Page 1 ’ ’ ’...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler LLC shall be deemed to be deleted and the features and equipment that are either standard or op- name Chrysler Canada Inc.
Page 3: Introduction
TABLE OF CONTENTS SECTION PAGE ............. 3 INTRODUCTION .
Page 5: Table Of Contents
INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION HOW TO USE THIS MANUAL This Owner’s Manual has been prepared with the assis- Consult the Table of Contents to determine which section tance of service and engineering specialists to acquaint contains the information you desire. you with the operation and maintenance of your vehicle. The detailed Index at the back of this Owner’s Manual It is supplemented by a Warranty Information Booklet contains a complete listing of all subjects.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Remote Starting System — If Equipped ..28 Wireless Ignition Node (WIN) .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Sliding Side Door ..... . . 42 Enhanced Seat Belt Use Reminder System (BeltAlert ) .
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 Rear Seat Delete Feature (Commercial Vehicles Safety Tips ......94 Only) —...
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Remote Keyless Entry (RKE) transmitter with integrated ignition key and a Wireless Ignition Node (WIN) with integral ignition switch. You can insert the double-sided key into the ignition switch with either side up.
Page 15 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Integrated Ignition Key The integrated ignition key operates the ignition switch. It also contains the Remote Keyless Entry (RKE) trans- mitter and a Valet Key, which stores in the rear of the RKE transmitter.
Page 16 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Tip Start Feature WARNING! 1. Do not press the accelerator pedal during this process. NEVER leave children alone in a vehicle. Leaving 2. Insert the integrated ignition key into the ignition unattended children in a vehicle is dangerous for a switch.
Page 17: Sentry Key Immobilizer System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Key-In-Ignition Reminder the vehicle. The system will shut the engine off in two If you open the driver’s door with the integrated ignition seconds if an invalid RKE transmitter is used to start the key in the ignition, a chime will sound to remind you to engine.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: the vehicle. Once an RKE transmitter is programmed to a The Sentry Key Immobilizer system is not compatible vehicle, it cannot be reprogrammed to any other vehicle. with aftermarket remote starting systems. Use of these CAUTION! systems may result in vehicle starting problems and loss of security protection.
Page 19 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 NOTE: When having the Sentry Key Immobilizer 3. Insert a blank integrated key into the ignition switch system serviced, bring all vehicle RKE transmitters with and turn the ignition switch to the ON position within you to the authorized dealer.
Page 20: Vehicle Security Alarm System - If Equipped
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If a programmed key is lost, see your authorized VEHICLE SECURITY ALARM SYSTEM — IF dealer to have all remaining keys erased from the sys- EQUIPPED tem’s memory. This will prevent the lost key from The Vehicle Security Alarm system monitors the vehicle starting your vehicle.
Page 21 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 Arming The System NOTE: Remove the key from the ignition switch and either press The driver’s door key cylinder and the liftgate button a power door lock switch while the driver or passenger on the RKE transmitter cannot arm or disarm the door is open, or press the LOCK button on the Remote system.
Page 22: Illuminated Entry System - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the Vehicle Security Alarm system is armed and the ILLUMINATED ENTRY SYSTEM — IF EQUIPPED battery becomes disconnected, the system will remain The courtesy lights will turn on when you use the armed when the battery is reconnected;...
Page 23: Remote Keyless Entry (Rke) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 REMOTE KEYLESS ENTRY (RKE) — IF Using the RKE Transmitter EQUIPPED Three-button RKE transmitters will provide basic UN- This system allows you to lock or unlock the doors and LOCK, LOCK and PANIC functions. liftgate, and activate the Panic Alarm, optional power liftgate, left power sliding door, and right power sliding door from distances up to about 23 ft (7 m) using a...
Page 24 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE (optional), power sliding doors, Remote Start feature Remote Unlock Doors and Liftgate (optional). Some features can be programmed to the Press and release the UNLOCK button on the RKE customers preferences. For example, flash headlights or transmitter once to unlock the driver’s door or twice to sound horn on LOCK.
Page 25 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 For vehicles not equipped with the EVIC, the Remote Express Down Window Feature Unlock feature can be enabled or disabled by perform- This feature allows you to remotely lower both front door ing the following steps: windows at the same time.
Page 26 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. While the LOCK button is pressed (after five seconds) NOTE: When you turn off the Panic Alarm by pressing press the PANIC button. Release both buttons. the PANIC button a second time, you may have to be closer to the vehicle due to the Radio Frequency (RF) The Sound Horn with Remote Key Lock feature can be noises of the system.
Page 27 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 If equipped with a rear interior switch on the left rear Turn Off Flash Lights with RKE Lock — If pillar, pushing this switch once will close the liftgate only. Equipped The liftgate cannot be opened from this switch. If desired, the Flash Lights with RKE Lock feature can be turned on and off by performing the following steps: Open/Close Power Left Power Sliding Door —...
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The table below explains the Lamp Flash options. Replacing the RKE Transmitter Battery The recommended replacement battery is one CR2032 Which Turn Number of Function battery. Signal Lamps Flashes Lock NOTE: Unlock 1st Press Left Side Perchlorate Material —...
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 3. Reposition the access door panel over the battery opening and snap into place. General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: This device may not cause harmful interference.
Page 30: Remote Starting System - If Equipped
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE STARTING SYSTEM — IF EQUIPPED Trunk closed The Remote Starting system conveniently starts the en- Hazard switch off gine from outside the vehicle by using the Remote Keyless Entry (RKE) transmitter while maintaining the Brake switch inactive (brake pedal not pressed) Vehicle Security Alarm system.
Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 For security, power window and power sunroof op- eration (if equipped) are disabled when the vehicle is in the Remote Start mode. The engine can be started two consecutive 15-minute cycles with the RKE transmitter. However, the ignition switch must be turned to the ON position before you can repeat the start sequence.
Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Exit Remote Start Mode and Drive the Vehicle The engine stalls or engine speed exceeds 2500 rpm Before the end of the 15-minute cycle, press and release Any engine warning lights come on the UNLOCK button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm (if The hood is opened...
Page 33: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 When to Reset Remote Start The vehicle can be started remotely up to a maximum of two times. The vehicle is also allowed a maximum of one failed start, where the Remote Starting sequence was initiated but the engine stopped cranking without start- ing.
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! For personal security and safety in the event of an accident, lock the vehicle doors as you drive as well as when you park and leave the vehicle. When leaving the vehicle always remove the key from the ignition switch, and lock your vehicle.
Page 35: Power Door Locks - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 Power Door Locks — If Equipped If you press the power door lock switch while the key is A power door lock switch is on each front door trim in the ignition, and any front door is open, the power panel.
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lock Doors Automatically — If Equipped If the Lock Doors Automatically feature is enabled, your door locks will lock automatically when the vehicle’s speed exceeds 15 mph (24 km/h). The Lock Doors Automatically feature is enabled when your vehicle is shipped from the assembly plant and can be disabled by using the following procedure: On vehicles equipped with the optional Electronic...
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 3. Place the key into the ignition. The Lock Doors Automatically at 15 mph (24 km/h) feature can be reactivated by repeating the above men- 4. Within 15 seconds, cycle the ignition key from the tioned procedure or by performing the procedure in the LOCK position to the ON/RUN position a minimum of EVIC (if equipped), Personal Settings (Customer-...
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Unlock Doors Automatically On Exit feature can be 7. To reactivate this feature, repeat the above steps. enabled or disabled by performing the following proce- 8. If a chime is not heard, the program mode was dure: canceled before the feature could be changed.
Page 39: Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 The Remote Power Unlock On First Press feature can be WINDOWS enabled or disabled by performing the following proce- Power Vent Windows — If Equipped dure: Switches on the driver’s door trim panel let the driver 1.
Page 40: Power Windows
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Windows You can control either the front or rear windows using switches located on the driver’s door trim panel. The switches will operate only when the ignition switch is in the ON or ACC position and during power accessory delay.
Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 Power Window Lockout Switch — If Equipped and locks and unlocks all doors. The switch will operate The driver may lock out all power windows by depressing only when the ignition switch is in the ON or ACC the bar switch just below the power window switches.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Sliding Side Door Power Window Switch NOTE: Please note that the sliding door windows do Second row passengers may power the sliding door not fully recline, stopping several inches above the window by a single switch on the door handle assembly. window sill.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Auto Up Feature With Anti–Pinch Protection — If Any impact due to rough road conditions may trigger Equipped the auto reverse function unexpectedly during auto- The front Driver switch may be equipped with an Auto closure.
Page 44: Sliding Side Door
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Push the window switch down firmly to the second SLIDING SIDE DOOR detent to open the window completely and continue to The sliding door may be opened from the inside or the hold the switch down for an additional two seconds after outside.
Page 45: Power Sliding Side Door - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 There is a hold-open latch that is activated when the overhead console switch, or rear door switch. Pulling the sliding door is fully opened. This latch will keep your inside or outside power sliding door handle will also sliding door open on any incline.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To avoid unintentional operation of the power sliding doors from the rear seats, press the power sliding door master lock button, located in the overhead console, to disable the switches and handles for the rear seat passen- gers.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 door switch is pressed. To close the door, wait until it Power Sliding Side Door Open Flash is fully open and then press the switch again. The left and right exterior hazard lights will flash for 12 seconds when either sliding door is opened.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Sliding Side Door Master Lock Switch The power sliding side door may also be opened by pressing the switches on the overhead console or the switch located on the trim panel just in front of the sliding door.
Page 49: Sliding Side Door Child Protection Lock
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 Sliding Side Door Child Protection Lock To provide a safer environment for small children riding in the rear seats, the sliding doors are equipped with a Child Protection Door Lock system. NOTE: When the Child Protection Door Lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked position.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE When the Child Protection Door Lock system is en- WARNING! gaged, (even if the inside door lock is in the unlocked position) the door can be opened only by using the Avoid trapping anyone in the vehicle in a collision. outside door handle, the RKE transmitter, the switches Remember that the sliding doors can only be opened on the overhead console or the switches located on the...
Page 51: Liftgate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 NOTE: LIFTGATE After setting the Child Protection Door Lock system, On vehicles equipped with power locks, the liftgate can always test the door from the inside to make certain it be unlocked using the Remote Keyless Entry (RKE) is in the desired position.
Page 52: Power Liftgate - If Equipped
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Liftgate — If Equipped The power liftgate may be opened manually or by using the button on the Remote Keyless Entry (RKE) transmit- ter. Press the button on the transmitter twice within five seconds, to open the power liftgate.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Overhead Console Master Power Switch Liftgate Rear Switch When the RKE transmitter button is pressed and the 1 — Left Door 3 — Right Door 2 — Liftgate 4 — Master Lock Flash Lights feature is enabled, the tail lights will flash to signal that the liftgate is opening or closing.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The power liftgate must be in the full open or close WARNING! positions for any of the buttons to operate. If the liftgate is not in the full open or close positions, it must During power operation, personal injury or cargo be opened or closed manually.
Page 55: Storage Bin Safety Warning
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 If the power liftgate encounters multiple obstructions STORAGE BIN SAFETY WARNING within the same cycle, the system will automatically Safety Warning stop and must be opened or closed manually. WARNING! WARNING! Always close the storage bin covers when your Driving with the liftgate open can allow poison- vehicle is unattended.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) Do not operate the storage bin covers while the vehicle is in motion. Do not use a storage bin latch as a tie down. CAUTION! The storage bin cover must be flat and locked to avoid damage from contact with the front seat tracks, which have minimal clearance to the cover.
Page 57: Occupant Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 OCCUPANT RESTRAINTS Front seat belt retractors incorporate pretensioners to Some of the most important safety features in your enhance occupant protection by managing occupant vehicle are the restraint systems: energy during an impact event. Three-point lap and shoulder belts for all seating All seat belt systems (except the driver’s, Swivel n’...
Page 58: Lap/Shoulder Belts
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Please pay close attention to the information in this Research has shown that seat belts save lives, and they section. It tells you how to use your restraint system can reduce the seriousness of injuries in a collision. Some properly to keep you and your passengers as safe as of the worst injuries happen when people are thrown possible.
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 WARNING! WARNING! (Continued) Wearing your belt in the wrong place could make It is extremely dangerous to ride in a cargo area, your injuries in a collision much worse. You might inside or outside of a vehicle. In a collision, people suffer internal injuries, or you could even slide out riding in these areas are more likely to be seri- of part of the belt.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. The seat belt latch plate is near the seatback of the WARNING! front seats and next to your arm in the rear seats. Grasp the latch plate and pull out the belt. Slide the latch plate A belt that is worn under your arm is very danger- up the webbing as far as necessary to allow the belt to go ous.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 3. When the belt is long enough to fit, insert the latch WARNING! plate into the buckle until you hear a “click”. A belt that is buckled into the wrong buckle will not protect you properly.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your WARNING! abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, A lap belt worn too high can increase the risk of tilt the latch plate and pull on the lap belt.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 is long enough to fit, insert the large latch plate into the WARNING! buckle until you hear a “click.” The retractor should withdraw any slack in the belt. A frayed or torn belt could rip apart in a collision and leave you with no protection.
Page 64: Automatic Locking Retractors (Alr) Mode - If Equipped
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE As a guide, if you are shorter than average you will How to Use the Automatic Locking Mode prefer a lower position, and if you are taller than average 1. Buckle the combination lap/shoulder belt. you will prefer a higher position.
Page 65: Enhanced Seat Belt Use Reminder System (Beltalert )
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 by assuring that the belt is tight about the occupant early Once the warning is triggered, BeltAlert will continue to in a collision. Pretensioners work for all size occupants, chime and flash the Seat Belt Warning Light for 96 sec- including those in child restraints.
Page 66: Seat Belts And Pregnant Women
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Turn the ignition switch to the ON position (engine Seat Belts and Pregnant Women does not need to be running), and wait for the Seat Belt We recommend that pregnant women use the seat belts Warning Light to turn off.
Page 67: Supplemental Restraint System (Srs) - Airbag
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 The front airbags have a multistage inflator design. This WARNING! may allow the airbag to have different rates of inflation that are based on collision severity and occupant size. Using a seat belt extender when not needed can increase the risk of injury in a collision.
Page 68: Airbag System Components
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag System Components Supplemental Seat Side Airbag Inflatable Curtains The airbag system consists of the following: (SABIC) (if equipped) Occupant Restraint Controller (ORC) Front Seat Airbag Features The front airbag system has dual-stage driver and front Airbag Warning Light passenger airbags.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Driver Airbag Special Features WARNING! Driver airbag deployment and force level is controlled by the driver’s seat position as well as impact severity. Use Do not put anything on or around the airbag of special inflators result in a very compact driver’s side covers or attempt to open them manually.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Side Airbag Inflatable Curtain WARNING! (SABIC) — If Equipped SABIC Airbags offer side-impact and vehicle rollover If your vehicle is equipped with left and right Side protection to front and rear seat outboard occupants in Airbag Inflatable Curtain (SABIC), do not stack addition to that provided by the body structure.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 collisions, both the front and side airbags may be trig- ride properly buckled up in the rear seat. Never allow gered. However, even in collisions where the airbags children to slide the shoulder belt behind them or under work, you need the seat belts to keep you in the right their arm.
Page 72: Airbag Deployment Sensors And Controls
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the airbag system in this vehicle needs to be modified WARNING! (Continued) to accommodate a disabled person, contact the Customer Side airbags also need room to inflate. Do not lean Center. Phone numbers are provided under If You Need against the door.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 or ON position. These include all of the components It also includes diagnostics that will illuminate the instru- listed above except the steering wheel and column, ment cluster Airbag Warning Light if a malfunction is instrument panel, and seat belt reminder light.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Acceleration Sensors NOTE: The ORC will also detect and protect for rollover Acceleration Sensors trigger airbag deployment based on when equipped with SABIC airbags. In a rollover the dramatic acceleration change of the vehicle. SABIC airbags will deploy on both sides of the vehicle.
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 If A Deployment Occurs They are not permanent and normally heal quickly. The airbag systems are designed to deploy when the However, if you haven’t healed significantly within a Occupant Restraint Controller (ORC) detects a moderate- few days, or if you have any blistering, see your doctor to-severe collision, to help restrain the driver, front immediately.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag System WARNING! WARNING! Deployed airbags and seat belt pretensioners cannot protect you in another collision. Have the airbags, Modifications to any part of the airbag system seat belt pretensioners, and the front passenger seat could cause it to fail when you need it.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Airbag Warning Light WARNING! (Continued) You will want to have the airbags ready to Do not attempt to modify any part of your ad- inflate for your protection in a collision. While vanced airbag system.
Page 78: Event Data Recorder (Edr)
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE located on the inside of the fuse block cover for the Under certain circumstances, EDR data may not be proper airbag fuses. See your authorized dealer if the recorded (e.g., loss of battery power). fuse is good.
