Page 3: Table Of Contents
SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 5 CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by a Warranty Information Booklet and various customer-oriented documents. You are urged to read these publications carefully.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Locking Doors With The Key .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Sound Horn With Remote Key Lock ..22 Flash Lights With Remote Key Lock/Unlock . . 23 Using The Panic Alarm ....24 Programming Additional RKE Transmitters .
Page 13 Child Restraints ..... . 62 Engine Break-In Recommendations ..70 Safety Tips ......71 Transporting Passengers .
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The authorized dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys. Ask your authorized dealer for these numbers and keep them in a safe place.
Page 15 Ignition Switch Positions 1 — LOCK 3 — ON 2 — ACC (ACCESSORY) 4 — START NOTE: If you try to remove the key before you place the shift lever in PARK, the key may become trapped tem- porarily in the ignition switch cylinder. If this occurs, rotate the key to the right slightly, then remove the key as THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 described.
Page 16 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! An unlocked car is an invitation to thieves. Always remove the key from the ignition and lock all the doors when leaving the vehicle unattended. Manual Transmission 1. Turn the ignition switch to the ACC (Accessory) position.
Page 17: Locking Doors With The Key
Locking Doors With The Key You can insert the key with either side up. To lock the door, turn the key to the right. To unlock the door, turn the key to the left. Refer to “Body Lubrication” under “Maintenance Procedures” in Section 7. Key-In-Ignition Reminder Opening the driver’s door when the key is in the ignition and the ignition position is LOCK or ACC, sounds a...
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE someone used an invalid key to try to start the engine. Either of these conditions will result in the engine being shut off after two seconds. If the Vehicle Security Light turns on during normal vehicle operation (vehicle running for longer than 10 sec- onds), it indicates that there is a fault in the electronics.
Page 19: Customer Key Programming
At the time of purchase, the original owner is provided with a four-digit Personal Identification Number (PIN). Keep the PIN in a secure location. This number is required for authorized dealer replacement of keys. Du- plication of keys may be performed at an authorized dealer or by following the customer key programming procedure.
Page 20: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The new Sentry Key is programmed. The Remote Keyless Entry (RKE) transmitter will also be pro- grammed during this procedure. Repeat this procedure to program up to eight keys. If you do not have a programmed Sentry Key , contact your authorized dealer for details.
Page 21: To Set The Security Alarm
To Set The Security Alarm 1. Remove the key from the ignition switch and get out of the vehicle. 2. Lock the door using either the power door LOCK switch or the Remote Keyless Entry (RKE) transmitter and close all doors. 3.
Page 22: Remote Keyless Entry - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE KEYLESS ENTRY — IF EQUIPPED This system allows you to lock or unlock the doors and liftgate or activate the Panic Alarm from distances up to approximately 66 ft (20 m) using a handheld Remote Keyless Entry (RKE) transmitter.
Page 23: To Unlock The Doors And Liftgate
To Unlock The Doors And Liftgate Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door, or twice within five seconds to unlock all doors and liftgate. The turn signal lights will flash to acknowledge the unlock signal.
Page 24: Illuminated Approach - If Equipped
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Pressing the LOCK button on the RKE transmit- ter while you are inside the vehicle will activate the Vehicle Security Alarm. Opening a door with the Vehicle Security Alarm activated will cause the alarm to sound. Press the UNLOCK button to deactivate the Vehicle Security Alarm.
Page 25: Flash Lights With Remote Key Lock/Unlock
For vehicles not equipped with the EVIC, perform the following steps: 1. Press the LOCK button on a programmed RKE trans- mitter for at least 4 seconds, but no longer than 10 sec- onds. Then, press the PANIC button while still holding the LOCK button.
Page 26: Using The Panic Alarm
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE For vehicles not equipped with the EVIC, perform the following steps: 1. Press and hold the UNLOCK button on a programmed RKE transmitter for at least 4 seconds, but no longer than 10 seconds.
Page 27: Programming Additional Rke Transmitters
Programming Additional RKE Transmitters Refer to Sentry Key “Customer Key Programming.” If you do not have a programmed RKE transmitter, contact your authorized dealer for details. General Information This device complies with Part 15 of FCC rules and with RS-210 of Industry Canada. Operation is subject to the following conditions: 1.
Page 28: Door Locks
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. If the RKE transmitter is equipped with a screw, remove the screw. With the RKE transmitter buttons facing down, use a flat blade to pry the two halves of the RKE transmitter apart. Make sure not to damage the elastomer seal during removal.
Page 29: Power Door Locks
Manual Door Lock Plunger WARNING! For personal security and safety in the event of an accident, lock the vehicle doors as you drive as well as when you park and leave the vehicle. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 WARNING! (Continued) When leaving the vehicle, always remove the key from the ignition lock and lock your vehicle.
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: To prevent from locking the key in the vehicle, the power door lock switch will not operate when the key is in the ignition and either front door is open. A chime will sound as a reminder to remove the key.
Page 31 Automatic Door Locks Programming The Automatic Door Locks feature can be enabled or disabled as follows: For vehicles equipped with the Electronic Vehicle Information Center (EVIC), refer to “Personal Settings (Customer-Programmable Features)” under “Elec- tronic Vehicle Information Center (EVIC) — If Equipped”...
Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. The transmission is in NEUTRAL or PARK. 4. The driver’s door is opened. 5. The doors were not previously unlocked. Automatic Unlock Doors on Exit Programming The Automatic Unlock Doors On Exit feature can be enabled or disabled as follows: For vehicles equipped with the EVIC, refer to “Per- sonal Settings (Customer-Programmable Features)”...
Page 33: Child-Protection Door Lock System (Rear Doors) - If Equipped
Child-Protection Door Lock System (Rear Doors) — If Equipped Insert the tip of the ignition key into the lock and rotate to the LOCK or UNLOCK position. Child-Protection Door Lock Location THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 Child-Protection Door Lock Function WARNING! Avoid trapping anyone in a vehicle in a collision.
Page 34: Power Windows - If Equipped
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: For emergency exit with the system engaged, move the lock plunger up (unlocked position), roll down the window and open the door with the outside door handle. POWER WINDOWS — IF EQUIPPED Power Window Switches Power Window Switch Location The window controls on the driver’s door trim panel...
Page 35: Auto Down
controls on each passenger door trim panel, which oper- ate the passenger door windows. The window controls will operate when the ignition switch is in the ON or ACC position. NOTE: For vehicles not equipped with the Electronic Vehicle Information Center (EVIC), the power window switches will remain active for 45 seconds after the ignition switch is turned to the LOCK position.
Page 36: Window Lockout Switch
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window Lockout Switch The window lockout switch on the driver’s door allows you to disable the window control on the other doors. To disable the window controls on the other doors, press the window LOCKOUT switch.
Page 37 Liftgate Handle NOTE: In the event of a power malfunction, or the RKE transmitter is inoperative, insert the key into the liftgate lock cylinder and turn it to the right (manual lock models only). Using the liftgate handle, pull the liftgate open with one fluid motion.
Page 38: Occupant Restraints
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Gas props support the liftgate in the open position. However, because the gas pressure drops with tempera- ture, it may be necessary to assist the props when opening the liftgate in cold weather. OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems.
Page 39: Lap/Shoulder Belts
ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times. Lap/Shoulder Belts All the seats in your vehicle are equipped with lap/ shoulder belts. The belt webbing retractor is designed to lock during very sudden stops or collisions.
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your pas- sengers safe, too.
Page 41 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Inserting Latch Plate into Buckle THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 WARNING! A belt that is buckled into the wrong buckle will not protect you properly.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) A belt that is worn under your arm is very danger- ous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries.
Page 43 WARNING! A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap belt as low as possible and keep it snug.
Page 44: Adjustable Upper Shoulder Belt Anchorage
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Adjustable Upper Shoulder Belt Anchorage In the front seat, the shoulder belt can be adjusted upward or downward to position the belt away from your neck. Push the anchorage button to release the anchorage, and move it up or down to the position that fits you best.
Page 45: Second Row Center Lap/Shoulder Belt Operating Instructions
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 Second Row Center Lap/Shoulder Belt Operating Instructions The second row center lap/shoulder belt features a three point seat belt with a mini-latch and buckle, which allows the shoulder belt to detach from the lower anchor when the seat is folded.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Grasp the mini-latch plate and pull the belt over the seat. 3. Route the shoulder belt to the inside of the right head restraint. Routing the Rear Center Shoulder Belt Routing the Rear Center Shoulder Belt 4.
Page 47 6. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Connecting Mini-Latch to Buckle 7. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 on the shoulder belt.
Page 48: Seat Belt Pretensioners
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 9. To release the belt, push the red button on the buckle. Detaching Mini-Latch And Buckle 10. To disengage the mini-latch from the mini-buckle for storage, insert the regular latch plate into the black button on the top of the mini-buckle.
Page 49: Enhanced Seat Belt Use Reminder System (Beltalert )
front airbags, the pretensioners are single use items. After a collision that is severe enough to deploy the airbags and pretensioners, both must be replaced. Enhanced Seat Belt Use Reminder System (BeltAlert ) If the driver’s seat belt has not been buckled within 60 seconds of starting the vehicle and if the vehicle speed is greater than 5 mph (8 km/h), the Enhanced Seat Belt Use Reminder System (BeltAlert ) will alert the driver to...
Page 50: Seat Belts And Pregnant Women
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Watch for the Seat Belt Reminder Light to turn on while unbuckling and off while re-buckling the seat belt. It may be necessary to retract the seat belt. 4. Turn the ignition switch to the LOCK position. A single chime will sound to signify that you have success- fully completed the programming.
Page 51: Driver And Front Passenger Supplemental Restraint System (Srs) - Airbag
Driver And Front Passenger Supplemental Restraint System (SRS) — Airbag This vehicle has airbags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s front airbag is mounted in the center of the steering wheel. The passenger’s front airbag is mounted in the instrument panel, above the glove compartment.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity. This vehicle may also be equipped with side curtain airbags to protect the driver and passengers sitting next to a window.
Page 53 WARNING! Do not put anything on or around the airbag covers or attempt to manually open them. You may damage the airbags and you could be injured because the airbags are not there to protect you. These protective covers for the airbag cushions are designed to open only when the airbags are inflat- ing.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE moderate to severe side collisions. In certain types of collisions, both the front and side airbags may be trig- gered. But even in collisions where the airbags work, you need the seat belts to keep you in the right position for the airbags to protect you properly.
Page 55 4. If your vehicle has side airbags, do not lean against the door; airbags will inflate forcefully into the space between you and the door. 5. If the airbag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Side Curtain Airbags Above Side Win- dows (If Equipped) Steering Wheel and Column Instrument Panel Interconnecting Wiring Seat Belt Reminder Light Knee Impact Bolsters Driver Inflatable Knee Blocker Front Acceleration Sensors Driver and Front Passenger Seat Belt Pretensioners How The Airbag System Works The Occupant Restraint Controller (ORC) determines...
Page 57 Airbag Warning Light either momentarily or continu- ously. A single chime will sound if the light comes on again after initial start up. WARNING! Ignoring the AIRBAG Warning Light in your instru- ment panel could mean you won’t have the airbags to protect you in a collision.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The ORC module determines if a side collision is severe enough to require the side airbags to inflate. The side airbag control module will not detect roll over, front or rear collisions. The ORC module monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or ON position.
