- Page 2 ZOTAC. Products and corporate names mentioned in this manual may not be reg- istered trademarks or copyrights of their respective companies, and are used for identification purposes only.
-
Page 3: Table Of Contents
Connecting a SPDIF cable ------------------------------------------------------------------ 16 Setting up the ZOTAC ZBOX nano XS ------------------------------------------------------ 17 Positioning the ZOTAC ZBOX nano XS ---------------------------------------------------- 18 Mounting the ZOTAC ZBOX nano XS to a LCD monitor ----------------------------- 18 IR receiver --------------------------------------------------------------------------------------- 19 Remote control (optional) -------------------------------------------------------------------- 20... -
Page 4: Product Specifications
ZOTAC ZBOX nano XS Product specifications Chipset • AMD M1 Product dimensions • 106mm x 106mm x 37mm Onboard CPU • AMD E-450 (Dual-core, 1.65 GHz) Onboard graphics • AMD Radeon HD 6320, DirectX11 • Support HDMI (1920x1200 resolution) output •... -
Page 5: Safety Information
ZOTAC ZBOX nano XS Safety information Your ZOTAC ZBOX nano XS is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. -
Page 6: Welcome
ZOTAC ZBOX nano XS Welcome Congratulations on your purchase of the ZOTAC ZBOX nano XS mini-PC. The following illustration displays the package contents of your new ZOTAC ZBOX nano XS. Please contact your retailer If any of the below items are damaged or missed. -
Page 7: Getting To Know Your Zotac Zbox Nano Xs
ZOTAC ZBOX nano XS Getting to know your ZOTAC ZBOX nano XS Front view Refer to the diagram below to identify the components on this side of the system 1. Power switch The power switch turns the mini-PC ON and OFF. -
Page 8: Rear View
ZOTAC ZBOX nano XS Rear view Refer to the diagram below to identify the components on this side of the system. 1. Power input (DC19V) The supplied power adapter converts AC power to DC power for use with this jack. -
Page 9: Bios Settings Of Specific Functions
ZOTAC ZBOX nano XS BIOS settings of specific functions ZOTAC ZBOX nano XS has some specific functions which can be enabled or disabled in BIOS settings, such as LED indicator, USB2.0 charge and CIR controller. How to disable the ring LED indicator Turn on the ZBOX nano XS mini-PC, then press <Delete>... - Page 10 ZOTAC ZBOX nano XS Press <Enter> to display the Onboard Device Config and navigate to Backlight Control. Press <Enter> and select Disabled. Press F10 to save the configuration and exit. The PC will reboo...
-
Page 11: How To Enable Usb2.0 Hotplug Charge (For S3/S4/S5 Status)
ZOTAC ZBOX nano XS How to enable USB2.0 hotplug charge (for S3/S4/S5 status) In Chipset menu, select Onboard Device Config and press <Enter>. Use the arrow keys to enter the item Top / Bottom / Combo e-SATA/ USB2.0 hotplug Charge, and select Enabled. -
Page 12: High Current/Fast Charging Usb Ports
Hibernation mode (S4) or Power off mode (S5). With this USB Charging driver installed, you can enjoy marvelous charging experience than ever. Please visit the ZOTAC website “Support” -> “Download” to get the USB Charging driver for your mini-PC: http://www.zotac.com... - Page 13 ZOTAC ZBOX nano XS Press <Enter> to display the Super IO Configuration and enter CIR Controller Configuration. Enter CIR Controller and select Disabled. Enabled: enable the internal IR receiver (default) Disabled: disable the internal IR receiver...
-
Page 14: Customizing The Zotac Zbox Nano Xs
ZOTAC ZBOX nano XS Customizing the ZOTAC ZBOX nano XS Please follow the instructions below to remove the cover of the ZOTAC ZBOX nano XS before customizing. 1. Loosen the 4 screws securing the bottom cover into place. 2. Gently remove the cover. -
Page 15: Installing A Memory Module
ZOTAC ZBOX nano XS Installing a memory module 1. Locate the SO-DIMM memory slot and insert a SO-DIMM memory module into the slot at a 45 degree angle. 2. Gently press down on the memory module until it locks into place by the arms... -
Page 16: Installing An Msata
ZOTAC ZBOX nano XS Installing an mSATA 1. Insert the mSATA into the slot and gently slide into the connector. 2. Install the screws of the mSATA. -
Page 17: Connecting A Spdif Cable
ZOTAC ZBOX nano XS Connecting a SPDIF cable 1. Connect the SPDIF cable to the headphone/SPDIF adapter correctly. 2. Locate the front panel and connect the headphone/SPDIF adapter to the headphone/SPDIF jack. -
Page 18: Setting Up The Zotac Zbox Nano Xs
ZOTAC ZBOX nano XS Setting up the ZOTAC ZBOX nano XS Please connect the peripherals before using the ZOTAC ZBOX nano XS. 1. Turning on the system Connect the supplied AC adapter to the DC IN jack on the system rear panel and then press the power switch on the front panel to turn on the system. -
Page 19: Positioning The Zotac Zbox Nano Xs
ZOTAC ZBOX nano XS Positioning the ZOTAC ZBOX nano XS • Do not cover or block the ventilation holes on ZOTAC ZBOX nano XS. To ensure proper operation and reliability, leave aproximately 4 inches (10 cm) of spacing in front of the ventilation holes. -
Page 20: Ir Receiver
ZOTAC ZBOX nano XS Connect the ZOTAC ZBOX nano XS to your LCD monitor with an HDMI cable. IR receiver Users can control the LCD monitor/TV by either IR receiver or external USB IR receiver. 1. IR receiver Note: Please install CIR driver from DVD before you use the IR receiver. -
Page 21: Remote Control (Optional)
ZOTAC ZBOX nano XS Remote control (optional) ZOTAC ZBOX nano XS is shipped with a remote control. Follow the instructions below to use the remote control. Function keys Navigation Buttons Playback Buttons RECORD PAUSE STOP START BACK INFORMATION ... -
Page 22: Lithium Cell Installation
ZOTAC ZBOX nano XS Lithium cell installation 1. Locate the arrow on the rear cover of the remote control, and push the cover as the arrow direction. 2. Remove the rear cover, and insert the CR2032 lithium cells into the battery jar at a 45 degree angle. -
Page 23: Installing Drivers And Software
Installing system drivers Before you can use the full features of the ZOTAC ZBOX nano XS, the system drivers must be installed. The following types of operating systems are supported by the ZOTAC ZBOX nano XS driver DVD: •... -
Page 24: Using Your Zotac Zbox Nano Xs
• Usb Charger • CIR Driver • USB WiFi driver (from another driver disc) Note: 1. Each driver must be installed individually to ensure proper operation of the ZOTAC ZBOX nano XS. 2. USB charging does not support WinXP 64bit. -
Page 25: Using A Dynamic Ip (Pppoe Connection)
Configuring audio output via an HDMI device Follow the steps below to enable audio output via HDMI when connecting the ZOTAC ZBOX nano XS to a TV or receiver via HDMI. Access the Sound settings via the system Control Panel.