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 the vehicle owner or lessee) before accessing the elec- 3. Requested by police under a legal warrant. tronic data stored, unless ordered to download data by a 4. Otherwise required by law. court with legal jurisdiction (i.e., pursuant to a warrant).
Page 80: Integrated Child Booster Seat - If Equipped
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Engine control status (including engine speed) Transmission gear selection Cruise control status Traction/stability control status Tire Pressure Monitoring System status (if equipped) Integrated Child Booster Seat — If Equipped The Integrated Child Booster Seat (if equipped) is located in each second-row passenger seat.
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 NOTE: The lap portion of the seat belt should be low on the hips and as snug as possible. 5. Once the seat belt is long enough to fit properly, insert the latch plate into the buckle until you hear a “click.” 6.
Page 82: Integrated Child Seat - If Equipped
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the instructions are not with the seat or in the Owner’s Manual Package, replacement instruction can be ob- tained. Integrated Child Booster Seat 7. To release the seat belt, push the red button on the buckle.
Page 83: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 To obtain Integrated Child Seat replacement instruc- WARNING! tions: Refer to the Publication order forms at the back of this manual specify publication number In a collision, an unrestrained child, even a tiny baby, 81–226–0919.
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety experts recommend that children ride WARNING! rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types Rearward-facing child seats must NEVER be used in of child restraints can be used rearward-facing: infant the front seat of a vehicle with a front passenger carriers and convertible child seats.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 Older Children and Child Restraints shoulder belt. (Some booster seats are equipped with a Children who weigh more than 20 lbs (9 kg) and who are front shield and are held in the vehicle by the lap older than one year can ride forward-facing in the portion.) vehicle.
Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE and use the lap belt. Never allow a child to put the WARNING! (Continued) shoulder belt under an arm or behind their back. Occupants riding in Swivel ’n Go seating must be additional information, refer...
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 Carefully follow the instructions that come with the belt several times to shorten it. Insert the latch plate restraint. If you install the restraint improperly, it may into the buckle with the release button facing out. not work when you need it.
Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lower Anchors and Tether for CHildren (LATCH) Each vehicle, except commercial cargo vehicles, is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tether for CHildren. Two LATCH child restraint anchor- age systems are installed on all second-row seats and in the center position on all third row fold-in-floor seats.
Page 89 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.
Page 90 88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Installing the Child Restraint Using the Vehicle When using the LATCH attaching system to install a Seat Belts child restraint, please ensure that all seat belts not Because the lower anchorages are to be introduced to being used for occupant restraints are stowed and out passenger carrying vehicles over a period of years, child of reach of children.
Page 91 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 To install a child restraint, pull enough of the seat belt In general, you will first loosen the adjusters on the lower webbing from the retractor to route it through the belt straps and tether straps so that you can more easily attach path of the child restraint and slide the latch plate into the the hook or connector to the lower anchorages and tether...
Page 92: Rear Seat Delete Feature (Commercial Vehicles Only) - If Equipped
90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transporting Pets WARNING! Airbags deploying in the front seat could harm your pet. An unrestrained pet could be thrown about and possibly NEVER carry a child in a rear facing infant carrier in injured, or injure a passenger during panic braking or in a vehicle without rear seats.
Page 93: Restraining Infants And Small Children With Seat Delete Feature (Commercial Vehicles Only)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91 This vehicle is equipped with a child restraint tether The rearward-facing infant carrier is for babies weigh- anchor located on the lower rear of the front passenger ing up to about 20 lbs (9 kg), and less than one year seat.
Page 94 92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children more than 40 lbs (18 kg) should be secured in 3. Route the tether strap under the head rest. the passenger seat in a child restraint or belt- NOTE: Ensure that the child restraint tether strap is positioning booster seat with the seat adjusted to the centered between the headrest supports underneath the rear most position.
Page 95: Engine Break-In Recommendations
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93 While cruising, brief full-throttle acceleration within the WARNING! limits of local traffic laws, contributes to a good break-in. Wide-open throttle acceleration in low gear can be detri- The vehicle tether anchor is designed to be used with mental and should be avoided.
Page 96: Safety Tips
94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SAFETY TIPS Airbag Warning Light The light should come on and remain on for four seconds Safety Checks You Should Make Inside the as a bulb check when the ignition switch is first turned Vehicle ON.
Page 97: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 95 Periodic Safety Checks You Should Make Outside Exhaust Gas the Vehicle WARNING! Tires Examine tires for excessive tread wear or uneven wear Exhaust gases can injure or kill. They contain carbon patterns. Check for stones, nails, glass, or other objects monoxide (CO) which is colorless and odorless.
Page 98 96 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! If you are required to drive with the deck lid / liftgate open, make sure that all windows are closed, and the climate control blower switch is set at high speed. DO NOT use the recirculation mode.
Page 99 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......102 Tilt Mirrors In Reverse (Available With Memory Seat Only) —...
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Things You Should Know About Your Easy Access Seating ....153 UConnect System ....134 Swivel ’n Go Premium Seating —...
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Headlights ......174 Tilt Steering Column — If Equipped ..181 Automatic Headlights —...
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Overhead Consoles ..... 194 Instrument Panel Cupholders ... . 209 Front Overhead Console .
Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 Console Features ..... . 217 Umbrella Holder ..... . 224 Basic Console .
Page 104: Mirrors
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror — If Equipped A two point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 105: Outside Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight overlap of the view obtained on the inside mirror. WARNING! Vehicles and other objects seen in an outside convex mirror will look smaller and farther away than they really are.
Page 106: Driver's Auto-Dimming Sideview Mirror - If Equipped
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Driver’s Auto-Dimming Sideview Mirror — If Equipped This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn this feature on or off by pressing the button at the base of the rearview mirror.
Page 107: Heated Power Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Select a mirror and press one of the four arrows for the ground rearward of the front doors. The outside mirrors direction you want the mirror to move. will move slightly downward from the present position when the vehicle is shifted into the Reverse position.
Page 108: Illuminated Vanity Mirrors - If Equipped
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors — If Equipped Blind Spot Monitoring — If Equipped An illuminated vanity mirror is located on the sun visor. The Blind Spot Monitoring (BSM) system uses two radar- To use the mirror, rotate the sun visor down and swing based sensors, located inside the rear bumper fascia, to the mirror cover upward.
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 When the vehicle is started, the BSM warning light will NOTE: be momentarily illuminated in both outside rear view The BSM system does NOT alert the driver about mirrors to let the driver know that the system is opera- rapidly approaching vehicles that are outside the tional.
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The area on the rear fascia where the radar sensors are The BSM system notifies the driver of objects in the located must remain free of snow, ice, and dirt/road detection zones by illuminating the BSM warning light contamination so that the BSM system can function located in the outside mirrors.
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 The BSM system can also be configured to sound an audible (chime) alert and mute the radio to notify the driver of objects that have entered the detection zones. Refer to “Modes Of Operation” in this section. The BSM system monitors the detection zone from three different entry points (Side, Rear, Front) while driving to see if an alert is necessary.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Entering From The Rear Overtaking Traffic Vehicles that come up from behind your vehicle on either If you pass another vehicle slowly (with a relative speed side and enter the rear detection zone with a relative less than 10 mph (16 km/h) and the vehicle remains in the speed of less than 30 mph (48 km/h).
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Overtaking/Passing Stationary Objects The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, berms, etc. However, occasionally the system may alert on such objects. This is normal operation and your vehicle does not require service.
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The BSM system will not alert you of objects that are WARNING! traveling in the opposite direction of the vehicle in adjacent lanes. The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones.
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 NOTE: In a parking lot situation, oncoming vehicles can be obscured by vehicles parked on either side. If the sensors are blocked by other structures or vehicles, the system will not be able to alert the driver. When RCP is on and the vehicle is in REVERSE, the driver is alerted using both the visual and audible alarms, including radio muting.
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Modes Of Operation signal is then activated, and it corresponds to an alert Three selectable modes of operation are available in the present on that side of the vehicle, an audible chime will Electronic Vehicle Information Center (EVIC).
Page 117: Hands-Free Communication (Uconnect ) - If Equipped
NOTE: The sales code RER and REU radios contain an following websites: integrated Hands-Free Communication (UConnect ) www.chrysler.com/uconnect system. Refer to your “Navigation User’s Manual” for UConnect system operating instructions for these ra- www.dodge.com/uconnect dios. www.jeep.com/uconnect UConnect is a voice-activated, hands-free, in-vehicle or call 1–877–855–8400...
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UConnect allows you to transfer calls between the Phone Button system and your cellular phone as you enter or exit your The rearview mirror contains the microphone vehicle and enables you to mute the system’s microphone for the system (depending on the type of for private conversation.
Page 119: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 The UConnect system is fully integrated with the vehi- For certain operations, compound commands can be cle’s audio system. The volume of the UConnect system used. For example, instead of saying Setup and then can be adjusted either from the radio volume control Phone Pairing, the following compound command knob or from the steering wheel radio control (right...
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Help Command To complete the pairing process, you will need to refer- If you need assistance at any prompt, or if you want to ence your cellular phone Owner’s Manual. The know your options at any prompt, say Help following UConnect website may also provide detailed instruc- the beep.
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 For identification purposes, you will be prompted to Dial by Saying a Number give the UConnect system a name for your cellular Press the PHONE button to begin. phone. Each cellular phone that is paired should be given a unique phone name.
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The system will prompt you to say the name of the After the Ready prompt and the following beep, say person you want to call. Phonebook New Entry. After the Ready prompt and the following beep, say When prompted, say the name of the new entry.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 The UConnect system will allow you to enter up to 32 Automatic download and update, if supported, begins names in the phonebook with each name having up to as soon as the phone Bluetooth wireless connection is four associated phone numbers and designations.
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This downloaded phonebook cannot be edited or Some phones cannot send phonebook entries if they deleted on the UConnect . These can only be edited on are already connected to any system via Bluetooth , the mobile phone.
Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Press the PHONE button to begin. and a home number, but you can add ”John Doe’s” work number later using the Phonebook Edit feature. After the Ready prompt and the following beep, say Phonebook Edit.
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you enter the name, the UConnect system will Note that only the phonebook in the current language ask you which designation you wish to delete: home, is deleted. work, mobile, pager, or all. Say the designation you Automatic downloaded phonebook entries cannot be wish to delete.
Page 127: Phone Call Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 The UConnect system will then prompt you as to the the call, press and hold the PHONE button until you hear number designation you wish to call. a single beep, indicating that the incoming call was rejected.
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Making a Second Call While Current Call in indicating that the active and hold status of the two calls Progress have switched. Only one call can be placed on hold at one To make a second call while you are currently on a call, time.
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Call Termination Call Continuation To end a call in progress, momentarily press the PHONE Call continuation is the progression of a phone call on the button. Only the active call(s) will be terminated and if UConnect system after the vehicle ignition key has been there is a call on hold, it will become the new active call.
Page 130: Uconnect System Features
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UConnect System Features Emergency Assistance If you are in an emergency and the mobile phone is Language Selection reachable: To change the language that the UConnect system is using: Pick up the phone and manually dial the emergency number for your area.
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 Canada and 060 for Mexico). The number dialed may Towing Assistance not be applicable with the available cellular service If you need towing assistance: and area. Press the PHONE button to begin. If supported, this number may be programmable on After the Ready prompt and the following beep, say some systems.
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE certain companies, which time out a little too soon to sequence on your cellular phone keypad, you can press work properly with the UConnect system. the “Voice Recognition” button and say the sequence you wish to enter, followed by the word Send.
Page 133 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 NOTE: Press the PHONE button to begin. You may not hear all of the tones due to cellular phone After the Ready prompt and the following beep, say network configurations; this is normal. Setup Confirmations.
Page 134: Advanced Phone Connectivity
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE dialing a number with your paired Bluetooth cellular Following the beep, say Mute. phone, the audio will be played through your vehicle’s In order to un-mute the UConnect system: audio system. The UConnect system will work the same as if you dial the number using voice recognition.
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Connect or Disconnect Link Between the the lowest priority. To “select” or “delete” a paired UConnect System and Cellular Phone phone being announced, press the “Voice Recogni- Your cellular phone can be paired with many different tion”...
Page 136: Uconnect System
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The selected phone will be used for the next phone Things You Should Know About Your UConnect call. If the selected phone is not available, the System UConnect system will return to using the highest UConnect Tutorial priority phone present in or near (approximately To hear a brief tutorial of the system features, press the...
Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Repeat the words and phrases when prompted by the Speak normally, without pausing, just as you would UConnect system. For best results, the Voice Training speak to a person sitting a few feet/meters away from session should be completed when the vehicle is parked you.
Page 138 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When navigating through an automated system such In a convertible vehicle, system performance may be as voice mail, or when sending a page, at the end of compromised with the convertible top down. speaking the digit string, make sure to say Send.
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Echo at the far end can sometimes be reduced by Power-Up lowering the in-vehicle audio volume. After switching the ignition key from OFF to either ON or ACC position, or after a language change, you must In a convertible vehicle, system performance may be wait at least five seconds prior to using the system.
Page 140 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139...
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...
Page 145: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 General Information SEATS This device complies with Part 15 of the FCC rules and Seats are a primary part of the Occupant Restraint RSS 210 of Industry Canada. Operation is subject to the (protection) System of the vehicle.
Page 146: Manual Front And Second Row Seat Adjuster
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Front And Second Row Seat Adjuster Using body pressure, move forward and rearward on the The adjusting bar is located under the front of the seat. seat to be sure the seat adjusters have latched. Pull the bar upward and move the seat to the desired WARNING! position.
Page 147: Eight-Way Driver And Passenger Power Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 Eight–Way Driver And Passenger Power Seat — If Equipped The power seat switches are located on the outboard side of the seat. The front switch controls the up/down, forward/rearward and tilt adjustment. The rear switch controls the recline adjustment of the seatback.
Page 148: Adjustable Head Restraints
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! DO NOT place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.
Page 149: Heated Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Heated Seats — If Equipped This feature heats the front driver and passenger seats. The controls for front heated seats are located on the center instrument panel area. The switch indicator lights will show when the High or Low heat is on. Press the switch once to choose High (two lights), press it a second time to choose Low (one light), press it a third...
Page 150: Manual Reclining Seats - If Equipped
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE its normal position. Using body pressure, lean forward WARNING! and rearward on the seat to be sure the seatback has latched. Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion or other physical condition must exercise care when using the seat heater.
Page 151: Manual Lumbar Adjust Lever - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 WARNING! DO NOT ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or fatally injured. Use the recliner only when the vehicle is parked.
Page 152 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Fold Second Row Seats 1. Move the front seat fully forward. 2. Lower the head restraints and raise the armrests on the second row seat. 3. Slide the storage bin locking mechanism to the LOCK position and then pull up on the storage bin latch to open the cover.
Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Second Row Seat Release Strap Second Row Seatback Release Lever 6. Close the storage bin cover. 5. Pull rearward on the release strap located at the rear of the seat and tumble the seat forward into the storage bin.
Page 154 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Pull up on the handle to lift the seat out of the storage CAUTION! bin and push the seat rearward to latch the seat anchors. The storage bin cover must be locked and flat to avoid damage from contact with the front seat tracks, which have minimal clearance to the cover.
Page 155: Easy Access Seating
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 To tilt the seat, pull forward on the release strap located on the front of the seat between the seatback and seat cushion and tilt the seat fully forward. To return the seat to its upright position, push rearward on the seatback until it latches.
Page 156: Swivel 'N Go Premium Seating - If Equipped
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seats are removable WARNING! In the event of a collision you could be injured if the seat is not fully latched. Swivel ’n Go Premium Seating — If Equipped Premium second row Swivel ’n Go Seating features include: A table that installs between the second and third row seats.
Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 rotation. Once the seat begins to rotate, the handle may WARNING! be released. The seat locks in position once reaching the forward or rearward positions only. Failure to comply with the following conditions could result in serious injury or even death.
Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) Occupants riding in Swivel ’n Go seating must be wearing their seat belt and the seat must be locked in either the forward-facing or rearward-facing position. Make sure the Swivel ’n Go seat is in a locked position with the release handle fully engaged.
Page 159 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 5. Lower the release handle located at the bottom front Swivel ’n Go Premium Seating Table — If edge of the seat. Equipped The Swivel ’n Go Seating Table consists of an easily Each seat weighs about 90 lbs (81 kg).
Page 160 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The table and leg are stored beneath the floor when not in 3. Swivel the second row seats so they are facing the rear. use. To install the table follow these steps: 4. Insert pole into base by aligning the lock button into 1.
Page 161 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 NOTE: You will hear an audible “click” when the lock WARNING! (Continued) button engages the base. DO NOT place liquid drinks on the table, use 6. Place the table top over the installed pole aligning available cupholders.
Page 162 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The table top should be removed from the leg prior to removing the leg from its mounting base. 4. Locate the release button on the pole. Press the release button firmly to activate the release from the base. 5.
