Statement:
This manual is the intellectual property of Foxconn, Inc. Although the information
in this manual may be changed or modified at any time, Foxconn does not
obligate itself to inform the user of these changes. Additionally, Foxconn does
not accept responsibility for any direct or indirect accident relating with the use
of this manual.
Trademark:
All trademarks are the property of their respective owners.
Intel
and Pentium
®
PS/2 and OS/2 are the registered trademarks of IBM, Inc.
Windows
95/98/2000/NT/XP/Me is the registered trademark of Microsoft.
®
Award
is the registered trademark of Award, Inc.
®
Version:
User manual V1.3 in English for 865A01 series
P/N:91-181-613-14-40
Symbol description:
Note: refers to important information that can help you use motherboard better.
Attention:
indicates that it may damage hardware or cause data loss, and tells
you how to avoid such problems.
Warning:
means that a potential risk of property damage or physical injury exists.
More information:
If you want more information about our products, please visit Foxconn's
website:
Foxconn: www.foxconnchannel.com
865A01-English preface-V1.3-121603.p65
are registered trademarks of Intel Corporation.
®
1
2004-5-27, 18:12