Page 59 WARNING! Unapproved modifications or service procedures to the front passenger seat assembly, its related compo- nents, or seat cover may inadvertently change the airbag deployment in case of a frontal crash. This could result in death or serious injury to the front seat passenger if the vehicle is involved in an acci- dent.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE As the airbags deflate you may see some smoke-like particles. The particles are a normal by-product of the process that generates the nontoxic gas used for airbag inflation. These airborne particles may irritate the skin, eyes, nose, or throat.
Page 61 Maintaining Your Airbag System WARNING! Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper passenger side of the instrument panel.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE moment of airbag deployment, or near-deployment, and up to a quarter second of high-speed deceleration data during and/or after air bag deployment or near- deployment. EDR data are ONLY recorded if an airbag deploys, or nearly deploys, and are otherwise unavail- able.
Page 63 particular driver, vehicle, or crash, will be treated confi- dentially. Confidential data will not be disclosed by Chrysler LLC to any third party except when: 1. Used for research purposes, such as to match data with a particular crash record in an aggregate database, provided confidentiality of personal data is thereafter preserved 2.
Page 64: Child Restraints
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Restraints Everyone in your vehicle needs to be buckled up all the time, including babies and children. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it.
Page 65 Infants and Child Restraints There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat owner’s manual to ensure you have the correct seat for your child.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE are older than one year. These child seats are also held in the vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system. The belt-positioning booster seat is for children weigh- ing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly.
Page 67 Standards. We also recommend that you make sure that you can install the child restraint in the vehicle where you will use it before you buy it. The restraint must be appropriate for your child’s weight and height. Check the label on the restraint for weight and height limits.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE around, and insert the latch plate into the buckle again. If you still can’t make the child restraint secure, try a different seating position. Buckle the child into the seat according to the child restraint manufacturer’s directions.
Page 69 Your vehicle is equipped with the child restraint anchor- age system called LATCH. The LATCH system provides for the installation of the child restraint without using the vehicle seat belt. All three rear seating positions have lower anchorages that are capable of accommodating LATCH-compatible child seats having flexible, webbing- mounted lower attachments.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE provide add-on tether strap kits for some of their older products. Tether anchorage kits are also available for most older vehicles. Because the lower anchorages are to be introduced to passenger carrying vehicles over a period of years, child restraint systems having attachments for those anchor- ages will continue to have features for installation in vehicles using the lap or lap/shoulder belt.
Page 71 In general, you will first loosen the adjusters on the lower and tether straps so that you can more easily attach the hook or connector to the lower and tether anchorages. The tether strap should be routed under the center of the head restraint and attached to the tether anchor on the rear of the seat back.
Page 72: Engine Break-In Recommendations
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor position directly behind the child seat to secure a child restraint top tether strap.
Page 73: Safety Tips
While cruising, brief full-throttle acceleration within the limits of local traffic laws, contributes to a good break-in. Wide-open throttle acceleration in low gear can be detri- mental and should be avoided. The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant.
Page 74: Exhaust Gas
72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or...
Page 75: Safety Checks You Should Make Inside The Vehicle
Safety Checks You Should Make Inside The Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lights Have someone observe the operation of exterior lights while you work the controls. Check turn signal and high beam indicator lights on the instrument panel. Door Latches Check for positive closing, latching, and locking. Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks.
Page 77 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......79 Inside Day/Night Mirror ....79 Automatic Dimming Inside Mirror —...
Page 78 76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Recognition System (VR) — If Equipped ......112 Voice Recognition System (VR) Operation .
Page 79 Daytime Running Lights (DRL) — If Equipped ......131 Windshield Wipers And Washers ..131 Windshield Wiper Operation .
Page 80 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening The Sunroof ....145 Closing The Sunroof ....146 Pinch Protect Feature .
Page 81: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of vehicle).
Page 82: Automatic Dimming Inside Mirror - If
80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Inside Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 83: Power Mirrors - If Equipped
WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in this convex mirror.
Page 84 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To adjust a mirror, turn the control wand toward the left or right mirror positions indicated. Tilt the control wand in the direction you want the mirror to move. When finished adjusting the mirror, turn the control to the center position to prevent accidentally moving a mirror.
Page 85: Vanity Mirrors - If Equipped
Vanity Mirrors — If Equipped To use the vanity mirror, rotate the sun visor down and swing the mirror cover upward. Vanity Mirror Sun Visor Sliding Feature The sun visors may be extended out to provide more coverage of the side glass. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 uconnect phone —...
Page 86 For uconnect customer support, visit the following websites: www.chrysler.com/uconnect www.dodge.com/uconnect www.jeep.com/uconnect or call 1–877–855–8400 uconnect allows you to transfer calls between the sys- tem and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone for private conversation.
Page 87: Operation
Phone Button The rearview mirror contains the microphone for the system (depending on the type of mirror and radio equipped), and either the radio or the mirror has the two control buttons (PHONE Button and VOICE RECOGNITION button) that will enable you to access the system. Voice Recognition Button Actual button location may vary with the ra- dio.
Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For certain operations, compound commands can be used. For example, instead of saying Setup and then Phone Pairing, the following compound command can be said: Setup Phone Pairing. For each feature explanation in this section, only the combined form of the voice command is given.
Page 89 To complete the pairing process, you will need to refer- ence your cellular phone Owner’s Manual. The uconnect website may also provide detailed instructions for pairing. The following are general phone to uconnect phone pairing instructions: Press the PHONE button to begin. After the Ready prompt and the following beep, say Setup Phone Pairing.
Page 90 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dial by Saying a Number Press the PHONE button to begin. After the Ready prompt and the following beep, say Dial. The system will prompt you to say the number you want to call. For example, you can say 234-567-8901 .
Page 91 After the Ready prompt and the following beep, say Phonebook New Entry. When prompted, say the name of the new entry. Use of long names helps the voice recognition and it is recommended. For example, say Robert Smith or Robert instead of Bob. When prompted, enter the number designation (e.g., Home, Work, Mobile, or Pager ).
Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic download and update, if supported, begins as soon as the Bluetooth wireless phone connection is made to the uconnect phone, for example, after you start the vehicle. A maximum of 1000 entries per phone will be down- loaded and updated every time a phone is connected to the uconnect phone.
Page 93 NOTE: The phone handset must support Bluetooth OBEX transfers of phonebook entries to use this feature. Some phones cannot send phonebook entries if they are already connected to any system via Bluetooth , and you may see a message on the phone display that the Bluetooth link is busy.
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you are finished editing an entry in the phonebook, you will be given the opportunity to edit another entry in the phonebook, call the number you just edited, or return to the main menu. Phonebook Edit can be used to add another phone number to a name entry that already exists in the phonebook.
Page 95 Delete/Erase “All” uconnect Phonebook Entries Press the PHONE button to begin. After the Ready prompt and the following beep, say Phonebook Erase All. The uconnect phone will ask you to verify that you wish to delete all the entries from the phonebook. After confirmation, the phonebook entries will be deleted.
Page 96: Phone Call Features
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Call Features The following features can be accessed through the uconnect phone if the feature(s) are available on your cellular service plan. For example, if your cellular service plan provides three-way calling, this feature can be accessed through the uconnect phone.
Page 97 refer to Toggling Between Calls in this section. To combine two calls, refer to Conference Call in this section. Place/Retrieve a Call From Hold To put a call on hold, press the PHONE button until you hear a single beep. This indicates that the call is on hold. To bring the call back from hold, press and hold the PHONE button until you hear a single beep.
Page 98: Uconnect Phone Features
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE hold may not become active automatically. This is cell phone-dependent. To bring the call back from hold, press and hold the PHONE button until you hear a single beep. Redial Press the PHONE button to begin. After the Ready prompt and the following beep, say Redial.
Page 99 After the Ready prompt and the following beep, say the name of the language you wish to switch to English, Espanol, or Francais. Continue to follow the system prompts to complete the language selection. After selecting one of the languages, all prompts and voice commands will be in that language.
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If supported, this number may be programmable on some systems. To do this, press the PHONE button and say ‘Setup’, followed by ‘Emergency’. The uconnect phone does slightly lower your chances of successfully making a phone call as to that for the cell phone directly.
Page 101 Voice Mail Calling To learn how to access your voice mail, refer to Working with Automated Systems. Working with Automated Systems This method is used in instances where one generally has to press numbers on the cellular phone keypad while navigating through an automated telephone system.
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Some paging and voice mail systems have system time out settings that are too short and may not allow the use of this feature. Barge In - Overriding Prompts The “Voice Recognition” button can be used when you wish to skip part of a prompt and issue your voice recognition command immediately.
Page 103: Advanced Phone Connectivity
phone, the audio will be played through your vehicle’s audio system. The uconnect phone will work the same as if you dial the number using voice recognition. NOTE: Certain brands of cellular phones do not send the dial ring to the uconnect phone to play it on the vehicle audio system, so you will not hear it.
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you would like to connect or disconnect the Bluetooth connection between a uconnect phone paired cellular phone and the uconnect phone, follow the instructions described in your cellular phone User’s Manual. List Paired Cellular Phone Names Press the PHONE button to begin.
Page 105: Things You Should Know About Your Uconnect Phone
Delete uconnect phone Paired Cellular Phones Press the PHONE button to begin. After the Ready prompt and the following beep, say Setup Phone Pairing. At the next prompt, say Delete and follow the prompts. You can also press the VOICE RECOGNITION button at any time while the list is being played, and then choose the phone you wish to delete.
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This procedure may be repeated with a new user. The system will adapt to the last trained voice only. To restore the Voice Recognition system to factory default settings, enter the Voice Training session via the above procedure and follow the prompts.
Page 107 It is not recommended to store similar sounding names in the uconnect phonebook. Phonebook (Downloaded and uconnect phone Local) name recognition rate is optimized when the entries are not similar. You can say O (letter O ) for 0 (zero). 800 must be spoken eight-zero-zero.
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Bluetooth Communication Link Cellular phones have been found to lose connection to the uconnect phone. When this happens, the connection can generally be reestablished by switching the phone off/on. Your cellular phone is recommended to remain in Bluetooth ON mode.
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107...
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109...
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 113 Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 114: General Information
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 115 When you press the VR button, you will hear a beep. The beep is your signal to give a command. NOTE: If you do not say a command within a few seconds, the system will present you with a list of options.
Page 116: Commands
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Commands The Voice Recognition system understands two types of commands. Universal commands are available at all times. Local commands are available if the supported radio mode is active. Changing the Volume 1. Start a dialogue by pressing the VR button. 2.
Page 117 Radio FM To switch to the FM band say “FM” or “Radio FM”. In this mode, you may say the following commands: “Frequency” (to change the frequency) “Next Station” (to select the next station) “Previous Station” (to select the previous station) “Radio Menu”...
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Memo To switch to the voice recorder mode say “Memo”. In this mode, you may say the following commands: “New Memo” (to record a new memo) — During the recording you may press the VR button to stop record- ing.
