MARINE RADAR
FR-1710/1725/1760DS
MODEL

Summary of Contents

  • Page 1

    MARINE RADAR FR-1710/1725/1760DS MODEL...

  • Page 2

    9 - 5 2 , A s h i h a r a - c h o , N i s h i n o m i y a , J a p a n Te l e p h o n e : 0 7 9 8 - 6 5 - 2 111 Te l e f a x : 0 7 9 8 - 6 5 - 4 2 0 0...

  • Page 3

    Note: If the scanner unit is installed at a close distance in front of the wheelhouse, your administration may require halt of transmission within a certain sector of scanner revolution. This is possible Ask your FURUNO representative or dealer to provide this feature. Distance to Radiator Model...

  • Page 4

    Unit This radar system contains the danger/ warning labels shown below. Do not remove the labels. If a label is peeling off or is illeg- ible, contact a FURUNO agent for replace- ment. WARNING To avoid electrical shock, do not remove cover.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ... v SYSTEM CONFIGURATION ... vi| MENU TREE ... viii OPERATIONAL OVERVIEW 1.1 Turning on the Power ... 1-1 1.2 Transmitter ON ... 1-1 1.3 Control Description... 1-2 1.4 CRT Brilliance ... 1-3 1.5 Control Panel Backlighting ... 1-3 1.6 Tuning the Receiver ...

  • Page 6: Table Of Contents

    1.41 Clutter Sweep... 1-32 1.42 Outputting Target Position ... 1-32 1.43 Background Color ... 1-33 1.44 Selecting Range Scales ... 1-33 1.45 Selecting Bearing Scale Format ... 1-33 1.46 A/D Converter Curve Setting ... 1-34 1.47 Enlarging Close-in Targets ... 1-34 1.48 Alarms ...

  • Page 7

    A Word to the Owner of This FURUNO Radar Thank you for purchasing this FURUNO radar. We are confident you will discover why FURUNO has become synonymous with quality and reliability. Dedicated in the design and manufacture of marine electronics equipment for half a century, FURUNO Electric Company has gained an unrivaled reputation as a world leader in the in- dustry.

  • Page 8

    FR-1760DS 110/115/ Rectifier 220 VAC, RU-3305 1 , 50/60 Hz 100 VAC, 1 , 50/60 Hz 100/110/ 115 VAC, 1 , 50/60 Hz 220 VAC, Rectifier 1 , 50/60 Hz RU-1758 440 VAC, Rectifier 1 , 50/60 Hz RU-1803 GPS, etc. Speed Log Water temperature, water depth...

  • Page 9

    FR-1710/1725 Serial Data (I/O) GPS, etc. Pulse Input Speed Log Water temperature, water depth Gyrocompass External Buzzer OP03-21 Option Ship’s Mains 24/32 VDC 100/110/115/220/230 VAC, 1 , 50/60 Hz FR-1710 ANTENNA UNIT XN12AF-RSB0074-062 (24 rpm) XN20AF-RSB0074-062 (24 rpm) XN12AF-RSB0075-062 (42 rpm)

  • Page 10

    MENU MENU 1. VIDEO PLOT* 2. TGT TRAIL 3. TGT ALARM 4. PANEL DIM 5. ECHO SIG 6. FUNC 7. PLOT 8. MARK 9. BRILL 0. OTHER * Requires Video Plotter RP-17. TGT TRAIL 1. TIME 15S 30S 1M 15M 30M CONT 2.

  • Page 11

    PLOT MENU 1 1. MARK DISP OFF ON 2. ERASE 3. VEC REF REL TRUE 4. VEC TIME 5. CPA SET 6. TCPA SET 7. TRACK 8. AUDIO ALARM 9. INTVAL* PLOT MENU 2* 2. AUTO 3. GUARD ZONE 4. TRACK TEST 5.

  • Page 12

    OTHER 1. HDG SET 2. SPD MODE MAN LOG NAV LOG (S-BT) LOG (S-WT) 3. MAN SPD 4. DRIFT SET 5. DISPLAY 6. MARK/LINE 7. TUNE 8. NAV DATA 9. EBL/VRM EBL/VRM 2. CURS BRG REL TRUE 3. EBL1 REL TRUE 4.

