Desa W26LTF Assembly And Installation Instructions Manual

W26LTF WaLL ManTeL and Base
Important: Read entire instruction sheet before
assembling or installing mantel kit.
this mantel is only approved for use with any Com-
fort Glow 26" intermediate fireplace system, Dimplex
Electric 26" intermediate fireplace and Style Selec-
tions 26" intermediate fireplace. Do not use mantel
with any other product.
This mantel kit contains the following:
• Mantel pieces - unassembled and marked as follows:
#1 Base
#2 Right Side with arrow
#3 Right Front Leg with arrow
#4 Left Side with arrow
#5 Left Front Leg with arrow
#6 Header with arrow
#7 Top
#14 Style Selections Filler Panel (for use with Style Selec-
tions gas fireplace model #256032 only)
#15 Filler Panel Assembly Block (3 pieces)
• Hardware Kit*
16 - Metal Brackets
32 - Screws M6 x 12 mm (1/2")
13 - Screws M6 x 30 mm (1
13 - Washers M6
1 - Allen Wrench
*Extra hardware may be included.

asseMBLY and InsTaLLaTIOn InsTRUCTIOns

118937-01
121149-01
/ ") 121335-01
1
4
121336-01
121337-01
www.desatech.com
If any wood pieces are missing or damaged, contact the
dealer where you purchased this mantel for replacement.
If hardware is missing or damaged, contact DESA Heating
Products at 1-866-672-6040 for referral information. You can
also visit DESA Heating Products' technical service web site
at www.desatech.com.
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Use only 1/2" screws to attach metal
angle brackets. Damage to mantel will result if other
screws are used for this purpose.
AssemblING mANtel
ImPORtANt: more than one person is required to as-
semble and lift mantel.
Estimated assembly time: 30 minutes.
When assembling mantel do not tighten screws completely
until told to do so. There should be some play in the pieces
to allow for proper alignment and best possible fit. It is very
important that more than one person assemble mantel together.
Panels must be held in proper alignment to each other while
tightening screws to assure fewer gaps and proper surface
alignment. When tightening screws, do not over tighten. This
may cause threads to strip. For this reason, the supplied Allen
wrench should be used rather than a power screwdriver. The
panels have threaded inserts installed to mark your screw
locations. Screws should start and turn easily in threaded
holes when assembled according to instructions. Do not force
screws into holes.
IMPORTANT: There is a serial number label inside of right
side panel and on outside package. When calling to request
technical assistance or for replacement parts please have
that number ready.