Page 163: Second Row Bench Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 Plastic Grocery Bag Retainer Hooks Retainer hooks which will hold plastic grocery bag handles are built into the seatbacks of all rear seats and some front seats. The floor supports the partial weight of the bagged goods.
Page 164: Third Row Power Seat - If Equipped
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! If not properly latched, the bench seats could become loose. Personal injuries could result. After reinstall- ing these seats, be sure the red indicator button on the release handles return into the handles. Third Row Power Seat —...
Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 Rear Panel Power Switch Bank One Touch Folding Seat Third Row The rear switch bank allows multiple power folding and 1 — Open to Normal 4 — Fold Flat 2 — Stow 5 — Right/Left Seats unfolding positions for the third row seats.
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE motion for a brief period. Should this occur, remove the obstacle and press the button again, for the desired position. To Fold Third Row Seats Manually — If Equipped 1. Lower the head restraint to its full down position. 2.
Page 167 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 To Unfold Third Row Seats Tailgate Mode 1. Pull up on the assist strap to lift the seat out of the 1. Pull release strap “2”, then pull release strap “3” to storage bin and push the seat forward until the anchors rotate the entire seat rearward.
Page 168: Driver Memory Seat System - If Equipped
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! To avoid serious injury or death, NEVER operate the vehicle with occupants in the third row seat while in the tailgate mode. DRIVER MEMORY SEAT SYSTEM — IF EQUIPPED Once programmed the Memory Buttons 1 and 2 on the driver’s door panel can be programmed to recall the driver’s seat, driver’s outside mirror, adjustable brake and accelerator pedals, and radio station preset settings.
Page 169: Setting Memory Positions And Linking Rke
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Setting Memory Positions And Linking RKE 5. Turn on the radio and set the radio station presets (up Transmitter To Memory to 10 AM and 10 FM stations can be set). NOTE: Each time the SET (S) button and a numbered 6.
Page 170 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 11. Select Remote Linked to Memory in the Electronic To recall the memory setting for driver two, press Memory Vehicle Information Center (EVIC). Refer to the button 2 on the driver’s door or the UNLOCK button on “Customer-Programmable Features”...
Page 171: Easy Entry/Exit Seat (Available With Memory Seat Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 3. Press and release the memory SET (S) button located Refer to the Remote Linked to Memory Customer- on the driver’s door. A chime will sound signaling that Programmable Features in the Electronic Vehicle Infor- you are in the memory set mode.
Page 172: To Open And Close The Hood
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When you remove the key from the ignition switch the NOTE: The Easy Entry/Easy Exit feature can be en- driver seat will move to a position 0.3 in (7.7 mm) abled or disabled through the programmable features in forward of the rear stop if the driver seat position is the Electronic Vehicle Information Center (EVIC).
Page 173 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Hood Release Lever Safety Lever Location 2. Move to the front of the vehicle and look inside the Use the hood prop rod to secure the hood in the open center of the hood opening. Locate, then push the safety position.
Page 174: Lights
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 12 in (30 cm) and then drop it. This should secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged. WARNING! If the hood is not fully latched, it could open when the vehicle is moving and block your forward vision.
Page 175 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 The interior lights will automatically turn off in approxi- Interior Lighting Defeat (Off) mately 10 minutes for the first activation and 90 seconds Rotate the dimmer control to the off every activation thereafter until the engine is started, if position (extreme bottom).
Page 176: Parking Lights
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dimmer Control Parking Lights With the parking lights or headlights Turn the headlight switch knob to the first detent on, rotating the dimmer control for the to turn on the parking lights. This also turns on all interior lights on the instrument panel instrument panel lighting.
Page 177: Headlights On With Wipers - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 will stay on for up to 90 seconds after you turn the Headlights On With Wipers — If Equipped ignition switch OFF. To turn the Automatic System off, When your headlights are in the Automatic mode and the turn the headlight switch clockwise to the “O”...
Page 178: Daytime Running Lights (Canada/Fleet Vehicles Only)
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When exiting the vehicle the driver can choose to have Lights-On Reminder the headlights remain on for 30, 60, or 90 seconds or not If the headlights or the parking lights are left on, or if the remain on.
Page 179: Front Fog Lights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Front Fog Lights — If Equipped The battery protection feature will be disabled if the To activate the front fog lights, turn on the parking ignition switch is turned to any other position other than lights or the low beam headlights and push in the LOCK during the three minute delay.
Page 180: Turn Signals
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signals If either indicator flashes at a rapid rate, check for a Move the multifunction lever up or down to signal either defective outside turn signal light bulb. If one of the a right or left turn.
Page 181: High Beam/Low Beam Select Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 High Beam/Low Beam Select Switch off position. If the windshield wiper switch is turned off When the headlights are turned on, pushing the multi- and the blades cannot return to the off position, damage function lever toward the instrument panel will switch to the wiper motor may occur.
Page 182: 180 Understanding The Features Of Your Vehicle
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. Mist, Front Wiper and Washer 2. Intermittent, Low and High Speed Wipers Press the end of the multifunction lever inward to the Use the intermittent wipers when weather conditions first detent and release to clear the windshield. Pressing make a single wiping cycle, with a variable pause be- the multifunction lever inward to the second detent will tween cycles, desirable.
Page 183: Tilt Steering Column - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 3. Rear Wiper and Washer TILT STEERING COLUMN — IF EQUIPPED Rotating the rotary ring to the first detent activates the To tilt the column, pull the lever downward (located on rear intermittent wipers. To activate the washers, rotate the steering column and below the steering wheel) to the the rotary ring fully forward and the washers will spray open position.
Page 184: Adjustable Pedals - If Equipped
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE improved position with the steering wheel. The adjust- able pedal system is designed to allow a greater range of driver comfort for steering wheel tilt and seat positions. The switch is located on the left side of the steering column.
Page 185: Electronic Speed Control - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Press the button forward to move the pedals forward CAUTION! (toward the front of the vehicle). Do not place any article under the adjustable pedals Press the button rearward to move the pedals rearward or impede its ability to move, as it may cause damage (toward the driver).
Page 186: To Activate
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE OFF button a second time, and both the Electronic Speed Control system and indicator will turn off. WARNING! Leaving the Electronic Speed Control system on when not in use is dangerous. You could accidently set the system or cause it to go faster than you want.
Page 187: Deactivating Electronic Speed Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 Deactivating Electronic Speed Control Raising the RESUME/ACCEL lever upward, once, will A soft tap on the brake pedal or pulling the Electronic result in a 1 mph (1 km/h) speed increase. Each time the Speed Control lever (CANCEL) toward you will deacti- lever is tapped upward speed increases, so tapping the vate the Electronic Speed Control without erasing the set...
Page 188: Accelerating To Pass
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Speed Control system can be reactivated by pushing the WARNING! Electronic Speed Control switch ON/OFF button and resetting the desired vehicle set speed. Electronic Speed Control can be dangerous where the system cannot maintain a constant speed. Your ve- Accelerating To Pass hicle could go too fast for the conditions, and you Depress the accelerator as you normally would.
Page 189: Rear Park Assist Sensors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 The Rear Park Assist system will remember the last Rear Park Assist Sensors system state (enabled or disabled) from the last ignition The four rear park assist sensors, located in the rear cycle, when the ignition is changed to the RUN/ON fascia, monitor the area behind the vehicle that is within position.
Page 190 188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE for about one second. Each side of the warning display has six yellow and two red LED lights, one set to warn of obstacles behind the left rear of the vehicle and the other set to warn of obstacles behind the right rear of the vehicle.
Page 191 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 WARNING DISPLAY DISTANCES DISPLAY OBSTACLE DISTANCE FROM: INDICATOR AUDIBLE SIGNAL INDICATOR COLOR REAR CORNERS REAR CENTER Inner LED 59 in (150 cm) Yellow Yes, Half Second 1st LED 51.2 in (130 cm) Yellow 2nd LED 45.3 in (115 cm) Yellow...
Page 192 190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! WARNING! (Continued) Before using the Rear Park Assist system, it is Drivers must be careful when backing up, even strongly recommended that the ball mount and when using the Rear Park Assist System. Always hitch ball assembly be disconnected from the check carefully behind your vehicle, and be sure to vehicle, when the vehicle is not used for towing.
Page 193 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 NOTE: CAUTION! Ensure that the rear bumper is free of dirt and debris to keep the system operating properly. To avoid vehicle damage, the Rear Park Assist system should only be used as a parking aid and is Jackhammers, large trucks, and other vibrations could unable to recognize every obstacle, including affect the performance of the system.
Page 194: Rear Backup Camera System - If Equipped
192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Vehicles Equipped With the Compass Mini-Trip Should this wrench symbol display with the Computer (CMTC) letter P next to it, your Park Sense system You can turn the Rear Park Assist system ON or OFF needs servicing.
Page 195 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 NOTE: The Rear Camera system can be enabled and 5. Backup as necessary. disabled, refer to your Radio/Navigation/Multimedia 6. Place the shift lever in PARK or DRIVE to exit the Rear manual. Backup Camera system. Use the following steps to access the Rear Backup Cam- WARNING! era feature:...
Page 196: Overhead Consoles
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE OVERHEAD CONSOLES CAUTION! Front Overhead Console To avoid vehicle damage the Rear Backup Camera Two versions of the overhead console are available. The System should only be used as a parking aid and base front overhead console model featured fixed incan- is unable to view every obstacle, or object in your descent courtesy/reading lights, flip-down sunglass stor-...
Page 197 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 when a front door, a sliding door or the liftgate is opened. If your vehicle is equipped with Remote Keyless Entry (RKE), the lights will also turn on when the UNLOCK button on the transmitter is pressed. The courtesy lights also function as reading lights.
Page 198 196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Press the door latch to open the compartment. The door will slowly rotate to an open position. Rotating bin upward to partial open, positions lid for conversation mirror use. NOTE: The front overhead console supplied with fac- tory sunroof, incorporates a sunroof switch.
Page 199: Garage Door Opener - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 Rear Courtesy/Reading Lights — If Equipped Lights — If Equipped” under “Lighting” in the “Under- The overhead console has two sets of courtesy lights. The standing The Features Of Your Vehicle” in Section 2. lights turn on when a front door, a sliding door or the GARAGE DOOR OPENER —...
Page 200 198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Your motorized door or gate will open and close while you are training the universal transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. Only use this trans- ceiver with a garage door opener that has a “stop and reverse”...
Page 201: Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 Programming Homelink Place the handheld transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink button you wish to program while Before You Begin keeping the indicator light in view. If you have not trained any of the HomeLink buttons, erase all channels before you begin training.
Page 202 200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After training a HomeLink channel, if the garage This can usually be found where the hanging antenna door does not operate with HomeLink and the ga- wire is attached to the garage door opener motor. It is rage door opener was manufactured after 1995, the NOT the button normally used to open and close the garage door opener may have a rolling code.
Page 203 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 6. Firmly press and release the “Learn” or “Training” Using HomeLink button. The name and color of the button may vary by To operate, simply press and release the programmed manufacturer. HomeLink button. Activation will now occur for the trained device (i.e., garage door opener, gate operator, NOTE: There are 30 seconds in which to initiate the next security system, entry door lock, home/office lighting,...
Page 204: Gate Operator/Canadian Programming
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Gate Operator/Canadian Programming has successfully accepted the frequency signal. The Canadian radio frequency laws require transmitter sig- indicator light will flash slowly and then rapidly when nals to time-out (or quit) after several seconds of trans- fully trained.
Page 205: Troubleshooting Tips
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 Troubleshooting Tips 2. This device must accept any interference that may be If you are having trouble programming HomeLink , here received including interference that may cause undesired are some of the most common solutions: operation.
Page 206: Power Sunroof - If Equipped
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER SUNROOF — IF EQUIPPED WARNING! The power sunroof control switch is located in the front overhead console.The sunroof panel tilts upward at the In an accident, there is greater risk of being thrown rear for ventilation or slides rearward under the roof.
Page 207 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 NOTE: The sunshade cannot be closed if the sunroof is Express-Vent open. Press and release the V button, and the sunroof will automatically open to the vent position. This is called WARNING! Express-Vent. Express-Close Never leave children in a vehicle with the key in the Press the switch forward and release, and the sunroof...
Page 208: Electrical Power Outlets - If Equipped
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ignition OFF Operation open or partially open positions. This is a normal occur- The power sunroof switch will remain active for 10 min- rence and can be minimized. If the buffeting occurs with utes after the ignition switch is turned OFF.
Page 209 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 The lower outlet is protected by an automatic reset circuit breaker. The automatic circuit breaker restores power when the overload is removed. The circuit breaker also supplies power to the outlet in the removable floor console, when in the front position.
Page 210: Power Inverter - If Equipped
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED CAUTION! (Continued) A 110-Volt, 150-Watt inverter outlet (if equipped) con- Accessories that draw higher power (i.e., coolers, verts DC current to AC current, and is located on the left vacuum cleaners, lights, etc.), will degrade the rear trim panel immediately behind the second row left battery even more quickly.
Page 211: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 The Power Inverter switch is located near the center of CUPHOLDERS the instrument panel below the two 12-Volt power out- There are nine cupholders in the interior. Two cupholders lets. Press the switch to turn the power on for the outlet, in the center front instrument panel, four in the floor press the switch a second time to turn the power off.
Page 212: Interior Bottle Holders
210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Interior Bottle Holders There are four bottle holders located in the interior. One bottle holder is molded into each front interior door trim panels, and one bottle holder is molded into each side sliding interior door trim panel.
Page 213: Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 The left rear trim panel cupholder is designed to accom- modate a second ash receiver, if desired. STORAGE Glove Compartments There are both upper and lower glove compartments. Upper Glove Compartment To open the upper compartment, press in on the upper latch.
Page 214: Door Trim Panel Storage
212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lower Glove Compartment To open the lower compartment pull out on the release handle. NOTE: The lower compartment is equipped with a lock that is part of the compartment handle (2). Door Trim Panel Storage Front Door Storage Both interior front door panels have multiple pockets for storage.
Page 215: Driver Seatback Storage - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 Sliding Side Door Bottle Holder Driver Seatback Storage — If Equipped Both sliding doors have a bottle holder molded right into The driver’s seatback has a primary storage pocket on all the trim. models and an optional secondary mesh pocket.
Page 216: Second Row Seat Storage Bins - If Equipped
214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Second Row Seat Storage Bins — If Equipped The seat storage bins are located on the floor in front of the second row seats. The area below the covers can be used for storage when the second row seat is in the upright position.
Page 217: Rear Compartment Storage Bins
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 WARNING! In an accident, serious injury could result if the seat storage bin covers are not properly latched. DO NOT drive the vehicle with the storage bin covers open. Keep the storage bin covers closed and latched while the vehicle is in motion.
Page 218: Coat Hooks
216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Coat Hooks Coat hooks are located along the headliner for the second and third row seating positions. The coat hook load limit is 10 lbs (4.5 kg). Exceeding the recommended load limit can cause the coat hooks to break or disengage from the vehicle.
Page 219: Console Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 CONSOLE FEATURES There are two consoles available: Basic and Premium. Basic Console Basic Console features consist of the following: The basic console profile allows vehicle occupants to easily pass through the first row to the second. Four cupholders accept up to extra large size beverage cups or 20 oz (.6 L) plastic bottles.
Page 220: Premium Console - If Equipped
218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Slide the console base forward while lifting slightly to WARNING! clear the rear load floor hook. In an accident, serious injury could result if the 3. Remove the console. removable floor console is not properly installed. To Reinstall The Basic Floor Console Always be sure the removable floor console is fully latched.
Page 221 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 Large console center storage will store headphones for the available rear DVD entertainment system or other items 12-Volt DC power outlet provides continuous power inside the console for cell phones or other electronics. Rear occupant accessible Multiple adjustments Removable from vehicle for additional floor space.
Page 222 220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The top and center console sections slide forward and rearward to provide added user comfort. A one-piece cup holder insert for both cavities can easily be removed for cleaning. The cupholders will also accommodate large size cups and 20 oz (.6 L) bottles.
Page 223 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 Position 2 shows the raised storage tray revealing a large easy access to the storage area below and provides two of storage area below. the four cupholders for the second row passengers. Console Position 2 Console Position 3 Dual Storage Bins Position 4 shows the complete console in its rearmost...
Page 224 222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Pull rearward to disengage from floor and remove console To reinstall the console: 1. Position the console at a slight angle (rear slightly higher than the front) 2. Slide the console forward into the floor bracket 3.
Page 225: Electric Rear Window Defroster - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223 After the initial time interval has expired, if the rear WARNING! window defogger switch is pressed to the on position again (during the same ignition cycle), the system will In an accident, serious injury could result if the automatically turn off after approximately five minutes.
Page 226: Umbrella Holder
224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UMBRELLA HOLDER LOAD-LEVELING SYSTEM An umbrella holder has been conveniently molded into The automatic load-leveling system will provide a level the left front door entry scuff molding. riding vehicle under most passenger and cargo loading conditions.