Page 119: Voice Training
NOTE: Keep in mind that you have to press the VR button first and wait for the beep before speaking the “Barge In” commands. Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, uconnect phone Voice Training feature may be used.
Page 120: Manual Seat Height Adjustment - If Equipped
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Using body pressure, move forward and rearward on the seat to be sure the seat adjusters have latched. WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control.
Page 121: Manual Lumbar - If Equipped
Manual Lumbar — If Equipped The lumbar adjustment handle is located on the outboard side of the driver’s seat. To increase or decrease support, rotate the handle up or down. Lumbar Adjustment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Driver’s Seatback Recline To recline: 1.
Page 122: Adjustable Head Restraints
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjustable Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear. Pull up or push down on the head restraints so that the upper edge is as high as practical.
Page 123 After turning the ignition ON, you can choose from High, Low, or Off heat settings. Amber indicator lights in each switch indicate the level of heat in use. Two indicator lights will illuminate for High, one for Low, and none for Off.
Page 124: Fold-Flat Front Passenger Seat
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fold-Flat Front Passenger Seat To fold the front passenger seat, lift the recliner handle to the full upward position and push the seatback forward until it rests on the seat cushion. Front Passenger Seat Folded Flat Fold-Flat Front Passenger Seat Handle...
Page 125: Folding Rear Seat
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Folding Rear Seat To provide additional storage area, each rear seatback can be folded forward. Pull the strap forward to move the seat forward and flat. Rear Seat Folded Flat Folding Rear Seat...
Page 126: Reclining Rear Seat - If Equipped
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reclining Rear Seat — If Equipped For additional comfort, pull the strap forward just enough to release the seatback latch. Reclining Rear Seat Strap Then push the seatback to a reclined position, approxi- mately 35 degrees maximum, and release the strap.
Page 127 Hood Release Lever 2. Move the safety catch located under the front edge of the hood, near the center and raise the hood. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Safety Catch Lift the hood prop rod, clipped to the left side (right side facing hood) of the engine compartment, to secure the hood in the open position.
Page 128: Lights
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! To prevent possible damage, do not slam the hood to close it. Lower the hood until it is open approxi- mately 8 in (20 cm) and then drop it. This should secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged.
Page 129: Lights-On Reminder
Headlight Control To change the brightness of the instrument panel lights, rotate the center portion of the multifunction lever up or down. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Dimmer Control Lights-on Reminder If the headlights or parking lights are on after the ignition is turned OFF, a chime will sound to alert the driver when the driver’s door is opened.
Page 130: Fog Lights - If Equipped
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fog Lights — If Equipped The front fog light switch is on the multifunction lever. To activate the front fog lights, turn on the parking lights or the low beam headlights and pull out the end of the multifunction lever.
Page 131: High Beam/Low Beam Select Switch
Turn Signal Control If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb. If an indicator fails to light when the multifunction lever is moved, it would suggest that the fuse or indicator bulb is defective.
Page 132: Flash-To-Pass
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flash-to-Pass You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you. This will cause the headlights to turn on at high beam and remain on until the multifunction lever is released. NOTE: If the multifunction lever is held in the flash-to- pass position for more than 30 seconds, the high beams will shut off.
Page 133: Daytime Running Lights (Drl) - If Equipped
Daytime Running Lights (DRL) — If Equipped The high beam headlights will come on as Daytime Running Lights (DRL) at DRL intensity, which is a lower intensity then the normal high beams. The DRL’s will come on whenever the ignition is ON, the engine is running, the headlight switch is off, the parking brake is off, the turn signal is off, and the shift lever is in any position except for PARK.
Page 134: Intermittent Wiper System
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Intermittent Wiper System Use the intermittent wiper when weather conditions make a single wiping cycle, with a variable pause be- tween cycles, desirable. Select the delay interval by turning the end of the lever. Rotate the knob upward (clockwise) to decrease the delay time and downward (counterclockwise) to increase the delay time.
Page 135: Mist Feature
Mist Feature Push down on the wiper control lever to activate a single wipe to clear the windshield of road mist or spray from a passing vehicle. As long as the lever is held down, the wipers will continue to operate. Mist Control UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 CAUTION!
Page 136: Tilt Steering Column
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT STEERING COLUMN To tilt the steering column, push down on the lever below the multifunction lever. With one hand firmly on the wheel, move the steering column up or down as desired. Push the lever back up to lock the column firmly in place.
Page 137: To Activate
Electronic Speed Control Lever NOTE: The Electronic Speed Control system has been designed to shut down if multiple speed control switch functions are operated simultaneously in order to ensure proper operation. If this occurs, the system can be UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 reactivated by pushing the Electronic Speed Control switch ON/OFF button and resetting the desired vehicle set speed.
Page 138: To Set At A Desired Speed
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Set At A Desired Speed When the vehicle has reached the desired speed, press down on the Electronic Speed Control lever and release. Release the accelerator and the vehicle will operate at the selected speed.
Page 139: Manual Transaxle
Tapping the SET DECEL button once will result in a 1 mph (1.6 km/h) speed decrease. Each time the button is tapped, speed decreases. Manual Transaxle Pressing the clutch pedal will disengage the speed con- trol. A slight increase in engine RPM before the Electronic Speed Control disengages is normal.
Page 140: Garage Door Opener - If Equipped
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE On steep hills, a greater speed loss or gain may occur so it may be preferable to drive without Electronic Speed Control. GARAGE DOOR OPENER — IF EQUIPPED HomeLink replaces up to three remote controls (hand- held transmitters) that operate devices such as garage door openers, motorized gates, lighting, or home security systems.
Page 141: Programming Homelink
WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. Only use this trans- ceiver with a garage door opener that has a “stop and reverse”...
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Place the hand-held transmitter 1–3 in (3-8 cm) away from the HomeLink button you wish to program while keeping the indicator light in view. 3. Simultaneously press and hold both the chosen HomeLink button and the hand-held transmitter button until the HomeLink indicator changes from a slow to a rapidly blinking light, then release both the HomeLink and hand-held transmitter buttons.
Page 143 This can usually be found where the hanging antenna wire is attached to the garage door opener motor (it is NOT the button normally used to open and close the door). 1 — Garage Door Opener 2 — Training Button UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 6.
Page 144: Gate Operator/Canadian Programming
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Gate Operator/Canadian Programming Canadian radio-frequency laws require transmitter sig- nals to “time-out” (or quit) after several seconds of transmission – which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U.S.
Page 145: Reprogramming A Single Homelink Button
Reprogramming A Single HomeLink Button To re-program a channel that has been previously trained, follow these steps: 1. Turn the ignition switch to the ON/RUN position. 2. Press and hold the desired HomeLink button until the indicator light begins to flash after 20 seconds. Do not release the button.
Page 146: General Information
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with FCC rules Part 15 and Industry Canada RSS-210. Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference that may be received including interference that may cause undesired operation NOTE: The transmitter has been tested and it complies...
Page 147: Understanding The Features Of Your Vehicle 145
WARNING! Never leave children in a vehicle, with the key in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death. In an accident, there is a greater risk of being thrown from a vehicle with an open sunroof.
Page 148: Closing The Sunroof
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Closing the Sunroof Manual Mode To close the sunroof, press and hold the switch in the forward position. Again, any release of the switch will stop the movement and the sunroof will remain in a partial close condition until the switch is pushed and held forward again.
Page 149: Venting Sunroof - Express
Venting Sunroof — Express Press and hold the “Vent” button, and the sunroof will open to the vent position. This is called “Express Vent”, and will occur regardless of the sunroof position. During Express Vent operation, any movement of the switch will stop the sunroof.
Page 150: Electrical Power Outlets
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRICAL POWER OUTLETS There is a standard 12-Volt power outlet located in the instrument panel for added convenience. This outlet can power cell phones, electronics and other low power devices. Power Outlet 12-Volts...
Page 151 WARNING! To avoid serious injury or death: Do not use a three-prong adapter. Do not insert any objects into the receptacles. Do not touch with wet hands. Close the lid when not in use and while driving the vehicle. If this outlet is mishandled, it may cause an electric shock and failure.
Page 152: Power Inverter - If Equipped
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED A 115-Volt (150-Watt) AC power inverter is located on the rear of the center console for added convenience. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 Watts. Certain high-end video games, such as Playstation3 and XBox360 will exceed this power limit, as will most power tools.
Page 153 WARNING! To avoid serious injury or death: Do not use a three-prong adaptor. Do not insert any objects into the receptacles. Do not touch with wet hands. Close the lid when not in use. If this outlet is mishandled, it may cause an electric shock and failure.
Page 154: Cupholders
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Your vehicle is equipped with four cupholders. There are two cupholders located in the front. Front Cupholders There are two cupholders behind the center console for rear passengers. Rear Cupholders CONSOLE FEATURES The floor console’s sliding armrest moves forward 3 in (76.2 mm) to accommodate shorter drivers.
Page 155 Floor Console Flip Pocket UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 WARNING! Do not operate this vehicle with the console compart- ment lid in the open position. Cell phones, music players, and other handheld electronic devices should be stowed while driving. Use of these devices while driving can cause an accident due to distrac- tion, resulting in death or injury.
Page 156: Cargo Area Features
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CARGO AREA FEATURES Cargo Light/Removable Self-Recharging Flashlight — If Equipped The dual-function light is mounted in the headliner above the cargo area to illuminate the cargo area, and part of it snaps out of the bezel to serve as a flashlight when needed.
Page 157: Cargo Cover - If Equipped
To operate the flashlight, press the switch once for high, twice for low, and a third time to return to off. Three-Press Switch Cargo Cover — If Equipped The cargo area trim panels include two notches for mounting the available tonneau cover that accommo- dates the reclining rear seat.
Page 158: Removable Load Floor
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Using the handle, pull the cover toward you and guide the rear cover posts into the guides located on both sides of the rear trim panel. Cargo Cover Guides WARNING! In an accident a cargo cover loose in the vehicle could cause injury.
Page 159: Cargo Tie-Down Loops
Rear Cargo Area Cargo Tie-Down Loops There are two D-rings installed in the cargo area for securing cargo. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 WARNING! Cargo tie-down loops are not safe anchors for a child seat tether strap. In a sudden stop or collision a loop could pull loose and allow the child seat to come loose.
Page 160: Fold Down Speakers - If Equipped
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) Place as much cargo as possible in front of the rear axle. Too much weight or improperly placed weight over or behind the rear axle can cause the rear of the vehicle to sway. Do not pile luggage or cargo higher than the top of the seatback.
Page 161: Rear Window Defroster
activate the wiper. The rear wiper operates in an inter- mittent mode only. Rotating the center of the switch all the way forward will turn on the wash function. The wash pump will continue to operate as long as the button is pressed.
Page 162: Cooled Beverage Storage Bin/Glove Compartment - If Equipped
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE approximately 10 minutes. For an additional five minutes of operation, press the switch a second time. To prevent excessive battery drain, use the defroster only when the engine is operating. CAUTION! Use care when washing the inside of the rear window to prevent damage to heating elements.
Page 163 NOTE: The use of the Cooled Beverage Storage Bin is for nonperishable beverages only. To operate the beverage cooler, pull the slide control about 0.5 in (12 mm) toward the passenger compartment. This will allow cool air to enter the beverage cooler. To shut off the beverage cooler when not in use, push the slide control back 0.5 in (12 mm).
