FujiFilm PICTROGRAPHY 4500N Instruction Manual

Digital image printer up type
Hide thumbs Also See for PICTROGRAPHY 4500N:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
DIGITAL IMAGE PRINTER
4500N
PICTROGRAPHY
UC Type
First Edition
PP3-B506E

Advertisement

Table of Contents
loading

Related Manuals for FujiFilm PICTROGRAPHY 4500N

Summary of Contents for FujiFilm PICTROGRAPHY 4500N

  • Page 1 INSTRUCTION MANUAL DIGITAL IMAGE PRINTER 4500N PICTROGRAPHY UC Type First Edition PP3-B506E...
  • Page 2 • T o correctly use and obtain optimum performance from the Pictrography 4500N, it is essential that you read this manual thoroughly before using the machine. • S tore this manual at a predetermined place near the Pictrography 4500N so that you can readily refer to it regarding specific operating or handling procedures.
  • Page 3 Laser Radiation Safety Notes on Laser Safety <Laser Radiation Safety> This product is a Class laser device for which biological hazards have not been established. Heed all warnings that appear in device labels or in the Instruction Manual. Laser Radiation Specifications Class Laser Semiconductor laser...
  • Page 4 Laser Warning Labels Label #2 Visible and invisible laser radiation when open and interlock defeated. AVOID DIRECT EXPOSURE TO BEAM Label #1 Visible and invisible laser radiation when open. AVOID DIRECT EXPOSURE TO BEAM...

  • Page 5: About This Manual

    ABOUT THIS MANUAL Operations to be performed by the operator are indicated by step numbers 1, 2, 3, and so on, whereas operations carried out by the machine are marked . [Example] 1. Operate the Host Computer to start printing. The message changes to "Data Busy".
  • Page 6 SECTION 1 GENERAL PRECAUTIONS SECTION 2 COMPONENT NAMES AND FUNCTIONS SECTION 3 OPERATING PROCEDURES SECTION 4 HOW TO USE THE OPERATION PANEL SECTION 5 MAINTENANCE SECTION 6 DONOR/RECEIVER JAM CLEARING PROCEDURES SECTION 7 TROUBLESHOOTING GUIDE MAJOR SPECIFICATIONS APPENDIX...

  • Page 7: Table Of Contents

    Contents SECTION 1 GENERAL PRECAUTIONS ... Operating Environment ... Room Conditions ... Installation Space ... Electrical Hookup ... Donors and Receivers ... Duplication Restrictions ... 11 SECTION 2 COMPONENT NAMES AND FUNCTIONS ... 13 Overview ... 14 Operation Panel ... 16 Alarm ...
  • Page 8 4.15 Network Setting ... 68 4.15.1 Setting Using the Operation Panel ... 68 4.15.2 Setup Using Utility ... 72 SECTION 5 MAINTENANCE ... 83 Regular Maintenance Program ... 84 Side Air Filter Replacement ... 85 Water Filter Replacement ... 86 Auto Calibrator White Board Cleaning ...
  • Page 9 Blank Page.

  • Page 10: Section 1 General Precautions

    SECTION 1 Operating Environment ... 2 Room Conditions ... 4 Installation Space ... 5 Electrical Hookup ... 6 Donors and Receivers ... 7 Duplication Restrictions ... 11 Before using this product, read and understand this section thoroughly. Safety precautions include WARNING and CAUTION. Supplementary explanations for operations are indicated as IMPORTANT or NOTE.

  • Page 11: Operating Environment

    Operating Environment General Precautions Follow the instructions provided in this manual only. WARNING: Use the indicated voltage only. Do not use an extension cord with an insufficient power rating or serially connected extension cords as fire or electrical shock may result. A 2-pin outlet cannot be grounded.
  • Page 12 Do not lean against the machine or sit on it. Do not place heavy objects on the machine or subject it to a large impact. Use Fuji-recommended parts for repairs. If other parts are used, Fujifilm will not ensure the quality of the machine.

  • Page 13: Room Conditions

    Room Conditions For normal and safe operation, install the machine in the following environment. Temperature: 15 C to 28 C (Free from moisture condensation) If the temperature in the room is over 28 C or under 15 C, proper printing quality may not be assured.

  • Page 14: Section 5 Maintenance

    Installation Space Secure the amount of space shown below to ensure the proper operation, replacement of consumables, and maintenance of the machine. IMPORTANT: There is a vent at the rear of the machine. Provide a minimum clearance of 8 in. (20 cm) between the vent and the wall. 21in.(530mm) 62in.(1565mm) 8in.(200mm)

  • Page 15: Electrical Hookup

    Electrical Hookup Connect the power plug directly into a 120V 10V, 60 Hz grounded outlet (3-pin) which has a power rating of 15 A or more. WARNING: DO NOT USE a two-pin power outlet which is not grounded, as an electrical shock may result when short circuiting occurs.