Page 227: Roof Luggage Rack - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 inside the vehicle plus that on the external rack does not WARNING! exceed the maximum vehicle load capacity. Do not install the load-leveling system on vehicles To move the crossbars, loosen the thumb screws located that are not equipped with Anti-Lock Brakes.
Page 228 226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The tie down holes on the crossbar ends should always CAUTION! (Continued) be used to tie down the load. Check the straps frequently Long loads which extend over the windshield, to be sure that the load remains securely attached. such as wood panels or surfboards, or loads with large frontal area should be secured to both the CAUTION!
Page 229: Sun Screens - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in per- sonal injury or property damage. Follow the Roof Rack Cautions when carrying cargo on your roof rack.
Page 230 228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sun Screen Attaching To Retainer Clips Sun Screen Extended Once the screen is completely to the top of the window, To lower the sun screen, gently lift the tab upward to extend the top bar of the sun screen over the two hooks disengage the hooks, and feed the screen back into the attached to the top of the window.
Page 231 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....233 Compass/Temperature Display ... 250 Instrument Cluster – Base ....234 Electronic Vehicle Information Center (EVIC) —...
Page 232 230 UNDERSTANDING YOUR INSTRUMENT PANEL AM/FM/CD/DVD Multimedia System Radio Sales Code RES/RSC — AM/FM Stereo Radio (RER/REN) – If Equipped ....263 With CD Player (MP3 AUX Jack) And Sirius Radio.
Page 233 UNDERSTANDING YOUR INSTRUMENT PANEL 231 Play Mode ......288 Operating Instructions — Video Entertainment System (VES)™ List Or Browse Mode .
Page 234 232 UNDERSTANDING YOUR INSTRUMENT PANEL Climate Controls ..... . 301 Winter Operation ..... 319 Manual Heating, Ventilation And Air Vacation/Storage .
Page 235: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 233 INSTRUMENT PANEL FEATURES 1 - Air Vent 5 - Storage Bin 9 - Storage or DVD 13 - Hazard Switch 2 - Instrument Cluster 6 - Upper Glove Compartment 10 - Cup Holders 14 - Ignition Switch 3 - Shift Lever 7 - Lower Glove Compartment 11 - Storage Bin...
Page 236: Instrument Cluster - Base
234 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER – BASE...
Page 237: Instrument Cluster - Premium
UNDERSTANDING YOUR INSTRUMENT PANEL 235 INSTRUMENT CLUSTER – PREMIUM...
Page 238: Instrument Cluster Descriptions
236 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS CAUTION! 1. Fuel Gauge Driving with a hot engine cooling system could The pointer shows the level of fuel in the fuel tank when damage your vehicle. If temperature gauge reads the ignition switch is in the ON position. “H“, pull over and stop the vehicle.
Page 239 UNDERSTANDING YOUR INSTRUMENT PANEL 237 continuous chime will sound to alert you to turn the WARNING! signals off. If either indicator flashes at a rapid rate, check for a defective outside light bulb. A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling 6.
Page 240 238 UNDERSTANDING YOUR INSTRUMENT PANEL If the ABS light is on, the brake system should be serviced System (ABS) / Electronic Stability Program (ESP) sys- as soon as possible to restore the benefits of Anti-Lock tem. In this case, the light will remain on until the brakes.
Page 241 UNDERSTANDING YOUR INSTRUMENT PANEL 239 If brake failure is indicated, immediate repair is neces- the parking brake is applied or a brake fault is detected. sary. If the light does not illuminate, have the light inspected by an authorized dealer. WARNING! The light also will turn on when the parking brake is applied with the ignition switch in the ON position.
Page 242 240 UNDERSTANDING YOUR INSTRUMENT PANEL 11. Odometer / Trip Odometer — If Equipped 12. PRNDL/Odometer Display Area The odometer shows the total distance the vehicle has When the appropriate conditions exist, the following been driven. odometer messages will display: U.S. federal regulations require that upon transfer of CHAngE OIL .
Page 243 UNDERSTANDING YOUR INSTRUMENT PANEL 241 NOTE: the next scheduled oil change interval. The engine oil If your vehicle is equipped with an hood switch, in the change indicator system is duty cycle-based, which case of hood ajar, a warning message will be displayed means the engine oil change interval may fluctuate in either the PRNDL/Odometer display as “hood”...
Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If the indicator message illuminates when you 15. Malfunction Indicator Light (MIL) start the vehicle, the oil change indicator system did not The Malfunction Indicator Light (MIL) is part of reset. If necessary repeat this procedure. an onboard diagnostic system called OBD that monitors engine and automatic transmission con- 13.
Page 245 UNDERSTANDING YOUR INSTRUMENT PANEL 243 16. Engine Temperature Warning Light 17. Electronic Throttle Control (ETC) Light This light warns of an overheated engine condi- This light informs you of a problem with the tion. As temperatures rise and the gauge ap- Electronic Throttle Control (ETC) system.
Page 246 244 UNDERSTANDING YOUR INSTRUMENT PANEL 18. Oil Pressure Warning Light check or when driving, if the driver’s seat belt remains This light indicates low engine oil pressure. The unbuckled, the Seat Belt Reminder Light will illuminate light should turn on momentarily when the engine and the chime will sound.
Page 247 UNDERSTANDING YOUR INSTRUMENT PANEL 245 23. Charging System Light 25. Tire Pressure Monitoring Telltale Light — If Equipped This light shows the status of the electrical charg- Each tire, including the spare (if provided), ing system. The light should come on when the should be checked monthly, when cold and ignition switch is first turned ON and remain on briefly inflated to the inflation pressure recommended...
Page 248 246 UNDERSTANDING YOUR INSTRUMENT PANEL overheat and can lead to tire failure. Under-inflation also approximately one minute and then remain continuously reduces fuel efficiency and tire tread life, and may affect illuminated. This sequence will continue upon subse- the vehicle’s handling and stopping ability. quent vehicle start-ups as long as the malfunction exists.
Page 249 UNDERSTANDING YOUR INSTRUMENT PANEL 247 switch is turned to the “ON” position. They should go CAUTION! out with the engine running. If the “ESP/BAS Warning Lamp” comes on continuously with the engine running, The TPMS has been optimized for the original a malfunction has been detected in either the ESP or the equipment tires and wheels.
Page 250: Compass Mini-Trip Computer (Cmtc) - If Equipped
248 UNDERSTANDING YOUR INSTRUMENT PANEL 28. Compass Mini-Trip Computer (CMTC) Display / COMPASS MINI-TRIP COMPUTER (CMTC) — IF Electronic Vehicle Information Center (EVIC) Display— EQUIPPED If Equipped NOTE: The compass on your vehicle is self-calibrating, CMTC Display — If Equipped eliminating the need to manually calibrate the compass.
Page 251: Cmtc Odometer Display
UNDERSTANDING YOUR INSTRUMENT PANEL 249 CMTC Odometer Display CMTC Reset Buttons When the appropriate conditions exist, the following CMTC Reset Button odometer messages will display: Press the left reset button located on the instrument cluster to scroll through sub menus (i.e., Trip Functions: CHAngE OIL .
Page 252: Compass/Temperature Display
250 UNDERSTANDING YOUR INSTRUMENT PANEL When the appropriate conditions exist, the following cluster to switch from odometer, to trip A or trip B. Press messages will display: and hold the right button, while the odometer/trip odometer is displayed, to reset. NE .
Page 253 UNDERSTANDING YOUR INSTRUMENT PANEL 251 NOTE: Magnetic and battery powered devices, (such as To Set the Variance cell phones, IPOD’s, radar detectors, PDA’s and laptops) Start the engine and leave the transmission gear selector should be kept away from the top of the instrument lever in the PARK position.
Page 254: Electronic Vehicle Information Center (Evic) - If Equipped
252 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Press and hold the CMTC reset button (for approxi- ELECTRONIC VEHICLE INFORMATION CENTER mately 10 seconds) until the current variance zone num- (EVIC) — IF EQUIPPED ber is displayed. 3. Release the CMTC reset button, then press and hold again for approximately 10 seconds, until the direction is displayed, with the CAL indicator on continuously in the display.
Page 255 UNDERSTANDING YOUR INSTRUMENT PANEL 253 This system conveniently allows the driver to select a EVIC Menu / Step Control Button, as variety of useful information by pressing the switches it appears on the left side of the steer- mounted on the steering wheel. The EVIC consists of the ing column.
Page 256: Evic Displays
254 UNDERSTANDING YOUR INSTRUMENT PANEL Steering Wheel EVIC Compass/Temp Door(s) Ajar (with a single chime, if vehicle is in Control Button, as it appears on the motion) right side of the steering column. Liftgate Ajar (chime will sound when vehicle starts moving) Hood Ajar (if equipped with hood switch) Check TPM System (refer to “Tire Pressure Monitoring...
Page 257: Trip Functions
UNDERSTANDING YOUR INSTRUMENT PANEL 255 Right Rear Turn Signal Light Out release the Menu button. To reset the oil change indicator system (after performing the scheduled maintenance) Park Assist Disabled perform the following steps. Service Park Assist System 1. Turn the ignition switch to the ON position (do not Personal Settings Not Available —...
Page 258 256 UNDERSTANDING YOUR INSTRUMENT PANEL The Trip Functions mode displays the following informa- When the DTE value is less than 30 miles (48 km) tion. estimated driving distance, the DTE display will change to a text display of LOW FUEL. This display will Average Fuel Economy continue until the vehicle runs out of fuel.
Page 259: Compass Display
UNDERSTANDING YOUR INSTRUMENT PANEL 257 resettable functions, press and release the RESET button Manual Compass Calibration a second time, within three seconds of resetting the If the compass appears erratic and the CAL indicator currently-displayed function (Reset ALL will display does not appear in the EVIC display, you must put the during this three-second window).
Page 260 258 UNDERSTANDING YOUR INSTRUMENT PANEL Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences, the variance should be set for the zone where the vehicle is driven, per the zone map. Once properly set, the compass will automatically compensate for the differences, and provide the most accurate compass heading.
Page 261: Personal Settings (Customer-Programmable Features)
UNDERSTANDING YOUR INSTRUMENT PANEL 259 4. Press and release the STEP button until the proper functions and the navigation system (if equipped). Press variance zone is selected, according to the map. the RESET button while in this display to select English, Spanish (Español), French (Français), Italian (Italiano), 5.
Page 262 260 UNDERSTANDING YOUR INSTRUMENT PANEL RKE Unlock position using the door mounted switch. Pressing the When Driver Door 1st Press is selected, only the driver’s RESET button when in this display will select Yes or door will unlock on the first press of the Remote Keyless Entry (RKE) transmitter UNLOCK button.
Page 263 UNDERSTANDING YOUR INSTRUMENT PANEL 261 Easy Exit Seat Key-Off Power Delay This feature provides automatic driver seat positioning to When this feature is selected, the power window enhance driver mobility when entering and exiting the switches, radio, hands-free system (if equipped), DVD vehicle.
Page 264 262 UNDERSTANDING YOUR INSTRUMENT PANEL Park ASST. System Sound Horn with Remote Key Lock When enable is selected, the Rear Park Assist System is When ON is selected, a short horn sound will occur when activated. When disable is selected the system is deacti- the RKE transmitter LOCK button is pressed.
Page 265: Am/Fm/Cd/Dvd Multimedia System Radio (Rer/Ren) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 263 Rain Sensing Intermittent Wipers — If Equipped Refer to your Multimedia system (REN) or Navigation When ON is selected, the system will automatically (RER) user’s manual for detailed operating instructions. activate the windshield wipers if it senses moisture on Operating Instructions —...
Page 266 264 UNDERSTANDING YOUR INSTRUMENT PANEL worldwide standard for time. This makes the system’s displayed. To move the minute backward, touch the clock very accurate, once the appropriate time zone and screen where the word “Min” with the arrow pointing daylight savings information is set. downward is displayed.
Page 267 UNDERSTANDING YOUR INSTRUMENT PANEL 265 Show Time if Radio is Off 2. Touch the screen where the time is displayed. The When selected, this feature will display the time of day clock setting menu will appear on the screen. on the touch screen when the multimedia system is 3.
Page 268: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
266 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RES — AM/FM STEREO RADIO Operating Instructions — Radio Mode WITH CD PLAYER (MP3 AUX JACK) NOTE: The ignition switch must be in the ON or ACC NOTE: The radio sales code is located on the lower right position to operate the radio.
Page 269 UNDERSTANDING YOUR INSTRUMENT PANEL 267 to seek up and the left switch to seek down. The radio 4. Adjust the minutes using the right side Tune/Scroll will remain tuned to the new station until you make control knob. Press the Tune/Scroll control knob to save another selection.
Page 270 268 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary Tune/Scroll control knob a second time AM/FM Button and MID will display. Turn the Tune/Scroll control knob Press the buttons to select either AM or FM mode. to the right or left to increase or decrease the mid-range SET/RND Button —...
Page 271: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 269 and 12 FM stations to be stored into pushbutton memory. This radio is capable of playing compact discs (CD), The stations stored in SET 2 memory can be selected by recordable compact discs (CD-R), rewritable compact pressing the pushbutton twice.
Page 272 270 UNDERSTANDING YOUR INSTRUMENT PANEL If you have ejected a disc and have not removed it within CAUTION! 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. This CD player will accept 4-3/4 in (12 cm) discs only.
Page 273: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 271 RW/FF Press the RND button a second time to stop Random Press the RW button to stop the CD at the beginning of Play. the current CD track/title. Notes on Playing MP3 Files Press and hold the FF (Fast Forward) button and the CD The radio can play MP3 files;...
Page 274 272 UNDERSTANDING YOUR INSTRUMENT PANEL The radio uses the following limits for file systems: Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal Maximum number of folder levels: 8 CD audio tracks and computer files (including MP3 files). Maximum number of files: 255 Discs created with an option such as keep disc open after writing are most likely multisession discs.
Page 275 UNDERSTANDING YOUR INSTRUMENT PANEL 273 rates (VBR) are also supported. The majority of MP3 files Playback of MP3 Files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or When a medium containing MP3 data is loaded, the VBR bit rate.
Page 276: Operation Instructions - Auxiliary Mode
274 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode SALES CODE RES/RSC — AM/FM STEREO The auxiliary (AUX) jack is an audio input jack, which RADIO WITH CD PLAYER (MP3 AUX JACK) AND allows the user to plug in a portable device, such as an SIRIUS RADIO MP3 player, or cassette player, and utilize the vehicle’s NOTE: The radio sales code is located on the lower right...
Page 277: Operating Instructions - Radio Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 275 Operating Instructions — Radio Mode to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make NOTE: The ignition switch must be in the ON or ACC another selection.
Page 278 276 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button (UConnect Hands-Free Phone) — If 3. After adjusting the hours, press the right side Tune/ Equipped Scroll control knob to set the minutes. The minutes will Press this button to operate the Hands-Free Phone begin to blink.
Page 279 UNDERSTANDING YOUR INSTRUMENT PANEL 277 INFO Button Push the rotary Tune/Scroll control knob a second time Press the INFO button for an RDS station (one with call and MID will display. Turn the Tune/Scroll control knob letters displayed). The radio will return a Radio Text to the right or left to increase or decrease the mid-range message broadcast from an FM station (FM mode only).
Page 280 278 UNDERSTANDING YOUR INSTRUMENT PANEL MUSIC TYPE Button 16-Digit Character Program Type Pressing this button once will turn on the Music Type Display mode for five seconds. Pressing the MUSIC TYPE button Foreign Language Language or turning the Tune/Scroll control knob within five Information Inform seconds will allow the program format type to be se-...
Page 281 UNDERSTANDING YOUR INSTRUMENT PANEL 279 Set Clock — Pressing the SELECT button will allow 16-Digit Character Program Type you to set the clock. Turn the Tune/Scroll control knob Display to adjust the hours and then press and turn the Sports Sports Tune/Scroll control knob to adjust the minutes.
Page 282: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
280 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second station to each pushbutton by Operation Instructions — CD MODE for CD and repeating the above procedure with this exception: Press MP3 Audio Play the SET/RND button twice and SET 2 will show in the NOTE: display window.
Page 283 UNDERSTANDING YOUR INSTRUMENT PANEL 281 If you insert a disc with the ignition ON and the radio EJECT Button - Ejecting a CD ON, the unit will switch from radio to CD mode and Press the EJECT button to eject the CD. begin to play when you insert the disc.
Page 284: Notes On Playing Mp3 Files
282 UNDERSTANDING YOUR INSTRUMENT PANEL the current selection. Pressing and holding the SEEK SET/RND Button (Random Play Button) button will allow faster scrolling through the tracks in Press this button while the CD is playing to activate CD, MP3 modes. Random Play.