Page 165 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....166 Instrument Cluster – Base ....167 Instrument Cluster –...
Page 166 164 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - (Disc Mode For CD And MP3/WMA Audio Play, DVD-Video) . . . 198 Notes On Playing MP3/WMA Files ..200 List Button (Disc Mode For MP3/WMA Play) ....203 Info Button (Disc Mode For MP3/WMA Play) .
Page 167 Info Button (CD Mode For MP3 Play) ..228 uconnect studios (Satellite Radio) — If Equipped (REN/REQ/RER/RES/REU Radios Only)....... 229 System Activation .
Page 168: Instrument Panel Features
166 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 - Air Outlet 5 - Upper Glove Compartment 2 - Demisters 6 - Lower Glove Compartment/Beverage Cooler – If Equipped 3 - Instrument Cluster 7 - Storage Bins 4 - Radio 8 - Climate Controls 9 - Heated Seat Switches –...
Page 169: Instrument Cluster - Base
UNDERSTANDING YOUR INSTRUMENT PANEL 167 INSTRUMENT CLUSTER – BASE...
Page 170: Instrument Cluster - Premium
168 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER – PREMIUM...
Page 171: Instrument Cluster Descriptions
INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge When the ignition switch is in the ON position, the pointer will show the level of fuel remaining in the fuel tank. 2. Fuel Door Reminder This indicates that the fuel filler door is located on the left side of the vehicle.
Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call an authorized dealer- ship for service if your vehicle overheats. If you decide to look under the hood yourself, see Section 7 of this manual.
Page 173 8. Airbag Warning Light This light turns on and remains on for seven seconds as a bulb check, when the ignition switch is first turned ON. If the light is not on during starting, stays on, or turns on while driving, have the system inspected by an authorized dealer as soon as possible.
Page 174 172 UNDERSTANDING YOUR INSTRUMENT PANEL 12. Engine Temperature Warning Light This light warns of an overheated engine condi- tion. As temperatures rise and the gauge ap- proaches H , this indicator will illuminate and a single chime will sound after reaching a set threshold. Further overheating will cause the temperature gauge to pass H , the indicator will continuously flash and a continuous chime will occur until the engine is allowed...
Page 175 Accordingly, when the low tire pressure telltale illumi- nates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly under-inflated tire causes the tire to overheat and can lead to tire failure. Under-inflation also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability.
Page 176 174 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system opera- tion or sensor damage may result when using re- placement equipment that is not of the same size, type, and/or style.
Page 177 means the engine oil change interval may fluctuate dependent upon your personal driving style. Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the Trip Odometer button on the instrument cluster.
Page 178 176 UNDERSTANDING YOUR INSTRUMENT PANEL 17. Cruise Indicator — If Equipped This indicator shows that the Speed Control system is ON. 18. Trip/Odometer Display Reset Button Press this button to change the display from odometer to either of the two trip odometer settings. Trip A or Trip B will appear when in the trip odometer mode.
Page 179 21. Turn Signal Indicators The arrow will flash with the exterior turn signal when the turn signal lever is operated. If the vehicle electronics sense that the vehicle has traveled about one mile with the turn signals on, a continuous chime will sound to alert you to turn the signals off.
Page 180 178 UNDERSTANDING YOUR INSTRUMENT PANEL brakes. If the ABS light does not turn on when the Ignition switch is turned to the ON position, have the light inspected by an authorized dealer. 25. High Beam Indicator This indicator shows that the headlights are on high beam.
Page 181 NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level condi- tions. The vehicle should have service performed, and the brake fluid level checked. If brake failure is indicated, immediate repair is neces- sary. WARNING! Driving a vehicle with the red brake light on is dangerous.
Page 182: Electronic Vehicle Information Center (Evic) - If Equipped
180 UNDERSTANDING YOUR INSTRUMENT PANEL 28. Electronic Vehicle Information Center Display — If Equipped When the appropriate conditions exist, this display shows the Electronic Vehicle Information Center (EVIC) messages. Refer to the Electronic Vehicle Information Center (EVIC) in this section for more information. 29.
Page 183 The EVIC consists of the following: System Status Vehicle information warning message displays Personal settings (customer programmable features) Compass heading Outside temperature display Trip computer functions uconnect phone displays — If equipped Audio mode display Tire Pressure Monitor (TPM) When the appropriate conditions exist, the EVIC displays the following messages.
Page 184: Oil Change Required
182 UNDERSTANDING YOUR INSTRUMENT PANEL Gate Ajar (with a single chime) Headlights On Key In Ignition Check TPM System Oil Change Required Oil Change Required Your vehicle is equipped with an engine oil change indicator system. The “Change Oil” message will flash in the instrument cluster odometer for approximately 5 sec- onds after a single chime has sounded to indicate the next scheduled oil change interval.
Page 185: Evic Functions
EVIC Functions EVIC Button Press the EVIC button until one of the following func- tions are displayed on the EVIC: Compass/Temperature/Audio Average Fuel Economy UNDERSTANDING YOUR INSTRUMENT PANEL 183 Distance To Empty (DTE) Elapsed Time Tire Pressure Monitor (TPM) Personal Settings To Reset The Display Pressing and holding the EVIC button once will clear the function currently being displayed.
Page 186: Compass/Temperature/Audio
184 UNDERSTANDING YOUR INSTRUMENT PANEL Compass/Temperature/Audio Press and release the EVIC button to display one of eight compass headings to indicate the direction the vehicle is facing, the outside temperature and the current radio station. For additional information regarding the compass, refer to “Personal Settings (Customer Programmable Fea- tures)”...
Page 187: Elapsed Time
Elapsed Time Shows the total elapsed time of travel since the last reset when the ignition switch is in the ACC position. Elapsed time will increment when the ignition switch is in the ON or START position. Tire Pressure Monitor (TPM) Refer to “Tire Pressure Monitoring System (TPMS)”...
Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL Auto Unlock On Exit When ON is selected all the vehicle’s doors will unlock when the driver’s door is opened if the vehicle is stopped (manual transmissions) or the vehicle is stopped and the transmission is in PARK or NEUTRAL position (auto- matic transmissions).
Page 189 when exiting the vehicle. Press and hold the EVIC button when in this display until 0, 30, 60, or 90 appears to make your selection. Delay Power Off to Accessories Until Exit When this feature is selected, the power window switches, radio, uconnect phone, power sunroof, and power outlets will remain active for up to 10 minutes after the ignition switch has been turned off.
Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: A good calibration requires a level surface and an environment free from large metallic objects such as buildings, bridges, underground cables, railroad tracks, Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To ensure compass accu- racy, the compass variance should be properly set accord- ing to the variance map for the zone where the vehicle will be driven.
Page 191 press and release (less than one second) the EVIC button several times until “Compass Variance” is highlighted. The “Compass Variance” message and the current vari- ance zone number will be displayed. To change the zone, press and hold (longer than two seconds) the EVIC button to increment the variance one step.
Page 192: Sales Code Req - Am/Fm Stereo Radio And 6-Disc Cd/Dvd Changer (Mp3/Wma Aux Jack)
190 UNDERSTANDING YOUR INSTRUMENT PANEL calibration mode. The CAL indicator will come on con- tinuously in the EVIC display to indicate that the com- pass is now in the calibration mode, and that the vehicle can now be driven to calibrate. 5.
Page 193: Operating Instructions - Radio Mode
Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Press the ON/VOLUME control knob a second time to turn off the radio.
Page 194 192 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button uconnect phone — If Equipped Press this button to operate the uconnect phone feature (if equipped). Refer to “uconnect phone” in Section 3. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With uconnect”...
Page 195 TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency. Setting the Tone, Balance, and Fade Push the rotary TUNE/SCROLL control knob and BASS will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the bass tones. Push the rotary TUNE/SCROLL control knob a second time and MID will display.
Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button to select the following format types: Program Type No program type or un- defined Adult Hits Classical Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies 16-Digit Character Display None Adlt Hit...
Page 197 By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station.
Page 198 196 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The available selections for each of the above entries varies depending upon the disc. These selections can only be made while playing a DVD. VES™ Power - Allows you to turn VES™ ON and OFF (if equipped).
Page 199 down and selecting other. Enter the country code using the TUNE/SCROLL control knob to scroll up and down to select the number and then push to select. Subtitle Language — If Equipped Selecting this item allows you to choose a default subtitle language (effective only if the language is supported by the disc).
Page 200: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
198 UNDERSTANDING YOUR INSTRUMENT PANEL SET Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET button. The symbol SET 1 will now show in the display window. Select the button (1-6) you wish to lock onto this station and press and release that button.
Page 201 CAUTION! The radio may shut down during extremely hot conditions. When this occurs, the radio will indicate “Disc Hot” and shut off until a safe temperature is reached. This shutdown is necessary to protect the optics of the DVD player and other radio internal components.
Page 202: Notes On Playing Mp3/Wma Files
200 UNDERSTANDING YOUR INSTRUMENT PANEL The disc can be ejected with the radio and ignition OFF. SEEK Button (CD MODE) Press the right SEEK button for the next selection on the CD. Press the left SEEK button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first second of the current selection.
Page 203 Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL frequencies in the following table are supported. In addition, variable bit rates (VBR) are also supported. The majority of MP3/WMA files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates. MPEG Sampling Specification...
Page 205: List Button (Disc Mode For Mp3/Wma Play)
Number of files and folders - Loading times will increase with more files and folders To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option before writing to the disc.
Page 206 204 UNDERSTANDING YOUR INSTRUMENT PANEL Pressing the AUX button will change the mode to auxil- iary device if the AUX jack is connected. NOTE: The AUX device must be turned on and the device’s volume set to the proper level. If the AUX audio is not loud enough, turn the device’s volume up.
Page 207: Equipped
Operating Instructions - uconnect studios (Satellite Radio) (If Equipped) Refer to “uconnect studios (Satellite Radio)” in this section. Operating Instructions - Video Entertainment System (VES)™ (If Equipped) Refer to separate “Video Entertainment System (VES)™ Guide.” Dolby Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
Page 208: Operating Instructions - Voice Recognition
206 UNDERSTANDING YOUR INSTRUMENT PANEL Refer to your uconnect tunes (REN) or (RER) user’s manual for detailed operating instructions. Operating Instructions — Voice Recognition System (VR) — If Equipped For the radio, refer to “Voice Recognition System (VR)” in Section 3. Operating Instructions —...
Page 209 6. To save the new time setting, touch the screen where the word “Save” is displayed. Changing Daylight Savings Time When selected, this feature will display the time of day in daylight savings time. Proceed as follows to change the current setting: 1.
Page 210: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
208 UNDERSTANDING YOUR INSTRUMENT PANEL Changing the Time Zone 1. Turn on the radio. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. Touch the screen where the words “Set Time Zone” are displayed.
Page 211 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping. Turning the ON/VOLUME control knob to the right increases the volume, and to the left decreases it.
Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM or FM frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 213: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button. The symbol SET 1 will now show in the display window. Select the button (1 to 6) you wish to lock onto this station and press and release that button.
Page 214 212 UNDERSTANDING YOUR INSTRUMENT PANEL This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up.