  • Page 16: Donors And Receivers

    Donors and Receivers Use the donors and receivers specified below. Donors Name Abbreviation 323 mm x 92 m (Equivalent to 182 Double Letter Wide sheets) 305 mm x 92 m (Equivalent to 194 Double Letter size sheets) Pictro PZ-D ER 262 mm x 92 m (Equivalent to 266 10 x 12 size sheets) 135 mm x 92 m...
  • Page 17 When storing the donor (the donor magazine) or receiver (the receiver magazine), place it in a horizontal position. If stored in an upright position, the donor/receiver roll may become loose and impossible to pull out of the magazine. IMPORTANT: If a sealed donor magazine/receiver magazine is left in a room for a long period or in a hot and damp place, good printing quality may not be obtained.
  • Page 18 When storing an unsealed magazine (D or R), place it in a cool dark place. It is recommended that the donor/receiver leading end be retained with a rubber band to prevent it from being wound into the magazine. Do not tape down the donor/receiver leading edge because residual tape adhesive may adhere to the edge, contaminating the donor/receiver and causing a malfunc- tion.
  • Page 19 Image quality is guaranteed over the entire sheet except for a 0.2- in. (5-mm) boarder along each sides (0.24 in, (6 mm) in the case of Double Letter wide sheets). 0.2in. (5mm) (0.24in. (6mm) for Double Letter wide sheets) The trailing end of the receiver has an end-detection hole. Therefore, the last print produced at the end of a receiver roll may have a hole in it.

  • Page 20: Duplication Restrictions

    Duplication Restrictions The possession of duplication equipment does not automatically entitle the owner to make copies. There are cases where legal restrictions are enforced. CAUTION: There are items whose duplication is prohibited by law. DO NOT duplicate such items, or make duplicates that may be used for illegal purposes. In order to copy materials that are protected by copyrights, you must first obtain permission from the copyright owner.
  • Page 21 Blank Page.

  • Page 22: Section 2 Component Names And Functions

    SECTION 2 COMPONENT NAMES AND FUNCTIONS Overview ... 14 Operation Panel ... 16 Alarm ... 18 Printing Mechanism ... 20 Power Saving Mode ... 21...

  • Page 23: Overview

    Overview PO2F001J...
  • Page 24 Number Name Front Door Water Bottle Receiver Magazine Compartment Contains the receiver magazine. Water Filter Operation Panel Auto Calibrator Right-hand Side Upper Door Thermal Processing Unit Power Switch Inner Door Lock Lever Thermal Processing Unit Release Lever Front Lower Door Inner Door/Donor Magazine Compartment Refuse Compartment...

  • Page 25: Operation Panel

    Operation Panel Number Name Transfer Monitor ONLINE indicator lamp ONLINE indicator key Message Display Function Indicates by LEDs the processing state of the donor and receiver. Alsming and errors related to the donor, receiver, water, and water filter. Lights when the machine is online and goes off when it is offline. Turns the machine online or offline.
  • Page 26 PREV NEXT Number Name + key / – key MODE key EXEC key DATA lamp Function Press to enter the value for each parameter, including print size and color control. PREV key: Press to return to the previous menu. NEXT key: Press to proceed to the next menu.

  • Page 27: Alarm

    Alarm An alarm sounds under the following conditions. The type of alarm depends on the machine condition. Alarm sound Beep (a single short beep) Beep-beep-beep-beep, beep-beep-beep-beep, ... (four successive short beeps, repeated) Beep, beep, ... (a single long beep, repeated) NOTE: The alarm stops when the door is opened.
  • Page 28 Blank Page.

  • Page 29: Printing Mechanism

    Printing Mechanism Digital image data 1. Data received 1. The digital image data received from the host computer is stored in the image memory. 2. The donor is exposed by laser while being transported. The light quantity is controlled according to the image data.

  • Page 30: Power Saving Mode

    Power Saving Mode Power Saving Mode When the machine is not used for a specific duration (10, 30, or 60 minutes) following a printing operation, the machine automatically decreases the temperature of the thermal processing unit in order to reduce power consumption. Power saving mode is released when any key on the panel is pressed or when a print instruction is issued from the host computer.
  • Page 31 Blank Page.

  • Page 32: Section 3 Operating Procedures

    SECTION 3 Connecting Other Devices ... 24 Machine Startup ... 25 Printing ... 26 3.3.1 Communication Error Display (for ONLINE operation) ... Donor Magazine Replacement ... 27 Receiver Magazine Replacement ... 32 Water Replacement ... 35 Refuse (Used Donor) Disposal ... 38 Turning OFF the Power ...

