Baxi GA Combi & System Boiler Range Specifications page 18

Baxi Megaflo System Compact GA
Key components and fitting dimensions
4
PCB with 'THINK Intelligence' within
1
2 Gas valve
2 Speed Grundfos pump
3
The THINK combustion management system utilises key components in the boiler
to manage the combustion process, delivering lower carbon emissions, reduced
wear and tear and lower fuel bills.
18
402050-06 Baxi range guide.indd 18
2
3
1
5
Cupboard fit dimensions
4
5 Low lift weight - from 32.5kg
5mm Min 390mm
(450mm - 32kW model)
162mm
106mm
450mm Min
For servicing
purposes
5mm Min
*
290mm 290mm
In operation
(345mm - 32kW model)
*300mm and 355mm (32kW) with control panel flap
For technical enquiries e-mail info@baxi.co.uk
5mm Min
175mm Min
(300mm Min if
using 80/125mm
flueing system)
700mm
(763mm -
32kW model)
150mm Min
At leas t 1.5°
