Grandstream Networks, Inc.
GXV3501/GXV3504 User Manual

Advertisement

Table of Contents
loading

Related Manuals for Grandstream Networks GXV3501

Summary of Contents for Grandstream Networks GXV3501

  • Page 1 Grandstream Networks, Inc. GXV3501/GXV3504 User Manual...

  • Page 2: Safety Instructions

    The average life time varies from the differences between operating environments and usage history. Regular maintenance checks are recommended for all users. Please contact your dealer for more details. Firmware 1.0.4.6 Page 2 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 3: Table Of Contents

    GXV3501/GXV3504 FTP Page ......................25   GXV3501/GXV3504 PTZ Page ......................26   GXV3501/GXV3504 Alarm Event ....................... 27   GXV3501/GXV3504 Motion Detection ....................30   GXV3501/GXV3504 System Log ......................31   FAQ ................................33   Firmware 1.0.4.6 Page 3 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 4: Welcome

    The GXV3501/3504 features the advanced functionality of embedded analytics (including motion detection and video loss) and powerful pre-recording. Grandstream’s flexible video management software enables users to monitor multiple environments in one easy to use application. The intuitive web interface lets users easily access, manage, view and record live video streams from the device.

  • Page 5: Package Contents

    2 12-pin terminal block connectors – 12-pin connector block for connecting external devices, such as infrared detector, smoke detector, to Alarm IN, Alarm OUT, RS485 pins and etc. • Quick installation guide Firmware 1.0.4.6 Page 5 of 36 Grandstream Networks, Inc. 09/2010...
  • Page 6 GXV3501/GXV3504 Digital Video Server Firmware 1.0.4.6 Page 6 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 7: Product Overview

    5 VIN – 1 BNC (Voltage: 1.0V p-p, Resistance 75Ω) port for video input3.5mm port for audio output devices, ie. Speakers. 6 LINE OUT – 3.5mm port for audio output devices, ie. Speakers. 7 MIC IN – 3.5mm port for audio input devices, ie. Microphones. Firmware 1.0.4.6 Page 7 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 8: Gxv3501 Sample Connection Diagram

    The indicators will light when video sources are connected. green 5 RESET – Press the Reset button for 6 seconds to perform a factory reset. 6 SD/MMC – The SD/MMC slot. Firmware 1.0.4.6 Page 8 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 9: Gxv3504 Back Panel

    6 VIN – 4 BNC (Voltage: 1.0V p-p, Resistance 75Ω) port for video input. 7 LINE OUT – 3.5mm port for audio output devices, ie. Speakers. 8 MIC-IN – 3.5mm port for audio input devices, ie. Microphones. GXV3504 Sample Connection Diagram Firmware 1.0.4.6 Page 9 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 10: Gxv3501/Gxv3504 Key Features

    Humidity 10–90% RH (non–condensing) Power Output: 12VDC/1.5A; Input: 100–240VAC, 50–60Hz Compliance FCC Part15, Subpart B Class B; EN 55022 Class B, EN61000-3-2, EN61000-3-3, EN 55024, EN60950-1; C-tick AS/NZS CISPR 22, CISPR 24 Firmware 1.0.4.6 Page 10 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 11: Installation Guide

    The VIDEO IN indicator will light up when the video inputs are connected to a video source. If you are going to connect the device to a hub/switch/router, please use a NOTE: Firmware 1.0.4.6 Page 11 of 36 Grandstream Networks, Inc. 09/2010...
  • Page 12 GXV3501/GXV3504 Digital Video Server straight-through cable. A cross over cable should be used if you are going to connect the device directly to a PC. Firmware 1.0.4.6 Page 12 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 13: Configuring The Gxv3501/Gxv3504 Via Web Browser

    Connect the Camera to DHCP server. 1. Navigate your browser to: http://www.grandstream.com/support/gxv_series_surveillance/general/resources/gs_ search.zip 2. Run the Grandstream GS_Search tool, that you just downloaded. 3. Click on button in order to begin device detection 4. The detected devices will appear in the Output field 5.

  • Page 14: Gxv350X Home Web Page

    7. The default user name and password are both set to admin. 8. IE will indicate that “This website wants to install the following add-on: ‘GSViewerX.cab’ from ‘Grandstream Networks Inc’.” Install this add-on by following the instructions in IE. 9. You will see the home page.
  • Page 15 SATURATION Resize the image to fit into the window panel in the home View Size scream. Plays/Stops the video. Play Captures the image displayed and saves it to C:\GS_Capture Capture Firmware 1.0.4.6 Page 15 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 16: Gxv3501/Gxv3504 System Page

    OSD Device Name Setting -This field lets you configure the name of the GXV3501/GXV3504, which helps GSurf and GS_NVR to indentify the device when using GS_Search to search all the Firmware 1.0.4.6 Page 16 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 17: Gxv3501/Gxv3504 Video & Audio Page

    GXV3501/GXV3504 Digital Video Server Grandstream network cameras or digit video cameras in the same subnet. DI and DO - Digital input and digital output Normal open: the circuit is by default open unless an event triggers the device to close the circuit.

