- Page 1 SHINDAIWA OWNER’S/OPERATOR'S MANUAL T282X TRIMMER Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye and hearing protection when operating this unit. WARNING! X7502827003 03/13...
-
Page 2: Table Of Contents
If you have questions regarding your power tool, or if you do not understand something in this manual, your Shindaiwa dealer will be glad to assist you. You may also contact Shindaiwa at the address printed on the back of this Manual. -
Page 3: Safety
Warning and Operational Labels Beware of thrown or Read and follow this opera- Always wear a harness when richocheted objects tor's manual. Failure to do so operating this unit with a blade. could result in serious injury.. A harness is also recommended when using trimmer line. - Page 4 Immediately replace damaged or missing information labels. New labels are available from your local autho- rized Shindaiwa dealer. The Properly Equipped Operator Wear hearing protection devices and a Always wear eye protection such as broad-brimmed hat or helmet.
- Page 5 Be Aware of the Working Environment Reduce the risk of bystanders Make sure being struck by flying debris. Make bystanders sure no one is within 15 meters or observers (50 feet)— that’s about 16 paces outside the of an operating attachment. Stop Avoid long-term 15 meter (50 immediately if a child, pet, or person...
-
Page 6: Product Description
Product Description Ignition Switch Throttle WARNING! Strap Interlock Do not make unauthorized modifications or alterations to any of these units or their components. Handle Grip Fuel Tank Outer Tube Throttle Trigger Using the illustration as a guide, famil- Barrier iarize yourself with your machine and its Gearcase Hanger various components. -
Page 7: Assembly
An Emission Control Label is located on the engine. (This is an EXAMPLE ONLY; information on label varies by engine FAMILY). PRODUCT EMISSION DURABILITY (EMISSION COMPLIANCE PERIOD) The 50 or 300 hour emission compliance period is the time span selected by the manufacturer certifying the en- gine emissions output meets applicable emissions regulations, provided that approved maintenance procedures are followed as listed in the Maintenance Section of this manual. - Page 8 Cutting Attachment Shield 1. Insert the cutting attachment shield between the outer tube and the cutting attachment mounting plate. Outer Tube Socket-Head Bracket NOTE: Cap Screws It may be necessary to loosen the retain- ing nut and clamp screw to adjust cutting attachment shield mounting plate.
- Page 9 Install trimmer head Retaining Plug 1. Turn the trimmer over so that the gear case output shaft faces UP. Holder 2. Remove and discard the black plastic protective cap from the output shaft. 3. Rotate the holder until the hole in the holder aligns with the notch on the Output shaft gear case.
-
Page 10: Mixing Fuel
2 Stroke Mixture Oil - A 2-stroke engine oil meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FD standards must be used. Shindaiwa One 2-Stroke Oil is strongly recommended as it meets this standard and is specifically formu- lated for use in all Shindaiwa 2-stroke engines. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD (ISO/CD 13738) and J.A.S.O. -
Page 11: Handling Fuel
IMPORTANT! Examples of 50:1 mixing quantities Shindaiwa One 2-Stroke oil or Red Armor engine oil may be mixed at 50:1 ratio for application in all Shindaiwa engines sold in the past, regardless of ratio specified in those manuals. IMPORTANT! Stored fuel ages. Do not mix more fuel than you expect to use in thirty (30) days, ninety (90) days when a fuel stabilizer is added. -
Page 12: Filling The Fuel Tank
Filling the fuel tank WARNING! Minimize the Risk of Fire ■ ■ NEVER smoke or light fires near the engine. ALWAYS store gasoline in a container approved for flam- ■ mable liquids. ALWAYS stop the engine and allow it to cool before ■... - Page 13 3. Set the choke lever (B) to the CLOSED position if engine is cold. 4. While holding the outer tube firmly with left hand. Use your other hand to slowly pull the recoil starter handle until resistance is felt, then pull quickly to start the engine.