Page 215 EJECT Button - Ejecting a CD Press the EJECT button to eject the CD. If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF.
Page 216: Notes On Playing Mp3 Files
214 UNDERSTANDING YOUR INSTRUMENT PANEL SET/RND Button (Random Play Button) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace. Press the right SEEK button to move to the next ran- domly selected track.
Page 217 exceeding 20 folders will result in this display. With 200 files, exceeding 50 folders will result in this display.) Maximum number of characters in file/folder names: Level 1: 12 (including a separator . and a three- character extension) Level 2: 31 (including a separator . and a three- character extension) Multisession disc formats are supported by the radio.
Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL MPEG Sampling Specification Frequency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios.
Page 219: Operation Instructions - Auxiliary Mode
Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device, such as an MP3 player, or cassette player, and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 220: Operating Instructions - Radio Mode
218 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio.
Page 221 If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With uconnect” message will display on the radio screen. TIME Button Press the TIME button to alternate locations of the time and frequency display.
Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency. Setting the Tone, Balance, and Fade Push the rotary TUNE/SCROLL control knob and BASS will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the bass tones.
Page 223 Toggle the MUSIC TYPE button to select the following format types: 16-Digit Character Program Type No program type or un- defined Adult Hits Classical Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies UNDERSTANDING YOUR INSTRUMENT PANEL 221 Program Type Personality Display...
Page 224 222 UNDERSTANDING YOUR INSTRUMENT PANEL By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode.
Page 225: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by pressing the pushbutton twice. Every time a preset button is used, a corresponding button number will display. Buttons 1 - 6 These buttons tune the radio to the stations that you commit to pushbutton memory (12 AM and 12 FM stations).
Page 226 224 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! This CD player will accept 4–3/4 in (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. Do not use adhesive labels. These labels can peel away and jam the player mechanism. RES is a single CD player.
Page 227: Notes On Playing Mp3 Files
RW/FF Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed. The RW (Reverse) button works in a similar manner. AM/FM Button Press the button to select either AM or FM mode. SET/RND Button (Random Play Button) Press this button while the CD is playing to activate Random Play.
Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL Maximum number of files: 255 Maximum number of folders. (The radio display of file names and folder names is limited. For large numbers of files and/or folders, the radio may be unable to display the file name and folder name and will assign a number instead.
Page 229 MPEG Sampling Specification Frequency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios.
Page 230: List Button (Cd Mode For Mp3 Play)
228 UNDERSTANDING YOUR INSTRUMENT PANEL LIST Button (CD Mode for MP3 Play) Pressing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE/SCROLL control knob. Selecting a folder by pressing the TUNE/SCROLL control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain...
Page 231: Uconnect Studios (Satellite Radio) - If Equipped
TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for five seconds (when the ignition is OFF). Operating Instructions - uconnect phone (If Equipped) Refer to “uconnect phone” in Section 3. Operating Instructions - uconnect studios (Satellite Radio) (If Equipped) Refer to “uconnect...
Page 232: Electronic Serial Number/Sirius Identification Number (Esn/Sid)
230 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Serial Number/Sirius Identification Number (ESN/SID) Please have the following information available when calling: 1. The Electronic Serial Number/Sirius Identification Number (ESN/SID). 2. Your Vehicle Identification Number. To access the ESN/SID, refer to the following steps: ESN/SID Access With REQ/RES Radios With the ignition switch in the ON/RUN or ACC posi- tion and the radio on, press the SETUP button and scroll...
Page 233: Satellite Antenna
Satellite Antenna To ensure optimum reception, do not place items on the roof around the rooftop antenna location or strap items to the trunk lid around the trunk lid antenna (if equipped). Metal objects placed within the line of sight of the antenna will cause decreased performance.
Page 234 232 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button — Except REU Radio Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- able). Also, pressing and holding the INFO button for an additional three seconds will make the radio display the song title all of the time (press and hold again to return to normal display).
Page 235 made, you can seek up or down or scan the channels and the radio will tune to the next station matching the selected format. There is no time-out for this screen. Pressing the MUSIC TYPE button again will close the Music Type screen.
Page 236: Operating Instructions - Uconnect Phone (If Equipped)
234 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — uconnect phone (If Equipped) Refer to “uconnect phone” in Section 3. Operating Instructions — Video Entertainment System (VES)™ (If Equipped) Refer to separate “Video Entertainment System (VES)™ Guide.” REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel.
Page 237: Radio Operation
The button located in the center of the right-hand control will switch modes to Radio or CD. The left-hand control is a rocker type switch with a pushbutton in the center. The function of the left-hand control is different depending on which mode you are in. The following describes the left-hand control operation in each mode.
Page 238: Radio Operation And Cellular Phones
236 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Do not apply paper or tape to the disc; avoid scratch- ing the disc. 4. Do not use solvents such as benzene, thinner, cleaners, or antistatic sprays. 5. Store the disc in its case after playing. 6.
Page 239 Climate Control The air conditioning system of your vehicle contains R-134a, a refrigerant that does not deplete the ozone layer in the upper atmosphere. The controls are as follows: UNDERSTANDING YOUR INSTRUMENT PANEL 237 Mode Control (Air Direction) The mode control allows you to choose from several patterns of air distribution as identified by the symbols.
Page 240 238 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: There is a difference in temperature between the upper and lower outlets for added comfort. The warmer air goes to the floor outlets. This feature gives improved comfort during sunny but cool conditions. Floor Air is directed through the floor outlets and side window demister outlets with a small amount through the defrost outlet.
Page 241 NOTE: For maximum airflow to the rear seat passen- gers, the center instrument panel outlets can be aimed, so that the left center outlet is directed toward the right rear passenger and the right center outlet is directed toward the left rear passenger. Fan Control Use this control to regulate the amount of air forced through the...
Page 242 240 UNDERSTANDING YOUR INSTRUMENT PANEL Circulation Control Use this button to choose between outside air intake or recirculation of the air inside the vehicle. A light will illuminate when you are in recirculate mode. Only use the recirculate mode to temporarily block out any outside odors, smoke, or dust and to cool the interior rapidly upon initial start...
Page 243: Air Filtration System - If Equipped
Air Conditioning (MAX A/C) For maximum cooling select the air direction to either the Panel or Bi-Level position using the mode control. Press the A/C button and the recirculation button so that both lights are illuminated and set the temperature control to its coolest setting.
Page 244: Operating Tips
242 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips...
Page 245 Window Fogging Vehicle side windows tend to fog on the inside in mild rainy or humid weather. To clear the windows, set mode to the mix or defrost position. Direct the panel outlets toward the side windows. Do not use recirculate without A/C for long periods as fogging may occur.
Page 246 244 UNDERSTANDING YOUR INSTRUMENT PANEL Side Window Demisters A side window demister outlet is at each end of the instrument panel. These nonadjustable outlets direct air toward the side windows when the system is in either the FLOOR, MIX, or DEFROST mode. The air is directed at the area of the windows through which you view the outside mirrors.
Page 247 STARTING AND OPERATING CONTENTS Starting Procedures ....249 Manual Transmission — If Equipped ..249 Automatic Transmission — If Equipped ..249 Normal Starting .
Page 248 246 STARTING AND OPERATING AutoStick — If Equipped ....257 Operation ......258 General Information .
Page 249 Tire Inflation Pressures ....284 Tire Pressures For High Speed Operation . . . 285 Radial Ply Tires ..... 286 Compact Spare Tire —...
Page 250 248 STARTING AND OPERATING Loose Fuel Filler Cap Message ... 307 Vehicle Loading ..... . 307 Vehicle Certification Label .
Page 251: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured.
Page 252: 250 Starting And Operating
250 STARTING AND OPERATING and release when the engine starts. If the engine fails to start within 15 seconds, turn the ignition switch to the OFF position, wait 10 to 15 seconds, then repeat the normal starting procedure. WARNING! Do not attempt to push or tow your vehicle to get it started.
Page 253: After Starting
WARNING! Never pour fuel or other flammable liquid into the throttle body air inlet opening in an attempt to start the vehicle. This could result in flash fire causing serious personal injury. CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time.
Page 254 252 STARTING AND OPERATING Fully depress the clutch pedal before you shift gears. As you release the clutch pedal, lightly depress the accelera- tor pedal. Shift Pattern Use each gear in numerical order, do not skip a gear. Be sure the transaxle is in 1st gear, (not 3rd), when starting from a standing position.
Page 255: Recommended Shift Speeds
Recommended Shift Speeds To use your manual transaxle for optimal fuel economy, it should be upshifted as listed in the following table. Manual Transaxle Recommended Shift Speeds Units in mph (km/h) Accel- Engine 1 to 2 2 to 3 eration Size Rate Accel...
Page 256: Brake/Transmission Interlock System
254 STARTING AND OPERATING CAUTION! Damage to the transaxle may occur if the following precautions are not observed: Shift into PARK only after the vehicle has come to a complete stop. Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
Page 257: Automatic Transaxle Ignition Interlock System
NOTE: If a malfunction occurs, the transaxle will not shift out of PARK. Battery power is required to release the brake/transmission interlock system. There is a remov- able plug in the right side of the shifter housing that allows you to insert your finger to override the system. If this occurs, obtain service as soon as possible.
Page 258 256 STARTING AND OPERATING Never use PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range. Always apply the parking brake first, and then place the shift lever into the PARK position. WARNING! Unintended movement of a vehicle could injure those in and near the vehicle.
Page 259: Autostick - If Equipped
REVERSE Shift into this range only after the vehicle has come to a complete stop. NEUTRAL The engine may be started in this range. DRIVE This should be used for most driving and provides the best ratio for optimum drivability, fuel economy, and performance.
Page 260: Operation
258 STARTING AND OPERATING Operation NOTE: Autostick is not functional until the CVT warms up in cold weather. Autostick operation is activated in the DRIVE position by moving the shift lever side-to-side. Moving the shift lever to the (+) side will activate Autostick and shift up to the next higher manual ratio, unless you are already operating in or near Overdrive, in which case 6th ratio will be selected.
Page 261: Driving On Slippery Surfaces
If the system detects powertrain overheating, the transmission will revert to the automatic shift mode and remain in that mode until the powertrain cools off. If the system detects a problem, it will disable the Autostick mode and the transmission will return to the automatic mode until the problem is corrected.
Page 262: Driving Through Water
260 STARTING AND OPERATING 2. Slow down if the road has standing water or puddles. 3. Replace the tires when tread wear indicators first become visible. 4. Keep the tires properly inflated. 5. Maintain enough distance between your vehicle and the vehicle in front of you to avoid a collision in a sudden stop.
Page 263 CAUTION! Always check the depth of the standing water before driving through it. Never drive through standing water that is deeper than the bottom of the tire rims mounted on the vehicle. Determine the condition of the road or the path that is under water and if there are any obstacles in the way before driving through the standing wa- ter.
Page 264: Power Steering
262 STARTING AND OPERATING WARNING! Driving through standing water limits your vehi- cle’s traction capabilities. Do not exceed 5 mph (8 km/h) when driving through standing water. Driving through standing water limits your vehi- cle’s braking capabilities, which increases stop- ping distances.
