- Page 1 2012 Consumer Electronics/ Bluetooth ® & Audio Technology Quick Reference Guide...
-
Page 2: Table Of Contents
Table of Contents Bluetooth Basics 2 - 3 Bluetooth without Navigation System Impreza 2.0i / WRX / WRX/STI / Forester 2.5X 4 - 7 Legacy and Outback 8 - 11 BlueConnect ® Tribeca 12 - 13 Bluetooth with Navigation System Impreza 2.0i / WRX / WRX/STI / Forester 2.5X 14 - 17... -
Page 3: Bluetooth Basics
Bluetooth Basics o The cell phone is turned off. o The cell phone is not in the phone call area. o The battery of the cell phone has run down. o The cell phone is behind the seat or in the glove box. o A metal material covers or touches the cell phone. - Page 4 the other party speak at the same time, it may be difficult for the other party to hear your voice and vice versa. This is normal. the party you are calling may notice an undesirable echo sound. o When air from the ventilator blows directly towards the microphone. o When the sound coming from the ventilator is loud.
-
Page 5: (Impreza 2.0I/Wrx/Wrx Sti, Forester 2.5X)
Bluetooth for AM/FM Stereo and Single Disc CD Player (Impreza 2.0i/WRX/WRX STI, Forester 2.5X) Forester 2.5X/WRX/WRX STI Impreza 2.0i Phone off Phone on Talk button Phone off Phone on Talk button hook button hook button hook button hook button Pairing Your Cell Phone Press the phone off hook button and listen to phone prompts. - Page 6 Press the talk button and say “confirm.” Pass-key for pairing will be given audibly as well as be displayed on the radio display. Put your phone into Bluetooth pairing mode and pair your phone to the system using the pass-key provided. When phone is successfully paired you will hear “The phone is e is paired and ready for use.”...
-
Page 7: Making A Call
Making a Call Press the talk button again and say the number. -
Page 8: Receiving A Call
Press the phone off hook button to dial or press the talk button to add more numbers. The phone will start dialing. To end the call, press the phone on hook button. Receiving a Call When a call comes in you will be notified. If the audio system is on, the audio system will mute and a voice prompt will inform you. -
Page 9: Legacy And Outback
Bluetooth for AM/FM Stereo with Display Type Radio (Legacy and Outback) Phone off Phone on Talk button hook button hook button Pairing Your Cell Phone Press the phone off hook button. Rotate the tune knob, to select “Pair Phone”. - Page 10 Follow the audible prompt, then select “Record Name” and then say the name to be registered. Select “Confirm pair phone?”. Select “Phone Only” to register a cell phone.
- Page 11 After “Car Multi-Media” is displayed, a pass key to pair phone will be displayed. “Phone paired successfully” will be displayed when pairing has been completed. Making a Call...
- Page 12 Press the talk button again and say the number. The system will audibly repeat the number. If correct, press the phone off hook button to dial, or press the talk button to change, cancel or delete the number. The phone will start dialing. To end the call, press the phone on hook button.
-
Page 13: Blueconnect
® BlueConnect (Tribeca 3.6R Limited and Touring models) Controls Location BlueConnect controls for the Tribeca are located in the overhead console. Controls Function Phone button – activate and deactivate system. Volume up and down buttons. Voice recognition button – Barge in button, to barge in so you don’t have to listen to all the prompts. - Page 14 Pairing Your Cell Phone using the pairing code you provided earlier. Making a Call Receiving a Call prompt will inform you.
-
Page 15: Forester 2.5X
Bluetooth for AM/FM Stereo with HD Radio , Single Disc CD Player and Navigation (Impreza 2.0i/WRX/WRX STI, Forester 2.5X) Pairing Your Cell Phone Then touch “Bluetooth.”... - Page 16 Touch “Add New.” A pass-key pairing number will appear on the screen. Put your phone into Bluetooth pairing mode and pair your phone to the system using the pass-key provided. When the phone is successfully paired the screen will show the phone’s name on the list.
- Page 17 Making a Call be displayed. Touch the numbers for the phone number you wish to call. When complete, touch the green phone soft key to make the call.
- Page 18 During a Call Red phone symbol – Touch this to end a call. numeric key input. Transfer – Touch to switch the volume of the call. the phone conversation back to your cell phone. Receiving a Call decline the incoming call. When a call comes in the incoming call screen appears automatically.
-
Page 19: Bluetooth With Navigation System
Bluetooth with Navigation System (Legacy and Outback) MENU button Phone off Phone on Talk button hook button hook button... - Page 20 Pairing Your Cell Phone Then touch “Bluetooth Settings.” Now touch “Register.” A pass-key number will appear on the screen.
- Page 21 Put your phone into Bluetooth pairing mode and pair your phone to the system using the pass-key provided. When the phone is successfully paired the screen will show the phone’s name on the list. Making a Call will be displayed. After the beep, say the numbers of the phone number you wish to call.
- Page 22 During a Call Mute – Touch this to mute the call. he call. Speaker – Touch to switch the phone conversation back to your cell phone. Red phone symbol – Touch this to end a call. 1 – 5 – Touch 1 through 5 to change the volume of the call.
- Page 23 ® TomTom Navigation with Bluetooth (Optional on Forester 2.5X Premium models) Pairing Your Cell Phone ap anywhere within the displayed navigation map to bring up the Main Menu.
- Page 24 Making a Call within the displayed navigation map to bring up the Main Menu. in the Main Menu. one phone is paired, make sure that your using your phone. Receiving a Call If someone calls when you are driving, a screen will automatically pop up, and you will have the option to Accept or Refuse the call.
- Page 25 Notes...
- Page 26 Your Subaru dealer is the best source for the most current information. For detailed operating and safety information, please consult your Owner’s Manual.