  • Page 33: Connecting Other Devices

    Make connection to the network when the network setting on PICTROGRAPHY 4500N has been completed. Connect the machine to other devices using the Ethernet cable. Ethernet interfaces that Pictography 4500N is compatible with are as shown below. 10BASE-T (compatible in half duplex mode and full duplex...

  • Page 34: Machine Startup

    Machine Startup Power Switch SelfCheck Data Ready400 LL/DP-W GLOSSY THICK ON LINE DATA Turn the power switch to the ON ( ) position. The operating panel displays "Self Check" and the machine starts the self-check. NOTE: The lower part of the message indicates the size of the donor and the type of the receiver used.

  • Page 35: Printing

    Use the host computer to enter the image data to be printed on the Pictrography 4500N (in online condition). When the entered image data is sent from the host computer to the Pictrography 4500N, the DATA indicator lamp starts blinking. When image data reading is completed, the message changes to "Data Busy"...

  • Page 36: Donor Magazine Replacement

    Donor Magazine Replacement There is a donor end detection hole on the trailing edge of the donor. When this hole is detected by the machine, the trailing edge is discharged as described below. When the D LED (red) lamp comes on in the transfer monitor, replace the donor magazine. When the D LED lamp blinks, it means that the amount of remaining donor is equal to that for the specified number of copies.
  • Page 37 Front Lower Door Inner Door Lock Lever Inner Door Donor Magazine 3.4 Donor Magazine Replacement NOTE: Be sure to replace the donor magazine with the power switch ON ( ). If the power switch is OFF ( replacement. The D LED lamp on the transfer monitor comes on the next time the power switch is turned to ON ( ).
  • Page 38 323mm 305mm 262mm 135mm Partition 3.4 Donor Magazine Replacement Take out the core from the donor magazine and adjust the partition to the size of the donor being used. The size of the donor corresponds to the size of the receiver, as shown in the table below.
  • Page 39 Tape Black Light Blocking Leader 0.8 in. Remove the tape securing the black light-blocking leader and pull out the edge of the film about 0.8 in. (2 cm) from 0.8 in. (2 cm) the donor magazine. Then close the cover and lock both sides.
  • Page 40 Guide Inner Door Lock Lever Inner Door Data Ready400 LL/DP-W GLOSSY THICK 3.4 Donor Magazine Replacement Grasp the donor's leading end and slowly insert the donor magazine along the guide. NOTE: Push the donor magazine all the way in. Close the inner door and rotate the inner door lock lever 90 degrees clockwise.

  • Page 41: Receiver Magazine Replacement

    Receiver Magazine Replacement There is a receiver end detection hole on the trailing edge of the receiver. When this hole is detected by the machine, the receiver's trailing edge is discharged as described below. Replace the receiver magazine when the R LED on the transfer monitor comes on. NOTE: If the donor or receiver magazine is left in a room or in a hot and damp place for a long time, print quality deterioration may result.
  • Page 42 315mm 297mm 254mm 127mm 102mm Partitions 0.8 in. (2 cm) Dip Switch 3.5 Receiver Magazine Replacement Remove the core of the receiver magazine and adjust the partitions to the receiver being used. The size of the receiver must correspond to the donor as shown below. Size of receiver 315 mm (Double Letter Wide,etc.) 279 mm (Double Letter and Letter)
  • Page 43 Guide SelfCheck LL/DP-W GLOSSY THICK Data Ready400 LL/DP-W GLOSSY THICK 3.5 Receiver Magazine Replacement Hold the leading edge of the receiver and slowly insert the receiver magazine along the guide. NOTE: Push the receiver magazine all the way. Close the front upper door. The message changes to "Self Check"...

  • Page 44: Water Replacement

    Water Replacement The Pictrography 4500N uses water to accelerate development. Replace the water in the water bottle when "Warning Change Water" is displayed on the operation panel. When the water level in the water bottle drops due to evaporation or other reasons, or no water bottle is set in the machine, the message changes to "Check Water Tank", and the water bottle...
  • Page 45 Water Supply Hose Water Bottle Stopper Stopper Water Supply Cap Water Inlet Pull out the water supply hose and insert it into the hole of the water coating section. Attach the stopper onto the water bottle and pull out the bottle.
  • Page 46 Water Inlet Water Inlet Upper-limit Line Lower-limit Line Pour water into the water bottle. IMPORTANT: Do not use well water. Use tap water for drinks at a temperature of between 20 C and 40 C. If the water temperature is below 20 C, it may take longer for the machine to become ready for printing;...

