- Page 5 ITEM / STANDING PILOT AND DSI IGNITION COMMON PARTS SERIAL # / N° PART NUMBER PIÈCE / UNE VEILLEUSE ET ALLUMAGE DSI PIÉCES COMMUNES DE SÉRIE / N° DE PIÈCE Piezo Ignitor / Allumage Piézo 418-513 Burner Orifice NG (#38) / Orifice de brûleur GN (#38) 057-800 Burner Orifice LP (#51) / Orifice de brûleur PL (#51) 079-803...
- Page 8 28 1/2 [724mm] 14 ¼ [362mm] 21 1/2 [548mm] 8 5/8 [219mm] 11 5/8 [297mm] 8 5/8 VENT COLLARS ELECTRICAL [219mm] ACCESS VENT COLLARS GAS LINE ACCESS 34 5/8 25 ¼ [965mm] [879mm] [642mm] 24 5/8 2 1/8 3 ½ [625mm] [55mm] [90mm]...
- Page 10 SHOWS CENTER OF12" X 12" VENT FRAMING HOLES FOR TOP & REAR VENTING. 1/2” CLEARANCE FROM BACK OF FIREPLACE TO COMBUSTIBLE 1/2” CLEARANCE FROM BOTH SIDES OF FIREPLACE TO COMBUSTIBLE FRAMING MEMBER 0” CLEARANCE TO 0” CLEARANCE FRAMING MEMBER...
- Page 11 6 7/16” (164mm) 8 1/2” (216mm) 8 1/2” (216mm) 11 1/16” 5 7/8” 7 3/8” (281mm) (187mm) (149mm) 6 1/2” 5 1/16” (165mm) (129mm) 8 5/8” 8 5/8” (220mm) (220mm) 11 15/16” (303mm) DV-90D DV-48D DV-36D DV17/24D DV-12/17D 17-24 (432-610mm) 35 3/4”...
- Page 12 VERTICAL TERMINATION STORM COLLAR ROOF FLASHING HORIZONTAL HORIZONTAL PIPE TERMINATION SUPPORT PIPE LENGTH WALL FIRESTOP CEILING WALL BRACKET FIRESTOP 90 DEGREE ELBOW DVK-01D DVK-TVCD DVK-01TRD...
- Page 13 90-DEGREE ELBOWS 45-DEGREE ELBOW 5” EXHAUST PIPE VERTICAL BAFFLE CENTER VERTICAL BAFFLE ON 5” EXHAUST PIPE...
- Page 18 STARTING COLLAR STOVE SEALANT BEAD FIRST VENT COMPONENT 1 INCH (25.4mm) SEAL SEAL HEAT INSULATION SHIELD DISCARD BOTH PIECES and HEAT SHIELD HEAT SHIELD DISCARD INSULATION HEAT SHIELD...
- Page 19 WALL BRACKET WALL STUD 8 FT. (2.4m) FLUE OUTLET 1 INCH MIN. (25.4mm)
- Page 20 12" (305mm) 12" (305mm) 1" (25.4 mm) VENT PIPE 11" (280 mm) 11" (280mm) CHIMNEY HOLE HEAT SHIELD TRIM HEAT SHIELD IF TOO EXISTING CEILING JOISTS LONG, ADD TO FRAMING SHIELD IF TOO MEMBERS SHORT CEILING EXTERIOR FIRESTOP INTERIOR FIRESTOP...
- Page 21 JOIST CEILING NAILS (4 REQUIRED) CEILING FIRESTOP ROUND CAP TERMINATION NAILS (4 REQUIRED) PERFORATION CANNOT BE INSIDE THE WALL RAFTER 7 1/2" (191mm) CEILING MINIMUM CEILING FIRESTOP TRAPEZOID CAP TERMINATION 7 1/4" (184mm)
- Page 22 openable fixed closed J or K 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4...
- Page 23 HORIZONTAL OVERHANG 2 FT. 2 FT. MIN. VERTICAL MIN. WALL LOWEST DISCHARGE OPENING TERMINATION ROOF PITCH IS X/ 12 H (MIN.) - MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING...
- Page 25 MANUAL SHUT-OFF VALVE VALVE CONTROL VALVE FLEX GAS LINE CONNECTOR ACCESS HOLE...
- Page 26 BLACK S2 WHITE T2 RED T1 THERMOPILE OPTIONAL REMOTE GAS VALVE OPTIONAL WALL SWITCH BLACK S1 VARIABLE SPEED CONTROL NOTE: IF ANY OF THE ORIGINAL WIRE AS SUPPLIED WITH THE APPLIANCE MUST BE REPLACED, IT MUST BE REPLACED WITH TYPE 105 C RATED WIRE. JUNCTION BOX BLOWER RECEPTACLE GROUND...
- Page 27 FINISH WALL MATERIAL MAY BE DRYWALL - TOP AND SIDES CEILING 12" HIGH TEMPERATURE (300 F/149 C MIN.) 11" TOP & SIDE SEAL JOINT 10" 9" 31” 8" 7" 6" 12” 5" 11” 10” 4" 9” 3" 8” 7” 2" 6”...
- Page 28 BEFORE FIRING THE UNIT Figure 34 Figure 35 Figure 36...
- Page 29 Figure 37 Figure 38...