Page 285 UNDERSTANDING YOUR INSTRUMENT PANEL 283 Supported Medium Formats (File Systems) exceeding 20 folders will result in this display. With The medium formats supported by the radio are ISO 9660 200 files, exceeding 50 folders will result in this Level 1 and Level 2 and includes the Joliet extension. display.) When reading discs recorded using formats other than Maximum number of characters in file/folder names:...
Page 286 284 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats MPEG Sampling Bit Rate (kbps) The radio will recognize only files with the *.MP3 exten- Specification Frequency (kHz) sion as MP3 files. Non-MP3 files named with the *.MP3 160, 128, 144, extension may cause playback problems.
Page 287: List Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 285 Loading times for playback of MP3 files may be affected playing the files contained in that folder (or the next by the following: folder in sequence if the selection does not contain playable files). Media - CD-RW media may take longer to load than CD-R media The folder list will time out after five seconds.
Page 288: Universal Consumer Interface (Uci) - If Equipped
286 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode Operating Instructions - Hands-Free Phone The auxiliary (AUX) jack is an audio input jack, which (UConnect ) (If Equipped) allows the user to plug in a portable device such as an Refer to “Hands-Free Communication (UConnect )”...
Page 289: Connecting The Ipod
UNDERSTANDING YOUR INSTRUMENT PANEL 287 UCI supports Mini, 4G, Photo, Nano, 5G iPod system (iPod may take a few seconds to connect), the iPhone devices. Some iPod software versions may not iPod starts charging and is ready for use by pressing fully support the UCI features.
Page 290: Controlling The Ipod Using Radio
288 UNDERSTANDING YOUR INSTRUMENT PANEL The iPod can be controlled using the radio buttons to Turning it clockwise (forward) by one click, while Play, Browse, and List the iPod contents. playing a track, skips to the next track. The iPod battery charges when plugged into the UCI Turning it counterclockwise (backward) by one connector.
Page 291: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 289 Use the << SEEK and SEEK >> buttons to jump to the current list and then forward to the next song. To stop previous or next track. If the << SEEK button is SCAN mode and start playing the desired track, when pressed during the first two seconds of the track, it will it is playing the track, press the SCAN button again.
Page 292 290 UNDERSTANDING YOUR INSTRUMENT PANEL Turning it clockwise (forward) and counterclock- Preset 3 – Albums wise (backward) scrolls through the lists, displaying Preset 4 – Genres the track detail on the radio display. Once you have the track to be played highlighted on the radio Preset 5 - Audiobooks display, press the TUNE control knob to select and Preset 6 –...
Page 293: Satellite Radio - If Equipped (Ren/Req/Rer/Res/Reu Radios Only)
UNDERSTANDING YOUR INSTRUMENT PANEL 291 the same steps to go to the desired track in that list. WARNING! Not all iPod sub-menu levels are available on this system. Do not plug in or remove the iPod while driving. Failure to following this warning could result in an MUSIC TYPE button: The MUSIC TYPE button is accident.
Page 294: System Activation
292 UNDERSTANDING YOUR INSTRUMENT PANEL System Activation To access the ESN/SID, refer to the following steps: Sirius Satellite Radio service is pre-activated, and you ESN/SID Access With REQ/RES Radios may begin listening immediately to the one year of audio With the ignition switch in the ON/RUN or ACC posi- service that is included with the factory-installed satellite tion and the radio on, press the SETUP button and scroll radio system in your vehicle.
Page 295: Selecting Satellite Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 293 Next, turn the knob surrounding the joystick in the center Reception Quality of the radio to scroll to Subscription, and then press and Satellite reception may be interrupted due to one of the release the joystick. All of the ESNs that apply to your following reasons: vehicle will display.
Page 296 294 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons additional three seconds will make the radio display the Press and release the SEEK buttons to search for the next Song Title all of the time (press and hold again to return channel in Satellite mode. Press the right switch to seek to normal display).
Page 297 UNDERSTANDING YOUR INSTRUMENT PANEL 295 MUSIC TYPE Button — Except REU Radio MUSIC TYPE Button — REU Radio Pressing this button once will turn on the Music Type Pressing this button provides a MUSIC TYPES list from mode for five seconds. Pressing the MUSIC TYPE button which you can make a selection.
Page 298: Operating Instructions - Hands-Free Phone (If Equipped)
296 UNDERSTANDING YOUR INSTRUMENT PANEL SET Button – To Set the Pushbutton Memory Every time a preset button is used, a corresponding When you are receiving a channel that you wish to button number will display. commit to pushbutton memory, press the SET button. Buttons 1 - 6 The symbol SET 1 will now show in the display window.
Page 299: Sirius Backseat Tv™ - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 297 SIRIUS BACKSEAT TV™ — IF EQUIPPED VIDEO ENTERTAINMENT SYSTEM (VES)™ — IF Satellite video uses direct satellite receiver broadcasting EQUIPPED technology to provide streaming video. The subscription The optional Video Entertainment System (VES)™ is service provider is SIRIUS Satellite Radio. SIRIUS Back- available with: seat TV™...
Page 300 298 UNDERSTANDING YOUR INSTRUMENT PANEL Nine different medias to choose from in each screen (AM, FM, Sirius Radio, DVD1, DVD2, Hard Drive Jukebox, AUX in radio, AUX1, AUX2) The LCD screen(s) are located in the overhead compart- ment console. VES™ Remote Control Location NOTE: Refer to your VES™...
Page 301: Remote Sound System Controls - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 299 REMOTE SOUND SYSTEM CONTROLS — IF system. Pressing the top of the rocker switch will increase EQUIPPED the volume. Pressing the bottom of the rocker switch will decrease the volume. Pressing the center button changes the operation of the radio from AM to FM, or Tape to CD mode, depending on which radio is in the vehicle.
Page 302: Cd Player
300 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Do not apply paper or tape to the disc; avoid scratch- CD Player Pressing the top of the switch once will go to the next ing the disc. track on the CD. Pressing the bottom of the switch once 4.
Page 303: Radio Operation And Cellular Phones
UNDERSTANDING YOUR INSTRUMENT PANEL 301 RADIO OPERATION AND CELLULAR PHONES Manual Heating, Ventilation And Air Conditioning Under certain conditions, the cellular phone being ON in (HVAC) System your vehicle can cause erratic or noisy performance from The controls for the manual HVAC system in this vehicle your radio.
Page 304 302 UNDERSTANDING YOUR INSTRUMENT PANEL Front Blower Control There are four blower speeds. Use this control to regulate the amount of air forced through the system in any mode you select. The blower speed increases as you move the control clockwise from the off position.
Page 305 UNDERSTANDING YOUR INSTRUMENT PANEL 303 Temperature Control Mode Control (Air Direction) Use this control to regulate the tem- Mode control allows you to choose perature of the air inside the passenger from several patterns of air distribu- compartment. Rotating the knob coun- tion.
Page 306 304 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: There is a difference in temperature (in any Defrost Mode conditions other than full cold or full hot), between the Air is directed through the windshield and side upper and lower outlets for added comfort. The warmer window demist outlets.
Page 307 UNDERSTANDING YOUR INSTRUMENT PANEL 305 Recirculation Control Continuous use of the RECIRCULATION mode may Press this button to choose between make the inside air stuffy and window fogging may outside air intake or recirculation of occur. Extended use of this mode is not recommended. the air inside the vehicle.
Page 308 306 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: For maximum airflow to the rear, the center NOTE: The air conditioning compressor will not engage instrument panel outlets can be directed toward the rear until the engine has been running for about 10 seconds. seat passengers.
Page 309 UNDERSTANDING YOUR INSTRUMENT PANEL 307 The Three-Zone Basic Temperature Control bottom panel controls rear Heating, Ventilation, and Air Conditioning (HVAC) operations. Front Upper Three Zone Temperature Control 1 – Left Temperature 7 – Right Temperature 2 – PANEL 8 – Rear DEFROST 3 –...
Page 310: Rear Manual Climate Control Zone - If Equipped
308 UNDERSTANDING YOUR INSTRUMENT PANEL The primary control for the rear blower is on the front climate control unit located on the instrument panel. The Three-Zone Basic Temperature Control bottom panel has five positions; off, rear, and a range of blower speeds. Only when the primary control for the rear blower is in the rear (RR) position do the second row seat occupants have control of the rear blower speed.
Page 311 UNDERSTANDING YOUR INSTRUMENT PANEL 309 Only when the front control for the rear blower is in the Rear Temperature Control RR position do the second row seat occupants have When the blower knob on the front climate control unit is control of the rear blower speed.
Page 312: Automatic Temperature Control (Atc) - If Equipped
310 UNDERSTANDING YOUR INSTRUMENT PANEL control is in FLOOR, DEFROST, or MIX modes, airflow Automatic Temperature Control (ATC) — If will be directed out of the rear floor outlets. Equipped Front Three-Zone ATC allows both driver and front Rear Mode Control passenger seat occupant, and rear seat occupants to Headliner Mode select individual comfort settings.
Page 313 UNDERSTANDING YOUR INSTRUMENT PANEL 311 The Infrared Three-Zone ATC System automatically maintains the interior comfort level desired by the driver and all passengers. This is accomplished by an infrared sensor, located in the forward overhead console. Based on the sensor input, the system automatically adjusts the air temperature, the airflow volume, amount of outside air recirculation and the airflow direction.
Page 314 312 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Operation 1. Press the AUTO button on the Front Upper ATC Panel and the word AUTO will illuminate in the front ATC display, along with three temperatures for driver, front passenger, and rear seats. The system will then automati- cally regulate the amount of airflow.
Page 315 UNDERSTANDING YOUR INSTRUMENT PANEL 313 NOTE: Manual Operation It is not necessary to move the temperature settings for This system offers a full complement of manual override cold or hot vehicles. The system automatically adjusts features. The AUTO symbol in the front ATC display will the temperature, mode and fan speed to provide be turned off when the system is being used in the comfort as quickly as possible.
Page 316 314 UNDERSTANDING YOUR INSTRUMENT PANEL Panel Mode Mix Mode Air comes from the outlets in the instrument panel. Air comes from the floor, defrost and side window Each of these outlets can be individually adjusted to demist outlets. This mode works best in cold or direct the flow of air.
Page 317 UNDERSTANDING YOUR INSTRUMENT PANEL 315 flows through the air outlets. If ECONOMY mode is a second time to turn off the RECIRCULATION mode desired, press the SNOWFLAKE button to turn off the LED and allow outside air into the vehicle. SNOWFLAKE mode in the ATC display, and deactivate NOTE: In cold weather, use of the RECIRCULATION the A/C system.
Page 318 316 UNDERSTANDING YOUR INSTRUMENT PANEL Pressing the REAR LOCK button for the Rear ATC System from the front lower ATC panel, illuminates a LOCK symbol in the rear display. The rear temperature and air source are controlled from the front lower ATC panel.
Page 319 UNDERSTANDING YOUR INSTRUMENT PANEL 317 2. Rotate the Rear Blower, Rear Temperature and the feature. Refer to the “Electronic Vehicle Information Rear Mode Control knobs to suit your comfort needs. Center (EVIC) — Customer-Programmable Features” in this Section of the manual. 3.
Page 320: Summer Operation
318 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Temperature Control Headliner Mode To change the temperature in the rear of the vehicle, Air comes from the outlets in the headliner. Each of rotate the temperature knob counterclockwise to lower these outlets can be individually adjusted to direct the temperature, and clockwise to increase the tempera- the flow of air.
Page 321: Winter Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 319 to provide proper corrosion protection and to protect fresh air with the blower setting in high. This will ensure against engine overheating. A 50% solution of ethylene adequate system lubrication to minimize the possibility glycol antifreeze coolant in water is recommended. Refer of compressor damage when the system is started again.
Page 322: Operating Tips
320 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips A/C Air Filter— If Equipped On vehicles equipped with Automatic Temperature Con- trol (ATC), the climate control system filters out dust and pollen from the air. Refer to “Air Conditioning” in Section 7 of this manual for filter replacement instructions.
Page 323: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....324 Acceleration ......334 Automatic Transaxle .
Page 324 322 STARTING AND OPERATING Anti-Lock Brake System (ABS) ... . 341 Tire Pressure ......358 Anti-Lock Brake Light .
Page 325 STARTING AND OPERATING 323 MMT In Gasoline ....381 Replacement Parts ....386 Materials Added To Fuel .
Page 326: Starting Procedures
324 STARTING AND OPERATING STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust the Be sure to turn off the engine and remove the key inside and outside mirrors, fasten your seat belt, and if from the ignition switch if you want to rest or present, instruct all other occupants to buckle their seat sleep in your car.
Page 327 STARTING AND OPERATING 325 2. Use the Fob with Integrated Key to briefly turn the To ensure reliable starting at these temperatures, use of ignition switch to the START position and release it as an externally powered electric engine block heater (avail- soon as the starter engages.
Page 328 326 STARTING AND OPERATING WARNING! (Continued) CAUTION! Do not attempt to push or tow your vehicle to get To prevent damage to the starter, DO NOT crank the it started. Vehicles equipped with an automatic engine for more than 15–second intervals at one time. transaxle cannot be started this way.
Page 329: Engine Block Heater - If Equipped
STARTING AND OPERATING 327 After Starting AUTOMATIC TRANSAXLE The idle speed will automatically decrease as the engine CAUTION! warms up. Damage to the transaxle may occur if the following ENGINE BLOCK HEATER — IF EQUIPPED precautions are not observed: The engine block heater warms engine coolant and Move the shift lever into PARK only after the permits quicker starts in cold weather.
Page 330: Brake/Transaxle Interlock System
328 STARTING AND OPERATING the ignition switch is in the ON position. Always press WARNING! the brake pedal first before moving the shift lever out of PARK. It is dangerous to move the shift lever out of PARK or NEUTRAL if the engine speed is higher than idle Automatic Transaxle Ignition Interlock System speed.
Page 331: Four-Speed Or Six-Speed Automatic Transaxle
STARTING AND OPERATING 329 NOTE: If a malfunction occurs, the system will trap the The transaxle has only PRND shift positions. Downshifts key in the ignition cylinder to warn you that this safety are carried out by an Electronic Range Select (ERS) by feature is inoperable.
Page 332 330 STARTING AND OPERATING When parking on a flat surface, place the shift lever in the WARNING! (Continued) PARK position first, and then apply the parking brake. Unintended movement of a vehicle could injure When parking on a hill, it is important to set the parking those in and near the vehicle.
Page 333 STARTING AND OPERATING 331 Look at the shift indicator window on the console to NEUTRAL ensure the shift lever is in the PARK position. Place the shift lever into this gear only after the vehicle has come to a complete stop. The engine may be started When engaged in PARK, you will not be able to move in this range.
Page 334 332 STARTING AND OPERATING operating the vehicle under heavy loading conditions, CAUTION! (i.e., in hilly terrain, traveling into strong head winds or while towing heavy trailers). Under these conditions, If the transaxle operating temperature exceeds ac- using the “5” range will improve performance and ceptable limits, the vehicle computer will override extend transaxle life by reducing excessive shifting and DRIVE and select “5”...
Page 335 STARTING AND OPERATING 333 Switching from ERS to DRIVE can be done at any vehicle Odometer speed. To shift from DRIVE mode to ERS mode, move the Screen Dis- shift lever to the left (-) once. The current gear will be play maintained as the top gear.
Page 336: Reset Mode - Electronic Transaxle
334 STARTING AND OPERATING Reset Mode - Electronic Transaxle 5. Shift into the desired gear range and resume driving. The transaxle is monitored electronically for abnormal NOTE: Even if the transaxle can be reset, it is recom- conditions. If a condition is detected that could cause mended that you visit an authorized dealer at your damage, the transaxle automatically shifts into 2nd gear earliest possible convenience.
Page 337: Traction
STARTING AND OPERATING 335 2. Slow down if the road has standing water or puddles. WARNING! 3. Replace the tires when tread wear indicators first Rapid acceleration on slippery surfaces is dangerous. become visible. Unequal traction can cause sudden pulling of the 4.
Page 338: Flowing/Rising Water
336 STARTING AND OPERATING Flowing/Rising Water CAUTION! WARNING! Always check the depth of the standing water before driving through it. Never drive through Do not drive on, or cross, a road or a path where standing water that is deeper than the bottom of water is flowing and/or rising (as in storm run-off).
Page 339 STARTING AND OPERATING 337 CAUTION! (Continued) WARNING! Driving through standing water may cause dam- Driving through standing water limits your vehi- age to your vehicle’s drivetrain components. Al- cle’s traction capabilities. Do not exceed 5 mph ways inspect your vehicle’s fluids (i.e., engine oil, (8 km/h) when driving through standing water.
Page 340: Power Steering
338 STARTING AND OPERATING POWER STEERING WARNING! The standard power steering system will give you good vehicle response and increased ease of maneuverability Continued operation with reduced power steering in tight spaces. The system will provide mechanical assist could pose a safety risk to yourself and others. steering capability if power assist is lost.
