The onboard I/O devices are PS/2 Keyboard, PS/2 Mouse, COM1 and COM2, RJ45 LAN, Printer,
game ports. The view angle of drawing shown here is from the back panel of the housing.
PS/2 Mouse
Connector
PS/2 Keyboard
Connector
PS/2 Keyboard:
For standard keyboard, which is using a PS/2 plug.
PS/2 Mouse:
For PC-Mouse, which is using a PS/2 plug.
USB Port:
Available for connecting USB devices.
Parallel Port:
To connect with SPP/ECP/EPP printer.
COM1/COM2 Port:
To connect with pointing devices, modem or others serial devices.
VGA Connector:
To connect with PC monitor.
Speaker Out:
To External Speaker, Earphone or Amplifier.
Line-In:
Comes from the signal sources, such as CD/Tape player.
MIC-In:
From Microphone.
e
d
B
a
c
k
P
a
n
e
l
e
d
B
a
c
k
P
a
n
e
l
SPP/EPP/ECP
Parallel Port
COM 1 Port
USB Port
(2.0)
RJ45 LAN Jack
USB Port
COM 2 Port
(2.0)
57
O
n
l
i
n
e
M
a
n
u
a
l
O
n
l
i
n
e
M
a
n
u
a
l
USB2.0
, AC97 sound and
Line-In
Speaker Out
MIC-In
