- Page 1 Model 5103 Owner’s Guide...
-
Page 3: Table Of Contents
Contents Warning! Safety first ..................iii What is included ....................1 Important information ..................1 Your warranty...................1 Standard transmitter configuration ...............2 Fcc/id notice ....................3 Caution ....................3 Transmitter functions ..................3 Standard configuration ................3 Using your system ....................6 Active arming ...................6 Passive arming ..................6 Multi-level security arming ................7 Arming while driving .................8 Disarming ....................8... - Page 4 Security & convenience expansions ..............24 Glossary of terms ....................25 Notes ......................29 Limited consumer warranty ................31 reserved. ©2009 Directed Electronics. All rights...
-
Page 5: Warning! Safety First
Warning! Safety first The following safety warnings must be observed at all times: Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer. When properly installed, this system can start the vehicle via a command signal from the remote control transmitter. - Page 6 All installations must be performed by an authorized Directed dealer. OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT- ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY.
-
Page 7: What Is Included
You can print additional or replacement copies of this manual by accessing our web site at www.avital.com. ➢ System maintenance The system requires no specific main te nance. Your remote is pow ered by a small, lightweight 3-volt CR2032 battery that will last approximately one year under normal use. -
Page 8: Standard Transmitter Configuration
Standard transmitter configuration control the Arm and Panic On/Off function. control the Disarm and Panic Off function. control Silent Mode™ and Auxiliary trunk output. control the Remote Start function. pressed together control the Timer mode. pressed together control Turbo/Short Run. �������... -
Page 9: Fcc/Id Notice
➢Fcc/id notice This device complies with Part 15 of FCC rules. Operation is subject to the fol- lowing two con di tions: (1) This device may not cause harmful interference, and (2) This device must accept any in ter fer ence re ceived, including in ter fer ence that may cause undesirable op er a tion. - Page 10 Button Silent Mode™ and an optional auxiliary function are controlled by this button. Silent Mode works by pressing it for less than one second before arming or dis- arming. An optional auxiliary function, such as trunk release, can be controlled by pressing this button for 1.5 seconds.
- Page 11 Buttons The 24 hour remote start timer mode is controlled by pressing these buttons simultaneously. When the feature is activated the parking lights flash fast four times. Once in 24 hour timer mode the system remote starts every 24 hours. Repeat this procedure to turn 24 hour timer mode off.
-
Page 12: Using Your System
Using your system ➢ Active arming You can arm the system by pressing on your trans mit ter for one second. When the system arms, you will hear a short siren chirp and see the parking lights flash once. If the power door locks are con trolled by the system, the doors will also lock. -
Page 13: Multi-Level Security Arming
• If a door is opened, the system will immediately start chirping the siren and flashing the parking lights. Three seconds later, the siren out put changes to a continuous blast. This pro gres sive re sponse gives you time to disarm the sys tem with your trans mit ter if you inadvertently open the door while the system is armed, while still providing instant re sponse (even if the door is immediately closed). -
Page 14: Arming While Driving
➢ Arming while driving Your security system can be armed while driving the vehicle. Press on the transmitter for two seconds while the vehicle is running. The siren will chirp once to indicate that the security system is armed, and then once more to indicate that the ig ni tion is on. -
Page 15: Disarming Without A Transmitter
➢ Disarming without a transmitter If your transmitter is lost or damaged, you can manually disarm your vehicle security system. To disarm the system without a transmitter, you must have the vehicle’s ignition key and know where the Valet switch is located. Be sure to ®... -
Page 16: Panic Mode
➢ Panic mode If you are threatened in or near your vehicle, you can attract attention by trigger- ing the system with your transmitter. Press for two seconds, and you will enter Panic Mode. The siren sounds and the parking lights flash for the programmed siren duration. To stop Panic Mode at any time, press on the remote transmitter again. -
Page 17: Remote Start
Remote start You can remotely start and run your vehicle for a pro gram ma ble period of time. This makes it possible to warm up the engine, and adjust the interior tem per a- ture of the vehicle with the climate control system. If interior heating or cooling is desired, the climate controls must be preset, and the fan blower must be set to the desired level prior to remote starting the vehicle. -
Page 18: Rear Defogger
When you are ready to drive the vehicle: Insert the ignition key and turn it to the On position. Press the brake pedal. Important: If the brake pedal is pressed before the key is in the ON position, the engine will shut down. -
Page 19: Valet Take-Over
To turn the rear defogger output ON: Simultaneously press & release the buttons on the re- mote control. The lights will flash 3 times. The rear defogger output will once again activate when the vehicle is remote started. ������� If the remote start is on, the lights turn off then flash 3-times before returning to normal output. -
Page 20: Timer Mode