  • Page 13

    FUNC 1 MENU 2. FUNC SEL COAST OCEAN R-SEA RAIN BIRD-N BIRD-F 3. ECHO AVG OFF 0.5 1 4. INT REJ OFF 1 5. STRETCH OFF 1 6. N REJ OFF ON 7. ENHANCE OFF ON 8. CONTRAST OFF 1 9.

  • Page 14

    2. ALARM INTV OFF 3M 6M 12M 15M 20M RANGE 2. RANGE 1/8 1/4 3/4 1 FR-1760DS Max. range: 120 NM FR-1710 Max. range: 72 NM FR-1725 Max. range: 96 NM 90 135 8 12 16 32 48 72 96 120...

  • Page 15: Turning On The Power, Transmitter On

    1.1 Turning on the Power The [POWER] switch is located at the top left corner of the display unit. Push it to switch on the radar set. To turn off the radar, push it again. The screen shows the bearing scale and digital timer approximately 15 seconds after power-on.

  • Page 16: Control Description

    1.3 Control Description Selects presentation mode. Turns on/off target trails. Enables/disables guard zone. Turns zoom function on/off. Turns parallel index lines on/off. Offset EBL origin to measure range, bearing between two targets; predict collision course. Turns power on/off. Chart card slot (Requires video plotter.) ROTATE: Adjusts...

  • Page 17: Crt Brilliance, Control Panel Backlighting, Tuning The Receiver

    1.4 CRT Brilliance Operate the BRILL control on the control panel of the display unit to adjust the entire screen brightness. Note that the optimum point of adjustment varies with ambient light- ing conditions, especially between daytime and nighttime. 1.5 Control Panel Backlighting 1.

  • Page 18: Degaussing The Screen, Initializing The Compass Readout

    3. Press the [7] key twice to display the TUNE menu. TUNE 2. MODE AUTO 3. TUNE SET Figure 1-6 TUNE menu 4. Press the [2] key to select the option AUTO or MAN from the MODE field. 5. Press the [ENTER/SELECT] key. 6.

  • Page 19: On-screen Legends And Markers

    1.9 On-screen Legends and Markers Heading (Requires heading sensor.) Heading line Range ring interval Range to cursor Range to cursor /2 NM 4.111NM Bearing to cursor 103.7 R PULSE MIP Presentation mode OFF CENT Pulselength FUNC1 Offcenter COAST Function Target alarm zone No.

  • Page 20: Presentation Modes

    1.10 Presentation Modes This radar has the following presentation modes: Head-up, Head-up/TB, Course-up, North-up, and True Motion. Selecting presentation mode Press the [MODE] key on the panel at the right side of the display unit. Each time the [MODE] key is pressed, the presentation mode and mode indication at the upper-left corner of the screen change cyclically.

  • Page 21

    Presentation mode, representative display Heading marker North 020 030 marker North Heading line Description Course-up Mode Heading An azimuth stabilized display in which a line connect- line ing the center with the top of the display indicates own ship’s intended course (namely, own ship’s previous heading just before this mode has been selected).

  • Page 22: Selecting The Range Scale

    Presentation mode, representative display North Heading marker line North marker Heading 340 350 line (a) True motion is selected Automatic resetting of own ship position in true motion mode 1.11 Selecting the Range Scale The range selected automatically determines the range ring interval, the number of range rings and pulse repetition rate, for optimal detection capability in short to long ranges.

  • Page 23: Entering Own Ship's Speed

    1.12 Entering Own Ship’s Speed EPA requires an own ship speed input and compass signal. The speed can be entered from a speed log or navaid (automatic) or through the plotting keypad (manual). Automatic speed input 1. Press the [MENU] key and the [0] key twice to show the OTHER menu.

  • Page 24: Pulselength, Echo Stretch

    1.13 Pulselength, Echo Stretch The ECHO control selects pulselength, and echo stretch when it is not turned on with a user key ([F1], [F2], [F3]). The pulselength in use is displayed at the upper-left position of the screen using the abbreviations (suffixed with “P”) shown in the table on the next page.

  • Page 25

    Table 1-1a ECHO control setting, pulselength and echo stretch (FR-1710/1725) – – – – – – – – – – – Table 1-1b ECHO control setting, pulselength and echo stretch (FR-1760DS) – – – – – – – – –...

