T775J ELECTRONIC REMOTE TEMPERATURE CONTROLLER

SPECIFICATIONS

IMPORTANT
The specifications given in this publication do not
include normal manufacturing tolerances. Therefore,
an individual unit may not exactly match the listed
specifications. Also, this product is tested and
calibrated under closely controlled conditions and
some minor differences in performance can be
expected if those conditions are changed.
Models (See Table 1):
The T775J family of electronic remote temperature controls
provides reset control for chillers, heating and cooling
systems, and other applications where electronic accuracy in
addition to remote sensing is desired.
T775J provides reset control with
one of either 4 to 20 mA, Electronic Series 90, or 0 to 18 Vdc
Proportional + Integral modulating output with 0 or 1 relay
output stages, or 1 to 2 relay output stages with no
modulation. Includes two part number 193987GA
Sensors.
Table 1. T775J Model Numbers and Outputs.
Model Modulation
Number Type
T775J1001 None
T775J1019 Series 90
T775J1027 4-20 mA
T775J1035 0-18 Vdc
T775J1043 Series 90
T775J1050 4-20 mA
T775J1068 0-18 Vdc
T775J1076 None

ORDERING INFORMATION

When purchasing replacement and modernization products from your TRADELINE® wholesaler or distributor, refer to the
TRADELINE® Catalog or price sheets for complete ordering number .
1. Model Number
2. Accessory
If you have additional questions, need further information, or would like to comment on our products or services, please write or
phone:
1. Your local Home and Building Control Sales Office (check white pages of your phone directory).
2. Home and Building Control Customer Logistics
Honeywell Inc., 1885 Douglas Drive North
Minneapolis, Minnesota 55422-4386
In Canada—Honeywell Limited/Honeywell Limitée, 35 Dynamic Drive, Scarborough, Ontario M1V 4Z9. International Sales and
Service Offices in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France, Germany, Japan, Mexico,
Netherlands, Spain, Taiwan, United Kingdom, U.S.A.
63-2248—4
two
temperature inputs and
Outputs
Number of Relay
Outputs
1
0
0
0
1
1
1
2
Electrical Ratings:
Voltage Input: 24/120/240 Vac, 50/60 Hz (+10/-15%).
Power Consumption:
50 Hz: 10 VA maximum.
60 Hz: 8 VA maximum.
Contact Ratings:
1/2 HP: 9.8 FLA, 58.8 LRA at 120 Vac.
1/2 HP: 4.9 FLA; 29;4 LRA at 240 Vac.
125 VA pilot duty at 120/240 Vac.
10A at 24 Vac (resistive).
Temperature Accuracy:
±1° F (0.6° C) (at nominal input voltage, 77°F (25°C)
operating ambient, nominal sensor ambient).
Setpoint Adjustment Range:
-40° F to +220° F
(-40° C to +105° C).
Operating Ambient Temperature:
Controller: -30°F to + 140°F (-34°C to 60°C).
Sensor: -45°F to + 225°F (-43°C to 107°C).
Throttling Range for Modulating Output:
Adjustable 2° to 30° F or C.
Differential Range for Staged Output:
Adjustable 1° to 30° F.
Reset Ratio:
Adjustable between 1 to 30 and 30 to 1.
Operating Humidity:
5 to 95 percent relative humidity, noncondensing.
Sensor:
Positive coefficient platinum type, 4.8 ohms/°F, 1000 feet
maximum distance between sensor and solid state controller
(requires calibration over 400 feet).
Approvals:
Underwriters Laboratories Inc. Listed: File No. E4436.
Guide XAPX.
Canadian Standards Association Certified: File No.
LR47125.
2
