RPMLoader Work Area
Online Device Tree Context Menu
Right-click anywhere inside the Online Device Tree Window to open a context menu containing the following
options:
Online Device Tree Context Menu Options
Refresh System
Online Tree
Refresh Network
Online Tree
Reboot Master
Device Properties
Launch Telnet Window With a device selected in the Online Device Tree, click this option to invoke a Telnet
Report
Bind / Unbind Device
Preferences
File Transfer List Window
When an RPMX file is opened, the File Transfer List window provides a listing of the files that are indicated in
the active RPMX file (FIG. 52).
FIG. 52
File Transfer List Window
By default, the files listed here are will be included in the file transfer (as indicated by the checkmark before
each filename).
30
Click to refresh the Online Device Tree for the local system (the system containing
the Master Controller that your PC is connected to). For NetLinx systems, it is the
Master Controller identified in the Network Connection field of the Connect to Master
dialog.
Click to refresh the entire Online Device Tree.
Click to reboot the NetLinx Master to which RPMLoader is currently connected. Note
that if the Master is rebooted, it may take several moments for it become available to
reconnect (via the Connect To Master option).
With a device selected in the Online Device Tree, click this option to invoke a
screen-tip that displays various properties of the selected device (Device Number,
Description, Manufacturer, Firmware Version, Device ID and Serial Number, as
applicable):
window for the selected device. The default Telnet program is TELNET.EXE, and
can be changed via the Preferences dialog.
Click to generate and open the Online Tree Report (OnlineTreeReport.TXT), which
provides a summary listing of all devices in the Online Device Tree.
Click to open the Bind/Unbind Devices dialog. Use the options in this dialog to
manually bind or unbind a selected device from a NetLinx Master. See the Binding/
Unbinding Devices topic for details.
Opens the Preferences dialog. Use the options in this dialog to specify display
options for the Online Device Tree, as well as the location for downloaded files.
RPMLoader