  • Page 26: Adjusting The Sensitivity, Suppressing Sea Clutter

    1.14 Adjusting the Sensitivity The GAIN control adjusts the sensitivity of the receiver. It works in precisely the same manner as the volume control of a broadcast receiver, amplifying the signals received. The proper setting is such that the back- ground noise is just visible on the screen.

  • Page 27: Suppressing Precipitation Clutter, Interference Rejector

    1.16 Suppressing Precipitation Clutter The vertical beamwidth of the scanner is de- signed to see surface targets even when the ship is rolling. However, by this design the unit will also detect rain clutter (rain, snow, or hail) in the same manner as normal tar- gets.

  • Page 28: Measuring The Range, Measuring Bearing

    1.18 Measuring the Range Measuring range by the fixed range rings Use the fixed range rings to obtain a rough estimate of the range to a target. They are concentric solid circles about own ship, or the sweep origin. The number of rings is auto- matically determined by the selected range scale and their interval is displayed at the upper-left position of the screen.

  • Page 29: Collision Assessment By The Offset Ebl

    Range and bearing to cursor 0.55 NM 15.0 R No. 2 EBL (dashed) Bearing to 45.5 R No. 1 EBL 314.0 R Bearing to No. 2 EBL Active marker is circumscribed. Figure 1-16 How to measure bearing by EBL 1.20 Collision Assessment by the Offset EBL The origin of the EBL can be placed any- where with the trackball to enable measure-...

  • Page 30: Measuring Range And Bearing Between Two Targets, Setting A Target Alarm Zone

    3. Turn the VRM rotary control until the range marker on the No. 1 EBL aligns with target 2 in Figure 1-18. The active VRM readout at the lower-right corner of the screen indicates the distance between the two targets. 4.

  • Page 31: Off-centering (shift)

    Figure 1-20 Target alarm Note: If you wish to create a target alarm zone having a 360-degree coverage around own ship, set point “B” in almost the same direction (approx. 3 ) as point “A” and press the [GZ ALARM] key. Two alarm zones can be set as described above.

  • Page 32: Echo Averaging

    Echo average requires log and compass sig- nals. If you wish to use this feature without a compass signal, consult a FURUNO repre- sentative. Manual speed entry is done at the menu item...

  • Page 33: Electronic Plotting Aid (epa)

    1.25 Electronic Plotting Aid (EPA) 10 operator-selected targets can be plotted electronically to assess their motion trend. Five past positions can be displayed for each of the plotted targets. If you enter a 6th plot on a certain target, the oldest plot (past posi- tion) will be erased.

  • Page 34

    True or relative vector, vector time Vectors can be displayed relative to own ship’s heading (Relative) or with reference to the North (True). This feature is available in all presentation modes (compass must be working correctly). The current vector mode is indicated at the upper-right corner of the screen.

  • Page 35

    2. Press the [2] key twice to select OFF from the ERASE field. 3. Press the [ENTER/SELECT] key followed by the [MENU] key. Setting CPA/TCPA alarm ranges When the predicted CPA of any target be- comes smaller than a preset CPA alarm range and its predicted TCPA less than a preset TCPA alarm limit, the EPA releases an au- dible alarm and displays the warning label...

  • Page 36: Target Trails (echo Trails)

    Past plot points Past plot points may be marked on the dis- play with as many as nine dots. You can turn this display on/off as follows: 1. Press the [MENU] key. 2. Press the [7] key twice to select PLOT. PLOT MENU 1 1.

  • Page 37

    4. Press the [ENTER/SELECT] key to con- firm your selection, then the [MENU] key to close the menu. Trail gradation Target trails may be shown in monotone or multitone. Gradual shading paints the trails getting thinner with time just like the after- glow on an analog PPI radar.

  • Page 38

    3. Press the [5] key to select ON or OFF from the TRAIL COPY field as appropriate. 4. Press the [ENTER/SELECT] key and [MENU] key in order. Resetting target trails To reset (or clear) the target trail memory, hold the [TGT TRAIL] key depressed for about 3 seconds.

  • Page 39: Parallel Index Lines, Origin Mark

    1.27 Parallel Index Lines Parallel index lines are useful for keeping a constant distance between own ship and a coastline or a partner ship when navigating. The orientation of the index lines is controlled with the EBL rotary control and the intervals between the lines adjusted with the VRM ro- tary control (provided that No.2 VRM is ac- tive).

