/07...
  • Page 33 SPACER, 3/8ODX.058WX.2814,CRS 86010620 85039 VAC SHOE, 15" OPEN 86010630 87013 WASHER, 1/4 ID X 5/8 OD SS 86010700 87074 WASHER, WAVE 3/8ID X3/4D X.125 86003780 35171 GASKET, ACCESSORY PORT 86008120 73955 SPRING, EXT .38D X2.75L X.055W CDT7IHB 86036840 03/12/07 5-10...

  • Page 34: Control Panel Assembly

    CONTROL PANEL ASSEMBLY (SEE SOLUTION TANK) CDT7IHB 86036840 03/12/07 5-11...
  • Page 35 LABEL, CONTROL PANEL, CDT 86010750 87100 WASHER, 3/8 ID INT.LOCK THIN 86005700 57104 NUT, 10-32 W/STAR WASHER PLTD 86006830 70386 SCR, 10-32 X 1.0 PPHMS 86002600 23682 CORD ASM, 230V EURO 86245040 50279 LABEL, GROUND SYMBOL CDT7IHB 86036840 03/12/07 5-12...

  • Page 36: Solution Tank Assembly

    SOLUTION TANK ASSEMBLY (SEE CONTROL PANEL) (SEE FRAME) (SEE PUMP) (SEE FRAME) CDT7IHB 86036840 03/12/07 5-13...
  • Page 37 35237 GASKET, TANK, L-R 86003970 35238 GASKET, TANK, RH 86275690 70525 SCR, #10 X 1.0 PPHST TYPE B 86003940 35235 GASKET, CDT PANEL OPEN 86002870 27417 CORD, 99807 1/8 X 12" 86232280 500012 CARD, INSTRUCTION CDT7 CDT7IHB 86036840 03/12/07 5-14...

  • Page 38: Recovery Tank Assembly

    RECOVERY TANK ASSEMBLY CDT7IHB 86036840 03/12/07 5-15...
  • Page 39 HOSE, CAP 86006600 70114 SCR, #10 X 3/4 PPHST TYPE B 86032770 75410 TANK, CDT RECOVERY TEAL 86001370 140408 BRKT, HOSE HOOK 86002870 27417 CORD, 99807 1/8 X 12" OPEN OPEN 86003330 28061 DOME ASM, CLP FAM CDT7IHB 86036840 03/12/07 5-16...

  • Page 40: Suggested Spare Parts

    VAC MOTOR ASM, 230V 86005420 53791 STRAINER, 3/8 IN. NPT 60 MESH 86007970 73864 BRUSH SET, 230V VAC AMETEK 86230760 140216 BRUSH SET, 230V VAC MTR WINDSOR 86135330 140688 FLOAT, SHUT-OFF 86003630 34351 DOME ASM, CLP FAM 86003330 28061 NOTES:...
  • Page 41 CDT7IHB 86036840 03/12/07 5-18...