Page 341: Parking Brake
STARTING AND OPERATING 339 apparent, and/or the system is not functioning as antici- PARKING BRAKE pated. Coordinate inspection efforts through an autho- When the parking brake is applied with the ignition rized dealer. switch ON, the brake light in the instrument cluster will turn on.
Page 342 340 STARTING AND OPERATING WARNING! Always fully apply the parking brake when leav- ing your vehicle, or it may roll and cause damage or injury. Also be certain to leave an automatic transaxle in PARK. Failure to do so may allow the vehicle to roll and cause damage or injury.
Page 343: Anti-Lock Brake System (Abs)
STARTING AND OPERATING 341 ANTI-LOCK BRAKE SYSTEM (ABS) WARNING! ABS provides increased vehicle stability and brake per- formance under most braking conditions. The system NEVER leave children alone in a vehicle. Leaving automatically “pumps” the brakes during severe braking unattended children in a vehicle is dangerous for a conditions to prevent wheel lock-up.
Page 344 342 STARTING AND OPERATING A slight drop or fall away of the brake pedal at the end WARNING! (Continued) of the stop The Anti-Lock Brake System cannot prevent acci- dents, including those resulting from excessive WARNING! speed in turns, following another vehicle too The Anti-Lock Brake System contains sophisti- closely, or hydroplaning.
Page 345: Anti-Lock Brake Light
STARTING AND OPERATING 343 Anti-Lock Brake Light If both the Brake Warning Light and the ABS Light The ABS light monitors the Anti-Lock Brake remain on, the ABS and Electronic Brake Force Distribu- System. The light will come on when the tion (EBD) systems are not functioning.
Page 346: Electronic Brake Control System
344 STARTING AND OPERATING In the event power assist is lost for any reason (for WARNING! (Continued) example, repeated brake applications with the engine Driving a vehicle with the brake light on is dan- off), the brakes will still function. The effort required to gerous.
Page 347: Traction Control System (Tcs)
STARTING AND OPERATING 345 Traction Control System (TCS) light flashes during acceleration, ease up on the accelera- This system monitors the amount of wheel spin of each of tor and apply as little throttle as possible. Be sure to adapt the driven wheels.
Page 348: Brake Assist System (Bas)
346 STARTING AND OPERATING Brake Assist System (BAS) WARNING! The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The The BAS cannot prevent the natural laws of phys- system detects an emergency braking situation by sens- ics from acting on the vehicle, nor can it increase ing the rate and amount of brake application, and then the traction afforded by prevailing road condi-...
Page 349: Electronic Stability Program (Esp)
STARTING AND OPERATING 347 Electronic Stability Program (ESP) ESP ON This system enhances directional control and stability of This is the normal operating mode for ESP on 2WD the vehicle under various driving conditions. ESP cor- vehicles. Whenever the vehicle is started, the ESP system rects for over/under steering of the vehicle by applying will be in this mode.
Page 350: Esp/Bas Warning Light
348 STARTING AND OPERATING gain traction. To turn ESP on again, momentarily depress Light comes on continuously with the engine running, a the ESP OFF switch. This will restore the normal ESP ON malfunction has been detected in either the ESP or the mode of operation.
Page 351: Tire Safety Information
STARTING AND OPERATING 349 TIRE SAFETY INFORMATION NOTE: P (Passenger) - Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. European-Metric tire sizing is based on European design standards.
Page 352 350 STARTING AND OPERATING Tires designed to this standard have the letter “T” High flotation tire sizing is based on U.S. design molded into the sidewall preceding the size designa- standards, and it begins with the tire diameter molded tion. Example: T145/80D18 103M. into the sidewall.
Page 353 STARTING AND OPERATING 351 EXAMPLE: R = Construction code — R means radial construction — D means diagonal or bias construction 15 = Rim diameter in inches (in) Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol —...
Page 354 352 STARTING AND OPERATING EXAMPLE: Load Identification: ..blank..= Absence of any text on the sidewall of the tire indicates a Standard Load (SL) Tire Extra Load (XL) = Extra load (or reinforced) tire Light Load = Light load tire C, D, E = Load range associated with the maximum load a tire can carry at a specified pressure Maximum Load —...
Page 355: Tire Identification Number (Tin)
STARTING AND OPERATING 353 Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 356: Tire Loading And Tire Pressure
354 STARTING AND OPERATING Tire Loading and Tire Pressure Tire and Loading Information Placard Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry...
Page 357 STARTING AND OPERATING 355 occupants and cargo should never exceed XXX kg or XXX 3) tire size designed for your vehicle lbs.” on the Tire and Loading Information placard. The 4) cold tire inflation pressures for the front, rear, and combined weight of occupants, cargo/luggage and spare tires.
Page 358 356 STARTING AND OPERATING available cargo and luggage load capacity is 650 lbs NOTE: (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs The following table shows examples on how to calcu- [295 kg]). late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations 5.
Page 359 STARTING AND OPERATING 357...
Page 360: Tires - General Information
358 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause accidents. recommended load capacity for your vehicle. Never Under-inflation increases tire flexing and can re- overload them.
Page 361 STARTING AND OPERATING 359 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the Unequal tire pressures from one side of the ve- driver’s side “B” Pillar. hicle to the other can cause the vehicle to drift to The tire pressure should be checked and adjusted, and the right or left.
Page 362 360 STARTING AND OPERATING is defined as the tire pressure after the vehicle has not Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) been driven for at least three hours, or driven less than during operation. Do not reduce this normal pressure 1 mile (1.6 km) after a three-hour period.
Page 363 STARTING AND OPERATING 361 Cuts and punctures in radial tires are repairable only in WARNING! the tread area because of sidewall flexing. Consult your authorized tire dealer for radial tire repairs. High-speed driving, with your vehicle at or above maximum load, is dangerous. The added strain on Compact Spare Tire —...
Page 364 362 STARTING AND OPERATING WARNING! (Continued) CAUTION! Temporary-use spare tires have limited tread life. Because of the reduced ground clearance, do not take When the tread is worn to the tread wear indica- your vehicle through an automatic car wash with the tors, the temporary use spare tire needs to be compact spare installed.
Page 365 STARTING AND OPERATING 363 Tire Spinning WARNING! When stuck in mud, sand, snow, or ice conditions, do not spin your vehicle’s wheels faster than 30 mph (48 km/h), The limited-use spare tire is for emergency use or continuously for longer than 30 seconds, without only.
Page 366 364 STARTING AND OPERATING Tread Wear Indicators These indicators are molded into the bottom of the tread Tread wear indicators are in the original-equipment tires grooves. They will appear as bands when the tread depth to help you in determining when your tires should be becomes 1/16 in (2 mm).
Page 367 STARTING AND OPERATING 365 wear and correct cold tire inflation pressure. The manu- WARNING! facturer strongly recommends that you use tires equiva- lent to the originals in size, quality and performance The tires and the spare tire should be replaced after when replacement is needed.
Page 368 366 STARTING AND OPERATING WARNING! WARNING! (Continued) Failure to equip your vehicle with tires having Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 369: Tire Chains
STARTING AND OPERATING 367 Tires may also cause the vehicle to pull to the left or right. CAUTION! Alignment will not correct this condition. See your authorized dealer for proper diagnosis. To avoid damage to your vehicle or tires, observe the following precautions: Improper alignment will not cause vehicle vibration.
Page 370: Snow Tires
368 STARTING AND OPERATING SNOW TIRES CAUTION! (Continued) Some areas of the country require the use of snow tires Do not drive for prolonged periods of time on dry during Winter. Standard tires are of the all-season type pavement. and satisfy this requirement as indicated by the M+S Observe the tire chain manufacturer’s instructions designation on the tire sidewall.
Page 371: Tire Rotation
STARTING AND OPERATING 369 TIRE ROTATION The suggested rotation method is the “forward-cross” Tires on the front and rear axles of vehicles operate at shown in the following diagram. different loads and perform different steering, driving, and braking functions. For these reasons, they wear at unequal rates, and tend to develop irregular wear pat- terns.
Page 372: Tire Pressure Monitor System (Tpms)
370 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) The TPMS will warn the driver of a low tire pressure if The TPMS will warn the driver of a low tire pressure the tire pressure falls below the low pressure warning based on the cold inflation tire pressure requirements threshold for any reason, including low temperature found on the tire placard located on the driver’s-side...
Page 373 STARTING AND OPERATING 371 For example, your vehicle may have a recommended CAUTION! cold (parked for more than three hours) tire pressure of 35 psi (241 kPa). If the ambient temperature is 68°F (20°C) The TPMS has been optimized for the original and the measured tire pressure is 30 psi (207 kPa), a equipment tires and wheels.
Page 374: Basic Tpms Without Evic - If Equipped
372 STARTING AND OPERATING NOTE: NOTE: Seasonal temperature changes will affect tire The TPMS is not intended to replace normal tire care pressure, and the TPMS will monitor the actual tire and maintenance, or to provide warning of a tire pressure in the tire.
Page 375 STARTING AND OPERATING 373 The TPMS Telltale Warning Light will illumi- ignition key is cycled, this sequence will repeat, provid- nate in the instrument cluster, and an audible ing the system fault still exists. The TPMS Warning Lamp chime will be activated when one or more of will turn off when the fault condition no longer exists.
Page 376: Premium Tpms With Evic - If Equipped
374 STARTING AND OPERATING NOTE: Telltale Warning Light will turn off as long as no tire 1. The compact spare tire (if equipped) does not have a pressure is below the low-pressure warning limit in any TPMS sensor. Therefore the TPMS will not monitor the of the four active road tires.
Page 377 STARTING AND OPERATING 375 Three Trigger Modules (mounted in three of the four wheel wells) Various TPMS messages, which display in the Elec- tronic Vehicle Information Center (EVIC), and graph- ics displaying tire pressures Yellow TPMS Telltale Warning Light TPMS Low Pressure Warnings The TPMS Telltale Warning Light will illuminate in the instrument cluster, and an audible chime will be acti- vated when one or more of the four active road tire...
Page 378 376 STARTING AND OPERATING the TPMS Telltale Warning Light will extinguish once the updated tire pressure(s) have been received. The vehicle may need to be driven for up to 10 minutes above 15 mph (25 km/h) to receive this information. Check TPMS Message The TPMS Telltale Warning Light will flash on and off for 75 seconds, and remain on solid when a system fault is...
Page 379 STARTING AND OPERATING 377 will not be present, and a pressure value will be dis- 2. If you install the compact spare tire in place of a road played instead of dashes. A system fault can occur by any tire that has a pressure below the low-pressure warning of the following scenarios: limit, upon the next ignition key cycle, the TPMS Telltale Warning Light will remain on, a chime will sound, and...
Page 380: Fuel Requirements
378 STARTING AND OPERATING 5. Once you repair or replace the original road tire, and The tire pressure sensors are regulated under one of the reinstall it on the vehicle in place of the compact spare, the following licenses: TPMS will update automatically. In addition, the TPMS Telltale Warning Light will turn off and the graphic in the United States .
Page 381: 4.0L Gasoline Engine
STARTING AND OPERATING 379 4.0L Gasoline Engine Poor quality gasoline can cause problems such as hard This engine is designed to meet all emis- starting, stalling and hesitations. If you experience these sions regulations and provide satisfactory symptoms, try another brand of “regular” gasoline be- fuel economy and performance when us- fore considering service for the vehicle.
Page 382: Gasoline/Oxygenate Blends
380 STARTING AND OPERATING The manufacturer supports the use of reformulated gaso- Problems that result from using methanol/gasoline or lines. Properly blended reformulated gasolines will pro- E85 Ethanol blends are not the responsibility of the vide excellent performance and durability of engine and manufacturer.
Page 383: Mmt In Gasoline
STARTING AND OPERATING 381 To fix a Non-FFV vehicle inadvertently fueled once with of gasoline may not be indicated on the gasoline pump, E-85 perform the following: therefore, you should ask your gasoline retailer whether the gasoline contains MMT. drain the fuel tank (see your authorized dealer) It is even more important to look for gasolines without change the engine oil and oil filter MMT in Canada, because MMT can be used at levels...
Page 384: Fuel System Cautions
382 STARTING AND OPERATING Fuel System Cautions Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives is not CAUTION! the responsibility of the manufacturer. NOTE: Intentional tampering with emissions control Follow these guidelines to maintain your vehicle’s systems can result in civil penalties being assessed performance: against you.
Page 385: Flexible Fuel - 3.3L Engines Only
STARTING AND OPERATING 383 FLEXIBLE FUEL — 3.3L ENGINES ONLY WARNING! (Continued) E-85 General Information NEVER run the engine in a closed area, such as a The information in this section is for Flexible Fuel Ve- garage, and NEVER sit in a parked vehicle with hicles (FFV) only.
Page 386: Ethanol Fuel (E-85)
384 STARTING AND OPERATING E-85 Fuel Cap E-85 Badge ETHANOL FUEL (E-85) CAUTION! E-85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline. Only vehicles with the E-85 Decal and/or fuel filler door label can operate on E-85.
Page 387: Fuel Requirements
STARTING AND OPERATING 385 you drive the vehicle immediately after refueling for at WARNING! least 5 miles (8 km) Ethanol vapors are extremely flammable and could Observing these precautions will avoid possible hard cause serious personal injury. Never have any smok- starting and/or significant deterioration in drivability ing materials lit in or near the vehicle when remov- during warm up.
Page 388: Selection Of Engine Oil For Flexible Fuel Vehicles (Ffv) E-85 And Gasoline Vehicles
386 STARTING AND OPERATING increase in the time it takes for your engine to start and a Cruising Range deterioration in drivability (sags and/or hesitations) un- Because E-85 fuel contains less energy per gallon than til the engine is fully warmed up. gasoline, you will experience an increase in fuel con- sumption.
Page 389: Maintenance
STARTING AND OPERATING 387 Maintenance NOTE: The driver’s side sliding door cannot be opened If you operate the vehicle using E-85 fuel, follow the while the fuel door is open. This feature operates only maintenance schedule section of this manual. when the sliding door is fully closed prior to opening the fuel door.
Page 390: Loose Fuel Filler Cap Message
388 STARTING AND OPERATING WARNING! WARNING! Never have any smoking materials lit in or near A fire may result if gasoline is pumped into a the vehicle when the gas cap is removed or the portable container that is inside of a vehicle. You tank filled.
Page 391: Vehicle Loading
STARTING AND OPERATING 389 If the problem continues, the message will appear the Gross Vehicle Weight Rating (GVWR) next time the vehicle is started. See your authorized Gross Axle Weight Rating (GAWR) — Front dealer as soon as possible. See Section 7 of this manual for more information.
Page 392 390 STARTING AND OPERATING Gross Axle Weight Rating (GAWR) Rim Size The GAWR is the maximum capacity of the front and rear This is the rim size that is appropriate for the tire size axles. Distribute the load over the front and rear axles listed.
Page 393 STARTING AND OPERATING 391 Overloading Loading The load carrying components (axle, springs, tires, To load your vehicle properly, first figure out its empty wheels, etc.) of your vehicle will provide satisfactory weight, axle-by-axle and side-by-side. Store heavier items service as long as you do not exceed the GVWR and front down low and be sure you distribute their weight as and rear GAWR.
Page 394 392 STARTING AND OPERATING CAUTION! Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR. If you do, parts on your vehicle can break, or it can change the way your vehicle handles. This could cause you to lose control.
Page 395: Trailer Towing
STARTING AND OPERATING 393 TRAILER TOWING LOADING TABLE — EXAMPLE ONLY In this section you will find safety tips and information Front Axle Rear Axle on limits to the type of towing you can reasonably do Empty Weight 2,140 lbs 1,470 lbs with your vehicle.
Page 396 394 STARTING AND OPERATING Gross Trailer Weight (GTW) WARNING! The GTW is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or tem- It is important that you do not exceed the maximum porary) loaded in or on the trailer in its loaded and front or rear GAWR.
Page 397 STARTING AND OPERATING 395 that typically provides adjustable friction associated with also dampens sway caused by traffic and crosswinds and the telescoping motion to dampen any unwanted trailer contributes positively to tow vehicle and trailer stability. swaying motions while traveling. Trailer sway control and a weight distributing (load equalizing) hitch are recommended for heavier tongue Weight-Carrying Hitch...
Page 398 396 STARTING AND OPERATING Without Weight-Distributing Hitch (Incorrect) With Weight-Distributing Hitch (Correct)
Page 399 STARTING AND OPERATING 397 The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow, and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. TRAILER HITCH CLASSIFICATIONS Max.
Page 400 398 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. GCWR (Gross Engine/Transaxle Frontal Area Max. GTW (Gross Trailer Wt.) Max. Tongue Wt. Combined Wt. Rating) 7,000 lbs Up to 2 persons &...