  • Page 40: Zoom, Markers

    1.29 Zoom The zoom function is useful for enlarging an area of interest as large as twice the normal viewing. This performs the range scale re- duction to a half and the offset at the same time. Zoom can be used on ranges other than 0.125, 72, 96, 120 nm.

  • Page 41: User Keys (f1, F2, F3), Function Keys

    1.31 User Keys (F1, F2, F3) The user keys [F1], [F2] and [F3] may be pro- grammed by the operator to display a desired menu. For example, you can program the [F2] key to select target trail time whenever the key is pressed.

  • Page 42

    Adjusting these features on a function key menu changes the original function key set- tings. To restore the original settings for a particular function key, it is necessary to dis- play the relevant function key menu and se- lect appropriate menu options. Table 1-2 FUNC key objectives 1.

  • Page 43: Suppressing Second-trace Echoes, Adjusting Brilliance Of Screen Data

    1.33 Suppressing Second-trace Echoes In certain situations, echoes from very dis- tant targets may appear as false echoes (sec- ond-trace echoes) on the screen. This occurs when the return echo is received one trans- mission cycle later, that is, after a next radar pulse has been transmitted.

  • Page 44: Noise Rejector, Time Alarm, Enhanced Video

    1.35 Noise Rejector The noise rejector suppresses white noise, which appears on the screen as many dots scattered randomly over the display. To suppress white noise: 1. Press the [MENU] key. 2. Press the [5] key twice to show the ECHO SIG menu.

  • Page 45: Degaussing Interval, Navigation Data

    Echo enlarged in bearing and range directions Figure 1-48 How the enhance function works Note: Enhanced video can also be selected with a user key. 1.38 Degaussing Interval The screen is degaussed automatically at certain time intervals, as well as each time the radar is turned on, to demagnetize the CRT screen to eliminate color contamination caused by earth’s magnetism or magnetized...

  • Page 46: Video Contrast, Clutter Sweep, Outputting Target Position

    1.40 Video Contrast The video contrast is adjustable in three lev- els according to the radar video sampling level. Select the level so that the video con- trast feature changes the dynamic range of the video signal to improve picture contrast. Picture shows up most clearly from the back- ground.

  • Page 47: Background Color, Selecting Range Scales

    1.43 Background Color The secondary function of the BRILL control (BKGND COLOR) is to select the color of the background, characters, menu, markers and indications, from the five color combinations shown in the table below. Each press of the control selects one of the five color combina- tions.

  • Page 48: A/d Converter Curve Setting, Enlarging Close-in Targets

    1.46 A/D Converter Curve Setting Video signal threshold level and color output setting (for the CRT) are executed when the video signal is converted from analog to digi- tal. Select the A/D curve according to objec- tive referring to the table below. The default setting is A.

  • Page 49: Alarms

    1.48 Alarms The table below shows the alarm indications which appear on the display screen. u l i u l i u l i u l i Table 1-6 Alarms " ° x " " c i t y l l c t i "...

  • Page 50: Peformance Monitor

    1.49 Peformance Monitor The performance monitor (PM-30 for FR-1710/1725, PM-50 for 1760DS) provides an effec- tive means of general performance check of a radar installation. It works like a transponder. Installed in the proximity of the radar antenna, it is triggered by part of the transmitted micro- wave energy and sends back a coded signal to the antenna for display on the radar screen.

  • Page 51: General

    The IMO Resolu- tion A. 477 (XII) and IEC 936 require the minimum range to be less than 50 m. All FURUNO radars satisfy this requirement. Maximum range The maximum detecting range of the radar,...

  • Page 52: False Echoes

    This is determined by pulselength only. Practically, a 0.08 microsec- ond pulse offers the discrimination better than 35 m as do so with all FURUNO radars. Test targets for determining the range and bearing resolution are radar reflectors hav-...

  • Page 53: Sart (search And Rescue Transponder)

    Target A Target B Target B (Spurious) (True) Figure 2-3 Sidelobe echoes Virtual image A relatively large target close to your ship may be represented at two positions on the screen. One of them is the true echo directly reflected by the target and the other is a false echo which is caused by the mirror effect of a large object on or close to your ship as shown in the figure below.