  • Page 47: Refuse (Used Donor) Disposal

    Refuse (Used Donor) Disposal Warning Refuse Full Front Lower Door Refuse Compartment Refuse Compartment When the refuse (used donor) compartment is filled with refuse, the machine indicates the necessity for refuse disposal as follows. The refuse LED lamp on the transfer monitor comes on and the message changes to "Warning Refuse Full".
  • Page 48 Refuse SelfCheck Data Ready400 LL/DP-W GLOSSY THICK 3.7 Refuse (Used Donor) Disposal Rotate the handle clockwise to pull out the refuse. NOTE: The refuse should be sent to the place where the donor was purchased, or kept in the donor casing or a cardboard box until sent to a disposal company.
  • Page 49 3.7 Refuse (Used Donor) Disposal Please contact your Fujifilm representative for details on our reclamation program. Please shred any refuse before returning it to the Fujifilm Reclamation Center if you believe such refuse may contain confidential information.

  • Page 50: Turning Off The Power

    Turning OFF the Power ON LINE DATA Power Switch ON LINE DATA To turn the power switch to OFF ( ), follow the steps below. Make sure that LED lamps 1 to 10 on the transfer monitor are off. IMPORTANT: If any of the LED lamps (1 to 10) on the transfer monitor is on, wait until all receivers are discharged.
  • Page 51 Blank Page.

  • Page 52: Section 4 How To Use The Operation Panel

    Checking the Remaining Consumables ... 55 Setting the Consumables Counters ... 57 4.10 Setting the Remaining Quantity of Consumables for Alarms .. 58 4.11 Pictrography 4500N Color Adjustment ... 60 4.12 Color Adjustment Procedures ... 61 4.13 Calibration (Standard Color Condition Setup) ... 62 4.14...

  • Page 53: Menu

    Menu Utility Displayed when OFF LINE is selected. *1 If the remaining quantity counters are set to "off" in the "Configuration" menu, "Counter Display" is not displayed. Counter Display Print Count Version Check Checks the software version. Ver.X.XX – 3D-LUT –...
  • Page 54 Color Control Brightness – 0 Adjusts the brightness of the print image. Contrast – 0 Adjusts the contract of the print image. R.Balance – 0 Adjusts the color balance (Red) of the print image. G.Balance – 0 Adjusts the color balance (Green) of the print image. B.Balance –...
  • Page 55 Configuration Calibration Size – A3W Selects the paper size. StandBy – 30min Selects the time required for the machine to enter power saving mode. Dot/Inch – 400 Selects the resolution (dpi). Alarm – ON Selects buzzer ON/OFF. Margin Control DISP.LANG. –...
  • Page 56 Network Setting Password Inputs passwords used for settings. TCP/IP Selects Enable/Disable for TCP/IP protocol. AppleTalk Selects Enable/Disable for AppleTalk. MAC Address 00:C0:2D:20:XX:XX:XX Displays MAC address for this machine. Mode Setting can be changed to the one whereby degradation of communication speed due to "packet lost"...

  • Page 57: How To Use The Keys

    Select OFFLINE to operate keys on the operation panel. Each mode screen can be called up with the Mode key. The Pictrography 4500N enters ONLINE mode whenever the power switch is turned to ON ( ), or when the cover is closed.

  • Page 58: Changing The Print Size

    Changing the Print Size To change the print size, follow the procedure below. NOTE: The print size can be changed (between Double Letter and Letter) when a 305- mm donor and 279- mm receiver are set. PREV NEXT Configuration PREV NEXT –...

  • Page 59: Changing The Power Saving Mode Timer Setup

    Changing the Power Saving Mode Timer Setup To change the time required for the machine to switch into the power saving mode*, follow the procedure below. The time can be set at 10 minutes, 30 minutes, and 60 minutes. The standard setting is 10 minutes. (The 10-minute setting is recommended.) * Power saving mode: When the machine is left unoperated for a predetermined period of time (10, 30, or 60 minutes), the machine enters power saving mode in order to conserve energy.

  • Page 60: Changing The Resolution (Dpi)

    Changing the Resolution (dpi) To change the resolution (dpi) of the finished print images, follow the procedure below. The resolution can be set at 267 or 400. NOTE: For a resolution of 267 dpi, interpolation is executed. To obtain exact reproduction of fine images, such as a one-dot-width line, select 400 dpi.

  • Page 61: Alarm On/Off

    Alarm ON/OFF Follow the procedure below to activate/deactivate the alarm which sounds when the WARNING indicator on the operation panel is turned on or is blinking, and when a donor/receiver jam occurs. PREV NEXT Configuration PREV NEXT – DP + Size PREV NEXT...

  • Page 62: Fine Adjustment Of Print Image Position

    Fine Adjustment of Print Image Position To adjust the position of a print image, follow the procedure below. NOTE: The X and Y directions with respect to the print output direction are indicated below. Image Area PREV NEXT Configuration PREV NEXT –...
  • Page 63 – PREV NEXT – – 4.7 Fine Adjustment of Print Image Position Enter the margin in the X direction by pressing the + key or – key. Each time the + key or – key is pressed, the margin increases or decreases by one mm. When the keys are held down, the value increases/decreases continuously.

