Retain for Future Reference
Thank you for purchasing the One For A l l
Wireless Universal Garage Remote. Your
One For All Wireless Universal Garage
Remote (referred to as GDK throughout
the rest of the manual) is designed to
operate most garage door openers as well
as most gate openers manufactured after
1981*. Your GDK will operate the following
manufacturer's products:
Sears Craftsman (Most units)
Genie:
Model AR85 (9-Position Switch)
Model AR90 (12-Positions Switch)
Model SD9500 (12-Positions
Switch)
Stanley
Chamberlain (Most Units)
Linear
Moore-o-Matic
Multi-Code
Wayne Dalton
Lift-Master
Master Mechanics
Ambassador
Automatic DoorMan
Doorkeeper
Liftadoor
Multi El Mac
Raynor
Shima
Vemco
Crawford
Powerlift
Blue Max
EZ Lift
l
Your GDK package contains the following
items:
.
1 - One For All Wireless Universal
Garage Remote
.
1 - Users Manual
.
1 - 9-volt battery
.
2 - 1" flathead screws for mounting the
One For All Wireless Universal Garage
Remote
Before getting started, you will need your
original garage door opener transmitter.
You will use the original transmitter during
the setup of the GDK. If you do not have
your original transmitter, please refer to the
"WHAT TO DO IF YOUR ORIGINAL
TRANSMITTER HAS TWO OR THREE
BUT-TONS OR IS LOST OR BROKEN"
section after setting up your password.
The GDK comes with one fresh 9-volt
battery. The battery is packaged inside the
battery compartment along with the two 1"
mounting screws, however, the battery is
not connected. To connect the battery:
1.
Slide off the battery cover
and remove the battery and
two mounting screws.
Connect the battery.
Insert the connected battery
3.
inside the battery
compartment and replace
the battery cover.
Advertisement
Related Manuals for One for All AR90
Summary of Contents for One for All AR90
- Page 1 Sears Craftsman (Most units) Genie: Model AR85 (9-Position Switch) The GDK comes with one fresh 9-volt Model AR90 (12-Positions Switch) battery. The battery is packaged inside the Model SD9500 (12-Positions battery compartment along with the two 1" Switch)
- Page 2 NOTE: If you make a mistake in entering w illuminate for two seconds followed your PIN, press the EXIT key and return to GENIE MODEL 12 BITS/390 MHZ STEP 2 to re-enter your new PIN. by two quick beeps. The GDK will AT90 power OFF.
- Page 3 “Smart” or “Learn” button on the head match your original garage door unit. The button should have an LED If you own a Genie AR90 Garage Door opener’s DIP switches, press (Light Emitting Diode) next to it. Opener, do not set more than eight LEDs E N T E R again to store your code.
- Page 4 Slide the GDK onto the screw, see figure 6. Figure 6 After you have stored your garage door opener(s) security codes in the memory the GDK and you have mounted the unit you are ready to use your GDK. To open your garage door: If your original transmitter has two or three buttons and uses DIP switches, set the #1...
- Page 5 The user is cautioned that changes and This equipment has been tested and found modifications made to the equipment to comply with the limits for a class B digital device, pursuant to part 15 of the without the approval of the manufacturer could void the user’s authority to operate FCC Rules.
