Vivotek IP8352 Specifications

Technical Specifications
Lens
．Board lens, vari-focal, f = 3 ~ 9 mm, F1.2 (wide), F2.1 (tele), auto-iris
．Removable IR-cut filter for day & night function
Field of View
．85.7~31.46° (horizontal)
．73.16~25.4° (vertical)
．99.82~39.67° (diagonal)
Shutter Time
．1/5 sec. to 1/32,000 sec.
Image Sensor
．1/3" CMOS sensor in 1280x1024 resolution
Minimum Illumination
．0.02 Lux @ F1.2 (Color)
．0.001 Lux @ F1.2 (B/W)
IR Illuminators
．Built-in IR illuminators, effective up to 20 meters
．IR LEDx12
Video
．Compression: H.264, MJPEG & MPEG-4
．Streaming:
Multiple simultaneous streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
H.264/MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
．Supports activity adaptive streaming for dynamic frame rate control
．Supports ePTZ for data efficiency
．Supports 3GPP mobile surveillance
．Frame rates:
H.264:
Up to 60 fps at 1280x720
Up to 30 fps at 1280x1024
MPEG-4:
Up to 25 fps at 1280x1024
MJPEG:
Up to 30 fps at 1280x1024
Image Settings
．Adjustable image size, quality and bit rate
．Time stamp and text caption overlay
．Flip & mirror
．Configurable brightness, contrast, saturation, sharpness, white balance and
exposure
．AGC, AWB, AES
．Automatic, manual or scheduled day/night mode
．BLC (Backlight Compensation)
．Supports privacy masks
Audio
．Compression:
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
G.711 audio encoding, bit rate: 64 kbps, μ-Law or A-Law mode selectable.
．Interface:
External microphone input
Audio output
．Supports two-way audio
．Supports audio mute
Networking
．10/100/1000 Mbps Gigabit Ethernet, RJ-45
．Onvif support
．Protocols:
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP,
SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, and
802.1X
Alarm and Event Management
．Triple-window video motion detection
．Tamper detection
．One D/I and one D/O for external sensor and alarm
．Event notification using HTTP, SMTP or FTP
．Local recording of MP4 file
All speci cations are subject to change without notice. Copyright © 2012 VIVOTEK INC. All rights reserved. P/N: 971005100
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
|T: +886-2-82455282| F: +886-2-82455532| E: sales@vivotek.com
On-board Storage
．MicroSD/SDHC card slot
．Stores snapshots and video clips
Security
．Multi-level user access with password protection
．IP address filtering
．HTTPS encrypted data transmission
．802.1X port-based authentication for network protection
Users
．Live viewing for up to 10 clients
Weight
．Net: 805 g
LED Indicator
．System power and status indicator
．System activity and network link indicator
Power
．12V DC
．24V AC
．Power consumption: Max. 10 W
．802.3af compliant Power-over-Ethernet (Class 3)
Housing
．Weather-proof IP67-rated housing
Approvals
．CE, LVD, FCC, VCCI, C-Tick, UL
Operating Environments
．Temperature: -20 °C ~ 50 °C (-4°F ~ 122 °F)
．Humidity: 90% RH
Viewing System Requirements
．OS: Microsoft Windows 7/Vista/XP/2000
．Browser: Mozilla Firefox, Internet Explorer 7.x or above
．Cell phone: 3GPP player
．Real Player: 10.5 or above
．Quick Time: 6.5 or above
Installation, Management, and Maintenance
．Mounting bracket with cable concealment
．RS-485 interface for scanners, pan/tilts
．Installation Wizard 2
．32-CH ST7501 recording software
．Supports firmware upgrade
Applications
．SDK available for application development and system integration
Warranty
．36 months
Dimensions
．Camera: Ø 70 mm x 186 mm
．Cable length: 520 mm
．Cable diameter: Ø 7.2 mm; Max width: Ø 14 mm
199 mm
269 mm
VIVOTEK USA, INC.
2050 Ringwood Avenue, San Jose, CA 95131
|T: 408-773-8686| F: 408-773-8298| E: salesusa@vivotek.com
Network Bullet Camera
IP8352
1.3 MP • Supreme Night Visibility • Exceptional 60 fps
VIVOTEK IP8352 is a best-in-class 1.3-Megapixel bullet network camera designed for diverse outdoor applications.
Incorporated with a progressive scan CMOS sensor with exceptional low lux capabilities, the IP8352 captures not only
razor-sharp images of fast-moving objects during daytime but also offers unparalleled night visibility under low light conditions.
Equipped with VIVOTEK's self-developed SoC, the IP8352 supports high-performance H.264/MPEG-4/MJPEG compression
technology and offers extra smooth video quality up to 60 fps @ 720p and 30fps @ 1.3MP. Furthermore, the IP8352 boasts a
number of innovative technologies, including Activity Adaptive Streaming, and Gigabit Ethernet Transmission, giving users the
utmost in bandwidth flexibility and storage efficiency.
To adapt to the ever-changing lighting condition, the IP8352 comes with a removable IR-cut filter and built-in IR illuminators for
both day and night applications. Its IP67-rated housing protects the camera body against rain and dust and ensures smooth
operation under extreme weather conditions. For complete installation and prevention of tampering and vandalism, the IP8352
is also packaged with a mounting bracket that conceals all cabling.
With other advanced features such as tamper detection, 802.3af compliant PoE, MicroSD/SDHC card slot for on-board storage,
Gigabit Ethernet Transmission, plus Supreme Night Visibility and 60 fps high definition video quality, the IP8352 is the best
choice for the most demanding outdoor surveillance applications such as parking lots, entrances, housing communities and
much more.
Ver 1.3