Page 265: Power Steering Fluid Check
WARNING! Continued operation with reduced power steering assist could pose a safety risk to yourself and others. Service should be obtained as soon as possible. CAUTION! Prolonged operation of the steering system at the end of the steering wheel travel will increase the steering fluid temperature and it should be avoided when possible.
Page 266: Parking Brake
264 STARTING AND OPERATING PARKING BRAKE When the parking brake is applied with the ignition ON, the Brake Light in the instrument cluster will come on. NOTE: This light only shows that the parking brake is on. It does not show the degree of brake application. If the parking brake is applied while the vehicle is moving, a chime will sound to alert the driver.
Page 267: Brake System
As an added precaution, turn the front wheels toward the curb on a downhill grade and away from the curb on a uphill grade. You should always apply the parking brake before leav- ing the vehicle. WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.
Page 268: Anti-Lock Brake System (Abs) - If Equipped
266 STARTING AND OPERATING If either of the two hydraulic systems lose normal capa- bility, the remaining system will still function with some loss of overall braking effectiveness. This will be evident by increased pedal travel during application and greater pedal force required to slow or stop.
Page 269 WARNING! (Continued) The ABS cannot prevent accidents, including those resulting from excessive speed in turns, following another vehicle too closely, or hydro- planing. Only a safe, attentive, and skillful driver can prevent accidents. The capabilities of an ABS-equipped vehicle must never be exploited in a reckless or dangerous manner which could jeopardize the user’s safety or the safety of others.
Page 270: Electronic Brake Control System
268 STARTING AND OPERATING ABS is activated during braking under certain road or stopping conditions. ABS-inducing conditions can in- clude ice, snow, gravel, bumps, railroad tracks, loose debris, or panic stops. You may also experience the following when the brake system goes into Anti-Lock mode: the ABS motor running (it may continue to run for a short time after the stop)
Page 271: Anti-Lock Brake System (Abs)
enhance vehicle stability and control in various driving conditions and are commonly referred to as ESP. Anti-Lock Brake System (ABS) This system aids the driver in maintaining vehicle control under adverse braking conditions. The system controls hydraulic brake pressure to prevent wheel lockup and help avoid skidding on slippery surfaces during braking.
Page 272: Traction Control System (Tcs)
270 STARTING AND OPERATING WARNING! (Continued) The capabilities of a BAS-equipped vehicle must never be exploited in a reckless or dangerous manner which could jeopardize the user’s safety or the safety of others. Traction Control System (TCS) This system monitors the amount of wheel spin of each of the driven wheels.
Page 273 Understeer - when the vehicle is turning less than appropriate for the steering wheel position. ESP Indicator Light The “ESP Indicator Light” located in the instrument cluster, starts to flash as soon as the tires lose traction and the ESP system becomes active. If the “ESP Indicator Light”...
Page 274 272 STARTING AND OPERATING ESP Operating Modes The ESP system has two available operating modes. Full On This is the normal operating mode for ESP. Whenever the vehicle is started the ESP system will be in this “On” mode. This mode should be used for most driving situations.
Page 275 ESP/BAS Warning Light and ESP Indicator Light The malfunction indicator for the ESP is combined with the BAS indicator. The yellow “ESP/BAS Warning Lamp” and the yellow “ESP Indicator Light” in the instrument cluster both come on when the ignition switch is turned to the ON position.
Page 276: Tire Safety Information
274 STARTING AND OPERATING TIRE SAFETY INFORMATION Tire Markings 1 — U.S. DOT Safety Standards 4 — Maximum Load Code (TIN) 2 — Size Designation 5 — Maximum Pressure 3 — Service Description 6 — Treadwear, Traction and Tem- perature Grades NOTE: P (Passenger) - Metric tire sizing is based on U.S.
Page 277 LT (Light Truck) - Metric tire sizing is based on U.S. design standards. The size designation for LT-Metric tires is the same as for P-Metric tires except for the letters “LT” that are molded into the sidewall preced- ing the size designation. Example: LT235/85R16. Temporary spare tires are high-pressure compact spares designed for temporary emergency use only.
Page 278 276 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 279 Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 280: Tire Identification Number (Tin)
278 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
Page 281: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire and Loading Information Placard STARTING AND OPERATING 279 This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry...
Page 282 280 STARTING AND OPERATING axles must not be exceeded. For further information on GAWRs, vehicle loading, and trailer towing, refer to “Vehicle Loading” in this section. To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of occupants and cargo should never exceed XXX lbs or XXX kg”...
Page 283 NOTE: The following table shows examples on how to calcu- late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations and number and size of occupants. This table is for illustration purposes only and may not be accurate for the seating and load carry capacity of your vehicle.
Page 284 282 STARTING AND OPERATING...
Page 285: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 286: Tire Inflation Pressures
284 STARTING AND OPERATING WARNING! (Continued) Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear patterns to develop across the tire tread.
Page 287: Tire Pressures For High Speed Operation
CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...
Page 288: Radial Ply Tires
286 STARTING AND OPERATING loading may be required for high-speed vehicle opera- tion. Refer to original equipment or an authorized tire dealer for recommended safe operating speeds, loading and cold tire inflation pressures. WARNING! High speed driving with your vehicle under maxi- mum load is dangerous.
Page 289: Limited-Use Spare - If Equipped
vehicle only. Since this tire has limited tread life, the original tire should be repaired (or replaced) and rein- stalled at the first opportunity. WARNING! Temporary use spare tires are for emergency use only. With these tires, do not drive more than 50 mph (80 km/h).
Page 290: Tire Spinning
288 STARTING AND OPERATING WARNING! The limited-use spare tires are for emergency use only. Installation of this limited-use spare tire affects vehicle handling. With this tire, do not drive more than 50 mph (80 km/h). Keep it inflated to the cold tire inflation pressure listed on either your tire plac- ard or limited-use spare tire and wheel assembly.
Page 291: Life Of Tire
1 — Worn Tire 2 — New Tire These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth becomes 1/16 in (2 mm). When the tread is worn to the tread wear indicators, the tire should be replaced.
Page 292: Replacement Tires
290 STARTING AND OPERATING Keep dismounted tires in a cool, dry place with as little exposure to light as possible. Protect tires from contact with oil, grease, and gasoline. Replacement Tires The tires on your new vehicle provide a balance of many characteristics.
Page 293: Tire Chains
WARNING! (Continued) Failure to equip your vehicle with tires having adequate speed capability can result in sudden tire failure and loss of vehicle control. CAUTION! Replacing original tires with tires of a different size may result in false speedometer and odometer read- ings.
Page 294: Tire Rotation Recommendations
292 STARTING AND OPERATING TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving, and braking functions. For these reasons, they wear at unequal rates and tend to develop irregular wear pat- terns.
Page 295: Tire Pressure Monitoring System (Tpms)
TIRE PRESSURE MONITORING SYSTEM (TPMS) The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recom- mended cold placard pressure. The tire pressure will vary with temperature by about 1 psi (6.9 kPa) for every 12°F (6.5°C). This means that when the outside temperature decreases, the tire pressure will decrease.
Page 296: 294 Starting And Operating
294 STARTING AND OPERATING For example, your vehicle may have a recommended cold (parked for more than three hours) placard pressure of 30 psi (207 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 27 psi (186 kPa), a temperature drop to 20°F (-7°C) will decrease the tire pressure to approximately 26 psi (179 kPa).
Page 297: Base System
NOTE: The TPMS is not intended to replace normal tire care and maintenance or to provide warning of a tire failure or condition. The TPMS should not be used as a tire pressure gauge while adjusting your tire pressure. Driving on a significantly under-inflated tire causes the tire to overheat and can lead to tire failure.
Page 298 296 STARTING AND OPERATING Four Tire Pressure Monitoring Sensors Tire Pressure Monitoring Telltale Light Tire Pressure Monitoring Low Pressure Warnings The Tire Pressure Monitoring Telltale Light will illumi- nate in the instrument cluster, and an audible chime will be activated when one or more of the four active road tire pressures are low.
Page 299: Premium System - If Equipped
1. The compact spare tire does not have a tire pressure monitoring sensor. Therefore, the TPMS will not monitor the tire pressure in the compact spare tire. 2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, a chime will sound and the Tire Pressure Monitoring Telltale Light...
Page 300 298 STARTING AND OPERATING The TPMS consists of the following components: Receiver Module Four Tire Pressure Monitoring Sensors Three Trigger Modules (mounted in three of the four wheel wells) Various Tire Pressure Monitoring System Messages, which display in the Electronic Vehicle Information Center (EVIC) Yellow Tire Pressure Monitoring Telltale Light Tire Pressure Monitoring Low Pressure Warnings...
Page 301 display to the vehicle’s recommended cold placard pres- sure value. The system will automatically update, the graphic display of the pressure value(s) will stop flash- ing, and the Tire Pressure Monitoring Light will extin- guish once the updated tire pressure(s) have been re- ceived.
Page 302 300 STARTING AND OPERATING will be displayed instead of dashes. A system fault can occur with any of the following scenarios: 1. Jamming due to electronic devices or driving next to facilities emitting the same radio frequencies as the TPM sensors.
Page 303: General Information
limit in any of the four active road tires. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada.
Page 304: Reformulated Gasoline
302 STARTING AND OPERATING Reformulated Gasoline Many areas of the country require the use of cleaner burning gasoline referred to as “reformulated gasoline”. “Reformulated gasolines” contain oxygenates and are specifically blended to reduce vehicle emissions and improve air quality. The manufacturer supports the use of “reformulated gasolines”.
Page 305: Mmt In Gasoline
If a Non-FFV vehicle is inadvertently fueled with E-85 fuel, the engine will have some or all of these symptoms: operate in a lean mode OBD II “Malfunction Indicator Light” on poor engine performance poor cold start and cold drivability increased risk for fuel system component corrosion To fix a Non-FFV vehicle inadvertently fueled once with E-85 perform the following:...
Page 306: Materials Added To Fuel
304 STARTING AND OPERATING MMT is prohibited in Federal and California reformu- lated gasolines. Materials Added To Fuel All gasoline sold in the United States is required to contain effective detergent additives. Use of additional detergents or other additives is not needed under normal conditions and would result in additional cost.
Page 307: Carbon Monoxide Warnings
Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period of time.
Page 308 306 STARTING AND OPERATING After removing the gas cap, place the gas cap tether cable over a hook on the inside of the fuel door. This keeps the gas cap suspended away from and protects the vehicle’s surface. Fuel Filler Door CAUTION! A poorly fitting gas cap may cause the Malfunc- tion Indicator Light (MIL) to turn on.
Page 309: Starting And Operating 307
NOTE: Tighten the gas cap about 1/4 turn until you hear one click. This is an indication that cap is properly tightened. If the gas cap is not tighten properly, the MIL will come on. Be sure the gas cap is tightened every time the vehicle is refueled.
Page 310: Vehicle Certification Label
308 STARTING AND OPERATING Vehicle Certification Label Your vehicle has a Vehicle Certification Label attached to the driver’s door B-Pillar. The label contains the following information: Name of manufacturer Month and year of manufacture Gross Vehicle Weight Rating (GVWR) Vehicle Identification Number (VIN) Type of Vehicle Month, Day and Hour of Manufacture (MDH) The bar code allows a computer scanner to read the...