Page 401 STARTING AND OPERATING 399 Trailer and Trailer Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 402 400 STARTING AND OPERATING NOTE: Remember that everything put into or on the CAUTION! (Continued) trailer adds to the load on your vehicle. Also, additional During the first 500 miles (805 km) of trailer factory-installed options, or authorized dealer-installed towing, limit your speed to 50 mph (80 km/h). options, must be considered as part of the total load on your vehicle.
Page 403 STARTING AND OPERATING 401 Vehicles with trailers should not be parked on a grade. WARNING! (Continued) When parking, apply the parking brake on the tow Make certain that the load is secured in the trailer vehicle. Put the tow vehicle automatic transmission in and will not shift during travel.
Page 404 402 STARTING AND OPERATING Towing Requirements — Tires When replacing tires, refer to the “Tires–General Infor- mation” section of this manual for proper tire replace- Do not attempt to tow a trailer while using a compact ment procedures. Replacing tires with a higher load spare tire.
Page 405 STARTING AND OPERATING 403 Trailer brakes are recommended for trailers over WARNING! (Continued) 1,000 lbs (454 kg) and required for trailers in excess of Towing any trailer will increase your stopping 2,000 lbs (907 kg). distance. When towing you should allow for addi- tional space between your vehicle and the vehicle CAUTION! in front of you.
Page 406 404 STARTING AND OPERATING The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following four-pin connector and seven-pin connector illustrations. Four-Pin Connector 1 — Female Pins 4 — Park 2 —...
Page 407: Towing Tips
STARTING AND OPERATING 405 Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic. Towing Tips — Automatic Transaxle The DRIVE gear can be selected when towing. However, if frequent shifting occurs while in DRIVE, move the gear selector lever into third gear (with four-speed transaxle) or fifth gear (with six-speed transaxle).
Page 408 406 STARTING AND OPERATING The automatic transaxle fluid and filter should be Use speed control in flat terrain and with light loads to changed if you REGULARLY tow a trailer for more than maximize fuel efficiency. 45 minutes of continuous operation. Refer to the “Main- Towing Tips —...
Page 409: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 407 RECREATIONAL TOWING (BEHIND NOTE: If the vehicle requires towing, make sure all four MOTORHOME, ETC.) wheels are off the ground. CAUTION! Towing this vehicle behind another vehicle (flat- towing with all four wheels on the ground) is not recommended.
Page 411: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....410 Jump-Starting Procedure ....424 If Your Engine Overheats .
Page 412: Hazard Warning Flasher
410 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER NOTE: With extended use, the Hazard Warning Flash- The Hazard Warning Flasher switch is located in the ers may wear down your battery. center of the instrument panel above the radio. IF YOUR ENGINE OVERHEATS Press the switch to turn on the Hazard In any of the following situations, you can reduce the...
Page 413 WHAT TO DO IN EMERGENCIES 411 the fan control to high. This allows the heater core to act WARNING! as a supplement to the radiator and aids in removing heat from the engine cooling system. A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling CAUTION! coolant.
Page 414: Jacking And Tire Changing
412 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! (Continued) For vehicles equipped with Stow ’n Go seating, if WARNING! it is necessary to retrieve the spare tire from under Getting under a jacked-up vehicle is dangerous. the vehicle on the side of the vehicle close to The vehicle could slip off the jack and fall on you.
Page 415 WHAT TO DO IN EMERGENCIES 413 center of the vehicle by means of a cable winch mecha- nism. The “spare tire drive” nut is located on the floor, under a plastic cap at the front of the floor console. NOTE: The base console, if equipped, must be removed to raise and lower the spare tire.
Page 416 414 WHAT TO DO IN EMERGENCIES Preparations For Jacking 1. Park the vehicle on a firm level surface. Avoid ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid being hit when operating the jack or changing the wheel.
Page 417 WHAT TO DO IN EMERGENCIES 415 6. Block both the front and rear of the WARNING! (Continued) wheel diagonally opposite the jacking Always park on a firm, level surface as far from position. For example, if changing the the edge of the roadway as possible before raising right front tire, block the left rear the vehicle.
Page 418 416 WHAT TO DO IN EMERGENCIES 2. To remove the compact spare tire/cover assembly, WARNING! (Continued) assemble the winch handle extensions to form a “T’ and If working on or near a roadway, be extremely fit the winch “T” handle over the drive nut. Rotate the careful of motor traffic.
Page 419 WHAT TO DO IN EMERGENCIES 417 WARNING! Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift.
Page 420 418 WHAT TO DO IN EMERGENCIES NOTE: Rear jack locations are between a pair of down-facing tabs on the sill flange of the vehicle side body. Front jack locations are on the sill flange of the vehicle side body, and align with front door edges. Squeezing Winch Retainer Tabs 5.
Page 421 WHAT TO DO IN EMERGENCIES 419 Jack Location...
Page 422 420 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! Do not attempt to raise the vehicle by jacking on Raising the vehicle higher than necessary can make locations other than those indicated in Step 5. the vehicle less stable. It could slip off the jack and hurt someone near it.
Page 423 WHAT TO DO IN EMERGENCIES 421 10. Lower the vehicle by turning the jack screw to the 13. Place the deflated (flat) tire and compact spare tire left. cover assembly. in the rear cargo area. Do not stow the deflated tire in the spare tire location. Have the full- 11.
Page 424 422 WHAT TO DO IN EMERGENCIES of operation, and after each time a tire is changed, to WARNING! allow the wheel nuts to become properly set. All nuts should first be firmly seated against the wheel. The nuts A loose compact spare tire/cover assembly, thrown should then be tightened to recommended torque.
Page 425 WHAT TO DO IN EMERGENCIES 423 3. Turn the compact spare tire so that the valve stem is WARNING! down, and place the tire into the spare tire/cover assem- bly. Slide the wheel spacer through the center of the Verify that both retainer tabs of the wheel spacer wheel and spare tire/cover assembly, so that the two have been properly extended through the center of retainer tabs snap out and engage the spare tire cover on...
Page 426: Jump-Starting Procedure
424 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! (Continued) If the vehicle has a discharged battery, booster For vehicles equipped with Stow ’n Go seating, the cables may be used to obtain a start from another winch mechanism is designed specifically to stow a vehicle.
Page 427 WHAT TO DO IN EMERGENCIES 425 2. When a boost is provided by a battery in another WARNING! (Continued) vehicle, park that vehicle within booster cable reach and Take special care to avoid the radiator cooling fan do not let the vehicles touch. Set the parking brake, place whenever the hood is raised.
Page 428 426 WHAT TO DO IN EMERGENCIES 5. Connect the other cable, first to the negative terminal 7. When removing the jumper cables, reverse the above of the booster battery, and then to the engine of the sequence exactly. Be careful of the moving belts and fan. vehicle with the discharged battery.
Page 429: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 427 FREEING A STUCK VEHICLE CAUTION! If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking motion. Turn your Racing the engine or spinning the wheels too fast steering wheel right and left to clear the area around the may lead to transmission overheating and failure.
Page 430 428 WHAT TO DO IN EMERGENCIES If the transmission is not operative, or if the vehicle is CAUTION! (Continued) to be towed more than 100 miles (160 km), the vehicle If the vehicle being towed requires steering, the must be towed with the front wheels off the ground. ignition switch must be in the OFF position, not in the LOCK or ACC positions.
Page 431 WHAT TO DO IN EMERGENCIES 429 Towing This Vehicle Behind Another Vehicle (Flat Towing This Vehicle Behind Another Vehicle With Towing With All Four Wheels On The Ground) A Tow Dolly Flat towing of vehicles equipped with an automatic The manufacturer does not recommend that you tow a transmission, is only permitted within the limitations front wheel drive vehicle on a tow dolly.
Page 433: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.3/3.8L ..433 Engine Oil ......438 Engine Compartment —...
Page 434 432 MAINTAINING YOUR VEHICLE Windshield Wiper Blades ....449 Headlights ......475 Cooling System .
Page 435: Engine Compartment - 3.3/3.8L
MAINTAINING YOUR VEHICLE 433 ENGINE COMPARTMENT — 3.3/3.8L 1 — Air Cleaner Filter 7 — Engine Oil Fill 2 — Automatic Transmission Dipstick (3.3L Only) 8 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 9 — Coolant Pressure Cap 4 —...
Page 436: Engine Compartment - 4.0L
434 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 4.0L 1 — Power Steering Fluid Reservoir 7 — Engine Oil Dipstick 2 — Air Cleaner Filter 8 — Engine Oil Fill 3 — Brake Fluid Reservoir 9 — Coolant Pressure Cap 4 — Battery 10 —...
Page 437: Onboard Diagnostic System - Obd Ii
MAINTAINING YOUR VEHICLE 435 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors Prolonged driving with the “Malfunction Indica- the performance of the emissions, engine, and automatic tor Light”...
Page 438: Emissions Inspection And Maintenance Programs
436 MAINTAINING YOUR VEHICLE filler cap message will be displayed in the instrument Indicator Light (MIL) is functioning and is not on when cluster. Tighten the gas cap until a clicking sound is the engine is running, and that the OBD II system is heard.
Page 439: Replacement Parts
MAINTAINING YOUR VEHICLE 437 4. As soon as you turn your key to the ON position, you you may need to do nothing more than drive your will see the MIL symbol come on as part of a normal bulb vehicle as you normally would in order for your OBD II check.
Page 440: Dealer Service
438 MAINTAINING YOUR VEHICLE DEALER SERVICE MAINTENANCE PROCEDURES Your authorized dealer has the qualified service person- The pages that follow contain the required maintenance nel, special tools, and equipment to perform all service services determined by the engineers who designed your operations in an expert manner.
Page 441 MAINTAINING YOUR VEHICLE 439 The best time to check the engine oil level is about five Change Engine Oil minutes after a fully warmed engine is shut OFF or The oil change indicator system will remind you that it is before starting the engine after it has sat overnight.
Page 442 440 MAINTAINING YOUR VEHICLE American Petroleum Institute (API) Engine Oil For information on engine oil filler cap location, refer to Identification Symbol “Engine Compartment” in this section. This symbol means that the oil has Lubricants that do not have both the engine oil certifica- been certified by the American tion mark and the correct SAE viscosity grade number, Petroleum Institute (API).
Page 443: Engine Oil Filter
MAINTAINING YOUR VEHICLE 441 Synthetic Engine Oils station, or governmental agency for advice on how and You may use synthetic engine oils provided the recom- where used oil and oil filters can be safely discarded in mended oil quality requirements are met, and the recom- your area.
Page 444: Exhaust System
442 MAINTAINING YOUR VEHICLE Exhaust System WARNING! The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust The air induction system (air cleaner, hoses, etc.) can system. provide a measure of protection in the case of engine backfire.
Page 445 MAINTAINING YOUR VEHICLE 443 WARNING! CAUTION! Exhaust gases can injure or kill. They contain carbon Damage to the catalytic converter can result if your monoxide (CO) which is colorless and odorless. vehicle is not kept in proper operating condition. In Breathing it can make you unconscious and can the event of engine malfunction, particularly involv- eventually poison you.
Page 446: Maintenance-Free Battery
444 MAINTAINING YOUR VEHICLE To minimize the possibility of catalyst damage: WARNING! Do not shut OFF the engine or interrupt the ignition A hot exhaust system can start a fire if you park over when the transaxle is in gear and the vehicle is in materials that can burn.
Page 447 MAINTAINING YOUR VEHICLE 445 WARNING! CAUTION! Battery fluid is a corrosive acid solution and can It is essential when replacing the cables on the burn or even blind you. Do not allow battery fluid battery that the positive cable is attached to the to contact your eyes, skin or clothing.
Page 448: Air Conditioner Maintenance
446 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! (Continued) For best possible performance, your air conditioner The air conditioning system contains refrigerant should be checked and serviced by an authorized dealer under high pressure. To avoid risk of personal at the start of each warm season. This service should injury or damage to the system, adding refrigerant include cleaning of the condenser fins and a system or any repair requiring lines to be disconnected...
Page 449 MAINTAINING YOUR VEHICLE 447 A/C Air Filter — If Equipped Refer to the “Maintenance Schedule” in Section 8 for the proper maintenance intervals. WARNING! Do not remove the A/C air filter while the blower is operating or personal injury may result. The A/C air filter is located in the fresh air inlet behind the glove box.
Page 450: Steering Shaft Seal
448 MAINTAINING YOUR VEHICLE damage when other maintenance is performed. If leakage CAUTION! or damage is evident, the universal joint boot and grease should be replaced immediately. The A/C air filter is labeled with an arrow to indicate airflow direction through the filter. Failure to prop- Continued operation could result in failure of the univer- erly install the filter will result in the need to replace sal joint due to water and dirt contamination of the...
Page 451: Windshield Wiper Blades
MAINTAINING YOUR VEHICLE 449 attention should also be given to hood latching compo- Avoid using the wiper blades to remove frost or ice from nents to insure proper function. When performing other the windshield. Keep the blade rubber out of contact with underhood services, the hood latch, release mechanism petroleum products such as engine oil, gasoline, etc.
Page 452: Cooling System
450 MAINTAINING YOUR VEHICLE Cooling System WARNING! WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care When working near the radiator cooling fan, dis- must be exercised when filling or working around connect the fan motor lead or turn the ignition the washer solution.
Page 453 MAINTAINING YOUR VEHICLE 451 Coolant Checks If the cap is sealing properly, the engine coolant (anti- Check the engine coolant (antifreeze) protection every freeze) will begin to drain from the coolant recovery 12 months (before the onset of freezing weather, where bottle.
Page 454 452 MAINTAINING YOUR VEHICLE CAUTION! CAUTION! (Continued) This vehicle has not been designed for use with Mixing of engine coolant (antifreeze) other than Propylene Glycol based engine coolant (anti- specified Hybrid Organic Additive Technology freeze). Use of Propylene Glycol based engine (HOAT) engine coolant (antifreeze), may result in coolant (antifreeze) is not recommended.
Page 455 MAINTAINING YOUR VEHICLE 453 When adding engine coolant (antifreeze), a minimum NOTE: Mixing engine coolant (antifreeze) types will solution of 50% recommended MOPAR Antifreeze/ decrease the life of the engine coolant (antifreeze) and Coolant Five Year/100,000 Mile Formula HOAT (Hybrid will require more frequent coolant changes.
Page 456 454 MAINTAINING YOUR VEHICLE rules for your community. To prevent ingestion by ani- WARNING! mals or children do not store ethylene glycol-based engine coolant (antifreeze) in open containers or allow it The warning words “DO NOT OPEN HOT” on to remain in puddles on the ground. If ingested by a the cooling system pressure cap are a safety pre- child, contact a physician immediately.
Page 457 MAINTAINING YOUR VEHICLE 455 of this. As long as the engine operating temperature is Do not overfill the coolant recovery bottle. satisfactory, the coolant bottle need only be checked once Check engine coolant (antifreeze) freeze point in the a month. radiator and in the coolant recovery bottle.
Page 458: Brakes
456 MAINTAINING YOUR VEHICLE Keep the front of the radiator clean. If your vehicle is WARNING! equipped with air conditioning, also keep the front of the condenser clean also. Riding the brakes can lead to brake failure and possibly an accident. Driving with your foot resting Do not change the thermostat for Summer or Winter or riding on the brake pedal can result in abnormally operation.
Page 459 MAINTAINING YOUR VEHICLE 457 Add enough fluid to bring the level up to the require- WARNING! (Continued) ments described on the brake fluid reservoir. With disc Use of a brake fluid that has a lower initial boiling brakes, fluid level can be expected to fall as the brake point than the recommended MOPAR DOT 3 pads wear.
Page 460: Automatic Transaxle
458 MAINTAINING YOUR VEHICLE Automatic Transaxle only the manufacturer’s recommended transmission The automatic transaxle and differential assembly are fluid. Refer to “Fluids, Lubricants and Genuine Parts” in contained within a single housing. this section for the correct fluid type. It is important that the transmission fluid be maintained at the prescribed The fluid level in the automatic transaxle should be level using the recommended fluid.
Page 461 MAINTAINING YOUR VEHICLE 459 Fluid Level Check — 3.8L and 4.0L Engines with 1. The vehicle must be on level ground. Six-Speed Automatic Transaxle — If Equipped 2. The engine should be running at curb idle speed for a The six-speed automatic transaxle is a sealed unit and has minimum of 60 seconds.
Page 462: Appearance Care And Protection From Corrosion
460 MAINTAINING YOUR VEHICLE a. If the fluid is hot, the reading should be in the If the transaxle is disassembled for any reason, the fluid crosshatched area marked “HOT” (between the upper and filter should be changed. two holes in the dipstick). Special Additives b.