  • Page 64: Checking The Remaining Consumables

    Checking the Remaining Consumables To check the remaining quantity of the donor and receiver and the processing capability available with the currently loaded water, follow the procedure below. NOTE: The counters are reset when a replacement is detected. This menu appears only when "Counter" in "Configuration"...
  • Page 65 PREV NEXT Water Filter 130sheets 4.8 Checking the Remaining Consumables To check the remaining processing capability available with the currently loaded water Press the NEXT key. The message changes to "Water Filter". Check the approximate processing capability available with the currently loaded water. The processing capability is displayed.

  • Page 66: Setting The Consumables Counters

    Setting the Consumables Counters To enable the donor, receiver, and water filter counters and to set the quantity of remaining donor, receiver, and water filter prior to replacement, follow the procedure below. PREV NEXT ON LINE Configuration PREV NEXT – DP + Size PREV...

  • Page 67: Setting The Remaining Quantity Of Consumables For Alarms

    4.10 Setting the Remaining Quantity of Consumables for Alarms To set the alarm to sound when the specified remaining quantity of donor, receiver, or water filter is reached, follow the procedure below. PREV NEXT ON LINE Configuration PREV NEXT – DP + Size PREV...
  • Page 68 To set the alarm level for the remaining quantity of water filter PREV NEXT – 10 + Filter Alarm 4.10 Setting the Remaining Quantity of Consumables for Alarms Press the NEXT key. The message changes to “ F ilter Alarm” . Press + or –...

  • Page 69: Pictrography 4500 Color Adjustment

    4.11 Pictrography 4500N Color Adjustment The Pictrography 4500N is equipped with the functions for calibration, color control, and color matching. To ensure optimum performance on the Pictrography 4500N, each of these functions should be fully understood. Calibration function Maintains the color conditions on the main unit at the optimum level. (See page 62.)

  • Page 70: Color Adjustment Procedures

    4.12 Color Adjustment Procedures Steps to follow Function Item Calibration Color matching On/Off selection Brightness/contrast adjustment Color balance adjustment IMPORTANT: Before making adjustments using the color control function, perform the calibration to make sure that the machine is in appropriate condition. The color control function may be used to produce prints in desired colors.

  • Page 71: Calibration (Standard Color Condition Setup)

    4.13 Calibration (Standard Color Condition Setup) The printer itself can be adjusted to provide consistent prints. Perform a calibration (standard color condition setup) whenever the donor is changed, or within one month after the last calibration. To calibrate (setup standard color conditions), follow the procedure given below:...
  • Page 72 Warmingup Measure Data Receiving Computing Complete MarginError NG Retry from Mesure Density 4.13 Calibration (Standard Color Condition Setup) Measurement Align the calibration pattern with the arrow, then align it to the right-hand end of the Auto-Calibrator insertion inlet. Insert the calibration pattern so that it just touches the end of the inlet.

  • Page 73: Color Control Adjustment Procedures

    ON 4 : The color matching function similar to the "Matching: OFF" on the Pictrography 4000 is activated. : The basic characteristics of the printer are used. Brightness control Press the ONLINE key on the operation panel to switch the machine to OFFLINE mode.
  • Page 74 – Brightness Contrast control PREV NEXT – Contrast – Contrast Red balance control PREV NEXT – R. Balance – R. Balance 4.14 Color Control Adjustment Procedures Press either the + key or – key to adjust the brightness. Each time the + key or – key is pressed, the brightness increases or decreases by 1 level.
  • Page 75 PREV NEXT – G. Balance – G. Balance PREV NEXT – B. Balance – B. Balance 4.14 Color Control Adjustment Procedures Green balance control Press the NEXT key. The message changes to "G.Balance". Press either the + key or – key to adjust the green balance. Each time the + key or –...
  • Page 76 The color matching function suitable for photo images is activated. The sRGB color space is used. The color matching function similar to the "Matching : OFF" on the Pictrography 4000 is activated. The basic characteristics of the printer are used for printing.

  • Page 77: Network Setting

    4.15 Network Setting The following is an explanation of network setting. There are 2 methods of setting the network as shown below. Set it by using the operation panel of PG4500N. Set it by installing the setting software on the connected host (PC). 4.15.1 Setting Using the Operation Panel PREV...
  • Page 78 Press the SEL key. PREV NEXT DHCP/BOOTP – Enable + DHCP/BOOTP – Disable + Press the NEXT key. PREV NEXT – Enable + RARP – Disable + RARP Press the NEXT key. PREV NEXT – Disable + APIPA NOTE: – Enable + APIPA Press the NEXT key.
  • Page 79 PREV NEXT Subnet Mask – 255.255.255.0 PREV NEXT Default Gateway – 192.168.001.001 + PREV NEXT – Enable + AppleTalk – Disable + AppleTalk PREV NEXT Mac Address 00:C0:2D:20:00:07 Press the NEXT key. Screen for setting subnet mask opens. Subnet mask currently set is displayed at this time.
  • Page 80 PREV NEXT – Mode AUTO – Mode 100M FULL – Mode 100M HALF – Mode FULL – Mode HALF PREV NEXT Password – Enable + Password – Disable + PREV NEXT Password 0000 – Press the NEXT key. Screen for communication mode setting will be displayed. While the machine will be used under "AUTO"...

