Table of contents Overview.................................3 Technician Notes..............................3 Disassembly Instructions............................3 Reassembly Instructions ............................3 Required Tools ...............................3 Hazardous Voltage ..............................4 Avoid Electrostatic Discharge..........................4 Power Supply Unit ..............................4 Removing the Battery.............................5 Removing the Memory Module ..........................6 Removing the Hard Disk Drive ..........................7 Removing the CPU..............................8 Removing the Keyboard............................9 Removing the Optical Disk Drive..........................10 Removing the LCD Module ..........................11...
Furthermore, the screws that are removed are shown next to the image of the parts themselves. NEC reserves the right to make changes to the Versa M440/EasyNote H5 chassis without notice. Technician Notes Only technicians authorized by NEC Computers International BV should attempt to repair this equipment.
WARNING Hazardous Voltage Ensure that the computer is disconnected from its power source and from all There is hazardous voltage present inside the computer telecommunications links, networks, or modem when it is connect to an AC supply, even when the lines whenever the chassis cover is removed.
Removing the Battery Perform the following steps to remove the battery: 1. Make sure to power off the Versa M440/EasyNote H5. 2. Turn the unit upside down. 3. Unscrews the bottom cover door and slide it out of its place as the arrow shows in Fig. 1 M2.5x7 Black...
Removing the Memory Module To remove the Memory Module, first remove the battery (see Removing the Battery), then perform the following steps: 1. Unclip the memory module as shown in Fig. 3 Fig. 3 Removing the memory module 2. Remove the memory module from its slot and put it aside. NEC Versa M440/PB Easy Note H5 Disassembly Manual Page 6...
Removing the Hard Disk Drive To remove the hard disk drive, first remove the battery (see Removing the Battery), then perform the following steps: 1. Remove the screws as shown in Fig. 4 M2.5x5 Silver Fig. 4 Screw retaining the HDD module 2.
Removing the CPU To remove the CPU first remove the battery (see Removing the Battery) then perform the following steps: 1. Unscrew screws on CPU Heat Sink in descending order (5 4 3 2 1) as shown in Fig. M2.5x5 Silver Fig.
Removing the Keyboard To remove the Keyboard, first remove the battery (see Removing the Battery), then perform the following steps: 1. Release the keyboard from the base unit by push KB lock with flat screws driver as shown in Fig. 8 Fig.
Removing the Optical Disk Drive To remove the ODD, first remove the battery (see Removing the Battery) then perform the following steps: 1. Flip over the unit, unscrew and pull the ODD module out from the base unit as shown in Fig.
Removing the LCD Module To remove the LCD Module first remove the battery (see Removing the Battery) and remove the Keyboard (see Removing the Keyboard) then perform the following steps: 1. Remove the hinge cover as shown in Fig. 11 M2x3 Black Fig.
Page 12
3. Release two screws at both side of LCD hinge, remain two outer screws attached. M2.5 x 7 Silver Fig. 13 Removing screws at LCD hinge 4. Open up the LCD panel at 45 then remove two outer screws on LCD hinge. M2.5 x 7 Silver Fig.
Removing the LCD Panel To remove the LCD panel, first remove the LCD module (see Removing the LCD Module), then perform the following steps: 1. Use a pin to remove the rubber cover on the LCD module as shown in Fig. 15 2.
Page 14
3. Carefully release LCD Bezel form LCD module as shown in Fig. 16 Fig. 16 Removing the LCD Bezel 4. Release the inverter board by remove the screw and disconnect all connectors as shown in Fig. 17 M2x5 Silver Fig. 17 Removing the Inverter Board NEC Versa M440/PB Easy Note H5 Disassembly Manual Page 14...
Page 15
5. Release six screws at the side of the LCD Penal and two screws on LCD Hinge. A = M2x5 Silver B = M2.5 x 5 Silver Fig. 18 Removing the LCD Panel hinges 6. Carefully lift up the LCD panel. 7.
Removing the Bottom Cover To remove the Top Cover , first remove the battery (see Removing the Battery), remove the Optical Disk Drive (see Removing the Optical Disk Drive) then perform the following steps: 1. Remove all screws on the bottom of the base unit as shown in Fig. 20 A = M2.5x7 Black B = M2.5 x 5 Silver...
3. Carefully lift up bottom cover from base unit as shown in Fig. 22 and place it aside. Fig. 22 Lifting up the Bottom cover Removing the MDC Modem To remove the MDC Modem, first remove the Bottom Cover (see Removing the Bottom Cover) then perform the following steps:...
Removing the Chipset Heat Sink To remove the Chipset heat sink, first remove the Bottom cover (see Removing the Bottom Cover) then perform the following steps: 1. Unscrew the screws on the Chipset Heat sink in descending order (4 3 2 1) disconnect the fan connector as shown in Fig.
Removing the Multi card reader To remove the Multi card reader, first remove the Hard Disk Drive (see Removing the Hard Disk Driver ) then perform the following steps: 1. Unscrew the screws on the Multi Card Reader and disconnect it as shown in Fig. 25 M2x4 Silver Fig.
Removing the Main Board To remove the Main Board, first remove the Bottom cover (see Removing the Bottom Cover) then perform the following steps: 1. Remove the right hinge cover as shown in Fig. 26 M2x3 Black Fig. 26 Removing the right hinge cover 2.
Page 21
3. Remove the Hex screws from the VGA Port as shown in Fig. 28 A = M2.5x6 Silver B = M2.5x9 Silver C = M2.5x19.5 Silver Fig. 28 Main Board 4. Release Hex screws from VGA and Parallel Port M2.5x10 Silver Fig.
Page 22
5. Pull the plastics part near to audio port outward to release Main Board and carefully lift up the Main Board as shown in Fig. 30 Fig. 30 Lifting up Main Board NEC Versa M440/PB Easy Note H5 Disassembly Manual Page 22...
Removing the Top Shield To remove the Top Shield, first remove the Main Board (see Removing the Main Board), then perform the following steps: 1. Remove screws on top cover as shown in Fig. 31 Fig. 31 Top Cover 2. Unscrew all screws and disconnect all cable on the Top Shield as shown in Fig. 32 A = M2.5 x 5 Silver B = M2.5x7 Black...
4. Release the Switch Board and LED Board on Top Shield by remove four screws encircle in Fig. 33 M2x3.5 Silver Fig. 33 Switch Board and LED Board Removing the Touch Pad To remove the touch pad, first remove the top shield (see Removing the Top Shield ) then perform the following steps:...
Removing the Speaker Assembly To remove the Speaker Assembly, first remove the Main Board (see Removing the Main Board) then perform the following steps: 1. Remove the screws holding Speaker Assembly as shown in Fig. 36 M2x3 Black Fig. 36 Speaker Assembly 2.