Page 463 MAINTAINING YOUR VEHICLE 461 road surfaces on which the vehicle is operated, extreme Atmospheric fallout/industrial pollutants hot or cold weather and other extreme conditions will Washing have an adverse effect on paint, metal trim, and under- body protection. Wash your vehicle regularly. Always wash your ve- hicle in the shade using MOPAR Car Wash or a mild The following maintenance recommendations will enable car wash soap, and rinse the panels completely with...
Page 464 462 MAINTAINING YOUR VEHICLE coating, have your vehicle repaired as soon as pos- CAUTION! sible. The cost of such repairs is considered the respon- sibility of the owner. Do not use abrasive or strong cleaning materials such as steel wool or scouring powder, which will scratch If you carry special cargo such as chemicals, fertilizers, metal and painted surfaces.
Page 465 MAINTAINING YOUR VEHICLE 463 a nonabrasive, non-acidic cleaner. Do not use scouring MOPAR Spot & Stain Remover if absolutely necessary. pads, steel wool, a bristle brush, or metal polishes. Only Do not use harsh cleaners or Armorall. Use MOPAR MOPAR or equivalent is recommended. Do not use Total Clean to clean vinyl upholstery oven cleaner.
Page 466 464 MAINTAINING YOUR VEHICLE For grease stains, apply MOPAR Multi-Purpose WARNING! Cleaner to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in Do not use any solvents or protectants on Yes Essen- closed areas they may cause respiratory harm.
Page 467 MAINTAINING YOUR VEHICLE 465 applique. Rub the applique with firm pressure then buff Glass Surfaces lightly with a clean cotton cloth until a high gloss shine is All glass surfaces should be cleaned on a regular basis achieved. with MOPAR Glass Cleaner or any commercial household-type glass cleaner.
Page 468: Cleaning The Instrument Panel Cupholders
466 MAINTAINING YOUR VEHICLE 1. Clean with a wet soft rag. A mild soap solution may be Cleaning the Instrument Panel Cupholders used, but do not use high alcohol content or abrasive Removal cleaners. If soap is used, wipe clean with a clean damp Pull the flexible liner from the cupholder drawer starting rag.
Page 469: Fuses
MAINTAINING YOUR VEHICLE 467 Installation CAUTION! Place the liner into the cupholder drawer and press the liner into place so that the retention tabs seat into the When installing the Totally Integrated Power corresponding openings in the drawer. Module cover, it is important to ensure the cover is properly positioned and fully latched.
Page 470 468 MAINTAINING YOUR VEHICLE The numbers inside the TIPM cover correspond to the FUSES/TIPM following table. Cartridge Mini- Cavity Description FUSES/TIPM Fuse Fuse Cartridge Mini- 40 Amp — Power Memory Seat Cavity Description Green (If Equipped) Fuse Fuse 40 Amp —...
Page 471 MAINTAINING YOUR VEHICLE 469 FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse 20 Amp — Powertrain Control — 10 Amp Trailer Tow Yellow Module (PCM) Trans Range — 25 Amp Inverter 60 Amp — Radiator Fan Natural Yellow...
Page 472 470 MAINTAINING YOUR VEHICLE FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 20 Amp Ignition Off Draw — — 20 Amp Ignition Off Draw— Yellow Vehicle Entertainment Yellow Cabin Compartment System (IOD-VES), Node (IOD-CCN), Satellite Digital Audio Wireless Control Receiver (SDARS),...
Page 473 MAINTAINING YOUR VEHICLE 471 FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 20 Amp COL MOD, IR SNS, — 10 Amp Occupant Restraint Yellow Heater Ventilation, Controller/Occupant Air Conditioning/ Classification Module Automatic Tempera- (ORC/OCM) ture Control (HVAC/ —...
Page 474 472 MAINTAINING YOUR VEHICLE FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 20 Amp Auto Shut Down — 10 Amp Ignition Switch (IGN Yellow (ASD #3) SW), Window Module (WIN MOD) — 10 Amp Right Horn (RT HORN (HI/LOW) —...
Page 475 MAINTAINING YOUR VEHICLE 473 FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 10 Amp Next Generation Con- — 10 Amp Anti-Lock Brake Sys- troller (NGC), Global tem (ABS), Electronic Powertrain Engine Stability Program Controller (GPEC) (ESP), Stop Lamp Switch (STP LP SW),...
Page 476: Vehicle Storage
474 MAINTAINING YOUR VEHICLE steering column. If you experience temporary or perma- REPLACEMENT LIGHT BULBS nent loss of these systems, see your authorized dealer for service. LIGHT BULBS — Interior Bulb Number Center & Rear Dome Light ....578 VEHICLE STORAGE Center &...
Page 477: Bulb Replacement
MAINTAINING YOUR VEHICLE 475 BULB REPLACEMENT LIGHT BULBS — Exterior Bulb Number Backup, Tail, Stop Light ....3157 Headlights Center High-Mounted Stop Light . . . LED (See Note 1) 1.
Page 478: Front Park/Turn Signal Lights
476 MAINTAINING YOUR VEHICLE 5. Connect the wiring connector to bulb and slide red 1. From behind the bumper fascia, or the access panel on lock tab forward. the air dam, twist the bulb counterclockwise, and remove bulb. Front Park/Turn Signal Lights CAUTION! 1.
Page 479: Rear Tail, Stop, Turn Signal, Side Marker And Backup Lights
MAINTAINING YOUR VEHICLE 477 Rear Tail, Stop, Turn Signal, Side Marker and Backup Lights 1. Raise the liftgate. 2. Remove the tail light assembly by removing the two screws from the inboard side. Use a fiber stick or similar tool to gently pry the light on the outboard side to disengage the two ball studs.
Page 480: Center High-Mounted Stop Light (Chmsl)
478 MAINTAINING YOUR VEHICLE Center High-Mounted Stop Light (CHMSL) The CHMSL uses LED lights that are not serviceable separately. The CHMSL must be replaced as an assembly. See your authorized dealer. License Light The light for the license plate light is located under the tailgate light bar and above the license plate.
Page 481: Fluids And Capacities
MAINTAINING YOUR VEHICLE 479 FLUIDS AND CAPACITIES U.S. Metric Fuel (Approximate) 20 Gallons 76 Liters Engine Oil with Filter 3.3L and 3.8L Engine (SAE 5W-20, API Certified) 5 Quarts 4.7 Liters 4.0 Liter Engine (SAE 10W-30, API Certified) 5.5 Quarts 5.2 Liters Cooling System * 3.3, 3.8, and 4.0 Liter Engine (MOPAR Engine Coolant/...
Page 482: Fluids, Lubricants And Genuine Parts
480 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant Five Year/100,000 Mile Formula HOAT Engine Coolant (Hybrid Organic Additive Technology) Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Engine Oil (3.3L and 3.8L Engines) Chrysler Material Standard MS-6395.
Page 483: Chassis
MAINTAINING YOUR VEHICLE 481 Chassis Component Fluid, Lubricant, or Genuine Part Automatic MOPAR ATF+4 Automatic Transmission Fluid Transaxle Brake Master MOPAR DOT 3 and SAE J1703 should be used or equivalent. If DOT 3 brake fluid is not Cylinder available, then DOT 4 is acceptable. Use only recommended brake fluids. Power Steering MOPAR Power Steering Fluid +4 or MOPAR ATF+4 Automatic Transmission Fluid Reservoir...
Page 485 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..484 Required Maintenance Intervals ..486 Maintenance Schedule ....484...
Page 486 484 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE MAINTENANCE SCHEDULE The Scheduled Maintenance services listed in bold type, The oil change indicator system will remind you that it is must be done at the times or mileages specified to ensure time to take your vehicle in for scheduled maintenance. the continued proper functioning of the Emissions Con- On Non-EVIC equipped vehicles, CHAngE OIL will trol System.
Page 487 MAINTENANCE SCHEDULES 485 NOTE: under “Odometer/Trip Odometer” in the “Instrument The oil change indicator message will not monitor the Cluster Descriptions section of this manual. time since the last oil change. Change your vehicle’s At Each Stop For Fuel oil if it has been six months since your last oil change, even if the oil change indicator message is NOT Check the engine oil level about five minutes after a illuminated.
Page 488 486 MAINTENANCE SCHEDULES Check the fluid levels of the coolant reservoir, the CAUTION! brake master cylinder, the power steering and the transaxle and add as needed. Failure to perform the required maintenance items may result in damage to the vehicle. Check all lights and other electrical items for correct operation.
Page 489 MAINTENANCE SCHEDULES 487 6,000 Miles (10,000 km) or 12,000 Miles (20,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule Schedule Change the engine oil and engine oil filter. Rotate tires. Change the engine oil and engine oil If using your vehicle for any of the following: Dusty or off-road conditions.
Page 490 488 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 24,000 Miles (40,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule Service Schedule Change the engine oil and engine oil filter. Rotate tires. Change the engine oil and engine oil If using your vehicle for any of the following: Dusty or off-road conditions.
Page 491 MAINTENANCE SCHEDULES 489 30,000 Miles (50,000 km) or 36,000 Miles (60,000 km) or 42,000 Miles (70,000 km) or 30 Months Maintenance 36 Months Maintenance 42 Months Maintenance Service Schedule Service Schedule Service Schedule Change the engine oil and engine oil Change the engine oil and engine oil Change the engine oil and engine oil filter.
Page 492: Service Schedule
490 MAINTENANCE SCHEDULES 48,000 Miles (80,000 km) or 48 Months Maintenance Service 54,000 Miles (90,000 km) or Schedule 54 Months Maintenance Change the engine oil and engine oil filter. Service Schedule Rotate tires. Change the engine oil and engine oil If using your vehicle for any of the following: Dusty or off-road conditions.
Page 493 MAINTENANCE SCHEDULES 491 60,000 Miles (100,000 km) or 66,000 Miles (110,000 km) or 60 Months Maintenance 66 Months Maintenance Service Schedule Service Schedule Change the engine oil and engine oil Change the engine oil and engine oil filter. filter. Rotate tires. Rotate tires.
Page 494 492 MAINTENANCE SCHEDULES 72,000 Miles (120,000 km) or 72 Months Maintenance Service 78,000 Miles (130,000 km) or Schedule 78 Months Maintenance Change the engine oil and engine oil filter. Service Schedule Rotate tires. Change the engine oil and engine oil If using your vehicle for any of the following: Dusty or off-road conditions.
Page 495 MAINTENANCE SCHEDULES 493 84,000 Miles (140,000 km) or 90,000 Miles (150,000 km) or 84 Months Maintenance 90 Months Maintenance Service Schedule Service Schedule Change the engine oil and engine oil Change the engine oil and engine oil filter. filter. Rotate tires. Rotate tires.
Page 496 494 MAINTENANCE SCHEDULES 96,000 Miles (160,000 km) or 96 Months Maintenance Service 102,000 Miles (170,000 km) or Schedule 102 Months Maintenance Change the engine oil and engine oil filter. Service Schedule Rotate tires. Change the engine oil and engine oil If using your vehicle for any of the following: Dusty or off-road conditions.
Page 497 MAINTENANCE SCHEDULES 495 108,000 Miles (180,000 km) or 114,000 Miles (190,000 km) or 108 Months Maintenance 114 Months Maintenance Service Schedule Service Schedule Change the engine oil and engine oil Change the engine oil and engine oil filter. filter. Rotate tires. Rotate tires.
Page 498 496 MAINTENANCE SCHEDULES 120,000 Miles (200,000 km) or 120 Months Maintenance Service 126,000 Miles (210,000 km) or Schedule 126 Months Maintenance Change the engine oil and engine oil filter. Service Schedule Rotate tires. Change the engine oil and engine oil Replace the engine air cleaner filter.
Page 499 MAINTENANCE SCHEDULES 497 132,000 Miles (220,000 km) or 138,000 Miles (230,000 km) or 144,000 Miles (240,000 km) or 132 Months Maintenance 138 Months Maintenance 144 Months Maintenance Service Schedule Service Schedule Service Schedule Change the engine oil and engine oil Change the engine oil and engine oil Change the engine oil and engine oil filter.
Page 500 498 MAINTENANCE SCHEDULES 150,000 Miles (250,000 km) or 150 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer...
Page 501 MAINTENANCE SCHEDULES 499 † This maintenance is recommended by the manufac- turer, but is not required to maintain emissions warranty. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment.
Page 503: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Customer Assistance For The Hearing Or Vehicle......503 Speech Impaired (TDD/TTY) .
Page 504 502 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....507 Traction Grades ..... . 509 Department Of Transportation Uniform Tire Temperature Grades .
Page 505: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 503 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 506: Chrysler Llc Customer Center
504 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Vehicle delivery date and mileage dealer’s service manager first. Most matters can be re- Chrysler LLC Customer Center solved with this process. P.O. Box 21–8004 If for some reason you are still not satisfied, talk to the Auburn Hills, MI 48321–8004 general manager or owner of the authorized dealer-...
Page 507: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 505 Customer Assistance For The Hearing Or Speech have any questions about the service contract, call the Impaired (TDD/TTY) manufacturer’s Service Contract National Customer Hot- To assist customers who have hearing difficulties, the line at 1-800-521-9922. manufacturer has installed special TDD (Telecommuni- The manufacturer will not stand behind any service cation Devices for the Deaf) equipment at its customer...
Page 508: Warranty Information (U.s. Vehicles Only)
506 IF YOU NEED CONSUMER ASSISTANCE the ownership experience. You’ll be pleased with their WARRANTY INFORMATION (U.S. Vehicles Only) sincere efforts to resolve any warranty issues or related See the Warranty Information Booklet for the terms and concerns. provisions of Chrysler Motors LLC warranties applicable to this vehicle.
Page 509: In Canada
IF YOU NEED CONSUMER ASSISTANCE 507 a group of vehicles, it may order a recall and remedy Transport Canada, Motor Vehicle Defect Investigations campaign. However, NHTSA cannot become involved in and Recalls, 2780 Sheffield Road, Ottawa, Ontario K1B individual problems between you, your authorized 3V9.
Page 510 508 IF YOU NEED CONSUMER ASSISTANCE vehicles. A complete working knowledge of the ve- Owner’s Manuals hicle, system, and/or components is written in These Owner’s Manuals have been prepared with the straightforward language with illustrations, diagrams, assistance of service and engineering specialists to and charts.
Page 511 IF YOU NEED CONSUMER ASSISTANCE 509 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
Page 512 510 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
Page 513 INDEX...
Page 514 512 INDEX Adding Engine Coolant (Antifreeze) ..452 Airbag Maintenance ..... . . 74 Adding Fuel .
Page 515 INDEX 513 Automatic Headlights ....174 Keyless Transmitter Replacement (RKE) ..26 Automatic Temperature Control (ATC) ..310 Saving Feature (Protection) .
Page 516 514 INDEX Camera, Rear ......192 Check Engine Light Capacities, Fluid ......479 (Malfunction Indicator Light) .
Page 517 INDEX 515 Computer, Trip/Travel ....255 Radiator Cap ......453 Connector Selection of Coolant (Antifreeze) .
Page 518 516 INDEX Disposal Electronic Stability Program ....347 Antifreeze (Engine Coolant) ....454 Electronic Speed Control (Cruise Control) .
Page 519 INDEX 517 Exhaust Gas Caution ....53,382 Exterior Folding Mirrors ....104 Flooded, Starting .
Page 520 518 INDEX Replacement Parts ..... 386 Additives ......381 Starting .
Page 521 INDEX 519 Gasoline, Reformulated ....380 Headlights ......174 Gauges Bulb Replacement .
Page 522 520 INDEX Ignition ....... 14 Jump Starting ......424 Key .
Page 523 INDEX 521 Airbag ..... . 66,71,75,94,244 High Beam/Low Beam Select ... . . 179 Alarm .
Page 524 522 INDEX Tire Pressure Monitoring (TPMS) ... 245 Maintenance, Sunroof ..... 206 Turn Signal .
Page 525 INDEX 523 Multi-Function Control Lever ....177 Recommendation ....439,479 Synthetic .
Page 526 524 INDEX Phone, Cellular ......115 Pretensioners Phone, Hands-Free (UConnect ) ... . . 115 Seat Belts .
Page 527 INDEX 525 Reminder, Seat Belt ..... . . 63 Safety Defects, Reporting ....506 Remote Keyless Entry (RKE) .
Page 528 526 INDEX Adjustment ......144 Service Engine Soon Light Cleaning ......464 (Malfunction Indicator) .
Page 529 INDEX 527 Remote ......28 System, Remote Starting ....28 Starting and Operating .
Page 530 528 INDEX Flat Changing ......421 Tongue Weight/Trailer Weight ....399 General Information .
Page 531 INDEX 529 Automatic ......327 Universal Consumer Interface (UCI) Connector . . . 286 Operation .
Page 532 530 INDEX Warranty Information ..... 506 Power ....... 38 Washer, Adding Fluid .
Page 533 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 534 Chrysler LLC 81-226-0919 First Edition Printed in U.S.A.