  • Page 54

    When the range to the SART is reduced to about 1 nm, the radar display may show also the 12 responses generated during the fast sweeps. These additional dot responses, which also are equally spaced by 0.64 nm, will be interspersed with the original line of 12 dots.

  • Page 55: Racon (radar Beacon)

    Radar side lobes As the SART is approached, side lobes from the radar scanner may show the SART re- sponses as a series of arcs or concentric rings. These can be removed by the use of the anti-clutter sea control although it may be operationally useful to observe the side lobes as they may be easier to detect in clut- ter conditions and also they will confirm that...

  • Page 56: Periodic Maintenance Schedule

    MAINTENANCE, TROUBLESHOOTING 3.1 Periodic Maintenance Schedule Periodic checks and maintenance are important for proper operation of any electronic sys- tems. This chapter contains maintenance instructions to be followed to obtain optimum per- formance and the longest possible life of the equipment. WARNING ELECTRICAL SHOCK HAZARD Do not open the equipment.

  • Page 57: Life Expectancy Of Major Parts

    Table 3-1 Maintenance schedule (con’t) s t l - i l t i n e i f ) y l t a i i r t t i n - i l e i f ) y l , s t 3.2 Life Expectancy of Major Parts Table 3-2 Life expectancy of major parts .

  • Page 58: Fuse Replacement, Replacement Of Batteries, Simple Troubleshooting

    3.3 Fuse Replacement Various fuses are used to protect the equip- ment from overvoltage (overcurrent) or equip- ment fault. If the fuse blows find the cause before replacing. If the fuse blows again after replacement, request service. CAUTION Use the proper fuse. Use of a wrong fuse can cause fire or equipment damage.

  • Page 59: Advanced-level Troubleshooting

    3.6 Advanced-level Troubleshooting This paragraph describes how to cure hardware and software troubles which should be car- ried out by qualified service personnel. Note: This radar equipment contains complex modules in which fault diagnosis and repair down to component level are not practicable by users. Serviceman qualification All adjustments of radio transmitter during or coinciding with the installation, servicing, or maintenance which may affect the proper operation must be performed by or under the imme-...

  • Page 60

    Table 3-6 Advanced-level troubleshooting i n i t i s ) . t y l l v i t y t i i f i l i f i l ) t i t r i v i t f i l y t i ) .

  • Page 61

    Table 3-7 Advanced-level troubleshooting (con’t) v i t E " " 1 E " " 2 l e l n i l n i l . y l y l t n i l l i r a i l y t i .

  • Page 62: Diagnostic Test

    3.7 Diagnostic Test A diagnostic test program is provided to en- able testing of major circuit boards in the ra- dar display unit. Note that the normal radar picture is lost during this test. Proceed as follows to execute the diagnostic test: 1.

  • Page 63

    FR-1700 Series TEST 1. Program No. 2. ROM Check 3. RAM Check 4. Antenna Rotation 5. Tx Trigger Frequency 3000Hz 6. Video Level 7. Video Signal 8. Navigation I/O 1 9. Navigation I/O 2 10. NMEA Heading IN 11. LOG Pulse IN ARP Test 1.

  • Page 64

    Select item with tenkey and adjust by VRM knob. CRT ADJUSTMENT 2. H SIZE 3. H POSITION 4. V SIZE 5. V POSITION 6. PINCUSHION 7. BRIGHTNESS Figure 3-3 Display circuit test...

  • Page 65: Parts Location

    Do not touch anode cap or its cable. Figure 4-1 Display unit, right side view Cooling Fan MMS-06C24DS-R01 FR-1710: HV Board 03P9017A FR-1725: HV Board 03P9017B FR-1710/1725: DC-PTU Board 03P9223A AC-PTU Board 03P9228A/B FR-1760DS: DC-PTU Board 03P9223B PARTS LOCATION...

  • Page 66

    GYRO CONVERTER Board (option) 64P1106A Figure 4-3 Display unit, top view Figure 4-4 Display unit, top view SPU Board 03P9230...