Page 311 Curb Weight The curb weight of a vehicle is defined as the total weight of the vehicle with all fluids, including vehicle fuel, at full capacity conditions, and with no occupants or cargo loaded into the vehicle. The front and rear curb weight values are determined by weighing your vehicle on a commercial scale before any occupants or cargo are added.
Page 312: Trailer Towing
310 STARTING AND OPERATING TRAILER TOWING In this section, you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer carefully re- view this information to tow your load as efficiently and safely as possible.
Page 313 WARNING! It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. Tongue Weight (TW) The tongue weight is the downward force exerted on the hitch ball by the trailer.
Page 314: Installing A Trailer Hitch
312 STARTING AND OPERATING consistent steering and brake control and thereby en- hancing towing safety. The addition of a friction/ hydraulic sway control also dampens sway caused by traffic and crosswinds, contributing positively to tow vehicle and trailer stability. Trailer sway control and a weight distributing (load equalizing) hitch are recom- mended for heavier Tongue Weights (TW) and may be required...
Page 315: Trailer Towing Weights (Maximum Trailer Weight Ratings)
Trailer Hitch Classification Definitions Class Max. Trailer Hitch Industry Class I - Light Duty 2,000 lbs (907 kg) Refer to the “Trailer Towing Weights (Maximum Trailer Weight Ratings)” chart for the Maximum Gross Trailer Weight (GTW) towable for your given drivetrain.
Page 316: Trailer And Tongue Weight
314 STARTING AND OPERATING Note 1 – The trailer tongue weight must be considered as part of the combined weight of occupants and cargo and should never exceed the weight referenced on the Tire and Loading Information placard. Refer to “Tire–Safety Information”...
Page 317: Towing Requirements
NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the “Tire and Loading Information placard”...
Page 318 316 STARTING AND OPERATING WARNING! (Continued) Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 319 4. Tongue weight rating for the trailer hitch utilized (this requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight). Towing Requirements — Tires − Do not attempt to tow a trailer while using a compact spare tire.
Page 320 318 STARTING AND OPERATING CAUTION! If the trailer weighs more than 1,000 lbs (450 kg) loaded, it should have its own brakes and they should be of adequate capacity. Failure to do this could lead to accelerated brake lining wear, higher brake pedal effort, and longer stopping distances.
Page 321 The electrical connections are all complete to the vehicle, but you must mate the harness to a trailer connector. Refer to the following illustrations. 4-Pin Connector 1 — Female Pins 4 — Park 2 — Male Pin 5 — Left Stop/Turn 3 —...
Page 322: Towing Tips
320 STARTING AND OPERATING Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic. If using a manual transmission vehicle for trailer towing, all starts must be in 1st gear to avoid excessive clutch slippage.
Page 323: Recreational Towing (Behind Motorhome, Etc.)
RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Ground) Recreational Manual Trans- Towing Condi- axle Vehicles tion Four Wheel Flat Tow (All Wheels on Ground) Two Wheel Never Dolly Tow (Front or Rear Wheels on Ground) Flat Bed Tow...
Page 325 WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....324 If Your Engine Overheats ....324 Automatic Transaxle Overheating .
Page 326: Hazard Warning Flasher
324 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is located on the instrument panel, below the radio. Press the switch to turn on the Hazard Warning flashers. When the Hazard Warning flasher switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 327: What To Do In Emergencies 325
the engine cooling system and turning off the A/C removes this heat. You can also turn the Temperature control to maximum heat, the Mode control to floor, and the fan control to high. This allows the heater core to act as a supplement to the radiator and aids in removing heat from the engine cooling system.
Page 328: Jacking And Tire Changing
326 WHAT TO DO IN EMERGENCIES requested speed. If the high speed is maintained, the overheating will reoccur, as before, in a cyclic fashion. JACKING AND TIRE CHANGING WARNING! Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed.
Page 329: Preparations For Jacking
Spare Tire Removal Lift up the load floor cover and remove the hold down. Preparations For Jacking 1. Park the vehicle on a firm level surface, avoiding ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic.
Page 330 328 WHAT TO DO IN EMERGENCIES WARNING! (Continued) Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle. Block the wheel diagonally opposite the wheel to be raised. Set the parking brake firmly and set an automatic transmission in PARK;...
Page 331 2. Loosen, but do not remove, the wheel nuts by turning them to the left one turn while the wheel is still on the ground. Jacking Locations WHAT TO DO IN EMERGENCIES 329 CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in Step 3.
Page 332 330 WHAT TO DO IN EMERGENCIES WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 5. Using the swivel wrench raise the vehicle by turning the jack screw to the right.
Page 333: Jump-Starting Procedures
9. Remove the wheel blocks and lower the jack until it is free. Reassemble the lug wrench to the jack assembly and stow it in the spare tire area. Secure the assembly using the means provided. WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the ve- hicle.
Page 334 332 WHAT TO DO IN EMERGENCIES WARNING! (Continued) Do not attempt to push or tow your vehicle to get it started. Vehicles equipped with an automatic transaxle cannot be started this way and may be damaged. Unburned fuel could enter the catalytic converter and once the engine has started, ignite and damage the converter and vehicle.
Page 335: Freeing A Stuck Vehicle
WARNING! Battery fluid is a corrosive acid solution; do not allow battery fluid to contact eyes, skin or cloth- ing. Don’t lean over the battery when attaching the clamps or allow the clamps to touch each other. If acid splashes in your eyes or on your skin, flush the contaminated area immediately with large quantities of water.
Page 336: Towing A Disabled Vehicle
334 WHAT TO DO IN EMERGENCIES front wheels. Then shift back and forth between RE- VERSE and 1st gear. Usually the least accelerator pedal pressure to maintain the rocking motion without spin- ning the wheels is most effective. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause axle, tire damage or failure.
Page 337 CAUTION! DO NOT flat tow any vehicle equipped with an automatic transmission. Damage to the drivetrain will result. Manual Transaxle Front Wheel Drive (FWD) or All Wheel Drive (AWD) vehicles can be flat towed (all four wheels on the ground) with the transmission in NEUTRAL. FWD vehicles can be towed with the front wheels elevated.
Page 338: Without The Ignition Key
336 WHAT TO DO IN EMERGENCIES Without The Ignition Key Special care must be taken when the vehicle is towed with the ignition in the LOCK position. A dolly should be used under the front wheels if the rear wheels are raised. Proper towing equipment is necessary to prevent dam- age to the vehicle.
Page 339 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 2.0L ... . . 339 Engine Compartment — 2.4L ... . . 340 Onboard Diagnostic System —...
Page 340 338 MAINTAINING YOUR VEHICLE Cooling System ..... 353 Brake System ..... . . 359 Automatic Transaxle (CVT) —...
Page 341: Engine Compartment - 2.0L
ENGINE COMPARTMENT — 2.0L 1 — Washer Fluid Reservoir 2 — Power Steering Fluid Reservoir 3 — Engine Oil Fill 4 — Air Cleaner Filter 5 — Brake Fluid Reservoir MAINTAINING YOUR VEHICLE 339 6 — Integrated Power Module 7 — Battery (Under Cover) 8 —...
Page 342: 340 Maintaining Your Vehicle
340 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 2.4L 1 — Washer Fluid Reservoir 2 — Power Steering Fluid Reservoir 3 — Engine Oil Fill 4 — Brake Fluid Reservoir 5 — Integrated Power Module 6 — Battery 7 — Air Cleaner Filter 8 —...
Page 343: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated Onboard Diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transaxle control systems. When these systems are oper- ating properly, your vehicle will provide excellent per- formance and fuel economy, as well as engine emissions well within current government regulations.
Page 344: Emissions Inspection And Maintenance Programs
342 MAINTAINING YOUR VEHICLE persists, the message will appear the next time the vehicle is started. This might indicate a damaged cap. If the problem is detected twice in a row, the system will turn on the MIL. Resolving the problem will turn the MIL light off.
Page 345: Replacement Parts
5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 346: Maintenance Procedures
344 MAINTAINING YOUR VEHICLE your vehicle. Refer to these manuals before attempting any procedure yourself. NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you. WARNING! You can be badly injured working on or around a motor vehicle.
Page 347 Checking the oil while the vehicle is on level ground and only when the engine is hot, will improve the accuracy of the oil level readings. Maintain the oil level between the range markings on the dipstick. The range markings will consist of a crosshatch zone that says SAFE or a cross- hatch zone that says MIN at the low end of the range and MAX at the high end of the range.
Page 348 346 MAINTAINING YOUR VEHICLE American Petroleum Institute (API) Engine Oil Identification Symbol This symbol means that the oil has been certified by the American Petroleum Institute (API). The manufacturer only recommends API Certified engine oils. Engine Oil Viscosity (SAE Grade) SAE 5W-20 engine oil is recommended for all operating temperatures.
Page 349: Engine Oil Filter
environment. Contact your authorized dealer, service station, or governmental agency for advice on how and where used oil and oil filters can be safely discarded in your area. Engine Oil Filter The engine oil filter should be replaced at every engine oil change.
Page 350: Maintenance-Free Battery
348 MAINTAINING YOUR VEHICLE Maintenance-Free Battery The top of the maintenance-free battery is permanently sealed. You will never have to add water, nor is periodic maintenance required. WARNING! Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing.
Page 351: Air Conditioner Maintenance
CAUTION! (Continued) If a “fast charger” is used while the battery is in the vehicle, disconnect both vehicle battery cables before connecting the charger to the battery. Do not use a “fast charger” to provide starting voltage. Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season.
Page 352: Body Lubrication
350 MAINTAINING YOUR VEHICLE Refrigerant Recovery And Recycling R-134a air conditioning refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.
Page 353: Adding Washer Fluid
Operation of the wipers on dry glass for long periods may cause deterioration of the wiper blades. Always use washer fluid when using the wipers to remove salt or dirt from a dry windshield. Avoid using the wiper blades to remove frost or ice from the windshield.
Page 354 352 MAINTAINING YOUR VEHICLE exhaust system each time the vehicle is raised for an oil change or lubrication. Replace as required. WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you.
Page 355: Cooling System
WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.
Page 356 354 MAINTAINING YOUR VEHICLE WARNING! (Continued) You or others can be badly burned by hot coolant or steam from your radiator. If you see or hear steam coming from under the hood, do not open the hood until the radiator has had time to cool. Never try to open a cooling system pressure cap when the radiator is hot.
Page 357 CAUTION! Mixing of engine coolant (antifreeze) other than specified Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion pro- tection. If a non-HOAT engine coolant (antifreeze) is introduced into the cooling system in an emer- gency, it should be replaced with the specified engine coolant (antifreeze) as soon as possible.
Page 358 356 MAINTAINING YOUR VEHICLE When adding engine coolant (antifreeze), a minimum solution of 50% recommended MOPAR Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology), or equivalent, in water should be used. Use higher concentrations (not to exceed 70%) if temperatures below 34°F ( 37°C) are antici- pated.
Page 359 WARNING! The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add engine coolant (antifreeze) when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine. Heat causes pressure to build up in the cooling system.