  • Page 18: Gxv3501/Gxv3504 Networking Page - Assign An Ip To Gxv3501/Gxv3504

    IP address can be set manually. To make GXV3501/GXV3504 work properly, the user needs to set the DNS configuration properly. For security purposes, the user can also assign the GXV3501/GXV3504 an HTTP Port other than 80. Firmware 1.0.4.6 Page 18 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 19: Gxv3501 Wifi Page

    RTSP port number equals HTTP Port plus 2000. GXV3501 Wifi Page GXV3501 supports WIFI via wireless dongles, not available on GXV3504. Enable Wifi – Checked to enable Wifi SSID – Click on Scan to view available network. Firmware 1.0.4.6 Page 19 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 20: Gxv3501/Gxv3504 Ddns Page

    The GXV3501/GXV3504 has the ability to receive phone calls and make phone calls when an alarm event is triggered through motion detection or alarm input. Register the GXV3501/GXV3504 to a SIP server to enable the product to make and receive phone calls. Firmware 1.0.4.6 Page 20 of 36 Grandstream Networks, Inc. 09/2010...
  • Page 21 GXV refreshes its registration with the specified registrar. The default interval is 60 minutes. Local SIP Port – This parameter defines the local SIP port used to listen and transmit. Firmware 1.0.4.6 Page 21 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 22: Gxv3501/Gxv3504 Status Page

    4. Numbers added to the system will be listed in this page. Available phone numbers With current firmware, only the first phone number in the list will be called when an NOTE: alarm is triggered. GXV3501/GXV3504 Status Page Firmware 1.0.4.6 Page 22 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 23: Gxv3501/Gxv3504 User Management Page

    You can insert or remove users from the list by click on the Add or Update or Delete button. User Name / Password – The user name and password Firmware 1.0.4.6 Page 23 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 24: Gxv3501/Gxv3504 Maintenance Page

    HTTP/HTTPS/TFTP upgrade and perform a configuration check once during the boot process. Performing a firmware upgrade: 1. Download the firmware package from http://www.grandstream.com/firmware.html. 2. Unzip the firmware package and copy the files to the firmware upgrade server directory.

  • Page 25: Gxv3501/Gxv3504 Smtp Page

    Enable FTP – The default setting is “No,” if you want the GXV3501/GXV3504 to upload the recorded video to the FTP server when an alarm is triggered, set this field to “Yes.” Firmware 1.0.4.6 Page 25 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 26: Gxv3501/Gxv3504 Ptz Page

    (signaling events) made to the transmission medium per second in a digitally modulated signal or a line code. Connect a PTZ device to the GXV3501/GXV3504 1. Connect the PTZ device to GXV3501/GXV3504 by following the connection diagram shown below Firmware 1.0.4.6 Page 26 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 27: Gxv3501/Gxv3504 Alarm Event

    When there is an alarm event, the GXV3501/GXV3504 will close the circuit to trigger the alarm. Connect Alarm Input Equipment to the GXV3501/GXV3504 Here are two sample connection diagrams. Connect the alarm equipment to the GXV3501/GXV3504 by following the diagram below. Firmware 1.0.4.6 Page 27 of 36 Grandstream Networks, Inc. 09/2010...
  • Page 28 Upload to Alarm Center – This option is an integrated feature with GSurf. If this option is checked, the GXV3501/GXV3504 will report the alarm event to GSurf. Firmware 1.0.4.6 Page 28 of 36 Grandstream Networks, Inc. 09/2010...
  • Page 29 To delete a schedule, check the schedule you would like to remove and click Delete. How to connect an Alarm Output Equipment to GXV3501/GXV3504 Here is a sample connection diagram. Connect the alarm output equipment to the GXV3501/GXV3504 by following the diagram below. Firmware 1.0.4.6 Page 29 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 30: Gxv3501/Gxv3504 Motion Detection

    Button to save sensitivity 5. Click Save to save the settings. only To Remove a Monitored Area 1. In the Select a Region dropdown list, select the region you would like to remove. Firmware 1.0.4.6 Page 30 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 31: Gxv3501/Gxv3504 System Log

    Syslog Server – The IP address or URL of System log server. Syslog Level – Select the device to report the log level. Default is None. The level is one of Debug, Info, Warning or Error. Firmware 1.0.4.6 Page 31 of 36 Grandstream Networks, Inc. 09/2010...
  • Page 32 Video List – This section displays the name, source storage and size of the video files on the connected storage devices. You can view, download or delete the stored files. Firmware 1.0.4.6 Page 32 of 36 Grandstream Networks, Inc. 09/2010...

  • Page 33: Faq

    Please check whether the IE add-on is installed correctly. Once you log into the GXV3501/ 3504 / 3601’s web interface Internet Explorer will indicate that “This website wants to install to following add-on: ‘GSViewer. cab’ from Grandstream Networks, Inc.”. Please install this add-on when prompted by IE.
  • Page 34 Login to the home page of the GXV3501/ 3504/ 3601 web GUI, click Play to watch the video stream. To watch a secondary video stream, right click on the video, and select Secondary Stream on the pop-up menu. Try reinstalling the Grandstream Viewer add-on for IE if you cannot see the video stream.
  • Page 35 4. If there are many files (ie. 1800 or more image batch files) on the SD/USB drive, it can take up to 5 minutes to read them. Please do not refresh the web interface at this time as the GXV3501/3504 will restart reading the SD/USB drive. Grandstream is currently working on a fix for this issue.
  • Page 36 Mobile Intel® 945GM Express Chipset Family Works normally Mobile intel® 915GM/GMS, 910GML Express Chipset Works normally Family Intel® G45/G43 Express Chipset Works normally ATI Technologies, RAGE XL PCI This display adapter cannot display videos. Firmware 1.0.4.6 Page 36 of 36 Grandstream Networks, Inc. 09/2010...

This manual is also suitable for:

Gxv3504
