To enter Configuration:
Press the Mode button (the Config LED will
1
light up).
Use the Back and Next buttons to navigate through the configuration
menus. Pressing Next enters the selected option for that menu item and
2
advances to the next menu. Adjust settings up or down by pressing the
Adjust Setting button.
The flow chart below illustrates basic zone panel configuration. For additional configuration, see
Advanced Configuration on page 8. The label on the inside cover of the HZ322 Zone Panel also con-
3
tains configuration information.
Fig. 14
WIRELESS HOME
CONFIG
CHECK OUT
MODE
BACK ADJUST SETTING NEXT
M24799

HZ322 TrueZONE
CONfiguraTiON
WIRELESS HOME
CONFIG
CHECK OUT
BACK ADJUST SETTING
Fig. 13
69-299—0
MODE
NEXT