Page 360 358 MAINTAINING YOUR VEHICLE long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month. When additional engine coolant (antifreeze) is needed to maintain the proper level, it should be added to the coolant bottle.
Page 361: Brake System
Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the condenser clean. Do not change the thermostat for Summer or Winter operation. If replacement is ever necessary, install ONLY the correct type thermostat. Other designs may result in unsatisfactory engine coolant (antifreeze) performance, poor gas mileage, and increased emissions.
Page 362 360 MAINTAINING YOUR VEHICLE when the pads are replaced. However, low fluid level may be caused by a leak and a checkup may be needed. NOTE: If your vehicle is equipped with a manual transaxle , the brake fluid reservoir supplies fluid to both the brake system and the clutch release system.
Page 363: Automatic Transaxle (Cvt) - If Equipped
Use only brake fluid that has been in a tightly closed container to avoid contamination from foreign matter. NOTE: Do not allow petroleum-based fluid to contami- nate the brake fluid as seal damage will result! Automatic Transaxle (CVT) — If Equipped Selection Of Lubricant It is important that the proper lubricant is used in the transaxle to assure optimum transaxle performance.
Page 364: Manual Transaxle - If Equipped
362 MAINTAINING YOUR VEHICLE (CVTF+4). CVTF+4 is an engineered product and its performance may be impaired by supplemental additives. Manual Transaxle — If Equipped Lubricant Selection Use only the manufacturers recommended transmission fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in this section for the correct fluid type.
Page 365 The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion resistance built into your vehicle. What Causes Corrosion? Corrosion is the result of deterioration or removal of paint and protective coatings from your vehicle. The most common causes of corrosion are: Road salt, dirt and moisture accumulation.
Page 366 364 MAINTAINING YOUR VEHICLE CAUTION! Do not use abrasive or strong cleaning materials such as steel wool or scouring powder, which will scratch metal and painted surfaces. Special Care If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month.
Page 367 heavy soil, use MOPAR Wheel Cleaner or select a nonabrasive, non-acidic cleaner. Do not use scouring pads, steel wool, a bristle brush or metal polishes. Only MOPAR cleaners are recommended. Do not use oven cleaner. Avoid automatic car washes that use acidic solutions or harsh brushes that may damage the wheels’...
Page 368 366 MAINTAINING YOUR VEHICLE Your leather upholstery can be best preserved by regular cleaning with a damp, soft cloth. Small particles of dirt can act as an abrasive and damage the leather upholstery and should be removed promptly with a damp cloth. Stubborn soils can be removed easily with a soft cloth and MOPAR Total Clean.
Page 369 quarter window equipped with the radio antenna. Do not use scrapers or other sharp instruments which may scratch the elements. When cleaning the rearview mirror, spray cleaner on the towel or rag that you are using. Do not spray cleaner directly on the mirror. Instrument Panel Cover The instrument panel cover has a low glare surface which minimizes reflections on the windshield.
Page 370: Fuses
368 MAINTAINING YOUR VEHICLE Seat Belt Maintenance Do not bleach, dye or clean the seat belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. If the seat belts need cleaning, use a mild soap solution or lukewarm water.
Page 371 Cavity Cartridge Mini- Fuse Fuse 30 Amp IOD Sense2 Green 40 Amp Power Seats Green 20 Amp CCN Power Locks/ Yellow Interior Lighting 15 Amp Power Outlet Lt Blue 20 Amp Ign Run/Acc Inverter Yellow 20 Amp Pwr Run/Acc Outlet Yellow RR/Dome Lamp/ Cigar Lighter...
Page 372 370 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Fuse Fuse 15 Amp Lt Blue 15 Amp Lt Blue 10 Amp 15 Amp Lt Blue 10 Amp 10 Amp 20 Amp Yellow Description Cavity Cartridge ENG ASD Relay Feed Power Sunroof Feed Heated Mirror (If Equipped) ENG ASD Relay Feed...
Page 373: Vehicle Storage
CAUTION! When installing the IPM cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the IPM, and possibly result in an electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating.
Page 374: Bulb Replacement
372 MAINTAINING YOUR VEHICLE LIGHTS BULBS — Exterior Bulb Number Low Beam/High Beam Headlight ... . H13 Front Park/Turn Signal/Side Marker Light ....3157AK or 3157A Front Fog Light .
Page 375: Tail Lights, Rear Turn Signals And Backup Lights
Tail Lights, Rear Turn Signals and Backup Lights 1. Remove the two push-pins from the tail light housing. MAINTAINING YOUR VEHICLE 373 2. Grasp the tail light and pull firmly to disengage the light from the aperture panel.
Page 376 374 MAINTAINING YOUR VEHICLE 3. Twist and remove socket from light. 4. Remove the bulb from the socket and replace.
Page 377: License Lights
MAINTAINING YOUR VEHICLE 375 License Lights 2. Rotate the socket 1/4 turn counterclockwise. 1. Use a screw driver to gently pry against the side of the snap tab to remove the lamp from the liftgate.
Page 378: Center High-Mounted Stoplight
376 MAINTAINING YOUR VEHICLE 3. Pull the bulb from the socket. Center High-Mounted Stoplight The light is an LED assembly. See your authorized dealer for replacement.
Page 379: Fluids And Capacities
FLUIDS AND CAPACITIES Fuel (Approximate) Engine Oil with Filter 2.0L and 2.4L Engine (SAE 5W-20, API Certified) Cooling System * 2.0L and 2.4L Engine (MOPAR Engine Coolant/Antifreeze 5 Year/100,000 Mile Formula) * Includes heater and coolant recovery bottle filled to MAX level. MAINTAINING YOUR VEHICLE 377 U.S.
Page 380: Fluids, Lubricants, And Genuine Parts
378 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 381: Chassis
Chassis Component Automatic Transaxle (CVT) Manual Transaxle Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR CVTF + 4 Automatic Transmission Fluid MOPAR ATF+4 Automatic Transmission Fluid MOPAR DOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable.
Page 383: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..382 Maintenance Schedule ....382 Required Maintenance Intervals ..384...
Page 384 382 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 385 oil if it has been six months since your last oil change and even if the oil change indicator message is NOT illuminated. Change your engine oil more often if you drive your vehicle off-road for an extended period of time. Under no circumstances should oil change intervals exceed 6,000 miles (10 000 km) or six months, which- ever comes first.
Page 386 384 MAINTENANCE SCHEDULES Once a Month Check the tire pressure and look for unusual wear or damage. Inspect the battery and clean and tighten the terminals as required. Check the fluid levels of coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
Page 387 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule Change the engine oil and engine oil filter.
Page 388 386 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 24,000 Miles (40,000 km) or 24 Months Maintenance Service Schedule Change the engine oil and engine oil filter.
Page 389 30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Replace the spark plugs (except 2.4L PZEV). Adjust the parking brake on vehicles equipped with four-wheel disc brakes. Odometer Reading Date Repair Order #...
Page 390: Service Schedule
388 MAINTENANCE SCHEDULES 48,000 Miles (80,000 km) or 48 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 391 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Inspect the brake linings; replace if necessary. Adjust the parking brake on vehicles equipped with four-wheel disc brakes. Replace the air conditioning filter.
Page 392 390 MAINTENANCE SCHEDULES 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 393 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 394 392 MAINTENANCE SCHEDULES 96,000 Miles (160,000 km) or 96 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 395 108,000 Miles (180,000 km) or 108 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 396 394 MAINTENANCE SCHEDULES 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Inspect the brake linings; replace if necessary. Adjust the parking brake on vehicles equipped with four-wheel disc brakes. Replace the air conditioning filter.
Page 397 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 398 396 MAINTENANCE SCHEDULES 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 399 † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 401 IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......401 Prepare For The Appointment .
Page 402 400 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....405 Department Of Transportation Uniform Tire Quality Grades ......406 Treadwear .
Page 403: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 404: 402 If You Need Consumer Assistance
402 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 405: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 406: Warranty Information (U.s. Vehicles Only)
404 IF YOU NEED CONSUMER ASSISTANCE the ownership experience. You’ll be pleased with their sincere efforts to resolve any warranty issues or related concerns. WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain, or emit, chemicals known to the State of California to cause cancer and birth defects, or other reproductive harm.
Page 407: In Canada
To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Adminis- trator, NHTSA, 400 Seventh Street, SW., Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from http://www.safercar.gov.
Page 408: Quality Grades
406 IF YOU NEED CONSUMER ASSISTANCE Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 409: Traction Grades
Treadwear The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded 100.
Page 410 408 IF YOU NEED CONSUMER ASSISTANCE Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel, than the minimum required by law. WARNING! The temperature grade for this tire is established for a tire that is properly inflated and not overloaded.
Page 411: Index
INDEX...
Page 412 410 INDEX ABS (Anti-Lock Brake System) ....266 Adding Engine Coolant (Antifreeze) ..355 Adding Fuel ......305 Adding Washer Fluid .
Page 413 Shifting ......255 Special Additives ..... . 361 Autostick .
Page 414 412 INDEX Cargo Tie-Downs ......157 Cellular Phone ......83,236 Center High Mounted Stop Light .
Page 415 Corrosion Protection ..... 362 Cruise Light ......176 Cupholders .
Page 416 414 INDEX Emergency, In Case of Jacking ......326 Jump Starting ......331 Towing .
Page 417 Fluid Level Checks Automatic Transaxle ....361 Power Steering ......263 Fluids .
Page 418 416 INDEX General Information ....18,112,301 General Maintenance ..... 344 Glass Cleaning .
Page 419 Integrated Power Module (Fuses) ... . 368 Interior Appearance Care ....365 Intermittent Wipers (Delay Wipers) ... 132 Introduction .
Page 420 418 INDEX Electronic Stability Program (ESP) Indicator ......271,273 Engine Temperature Warning ....172 Exterior .
Page 421 Malfunction Indicator Light (Check Engine) . . 175,342 Manual, Service ......405 Manual Transaxle ....249,251,362 Downshifting .
Page 422 420 INDEX Opener, Garage Door (HomeLink ) ... 138 Operator Manual (Owner’s Manual) ... . 4 Outside Air Intake ..... . . 243 Overdrive .
Page 423 Rear Wiper/Washer ..... . 158 Recorder, Event Data ..... . 59 Recreational Towing .
Page 424 422 INDEX Inspection ......73 Pretensioners ......46 Rear Seat .
Page 425 Speedometer and Odometer ....167 Starting ....... 249 Automatic Transmission .
Page 426 424 INDEX High Speed ......285 Inflation Pressures ..... 284 Jacking .
Page 427 Operation ......253 Overdrive ......257 Selection of Lubricant .
Page 428 426 INDEX Wheel and Wheel Trim Care ....364 Wind Buffeting ......147 Window Airbag (Side Curtain) .
Page 430 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
Page 431 Chrysler LLC 81-226-0939 Second Edition Printed in U.S.A.

This manual is also suitable for:

Caliber sxt 2009

Dodge 2009 Caliber Owner's Manual

Table of Contents

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

Starting and Operating 255

294 Starting and Operating

Starting and Operating 307

What to Do in Emergencies

Quick Links

Chapters

Related Manuals for Dodge 2009 Caliber

Summary of Contents for Dodge 2009 Caliber