  • Page 67

    FR-1760DS Scanner Unit (ATT Board ATT-7362 behind MIC) IF AMP 03P6570 (MBS Board 03P6569 behind IF AMP) J910, P910 J601, P601 Figure 4-5 Scanner unit, left side view RTB Board [C] 03P6666 RELAY Board [A] 03P9004 CR808 Figure 4-6 Scanner unit, right side view J829 R811 R812...

  • Page 68

    FR-1760DS Scanner Unit (con’t) PULSE GENERATOR Board [A] MP-3795 Scanner motor B801 Figure 4-7 Scanner unit, right side view, RF section removed J821 Choke coil L801 Relay K801 K802 K803 PFN Board [C]03P6669 MAG HTR DET Board [A] 03P6827 MD Board 03P6668 Figure 4-8 RF section, rear view Fan motor...

  • Page 69

    FR-1760DS Power Supply Unit TX HV Board (2) 03P6810 Transformer T804 Check meter Switch S801 Hour meter Fuse 801 Fuse 802 Fuse 803 Figure 4-9 FR-1760DS Power supply unit Transmitter section TX HV Board (1) 03P6810 POWER Board 03P6810 Fan motor B801 RELAY Board [A] 03P9003 R813...

  • Page 70

    FR-1710/1725 Scanner Unit IF Board 03P9232 TB Board RF Module 03P9242 RF module (Upper part) S901 MP-3795 Board Motor Bow Side MIC Assy. RU-9253 (For RTR-063) RU-9371 (For RTR-062A) Diode Limitter RU-9099 RFC Board 03P9243...

  • Page 71

    MD Board 03P9244 J811 J812 Module (Lower part) Fan motor assy. 03-1900 Pulse Transformer RT-9025 (For RTR-062A) RT-9023 (For RTR-063) Magnetron E3566 (For RTR-062A) MG5436 (For RTR-063)

  • Page 72: Specifications

    SN4A: 26.0 dB, SN5A: 26.4 dB 51.5 m/s relative FR-1710/1725: 9410 MHz ±30 MHz FR-1760DS: 3050 MHz ±30 MHz FR-1710: 10 kW, FR-1725: 25 kW, FR-1760DS: 60 kW -40 dB or less 60 MHz, Logarithmic Short 1/2, Middle 1 pulse: 27 MHz...

  • Page 73

    (2) Scanning (3) Range scales and ring intervals Range(nm) 0.125 Ring interval(nm) 0.025 No. of Rings Maximum Range: FR-1710: 72 nm, FR-1725: 96 nm, FR-1760DS: 120 nm (4) Range discrimination (5) Bearing discrimination (6) Minimum range Range (nm) 0.25 0.75 0.07 s...

  • Page 74

    (8) Range accuracy (9) Presentation modes (10) Variable Range Markers (11) Electronic Bearing Lines (12) Offcenter 4. POWER SUPPLY (1) DC Source FR-1710/1725: FR-1760DS: (2) AC Source FR-1710: FR-1725: FR-1760DS: Display unit: Antenna power supply unit:100-115 VAC: 3.0 A, 1 phase, 50-60 Hz 5.

  • Page 75

    7. COATING COLOR (1) Display Unit (2) Antenna Unit 8. COMPASS SAFE DISTANCE (1) Display unit (2) Antenna unit FR-1710: FR-1725: FR-1760DS: (3) Antenna power supply unit Standard: 1.20 m To be installed in an exposed area Panel: N3.0, Chassis: 2.5GY5/1.5 N9.5...

  • Page 76

    A/C AUTO control 1-12 A/C RAIN control 1-13 A/C SEA control 1-12 ACQ key 1-20 A/D converter curve setting 1-35 Alarms 1-36 AUDIO OFF key 1-22 Background color 1-34 Battery replacement 3-3 Bearing measurement 1-14 Bearing scale format 1-34 BRILL control 1-3 Brilliance screen 1-3 screen data 1-30...

  • Page 77

    Sidelobe echoes 2-2 Speed input 1-9 STBY/TX key 1-1 Stern marker 1-27 System configuration vi Target alarm acknowledging alarm 1-17 deactivating 1-17 inward, outward alarms 1-17 setting 1-16 Target position output 1-33 Target trails afterglow 1-25 displaying, erasing target trails 1-24 restoring trails 1-24 target gradation 1-24 thin trails 1-25...