-
Page 14: Stopping The Engine
Checking Unit Condition NEVER operate the unit with the cutting attachment shield or other protective devices removed! Use only authorized Shindaiwa parts and accessories with your Shindaiwa trimmer. Do not make modifications to this unit without written approval from WARNING! Shindaiwa. -
Page 15: Operation
Operation WARNING! Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop before removing obstructions, clearing debris, or servicing unit. WARNING! Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a poison gas. -
Page 16: Using A Blade
Cutting Grass—Units equipped with a trimmer head Your Shindaiwa unit may be equipped Hold the trimmer so the trimmer head with one of several Shindaiwa trimmer is angled slightly into the area to be CAUTION! head models, each with features for cut. -
Page 17: Maintenance
When cutting wood with a blade, feed the blade slowly—never O'clock strike or “slam” a spinning blade against the wood. WARNING! Five DO NOT use 2-tooth or non-Shindaiwa approved 4-tooth cutting O'clock blades with Shindaiwa trimmers and brushcutters. Maintenance General maintenance... - Page 18 ■ Blades are not interchange- Never repair a damaged blade by engine and check the blade for cracks able between Shindaiwa edgers welding, straightening, or by modify- or other damage. Replace a damaged and trimmer/brushcutter models. ing its shape. An altered blade may...
-
Page 19: Hour Maintenance
If damage, splitting or deterioration is noted, the unit should be removed from service until it can be inspected or repaired by a Shindaiwa- trained service technician. CAUTION! Make sure you do not pierce the fuel line with the end of the hooked wire. - Page 20 Use only lithium- Gear shaft base grease such as Shindaiwa Gear collar Case Lubricant or equivalent. ■ Remove mainshaft and lubricate both Without cutting attachment installed on gearcase ends of the splines.
- Page 21 7. Gently tap the muffler on a wood surface to dislodge any loose carbon. 8. Reassemble the spark arrester, muffler and engine cover in the reverse order of disassembly. IMPORTANT! If you note excessive carbon buildup, consult with an authorized Shindaiwa servicing dealer.
-
Page 22: Carburetor Adjustment
NOTE: Every unit is run at the factory and the carburetor is set in compliance with emission regulations. Carburetor adjustments, other than idle speed, must be performed by an authorized Shindaiwa dealer.. WARNING! When carburetor adjustment is completed, the cutting attachment should not move at idle, otherwise serious personal injury may result. -
Page 23: Blade Sharpening
Blade Sharpening When the cutting edges of the blade become dull, they can be resharpened with a few strokes of a file. In order to keep the blade in balance, all cutting edges must be sharpened equally. WARNING! Wear protective gloves when handling or performing maintenance on the blade. -
Page 24: Long Term Storage
Damage resulting from stale or con- ■ stops running. Store the unit in a clean, dust-free taminated fuel is not covered by the area. Shindaiwa warranty policy. 3. Repeat steps 1 and 2 until the engine will no longer start. -
Page 25: Troubleshooting Guide
ISO-L-EGD and/or JASO FD classifi ed oils at 50:1 gasoline/oil ratio. ENGINE DOES NOT START What To Check Possible Cause Remedy Consult with an authorized Shindaiwa servicing dealer. Faulty recoil starter. Does the engine crank? Fluid in the crankcase. Internal damage. Tighten and re-test. - Page 26 89 or higher mixed with an air cooled engine oil that meets or exceeds ISO-L-EGD and/or JASO FD classifi ed oils at 50:1 gasoline/oil ratio. Piston seizure. Consult with an authorized Shindaiwa servicing dealer. Faulty carburetor and/or diaphragm. Overheating condition. Consult with an authorized Shindaiwa Engine is knocking.
- Page 27 Adjust idle. Check Specifi cations page for correct Idle set too high. Engine will not idle idle speed. down. Consult with an authorized Shindaiwa servicing Engine has an air leak. dealer. Adjust idle. Check Specifi cations page for correct idle Engine idle too high.
-
Page 28: Warranty Statement
The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as pre- scribed in the operator’s manual. Should a product difficulty occur, you must, at your expense, deliver or ship your Shindaiwa unit to an authorized Shindaiwa servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made. - Page 29 89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the Shindaiwa oil label and covered in your operator’s manual.
- Page 30 NOTES...
- Page 31 NOTES...
-
Page 32: Servicing Information
Genuine Shindaiwa Parts and Assemblies for your Shindaiwa products are available only from an Authorized Shindaiwa Dealer. When you do need to buy parts always have the Model Number and Serial Number of the unit with you. You can find these numbers on the engine. For future reference, write them in the space provided below.
