1. Introduction

1. Introduction
The WiN7000 is a member of the RuggedMAX™ family, a line of mobile WiMAX broadband
wireless access systems based on the 802.16e mobile WiMAX standard. RuggedMAX systems
are designed for robustness and simplicity, offering feature-rich services with low deployment and
operation costs.
The WiN7000 base station is a cost-effective solution for wireless access services, designed for
point-to-multipoint broadband wireless access applications in varying conditions and locations.
The WiN7000 is a one-sector base station, supporting up to 800 subscriber units. Through the
addition of routing units, the system can be extended to as many sectors as required and can
support additional subscribers and bandwidths.
The base station communicates with fixed and mobile subscriber units, according to defined
service criteria and customer service level agreements. The WiN7000 also connects to the service
provider backbone, supporting end-to-end Quality of Service (QoS) requirements.
The system uses OFDMA radio technology, providing robustness in adverse channel conditions
and enabling Non-Line-Of-Sight (NLOS) operation. This improves coverage and maintains a high
level of spectral efficiency. Modulation and coding are continuously adapted to prevailing link
conditions, ensuring an optimal balance between robustness and efficiency. The use of STC/
MRC and MIMO radio technologies optimizes link performance, ensuring enhanced bandwidth
and service coverage.
The RuggedMAX WiN7000 is a full outdoor base station, designed for easy installation and
mounting on poles, street lamps, towers, or walls. The WiN7000 can be equipped with copper or
fibre network interfaces for flexible integration into the operator's backbone.
The WiN7000 is supported by RuggedNMS™, RuggedCom's comprehensive Network
Management System.

1.1. About this Guide

This installation guides describes the installation if the RuggedMAX™ WiN7000 High Power Base
Station.
This guide is intended for use by base station installers and operators, and assumes readers have
a working knowledge of WiMAX technologies and procedures. While some safety precautions
are reviewed here, it is assumed that installers are trained in safe installation practices. Users
unfamiliar with safe installation procedures, WiMAX technologies, and service procedures should
not rely on this manual for comprehensive guidance.
RuggedCom® RuggedMAX WiN7000 7 Installation Guide Rev1