  • Page 81: Setup Using Utility

    4.15.2 Setup Using Utility A connected host (computer) could be a Windows machine or Macintosh machine. After the setting is made, be sure to turn the power of PICTROGRAPHY 4500N OFF, then ON. 4.15.2.1 Setting It up on Windows This section describes how to set up this product when using in the Windows95/98, WindowsNT4.0, Windows2000 or WindowsXP environment.
  • Page 82 5 and step 10 of "3.6.3.1 Make settings in Windows environment" of "Installation guide".) Click PICTROGRAPHY 4500N to select it. (It will be highlighted.) If it shows more than one PICTROGRAPHY 4500N, select the one you wish to set up.
  • Page 83 Click the [Timeout] tab to configure the [Timeout Setup]. Select [System Status] in the [Status] menu to gather the system status. Select [View Settings List] in the [Status] menu to display a list of the settings for the selected PICTROGRAPHY 4500N. 4.15 Network setting...
  • Page 84 AppleTalk can also be used in MacOS X environment. NOTE: The printer driver is compatible to MacOS8.6 and up. 4.15.2.2.1 Setting It Up on MacOS9 or Earlier (The figures are from MacOS9.) It is, therefore, necessary to set up Open Transport, TCP/IP, or Mac TCP.
  • Page 85 It prompts to select the language of your preference. Select [US English] and click the [OK] button. [Software License Agreement] appears. Click the [Agree] button. A dialog box to select the destination folder appears. Click the [Next] button. (The default destination folder is Macintosh HD:PICTROGRAPHY Tools.) When the installation is completed it prompts you to choose to start up or not start up "PG Setup Utility."...
  • Page 86 Ethernet address (MAC address) and the current IP address of the PICTROGRAPHY 4500N on the network. Click the PICTROGRAPHY 4500N to select it. (It will be highlighted.) If it shows more than one PICTROGRAPHY 4500N, select the one you wish to set up.
  • Page 87 Select [System Status] from the [Status] menu to gather the system status. If you select [IP address Setup] from the [Setup] menu with the IP address already configured, a message appears prompting you to select [PICTROGRAPHY Settings] from the [Setup] menu to change it. 4.15 Network setting...
  • Page 88 4.15.2.2.2 Setting It Up on MacOS X (The figures are from MacOS X 10.3.) Insert the User Software CD-ROM into the computer's disc drive to mount the CD-ROM. Double click the CD-ROM icon (PG45NDRV.) Four folders appear. Double click the "Utility" folder. Two folders appear.
  • Page 89 As you will be asked "YES/NO" to start PG Setup Utility, click on "YES" and then click on "COMPLETE" button. It searches for PICTROGRAPHY 4500N on the network and shows it. If there is no display, click on "OPTION", and designate the zone where PICTROGRAPHY 4500N exists.
  • Page 90 Click the PICTROGRAPHY 4500N to select it. (It will be highlighted.) If it shows more than one PICTROGRAPHY 4500N, select the one you wish to set up. Then select [PICTROGRAPHY Settings] from the [Setup] menu. A setup dialog box appears.
  • Page 91 Select [Preferences] from the [Options] menu to configure the settings. Click the "TCP/IP" tab to configure [Broadcast Setup]. Click the "AppleTalk" tab to configure [Network Zone] settings. 4.15 Network setting...

  • Page 92: Section 5 Maintenance

    SECTION 5 MAINTENANCE Regular Maintenance Program ... 84 Side Air Filter Replacement ... 85 Water Filter Replacement ... 86 Auto Calibrator White Board Cleaning ... 89 Scanner Cover Glass Cleaning ... 90...

  • Page 93: Regular Maintenance Program

    Regular Maintenance Program The regular maintenance program is to be conducted by the user is described below. To keep the machine in optimum condition, be sure to perform the regular maintenance shown in the table below. In addition to the regular maintenance program set forth below, a semi-annual maintenance program by a qualified service engineer is available (at a reasonable charge).

  • Page 94: Side Air Filter Replacement

    Side Air Filter Replacement Left Side Air Filter Holder Lock section ;;;; Air Filter ;;;; NOTE: Replace both air filters each time. Press the lock section to open two air filter holders on the left-hand side. Slide the side air filter holders forward and out from the machine.

