KIT CONTENTS:
A
Mounting bracket
D
Cable tie
5x
H
Console bin grommet 1x
TOOLS REQUIRED:
10 mm
ICON LEGENDS:
:
Remove/Disconnect
PART NUMBER
ISSUE
SPN0000267 A
v1.1
PART NUMBER:
DESCRIPTION:
B
iPod interface
1x
E
Bus cable
1x
I
User guide
1x
14 mm drill bit (9/16")
DATE
SUBARU OF AMERICA
01/14/08
H621SSC200
Impreza integration kit for iPod
C
1x
iPod dock cable
F
Plastic clip
2x
J
Quick reference
guide
1x
Drill with drill stop
:
Location of clip or screw
1x
G
Screw
2x
K
Install manual
1x
Nylon trim
removal tool
PAGE
1/5