➢ Timer mode When you activate timer mode the system automatically starts the vehicle every three hours for a maximum of 6 starts. The pre-programmed engine runtime is 12 minutes. • Press to activate timer mode. The parking lights flash four times, and after a 1 second delay, the engine starts. -
Page 21: Safety Features
Safety features This system has several important safety features to ensure proper operation of the motor and prevent accidental damage to the engine or its components. ➢ Starter anti-grind circuitry Whenever the vehicle is remote started, advanced anti-grind circuitry prevents the starter from engaging, even if the key is turned to the start position. -
Page 22: Nuisance Prevention Circuitry
Nuisance prevention circuitry ® Your system has Directed’s Nuisance Prevention Circuitry (NPC). It pre vents ® annoying repetitive trigger sequences due to faulty door pin switches or en vi ron- men tal con di tions such as thunder, jack ham mers, airport noise, etc. Example If the alarm triggers three times within a 60-minute period and each time the same sensor or switch triggers the alarm, NPC will interpret those triggers as... -
Page 23: Arming Diagnostics
➢ Arming diagnostics If the security system is armed at the same time that an input is active (such as a door opening or sensor triggering), you will hear one siren chirp to indicate arming and a second siren chirp to indicate Bypass Notification. A Bypass Notification chirp means that the security system ignores the input that was active when the system was armed, until that input ceases. -
Page 24: System Status Chirps
➢ System status chirps The siren will chirp when arming/disarming the system. The pattern of chirps will audibly report the system’s status as described below. Action Number of Chirps Description System armed 1 (3-second delay), 1 System armed with Bypass Notification Disarm System disarmed Disarm... -
Page 25: Table Of Zones
Table of zones A zone is represented by the number of LED flashes used by the system to identify a particular type of input. Standard input assignments are listed in the following table, along with spaces to write in any optional sensors or switches that have been installed. -
Page 26: Code Hopping
Code hopping The receiver and transmitters use a math e mat i cal formula called an algorithm to change their code each time the transmitter is used. This tech nol o gy has been de vel oped to increase the security of the unit. The control unit knows what the next codes should be. -
Page 27: Rapid Resume Logic
Rapid resume logic This Directed system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory. This means if the unit is in Valet Mode and the battery is dis con nect ed for any reason, such as servicing the car, when the battery is re con nect ed the unit will still be in Valet Mode. -
Page 28: Programming Options
Programming options Programming options control your system’s normal, operational set-up. Most op- tions do not require additional parts, but some may require installation labor. The following is a list of the programmable options, with the factory settings in Bold. • Active arming (transmitter only) or passive arming (automatic arming 30 seconds after the last door has been closed). - Page 29 30 or 60 seconds: This determines how long the • Full trigger response full triggered sequence lasts. Some states have laws regulating how long a security system can sound before it is considered a nuisance. If your installer is programming the security system with the Directed Bitwriter , the ®...
-
Page 30: Security & Convenience Expansions
Security & convenience expansions Listed below are expansion options avail able to you. Please consult your dealer for a complete explanation of all the options avail able to you. Audio Sensor: Metal glass, glass cracking, breaking glass produce dis tinc tive acoustic signatures. The 506T audio sen sor uses a mi cro phone to pick up sounds, then analyzes them with pro pri etary acoustic software to determine if the glass has been struck. -
Page 31: Glossary Of Terms
Glossary of terms Control Unit: The “brain” of your system. Usually hidden underneath the dash area of the vehicle. The control unit houses the microprocessor which monitors your vehicle and controls all system functions. Input: A physical connection to the system. An input can be provided by a sen- sor, pinswitch or by existing systems in the vehicle, such as ignition or courtesy lights. -
Page 33: Quick Reference Guide
Quick reference guide • Arming To arm, press . When the system arms, you will hear a short chirp, and the parking lights will flash once. • Arming while driving ������� To arm the system while driving, press on your transmitter while the ve- hicle is running. - Page 34 • Timer mode Press . The parking lights flash 4 times, after a 1 second de- lay the engine starts and runs for specified duration. The system will continue to start the engine every three hours (for a maximum of 6 starts) �������...
-
Page 35: Notes
Notes © 2009 Directed Electronics. All rights reserved. - Page 36 Notes reserved. ©2009 Directed Electronics. All rights...
-
Page 37: Limited Consumer Warranty
Limited consumer warranty For a period of one calendar year from the date of purchase of this auto-security device, Directed Electronics, (Directed) promises to the ORIGINAL PURCHASER to repair or replace (at Directed’s election) with a comparable reconditioned model, any Directed unit (hereafter the “unit”), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories which proves to be defective in workmanship or mate- rial under reasonable use, provided the following conditions (herein “Conditions”) are met:... - Page 38 state laws and applicable federal law shall apply and govern the dispute. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES ARE EXCLUDED, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/ OR ABROAD.
- Page 40 The company behind this system is Directed Elec tron ics Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, Directed is ISO 9001 registered.