  • Page 95: Water Filter Replacement

    Water Filter Replacement Warning Change Water Filter Front Upper Door Water Filter Cover When water filter replacement is needed, the following message appears. The " " LED lamp on the transfer monitor comes on, the message displays changes to "Warning Change Water Filter", and the alarm sounds.
  • Page 96 Water filter Water filter element O-ring 5.3 Water Filter Replacement Remove the old water filter. NOTE: The water filter consists of the water filter case and water filter element. When replacing only the water filter element, do Steps 4 to 6. When replacing the entire case, skip Steps 4 to 6 and do Step 7 after Step 3.
  • Page 97 Holder Partition Water Filter Notch Align the new water filter notch with the holder partition and place the new water filter into position. NOTE: Rotate the water filter in both directions to make sure that it is secured firmly. If the water filter moves, reinsert it, making sure the notch and partition are correctly aligned.

  • Page 98: Auto Calibrator White Board Cleaning

    Auto Calibrator White Board Cleaning Slide the whiteboard cover on the top of the auto calibrator towards the right and remove it. Clean the whiteboard with the supplied cotton swab. CAUTION: Take care not to scratch the whiteboard. Reinstall the whiteboard cover by sliding it towards the left. NOTE: Push the whiteboard cover all the way in until it clicks.

  • Page 99: Scanner Cover Glass Cleaning

    Scanner Cover Glass Cleaning If white stripes appear on the prints in the feed direction, follow the procedure below to clean the cover glass. Knob Scanner Cleaner Open the front lower door. Remove the knob and open the scanner cleaner cover. Move the scanner cleaner in and out a few times to clean the cover glass.

  • Page 100: Section 6 Donor/Receiver Jam Clearing Procedures

    SECTION 6 DONOR/RECEIVER JAM CLEARING PROCEDURES Clearing Donor/Receiver Jams ... 92 Jamming at Location "1" ... 94 Jamming at Location "2" ... 98 Jamming at Location "3" ... 99 Jamming at Location "6" ... 101 Jamming at Locations "7 and 8" ... 103 Jamming at Locations "4 and 5"...

  • Page 101: Clearing Donor/Receiver Jams

    Clearing Donor/Receiver Jams If the donor or receiver fails to be properly transported during printing, the machine stops and the following indications are made. The operation panel indicates a donor/receiver jam has occurred. A number or letter blinks in the monitor to indicate the location of the donor/receiver jam. The alarm sounds (four successive short beeps, repeated).
  • Page 102 Transfer display Remove the magazine. Pull out the donor's leading edge about 2 cm and insert the magazine again. IMPORTANT: If the leading edge is torn or bent, cut off the torn or bent portion with (+1) (+6) Rotate the "J1" knob in the direction indicated by the arrow. Open the left-hand upper side door and open the "J2"...

  • Page 103: Jamming At Location "1

    Jamming at Location "1" Inner Door Lock Lever Inner Door Donor Magazine Open the lower front door. Rotate the inner door lock lever 90 upward and open the inner door. Slowly pull out the donor magazine. NOTE: If the leading end of the donor gets caught and cannot be pulled out, push the donor magazine back in and do Steps 10 to 18.
  • Page 104 Guide Inner door lock lever Inner door 6.2 Jamming at Location "1" Hold the donor's leading end and slowly insert the donor magazine along the guide. NOTE: Insert the donor magazine all the way in. IMPORTANT: Inserting the magazine with the donor's leading end bent may cause the equipment to malfunction.
  • Page 105 Screw Manual Cutter SelfCheck Warning Check Donor - Magazine If the leading end of the donor gets caught and the donor magazine cannot be pulled out, do the following steps. Loosen the screw securing the knob [J12], pull the manual cutter towards you, and cut off the donor.
  • Page 106 Top Plate Knob Notch Leading End Portion of Donor After Steps 10 to 18, do Steps 6 to 9, and then insert the donor magazine. Donor Cut Slantwise 6.2 Jamming at Location "1" Pull the latch at the top of the donor insertion section towards you, and open the top plate downwards.

  • Page 107: Jamming At Location "2

    Jamming at Location "2" Left-hand Side Upper Door Front Upper Door "J2" guide "J1" knob Open the front upper door and left-hand side upper door. Rotate the "J1" knob clockwise while pushing down the "J2" guide to remove the jammed donor. IMPORTANT: When removing a jammed donor or receiver, use care not to tear it.

  • Page 108: Jamming At Location "3

    Jamming at Location "3" "J11" lever Thermal Processing Front Upper Unit Door Right-hand Side Upper Door Water Coating Section Donor "J3" knob Open the front lower door, raise the thermal processing unit release lever "J11", and slowly open the thermal processing unit to the right.
  • Page 109 Close the right-side upper door and close the thermal processing unit. Close the front upper door. 6.4 Jamming at Location "3"...

  • Page 110: Jamming At Location "6

    Jamming at Location "6" Receiver Magazine Front Upper Door Left-hand Side Upper Door Receiver "J6" guide 0.8 in. (2 cm) Open the front upper door and take out the receiver magazine. Open the left-hand side upper door. Push down the "J6" guide and remove the jammed receiver. IMPORTANT: Take care not to soil the receiver when handling the re- ceiver magazine.
  • Page 111 Adjust the donor so that about 0.8 in. (2 cm) protrudes from the receiver magazine. 0.8 in. (2 cm) Cut the leading end square. Make sure that the width of the protruding end does not vary by more than 0.12 in. (3 mm).

  • Page 112: Jamming At Locations "7 And 8

    Jamming at Locations "7 and 8" "J11" lever Thermal Processing Front Lower Unit Door Right-hand Side Upper Door "J7" knob "J8" guide Open the front lower door, raise the thermal processing unit release lever "J11", and slowly open the thermal processing unit to the right.

  • Page 113: Jamming At Locations "4 And 5

    Jamming at Locations "4 and 5" "J11" lever Thermal Processing Front Lower Unit Door Refuse Compartment "J4" knob Open the front lower door, raise the thermal processing unit release lever "J11", and slowly open the thermal processing unit to the right. CAUTION: The thermal processing unit is hot.

  • Page 114: Jamming At Locations "5 And 9

    Jamming at Locations "5 and 9" "J11" lever Thermal Processing Front Lower Unit Door "J5" knob Refuse Compartment "J9" guide Open the front lower door, raise the thermal processing unit release lever "J11", and slowly open the thermal processing unit to the right. CAUTION: The thermal processing unit is hot.
  • Page 115 6.8 Jamming at Locations "5 and 9" Replace the refuse compartment to its original position and close the front lower door.

  • Page 116: Jamming At Location "10

    Jamming at Location "10" Left-hand side lower door "J10" guide Remove the print tray. Open the left-hand side lower door. Push up the "J10" guide to remove the jammed receiver. Close the left-hand side lower door.
  • Page 117 Blank Page.

  • Page 118: Section 7 Troubleshooting Guide

    SECTION 7 TROUBLESHOOTING GUIDE When a Problem Occurs... 110 Error Code Display ... 111...

  • Page 119: When A Problem Occurs

    After the power is set to ON ( ), a "Warning Donor Empty" or "Warning Paper Empty" error appears in the display. The host computer is used to start a print job, but the printer does not respond. Possible Cause Power switch is not turned Turn the power switch to ON ( ).

  • Page 120: Error Code Display

    Error Code Display Actions to be taken when E and J errors are indicated When the display shows "Service" and an error code (E011 to E481) (J60-1 to J79-2), the machine is in an abnormal condition. Service Power Switch E011 Error code When the display shows "Service"...
  • Page 121 Actions to be taken when a C error is occurs If an error code (Cxxx-x) appears on the right-hand side of the operation panel, clear it by doing the action indicated in the table below. If the action does not correct the error, or if the error occurs frequently, contact your dealer.

  • Page 122: Major Specifications

    MAJOR SPECIFICATIONS Pictrography 4500N Major Specifications Item Name Pictrography 4500N Model Number PG 4500N Printing System Laser-exposure thermal processing transfer method Maximum Image Area 459 mm x 309 mm (Double Letter wide sheets) Resolution 267 and 400 dpi, selectable Number of Colors supported 16.7 million colors, 256 gradations for each cyan, magenta, and yellow...
  • Page 123 Consumables Donor PZ Donor Receiver PZ paper, Standard thickness, glossy, with backprinting PZ paper, Standard thickness, glossy, with backprinting PZ paper, Standard thickness, glossy, with backprinting PZ paper, Standard thickness, glossy, with backprinting PZ paper, Standard thickness, glossy, with backprinting PZ paper, Standard thickness, semi-glossy, with backprinting PZ paper, Standard thickness, semi-glossy, with backprinting PZ paper, Standard thickness, semi-glossy, with backprinting...

  • Page 124: Appendix

    APPENDIX...
  • Page 125 APPENDIX Maximum number of pixels per print size Border Receiver size Double Letter Wide Bordered (3 mm) 12 x 18 Bordered (3 mm) Bordered (3 mm) Letter Wide Borderless Double Letter Bordered (3 mm) Borderless Letter Bordered (3 mm) 10 x 12 Borderless Bordered (3 mm) Borderless...
  • Page 126 Print sizes Paper size Receiver size Border Double Letter Wide Bordered (3 mm) 465x315 12 x 18 Bordered (3 mm) 457x315 255x315 Letter Wide Bordered (3 mm) 432x279 Borderless Double Letter Bordered (3 mm) 432x279 Letter Borderless 216x279 Bordered (3 mm) 216x279 10 x 12 Borderless...
